2AS9T-ASRKET01RKE Transceiver

RKE TRANSCEIVER MANUAL FCC : 2AS9T-ASRKET01 ISED : 27298-ASRKET01 KC : R-C-Amo-ASRKET01 Description Features The RKE RF Transceiver acts as a control unit that transmits and receives RF signals sent from a vehicle key or smart key. After demodulating the received RF signal and performing digital signal processing, it interfaces with in-vehicle controllers to perform vehicle access control functions such as remote door lock/unlock, trunk opening/closing, and remote start CategoryItemDescription Product Information Product Name RKE Transceiver Manufacturer Amosense Application UHF Wireless Transceiver for RKE (Remote Keyless Entry) Wireless Communication Operating Frequency 433.92 MHz Frequency Bandwidth 25 kHz ~ 366 kHz Modulation Method FSK Antenna Type Ceramic Chip Antenna Power Specification Power Supply 12V Functional Summary Key Function UHF FSK Transceiver. Environmental Conditions Operating Temperature -40 °C ~ +85°C Operating Altitude 0 ~ 5000m How to install Recommaned mounting location is headliner. And position can be determined by evaluation result or sensitivity level(reception rate) - Set RKE and vehicle direction to 16 directions (22.5-degree intervals), numbering from 1 to 16. -Measure maximum reception distance (m) per direction -> A reception distance of at least 30 (m) must be obtained. RKE connector pin configuraration Functional Description The RKE Transceiver receives RF signals transmitted from the vehicle key FOB through an antenna. The received signal passes through a SAW filter and is then delivered to the RFIC (ATA5833). The RFIC demodulates the received RF signal using its internal Low-IF and digital DSP architecture, and transfers the demodulated data to the MCU (S32K312). The MCU verifies the received data and transmits it to the vehicle CAN network through the CAN Transceiver (TCAN1463), enabling communication with the BDC. During transmission, under MCU control, the RFIC outputs an RF transmission signal to the antenna, enabling two-way communication with the FOB or transmission of response signals. The RF transmit and receive paths are selectively switched through a switch. Power is supplied from the vehicle power source and converted to 5 V through an LDO (TPS7B8650). The 5 V power is then supplied to the RFIC, MCU, CAN Transceiver, and peripheral circuits. The unit is connected to the vehicle Local-CAN network through the CANH/CANL lines and transmits the received RKE-related RF data. FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Industry Canada Statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d’Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. Industry Canada Radiation Exposure Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. Déclaration d’exposition aux radiations Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non con trôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. Declaration of Conformity Hereby, Amosense , declares that this device is compliant with the essential requirements and other relevant provisions of Directive 2014/53/EC. The complete Declaration of Conformity may be requested through the following postal address: AMOSENSE Co., Ltd. 90, 4sandan 5-…

Text truncated - open the document above for the full version.

AMOSENSE 19-1BL, 90, 4Sandan 5 gil, Jiksan-eup, Cheonan-Si,Chungcheongnam-Do, South Korea Tel: +82-70-7429-2339, Fax: +82-02-540-3856 Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 09, 2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID : 2AS9T-ASRKET01 [AMOSENSE] (“the applicant”) certifies that the equipment for which authorization is soughtis not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [AMOSENSE] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant toDA-24-886andKDB 986446 D01 Covered Equipment Guidancesection B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, Manager / Taik Jin Yang AMOSENSE AMOSENSE 19-1BL, 90, 4Sandan 5 gil, Jiksan-eup, Cheonan-Si,Chungcheongnam-Do, South Korea Tel: +82-70-7429-2339, Fax: +82-02-540-3856 Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 09, 2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID : 2AS9T-ASRKET01 [AMOSENSE] (“the applicant”) certifies that, as of the date of the filing of the application, the applicantis notidentified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Manager / Taik Jin Yang AMOSENSE

AMOSENSE 19-1BL, 90, 4Sandan 5 gil, Jiksan-eup, Cheonan-Si,Chungcheongnam-Do, South Korea Tel: +82-70-7429-2339, Fax: +82-02-540-3856 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 09, 2026 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID : 2AS9T‐ASRKET01 Applicant FRN : 0029957610 AMOSENSE certifies that, as of the date of the filing of the application, FCC US AGENT, LLC. is our designated U.S. agent for service of process for the above referenced FCC ID. AMOSENSE accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission‐related proceeding involving the equipment. FCC US AGENT, LLC. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708‐571‐3148 Email: [email protected] Sincerely, AMOSENSE FCC US AGENT, LLC. Manager / Taik Jin Yang Tim Payne [U.S. Agent signature] Rev 1/26/2023

AMOSENSE 19-1BL, 90, 4Sandan 5 gil, Jiksan-eup, Cheonan-Si,Chungcheongnam-Do, South Korea Tel: +82-70-7429-2339, Fax: +82-02-540-3856 Date: June 09, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Innovation, Science and Economic Development Canada 3701 Carling Avenue (Building 94) P.O. Box 11490, Station H Ottawa, Ontario K2H 8S2 Confidentiality Request regarding application for certification of FCC ID : 2AS9T-ASRKET01 IC Number : 27298-ASRKET01 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules and IC regulation, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT Exhibit Type File Name Part List Part List.pdf Schematics Diagram(s) Schematic.pdf Operation description Operation description.pdf Block diagram Block diagram.pdf And the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Manager / Taik Jin Yang AMOSENSE

AMOSENSE 19-1BL, 90, 4Sandan 5 gil, Jiksan-eup, Cheonan-Si,Chungcheongnam-Do, South Korea Tel:+82-70-7429-2339, Fax:+82-02-540-3856 Date: June 09, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Chief, Certification and Engineering Bureau Industry Canada 1241 Clyde Avenue Ottawa, Ontario Canada K2C 1Y3 FCC ID : 2AS9T-ASRKET01 IC Number : 27298-ASRKET01 To whom it may concern: I, the undersigned, hereby authorize Young-Jin, Lee of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Young-Jin, Lee of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; AMOSENSE 19-1BL, 90, 4Sandan 5 gil, Jiksan-eup, Cheonan-Si,Chungcheongnam-Do, South Korea Tel:+82-70-7429-2339, Fax:+82-02-540-3856 e)upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)use certification only to indicate the products are certified as being in conformity with specified standards; g)endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h)ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Manager / Taik Jin Yang AMOSENSE REMARK: 1.This authorization letter will be sent along with your application when filing with the Certification Division. 2.Please follow the format and type it on company letterhead and send original to us. 3.Authorized signature must be in agreement with grantee code contact in FCC database.

FCC ID : 2AS9T-ASRKET01 IC Number : 27298-ASRKET01 Page 1 of 2 External photos FCC ID : 2AS9T-ASRKET01 IC Number : 27298-ASRKET01 Page 2 of 2

FCC ID : 2AS9T-ASRKET01 IC Number : 27298-ASRKET01 Page 1 of 1 Label Location Label The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the User’s Manual.

FCC ID : 2AS9T-ASRKET01 IC Number : 27298-ASRKET01 Page 1 of 1 Internal photos Cerimic Chip Antenna Blank

FCC ID : 2AS9T-ASRKET01Page 1 of 1 RF exposure FCC ID : 2AS9T-ASRKET01 According to FCC part 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in § 1.1307(b) Limits for Maximum Permissible Exposure (MPE) f= frequency in㎒ Friis transmission formula: P d = (P out ×G)/(4×pi×R 2 ) Where, P d = power density in㎽/㎠ P out = output power to antenna in㎽ G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm P d the limit of MPE, 1㎽/㎠. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Results Frequency (㎒) Max Tune-up Average Power(㏈m) Antenna gain (㏈i) Power density at 20㎝(㎽/㎠) Limit (㎽/㎠) 433.92㎒ -4.0-1.440.000 060.289 Frequency range (㎒) Electric field strength(V/m) Magnetic field strength (A/m) Power density (㎽/㎠) Average time (A) Limits for Occupational / Control Exposures 0.3 – 3.06141.63*(100)6 3.0 – 301842/f4.89/f*(900/f 2 )6 30 - 30061.40.1631.06 300 – 1 500----f/3006 1 500 - 100000----56 (B) Limits for General Population / Uncontrol Exposures 0.3 – 1.346141.63*(100)30 1.34 – 30824/f2.19/f*(180/f 2 )30 3.0 - 30027.50.0730.230 300 – 1 500----f/150030 1 500 – 100 000----103

TEST REPORT Report No. : KES-RF260249 Page1/25 KES Co., Ltd. #3002, #3503, #3701, 40, Simin-daero365beon-gil, Dongan-gu, Anyang-si,Gyeonggi-do, 14057, Republic ofKorea Tel : +82-31-425-6200, Fax : +82-31-341-3838 You can check the authenticity of this test report on the authenticity verification page on our website (www.kes.co.kr). KES-QP16-F01(00-23-01-01)KES Co., Ltd. FCC/IC TEST REPORT 1. Client ○ Name : AMOSENSE ○ Address : 19-1BL, 90, 4sandan 5-gil, Jiksan-eup, Seobuk-gu, Cheonan-si, Chungcheongnam-do, Republic of Korea 2. Sample Description ○ Product item : RKE Transceiver ○ Model name : ASRKET01 ○ Manufacturer etc. : AMOSENSE 3. Date of test :2026.05.18 ~ 2026.06.08 4. Location of Test :Permanent Testing LabOn Site Testing ○ Address : 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, 12658, Rep. of Korea 5. FCC & IC Rule part(s) :Part 15 Subpart C 15.231 & RSS-210(Issue 11) 6. Test result :PASS The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced and copied without permission without the written consent of KES Co., Ltd. This laboratory is not accredited for the test results marked *. This test report is not related to KOLAS accreditation. Affirmation Tested byTechnical Manager Name : Gu-Bong, Kang(Signature) Name :Yeong-Jun Cho(Signature) 2026. 06. 19. KES Co., Ltd. You can check the authenticity of this test report on the authenticity verification page on our website (www.kes.co.kr). Report No. : KES-RF260249 Page2/25 KES-QP16-F01(00-23-01-01)KES Co., Ltd. REPORT REVISION HISTORY DateTest Report No.Revision History 2026.06.19KES-RF260249Initial This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. This document may be altered or revised by KES Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KES Co., Ltd. will constitute fraud and shall nullify the document. You can check the authenticity of this test report on the authenticity verification page on our website (www.kes.co.kr). Report No. : KES-RF260249 Page3/25 KES-QP16-F01(00-23-01-01)KES Co., Ltd. TABLE OF CONTENTS 1.General information ................................................................................................................................... 4 1.1.EUT description .......................................................................................................................... 4 1.2.Test configuration........................................................................................................................ 4 1.3.Information about derivative model ............................................................................................ 5 1.4.Accessory information ................................................................................................................ 5 1.5.Sample calculation ..................................................................................................................... 5 1.6.Measurement Uncertainty .......................................................................................................... 5 1.7.Frequency/channel operations ................................................................................................... 6 2.Summary of tests ....................................................................................................................................... 7 3.Test results ................................................................................................................................................. 8 3.1.99% Occupied Bandwidth .......................................................................................................... 8 3.2.20㏈bandwidth ...................................................................................................................... 10 3.3.Radiated emission, Spurious emission and Field Strength of Fundamental............................ 12 3.4.Transmission time..................................................................................................................... 22 3.5.Duty cycle correction factor ...................................................................................................... 23 3.6.Antenna Requirement............................................................................................................... 24 Appendix A. Measurement equipment.......................................................................................................... 25 You can check the authenticity of this test report on the authenticity verification page on our website (www.kes.co.kr). Report No. : KES-RF260249 Page4/25 KES-QP16-F01(00-23-01-01)KES Co., Ltd. 1.General information Applicant:AMOSENSE Applicant address:19-1BL, 90, 4sandan 5-gil, Jiksan-eup, Seobuk-gu, Cheonan-si, Chungcheongnam-do, Republic of Korea Test site:KES Co., Ltd. Test site address:#3002, #3503, #3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Rep. of Korea 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, 12658, Rep. of Korea Test FacilityFCC Accreditation Designation No.: KR0100, Registration No.: 444148 ISED CAB ID: KR0100, ISED Registration No.: 23298 FCC rule part(s):Part 15 Subpart C 15.231 IC rule part(s):RSS-210 (Issue 11), RSS-GEN (Issue 5) FCC ID:2AS9T-ASRKET01 IC Number :27298-ASRKET01 Test device serial No.:ProductionPre-productionEngineering 1.1.EUT description Equipment under test RKE Transceiver Frequency range433.92㎒ Model ASRKET01 Modulation technique FSK Number of channels433.92㎒: 1 ch Power sourceDC 12 V Antenna specification Ceramic Chip Antenna // Peak gain: -1.44㏈i H/W VersionA.00 S/W Version2633 Serial number260428R11010553 260428R11010554 1.2.Test configuration TheAMOSENSE // RKE Transceiver // ASRKET01 // FCC ID : 2AS9T-ASRKET01 // IC Number : 27298-ASRKET01was tested according to the specification of EU…

Text truncated - open the document above for the full version.

ModelRKET ApplicationRKE 2 1. Summary of the antenna test 1) Test Condition 2) Radiation Gain Efficiency [%] Avg. gain [dBi] Peak gain [dBi] 433.92 34.56-4.61-1.44 • Application – 433.92MHz 433.92MHz XY PlaneZx PlaneYZ Plane 3 2. Test : 433MHz 1) Antenna S-Parameter

FCC ID : 2AS9T-ASRKET01 IC Number : 27298-ASRKET01 Page 1 of 1 Appendix B. Measurement equipment Radiated test Blank
