2ARVRCP610LQI Wireless Charging Pad

Package contents • 10 W Qi Certified Wireless Charging Pad • 4 ft. (1.2 m) charging cable • Quick Setup Guide Compatibility Any Qi-enabled devices up to 10 W, including smartphones, headphones, smart watches. This includes the latest iPhone, Samsung Galaxy, and Note devices. 2 Plug the other end of the cable into a USB port on a computer or into a power adapter. Choosing the right USB power adapter: • A QC 2.0 or QC 3.0 charger is required to obtain the full 10 W of wireless charging performance. • A minimum of a 5 V/2 A (10 Watt) USB charger or powered USB port is required to obtain 5 W of wireless charging performance. • Using low-power USB ports (with less than 5 V/2 A of power output) could cause poor performance or cause the wireless charger not to operate at all. 3 Place your Qi-enabled device on the center of your charging pad with the screen facing up. The LED is blue/purple when your device is charging. Note: If the LED is red, your device is not charging. See “TROUBLESHOOTING” for more information . FLAT SIZE W×H): 9 × 5 in. (228.6 × 127 mm) FINAL FOLDED SIZE: 3 × 5 in. (76.2 × 127 mm) LED Pulsing blue Solid blue Solid purple Solid red Blinking red STATUS Standby Charging Quick charging Insufficient input power Charging error Before using your new product, please read these instructions to prevent any damage. 10-Watt Wireless Charging Pad Quick Setup Guide BE-MQP10W22K / BE-MQP10W22K-C LED indicator Features • 10 W output provides high-speed charging to Qi-compatible devices • Low-profile design for easy placement and reliable charging • Wireless design charges devices without cumbersome cords • LED indicator shows that your device is charging Product overview LED indicator status Using your charging pad 1 Connect the charging cable to your charging pad. Charging cable Micro USB port Troubleshooting Device not charging/LED is red • Make sure that your device is Qi-enabled. • Make sure that your charging pad is connected to a working USB port. • Make sure that your powered USB port meets the minimum power requirements. • Make sure that your device is positioned correctly on your charging pad. • Make sure that there are no other objects on the charging pad. • Remove your device’s case. It may be blocking the wireless signal. Device charges slowly • Your device may charge more slowly with the charging pad than a charging cable. This is normal behavior. • Make sure that your device is positioned in the center of your charging pad. Specifications Qi Wireless Charging Pads: Input: Micro USB 5 V/2 A, 9 V/2 A Wireless output: 10 W Max Dimensions: 3.5 × 3.5 × 0.4 in. (9 × 9 × 1 cm) Power requirements: 5 W wireless charging: 5 V/2 A USB port 10 W wireless charging: QC 2.0 or QC 3.0 USB port Charging cable: 4 ft. (1.2 m) Safety information • Avoid dropping. • Do not disassemble. • Do not place metal objects between devices and wireless charging pad. • Thick protective case (≥ .2 in. [5 mm]) or a case that includes a magnet or metallic material, may not allow proper charging function. • Keep wireless charging pad away from any liquid or moisture. • The maximum ambient temperature during use of this product must not exceed 113° F (45° C). • Do not place this device in fire or other excessively hot environments. equipment should be installed and operated with a minimum distance of 20 cm between the device and the user or bystanders. This device must not be co-located or operating in conjunction with any other antenna or transmitter. One-year limited warranty Visit www.bestbuy.com/bestbuyessentials for details. Contact Best Buy Essentials For customer service, call 866-597-8427 (U.S. and Canada) www.bestbuy.com/bestbuyessentials Best Buy Essentials is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2021 Best Buy. All rights reserved. Legal notices FCC Information FCC Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RSS-Gen Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:(1) This device may not cause interference; and(2) This device must accept any interference, including interference that may cause undesired operation of the device. RF exposure statement This equipment complies with radio frequency exposure limits set forth by the FCC for an uncontrolled environment. This equipment should…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test report no. CN21VR2A 001 Seite 27 von 32 Page 27 of 32 6Safety Human Exposure 6.1Radio Frequency Exposure Compliance 6.1.1Electromagnetic Fields RESULT:Pass Test Specification Test standard: CFR47 FCC Part 2: Subpart J Section 1.1310 FCC CFR 47 Part 1(1.1310) KDB 680106 D01 v03 According to the table 1 of FCC Part 2.1310, the reference limit as below: Test Setup: Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test report no. CN21VR2A 001 Seite 28 von 32 Page 28 of 32 Test Result: Table: H-Field Strength at 15 cm from the edges surrounding the EUT and 20cm from the top surface of the EUT Measured H-Field Strength Values (A/m) EUT Test Mode Test Position A Test Position B Test Position C Test Position D Test Position E 50% Limit (A/m) Limit (A/m)Result Device working at the maximum power 0.4620.6620.426 0.5700.650 0.8151.63Pass

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN21VR2A 001 Auftrags-Nr.: Order no.: 168306757 Seite 1 von 32 Page 1 of 32 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-02-07 Auftraggeber: Client: SHENZHEN DBK ELECTRONICS CO.,LTD. Room No .208-1, 308, 404-408 in Building Five, 2-4 Floor in Building Three, No.8 Qinghua Road, Zhu Village, Fucheng New Community, Guanlan Street, Longhua District, Shenzhen City, Guangdong Province, P.R.China Prüfgegenstand: Test item: QI Wireless Charging Pad Bezeichnung / Typ-Nr.: Identification / Type no.: BE-MQP10W22K, BE-xxxxxxxxxx, NS-xxxxxxxxxx, PT-xxxxxxxxxx, DX-xxxxxxxxxx, RF-xxxxxxxxxx("x" can be 0-9, A-Z, a-z, "-" or blank, for market purpose only, all models are identical except the model name or color) (Trademark: Best Buy essentials, INSIGNIA, MODAL, Platinum, DYNEX, Rocketfish) Auftrags-Inhalt: Order content: Type test Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 CFR47 FCC Part 15: Subpart B Section 15.107 CFR47 FCC Part 15: Subpart B Section 15.109 Wareneingangsdatum: Date of sample receipt: 2021-02-20 Refer to photos document Prüfmuster-Nr.: Test sample no.: A002999016-001 Prüfzeitraum: Testing period: 2021-02-21 – 2021-02-26 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Alex Lan genehmigt von: authorized by: X Datum: Date: 2021-04-06 Ausstellungsdatum: Issue date: 2021-04-06 Stellung / Position Senior Project Engineer Stellung / Position Department Manager Sonstiges / Other: FCC ID: 2ARVRCP610L Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged: * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhalt P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specifications(s) F(ail) = failed a.m. test specifications(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be V05 duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com Winni e Hou Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test report no. CN21VR2A 001 Seite 2 von 32 Page 2 of 32 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 20DB BANDWIDTH RESULT: Pass 5.1.3 RADIATED SPURIOUS EMISSION RESULT: Pass 5.1.4 CONDUCTED EMISSION ON AC MAINS RESULT: Pass 5.1.5 RADIATED EMISSION RESULT: Pass 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test report no. CN21VR2A 001 Seite 3 von 32 Page 3 of 32 Contents 1 GENERAL REMARKS ........................................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ............................................................................................................ 4 2 TEST SITES ........................................................................................................................................ 4 2.1 TEST FACILITIES ................................................................................................................................. 4 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS................................................................................. 5 2.3 TRACEABILITY .................................................................................................................................... 7 2.4 CALIBRATION ..................................................................................................................................... 7 2.5 MEASUREMENT UNCERTAINTY............................................................................................................. 7 2.6 LOCATION OF ORIGINAL DATA ............................................................................................................. 7 2.7 STATUS OF FACILITY USED FOR TESTING ............................................................................................. 7 3 GENERAL PRODUCT INFORMATION ...................................................................................................... 8 3.1 PRODUCT FUNCTION AND INTENDED USE ............................................................................................. 8 3.2 RATINGS AND SYSTEM DETAILS .......................................................................................................... 8 3.3 INDEPENDENT OPERATION MODES ...................................................................................................... 9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ......................................................................... 9 3.5 SUBMITTED DOCUMENTS..................................................................................................................... 9 4 TEST SET-UP AND OPERATION MODES ..............................................................................................10 4.1 PRINCIPLE OF CONFIGURATION SELECTION .....................…

Text truncated - open the document above for the full version.

Page 1 of 4 Photographs of the Test Set-Up PHOTOGRAPHS OF THE TEST SET-UP............................................................................................................................1 PHOTOGRAPH 1: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, 9KHZ - 30MHZ.......................................................................2 PHOTOGRAPH 2: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, 30MHZ - 1GHZ......................................................................2 PHOTOGRAPH 3: SET-UP PHOTO FOR CONDUCTED EMISSION ON AC MAINS.....................................................................................3 PHOTOGRAPH 4: SET-UP PHOTO FOR RADIATED EMISSIONS...........................................................................................................3 PHOTOGRAPH 5: SET-UP PHOTO FOR RF EXPOSURE......................................................................................................................4 Page 2 of 4 Photograph 1: Set-up photo for Radiated Spurious Emission, 9KHz - 30MHz Photograph 2: Set-up photo for Radiated Spurious Emission, 30MHz - 1GHz Page 3 of 4 Photograph 3: Set-up photo for Conducted Emission on AC Mains Photograph 4: Set-up photo for Radiated Emissions Page 4 of 4 Photograph 5: Set-up photo for RF Exposure
