2ASC7-HD43XTruck Scanner

OBDSPACE TECHNOLOGY CO,.LTD U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: June. 21, 2024 Signed by (Printed Name/Title): Kenneth Young/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: OBDSPACE TECHNOLOGY CO,.LTD Grantee Code: 2ASC7 FCC ID: 2ASC7-HD43X FRN: 0028167070 Contact Name: Frank Hao Street Address: Room D03, Building A, No.973, MinZhi Avenue LongHua district, Shenzhen City, China Telephone No: +86-13691649917 Email: [email protected] Applicant Signature: Date: 2024.06.21 Signed by (Printed Name/Title): Frank Hao / Manager

OBDSPACE TECHNOLOGY CO,.LTD Address: Room D03, Building A, No.973, MinZhi Avenue LongHua district, Shenzhen City, China Date: 2024-06-21 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing SUBJECT: FCC Application for FCC ID: 2ASC7-HD43X To Whom It May Concern: OBDSPACE TECHNOLOGY CO,.LTD certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Date: 2024-06-21

OBDSPACE TECHNOLOGY CO,.LTD Address: Room D03, Building A, No.973, MinZhi Avenue LongHua district, Shenzhen City, China Date: 2024-06-21 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing SUBJECT: FCC Application for FCC ID: 2ASC7-HD43X To Whom It May Concern: OBDSPACE TECHNOLOGY CO,.LTD certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Date: 2024-06-21

ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -1-/13 Customer SHENZHENFCARTECHNOLOGYCO.,LTD ProjectHD430 ProjectNOXBY240048 Date：2024/4/15 ShenzhenXiangboyi TechnologyCo.Ltd Antenna Specification ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -2-/13 Customerconfirmation EngineerPMQualityApproval Supplierconfirmation MERFExamineApproval Samplepaste ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -3-/13 Catalogue 1TestSystemandEquipment......................................-4- 2ProductDescription.......................................................-5- 3DeviceDescription........................................................-5- 4MatchingCircuits...........................................................-6- 5TestData.........................................................................-7- 6EngineeringDrawing...................................................-12- 7PhysicalAssemblyPicture........................................-13- ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -4-/13 1TestSystemandEquipment Testitemsequipment 1：Sparameter 1. 1. Return Return loss loss 2. 2. VSWR VSWR Network Network analyzer: analyzer: A338/A333/HP8753D A338/A333/HP8753D 2：Activetest Comprehensive Comprehensive test test instrument: instrument: Agilent Agilent 8960/ 8960/ CMW500 CMW500 3 ： Radiationmode andgain 1. 1. Radiation Radiation mode mode 2. 2. Gain Gain 1. 1. Shielding Shielding room room ： ： 7x4x3 7x4x3 m m (ETS-3D) (ETS-3D) 2. 2. Network Network analyzer analyzer ： ： HP HP 8753D 8753D ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -5-/13 2ProductDescription TechnicalrequirementsTechnicalindexRemarks Band WIFI:2.4G/5G RangeOfFrequency 2400-2500Mhz; 5180-5850Mhz VSWR 2400-2500Mhz<2.0 5180-5850Mhz<2.0 CenterFrequency Impendance 50Ω Polarization Linearpolarization operatingtemperature -32°C/+55°C storagetemperature -55°C/+85°C SaltFog 24h(24halterningwet&dry) RoHSCompliant yes 3DeviceDescription ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -6-/13 Thewholemachinephoto 4MatchingCircuits ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -7-/13 ElementValueVender E1(0402)NA E2(0402)0Ω E3(0402)NA E4(0402)0Ω Originalmatchunchanged. 5TestData ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -8-/13 WiFdirectivitydiagram ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -9-/13 ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -10-/13 ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -11-/13 Note:Thisantennaisonlyapplicabletothemotherboard versionofthecommissioningprototype.WithchangesorRF materials,peripheralcomponentsaroundtheantenna,itmust betestedandverifiedbyourcompany. ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -12-/13 6EngineeringDrawing ShenzhenXiangboyiTechnologyCo.Ltd Tel:(+86)0755-29369912Fax:(+86)0755-61624200 R&DCenter:101,floor1,Wenchengbuilding,YousongCulturalInnovationPark,No.95, YousongRoad,LonghuaDistrict,Shenzhen. ProductionBase:5/F,buildingB,Huazhichuanggu,No.7,Yuhuastreet,138Industrial Zone,TangxiaTown,DongguanCity. -13-/13 7.PhysicalAssemb…

Text truncated - open the document above for the full version.

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 OBDSPACE TECHNOLOGY CO,.LTD Room D03, Building A, No.973, MinZhi Avenue LongHua district, Shenzhen City, China Date：2024/06/21 Product Model Number: HD430, HD431, HD432, HD433, HD434, HD435, HD436, HD437, HD438, HD439 FCC ID：2ASC7-HD43X To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that OBDSPACE TECHNOLOGY CO,.LTD is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by OBDSPACE TECHNOLOGY CO,.LTD on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: +86-13691649917 On behalf of: OBDSPACE TECHNOLOGY CO,.LTD

OBDSPACE TECHNOLOGY CO,.LTD Room D03, Building A, No.973, MinZhi Avenue LongHua district, Shenzhen City, China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 21, 2024 Subject; Request for Confidentiality FCC ID: 2ASC7-HD43X To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Frank Hao Title: Manager

OBDSPACE TECHNOLOGY CO,.LTD Room D03, Building A, No.973, MinZhi Avenue LongHua district, Shenzhen City, China Series Models Description To whom it may concern: The device (Product Name: Truck Scanner) Models Name: HD430, HD431, HD432, HD433, HD434, HD435, HD436, HD437, HD438, HD439 have same electrical, PCB and BOM, only the model’s name and colour are different for marketing requirements. Sincerely, Frank Hao Phone: +86-13691649917 e-mail: [email protected] Dated: 06/21/2024

FCC ID: 2ASC7-HD43X Page 1 of 4 Report No.: CTL2404242101-WF External Photos of EUT FCC ID: 2ASC7-HD43X Page 2 of 4 Report No.: CTL2404242101-WF FCC ID: 2ASC7-HD43X Page 3 of 4 Report No.: CTL2404242101-WF FCC ID: 2ASC7-HD43X Page 4 of 4 Report No.: CTL2404242101-WF

FCC ID: 2ASC7-HD43X Page 1 of 1 Report No.: CTL2404242101-WF FCC-ID Label Information 1. Label location: Size: L3.0cm*W2.0cm Truck Scanner Model: HD430 FCC ID: 2ASC7-HD43X

FCC ID: 2ASC7-HD43X Page 1 of 3 Report No.: CTL2404242101-WF Internal Photos of EUT Antenna FCC ID: 2ASC7-HD43X Page 2 of 3 Report No.: CTL2404242101-WF FCC ID: 2ASC7-HD43X Page 3 of 3 Report No.: CTL2404242101-WF

FCC ID: 2ASC7-HD43X Page 1 of 4 Report No.: CTL2404242101-WF FCC RF Exposure Evaluation 1. Product Information FCC ID 2ASC7-HD43X Product Name Truck Scanner Test Model HD430, HD431, HD432, HD433, HD434, HD435, HD436, HD437, HD438, HD439 Power Supply DC12V power supply Modulation Type Bluetooth LE: GFSK 2.4G WIFI : 802.11b: DSSS 802.11g/802.11n(H20)/802.11n(H40): OFDM Antenna Type Internal Antenna Antenna Gain Bluetooth: 2.23dBi 2.4G WIFI : 2.23dBi Frequency Range 2402 – 2480MHz / 2412 – 2462MHz Exposure Category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Device 2. Evaluation Method and Limit Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3.1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices FCC ID: 2ASC7-HD43X Page 2 of 4 Report No.: CTL2404242101-WF 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information HD430 can only use antennas certificated as follows provided by manufacturer; Antenna type and antenna number Operate frequency band Maximum antenna gain Note Internal Antenna 2402 MHz – 2480 MHz 2412MHz – 2462MHz Bluetooth: 2.23dBi 2.4G WIFI : 2.23dBi Bluetooth & WLAN Antenna FCC ID: 2ASC7-HD43X Page 3 of 4 Report No.: CTL2404242101-WF 6.Conducted Power Results [BLE] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) 1M 0 2402 -7.89 19 2440 -8.17 39 2480 -8.70 2M 0 2402 -7.92 19 2440 -7.79 39 2480 -8.45 [2.4GWIFI Max Conducted Power] Mode Channel Frequency(MHz) Max Conducted Power(dBm) IEEE 802.11b 1 2412 -2.01 6 2437 -2.31 11 2462 -2.26 IEEE 802.11g 1 2412 -2.79 6 2437 -3.13 11 2462 -3.05 IEEE 802.11n HT20 1 2412 -3.80 6 2437 -4.13 11 2462 -4.05 IEEE 802.11n HT40 3 2422 -3.35 6 2437 -4.59 9 2452 -5.03 7.Manufacturing Tolerance <BLE-1M> GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) -8.0 -8.0 -8.0 Tolerance ±(dB) 1.0 1.0 1.0 <BLE-2M> GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) -8.0 -8.0 -8.0 Tolerance ±(dB) 1.0 1.0 1.0 FCC ID: 2ASC7-HD43X Page 4 of 4 Report No.: CTL2404242101-WF <2.4GWLAN > IEEE 802.11b (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) -2.0 -2.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11g (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) -3.0 -3.0 -3.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11n HT20 (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) -4.0 -4.0 -4.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11n HT40 (Peak) Channel Channel 3 Channel 6 Channel 9 Target (dBm) -3.0 -4.0 -5.0 Tolerance ±(dB) 1.0 1.0 1.0 8. Evaluation Results 8.1 Standalone MPE As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna refer to antenna information, the RF power density can be obtained. BLE Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) Duty Cycle MP…
