8 10 10 11 1 2 3 4 13 14 9" BT5.0 2 Specific Absorption Rate (SAR) information: This Table PC meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. Body-worn Operation The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Table PC (FCC ID: 2ASQ8-P9) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for worn on the body is 0.641W/kg. This device was tested for typical body-worn operations with the back of the handset kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0mm separation distance between the user's body and the back of the Table PC. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. The manufacturer ensures that the frequency stability of this U-NII device can maintain transmission within the operating frequency band under all normal operating conditions.

Shenzhen Mediafly Technology CO.,LTD Agent Authorization Company: Shenzhen Mediafly Technology CO.,LTD Address: 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Product Name: Tablet PC Model Number(s): MediaPad P9 Product Description: Tablet PC We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021/1/28 Name: ken.zhang Title: Manager Company: Shenzhen Mediafly Technology CO.,LTD

Shenzhen Mediafly Technology CO.,LTD Authorization Letter We, (the approval holder) Company name Shenzhen Mediafly Technology CO.,LTD Addresss 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China declare that the following representative (agent): Name (person) Bovey Yang Company name Shenzhen STS Test Services Co., Ltd. Addresss 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Micom Labs for product certification below Product Description Tablet PC Type or Model(s) MediaPad P9 Tradename or Brand(s) HAOVM Attestation: City: Date: Name: (this must be a person) Function: Signature: (or official company stamp) China 2021/01/28 ken.zhang Manager

Shenzhen Mediafly Technology CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/01/28 Subject; Request for Confidentiality FCC ID: 2ASQ8-P9 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: ken.zhang Shenzhen Mediafly Technology CO.,LTD Title: Manager

Page 1 of 5 Report No.: STS2101023 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: P9 Photo 1 Photo 2 Photo 3 Page 2 of 5 Report No.: STS2101023 Photo 4 Page 3 of 5 Report No.: STS2101023 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2101023 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2101023 Photo 9 Photo 10

FCC Label Table PC Model name: MediaPad P9 FCC ID: 2ASQ8-P9 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 6 Report No.: STS2101023 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: P9 Photo 1 Photo 2 Photo 3 Page 2 of 6 Report No.: STS2101023 Photo 4 BT/WIFI Antenna Page 3 of 6 Report No.: STS2101023 Photo 5 Photo 6 Page 4 of 6 Report No.: STS2101023 Photo 7 Photo 8 Page 5 of 6 Report No.: STS2101023 Photo 9 Photo 10 Page 6 of 6 Report No.: STS2101023 Photo 11 Photo 12

Ref : ACR.345.3.20.MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 41/18 EPGO334 Summary: This document presents the method and results from an accredited COMOSAR E-Field probe ca libration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report Page: 1/10 07/14/2020 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise - 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibretion date: 07/14/2020 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.MVGB.A Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Name Function Date Signature Prepared by : Jérôme LUC 7/28/2020 Checked by : Jérôme LUC 7/28/2020 Approved by : 7/28/2020 Yann Toutain Technical Manager Technical Manager Laboratory Director Issue Date Modifications A 7/28/2020Initial release Name Jérôme LUC Page: 2/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.MVGB.A TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment .................................................................................................... 10 Page: 3/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.MVGB.A 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 41/18 EPGO334 Product Condition (new / used) New Frequency Range of Probe 0.45 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.191 M Dipole 2: R2=0.216 M Dipole 3: R3=0.197 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528 and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. Page: 4/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.345.3.20.MVGB.A 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plastic box illuminated with the fields from a half wave dipole. The dipole is rotated about it…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2101023H01 Issued for Shenzhen Mediafly Technology CO.,LTD 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Product Name: Tablet PC Brand Name: HAOVM Model Name: MediaPad P9 Series Model: N/A FCC ID: 2ASQ8-P9 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Body: 0.641 W/kg S T L A B S Page 2 of 42 Report No.: STS2101023H01 Test Report Certification Applicant’s name ................. : Shenzhen Mediafly Technology CO.,LTD Address ................................. : 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Manufacture's Name ............ : Shenzhen Mediafly Technology CO.,LTD Address ................................. : 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Product description Product name ........................ : Tablet PC Brand name ......................... : HAOVM Model name ......................... : MediaPad P9 Series Model .......................... : 2ASQ8-P9 Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test Date (s) of performance of tests ............. : 11 Jan. 2021 ~ 13 Jan. 2021 Date of Issue .......................................... : 22 Jan. 2021 Test Result .............................................. : Pass Testing Engineer : (Lemon Li) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 42 Report No.: STS2101023H01 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Antenna Location Sketch 15 7.1 SAR test exclusion consider table 16 8. EUT Test Position 18 8.1 Body-worn Position Conditions: 18 8.2 Hotspot mode exposure position condition 18 9. Uncertainty 19 9.1 Measurement Uncertainty 19 9.2 System validation Uncertainty 20 10. Conducted Power Measurement 21 10.1 Test Result 21 11. EUT And Test Setup Photo 23 11.1 EUT Photo 23 11.2 Setup Photo 26 12. SAR Result Summary 29 12.1 Body-worn and Hotspot SAR 29 13. Equipment List 30 Appendix A. System Validation Plots 31 Appendix B. SAR Test Plots 37 Appendix C. Probe Calibration And Dipole Calibration Report 42 Page 4 of 42 Report No.: STS2101023H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 22 Jan. 2021 STS2101023H01 ALL Initial Issue Note: Format version of the report - V01 Page 5 of 42 Report No.: STS2101023H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name Tablet PC Brand Name HAOVM Model Name MediaPad P9 Series Model N/A Model Difference N/A Battery Rated Voltage: 3.8V Charge Limit: 4.35V Capacity: 5000mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version P30-9863A-V1.0 Software Version P9_V1.0_20201225 Frequency Range WLAN 802.11b/g/n20/n40: 2412 to 2462 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5180 to 5240 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5745 to 5825 MHz Bluetooth: 2402 to 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode Body Worn and Hotspot(W/kg) DTS 2.4GHz WLAN 0.641 NII 5.2GHz WLAN 0.542 NII 5.8GHz WLAN 0.109 DSS Bluetooth Note 0.263 FCC Equipment Class Part 15 Spread Spectrum Transmitter (DSS) Digital Transmission System (DTS) Unlicensed National Information Infrastructure TX (NII) Operating Mode WLAN: 802.11 a/b/g/n(HT20)ac(VHT20) /n(HT40)/ac(VHT40)/ac(VHT80) Bluetooth: 5.0+EDR (GFSK +π/4DQPSK+8DPSK) BLE:GFSK Antenna Specification BT,WLAN: PIFA Antenna Hotspot Mode Support DTM Mode Not Support Note: 1. Bluetooth SAR was estimated 2. The EUT battery must be fully charged and checked periodically during the test to ascertain uniform Page 6 of 42 Report No.: STS2101023H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration No.: 625569 IC Registration No.: 12108A A2LA Certificate No.: 4338.01 Page 7 of 42 Report No.: STS2101023H01 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Fre…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2101023W02 Issued for Shenzhen Mediafly Technology CO.,LTD 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Product Name: Tablet PC Brand Name: HAOVM Model Name: MediaPad P9 Series Model: N/A FCC ID: 2ASQ8-P9 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 60 Report No.: STS2101023W02 TEST RESULT CERTIFICATION Applicant’s Name ................. : Shenzhen Mediafly Technology CO.,LTD Address ................................. : 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Manufacturer's Name .......... : Shenzhen Mediafly Technology CO.,LTD Address ................................. : 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Product Description Product Name ....................... : Tablet PC Brand Name ........................ : HAOVM Model Name .......................... : MediaPad P9 Series Model ......................... : N/A Test Standards ..................... : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 07 Jan. 2021 Date (s) of performance of tests ............. : 07 Jan. 2021 ~ 19 Jan. 2021 Date of Issue .......................................... : 19 Jan. 2021 Test Result.............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 60 Report No.: STS2101023W02 Table of Contents 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 TEST PROCEDURE 16 3.3 TEST SETUP 16 3.4 EUT OPERATING CONDITIONS 16 3.5 TEST RESULTS 17 4. RADIATED EMISSION MEASUREMENT 19 4.1 RADIATED EMISSION LIMITS 19 4.2 TEST PROCEDURE 21 4.3 TEST SETUP 22 4.4 EUT OPERATING CONDITIONS 22 4.5 FIELD STRENGTH CALCULATION 23 4.6 TEST RESULTS 24 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 37 5.1 LIMIT 37 5.2 TEST PROCEDURE 37 5.3 TEST SETUP 37 5.4 EUT OPERATION CONDITIONS 37 5.5 TEST RESULTS 38 6. POWER SPECTRAL DENSITY TEST 46 6.1 LIMIT 46 6.2 TEST PROCEDURE 46 6.3 TEST SETUP 46 Page 4 of 60 Report No.: STS2101023W02 Table of Contents 6.4 EUT OPERATION CONDITIONS 46 6.5 TEST RESULTS 47 7. BANDWIDTH TEST 51 7.1 LIMIT 51 7.2 TEST PROCEDURE 51 7.3 TEST SETUP 51 7.4 EUT OPERATION CONDITIONS 51 7.5 TEST RESULTS 52 8. PEAK OUTPUT POWER TEST 56 8.1 LIMIT 56 8.2 TEST PROCEDURE 56 8.3 TEST SETUP 56 8.4 EUT OPERATION CONDITIONS 56 8.5 TEST RESULTS 57 9. ANTENNA REQUIREMENT 59 9.1 STANDARD REQUIREMENT 59 9.2 EUT ANTENNA 59 10. EUT TEST PHOTO 60 Page 5 of 60 Report No.: STS2101023W02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 19 Jan. 2021 STS2101023W02 ALL Initial Issue Page 6 of 60 Report No.: STS2101023W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 60 Report No.: STS2101023W02 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±4.39dB 4 All emissions, radiated 1G-6GHz ±5.10dB 5 All emissions, radiated>6G ±5.48dB 6 Conducted Emission (9KHz-150KHz) ±2.79dB 7 Conducted Emission (150KHz-30MHz) ±2.80dB Page 8 of 60 Report No.: STS2101023W02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Tablet PC Trade Name HAOVM Model Name MediaPad P9 Series Model N/A Model Difference N/A Product Description The EUT is a Tablet PC Operation Frequency: 2402~2480 MHz Modu…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2101023W03 Issued for Shenzhen Mediafly Technology CO.,LTD 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Product Name: Tablet PC Brand Name: HAOVM Model Name: MediaPad P9 Series Model: N/A FCC ID: 2ASQ8-P9 Test Standard: FCC Part 15.247 S T L A B S S T L A B S Page 2 of 70 Report No.:STS2101023W03 TEST RESULT CERTIFICATION Applicant’s Name ................. : Shenzhen Mediafly Technology CO.,LTD Address ................................. : 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Manufacturer's Name ........... : Shenzhen Mediafly Technology CO.,LTD Address ................................. : 1F A bldg ,weixing Tech-park 268-3 Baoshi Road, Shuitian community Shiyan St, ShenZhen, China Product Description Product Name ........................ : Tablet PC Brand Name ........................... : HAOVM Model Name .......................... : MediaPad P9 Series Model .......................... : N/A Test Standards ..................... : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ...................... : 07 Jan. 2021 Date (s) of performance of tests ............. : 07 Jan. 2021 ~ 19 Jan. 2021 Date of Issue .......................................... : 19 Jan. 2021 Test Result .............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 70 Report No.:STS2101023W03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 4.1 LIMIT 31 4.2 TEST PROCEDURE 31 4.3 DEVIATION FROM STANDARD 31 4.4 TEST SETUP 31 4.5 EUT OPERATION CONDITIONS 31 4.6 TEST RESULTS 32 5. POWER SPECTRAL DENSITY TEST 48 5.1 LIMIT 48 5.2 TEST PROCEDURE 48 5.3 DEVIATION FROM STANDARD 48 5.4 TEST SETUP 48 5.5 EUT OPERATION CONDITIONS 48 5.6 TEST RESULTS 49 6. BANDWIDTH TEST 57 6.1 LIMIT 57 6.2 TEST PROCEDURE 57 6.3 DEVIATION FROM STANDARD 57 6.4 TEST SETUP 57 6.5 EUT OPERATION CONDITIONS 57 Page 4 of 70 Report No.:STS2101023W03 Table of Contents Page 6.6 TEST RESULTS 58 7. PEAK OUTPUT POWER TEST 66 7.1 LIMIT 66 7.2 TEST PROCEDURE 66 7.3 DEVIATION FROM STANDARD 66 7.4 TEST SETUP 67 7.5 EUT OPERATION CONDITIONS 67 7.6 TEST RESULTS 68 8. ANTENNA REQUIREMENT 69 8.1 STANDARD REQUIREMENT 69 8.2 EUT ANTENNA 69 APPENDIX-PHOTOS OF TEST SETUP 70 Page 5 of 70 Report No.:STS2101023W03 Revision History Rev. Issue Date Report No. Effect Page Contents 00 19 Jan. 2021 STS2101023W03 ALL Initial Issue Page 6 of 70 Report No.:STS2101023W03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 70 Report No.:STS2101023W03 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±4.39dB 4 All emissions, radiated 1G-6GHz ±5.10dB 5 All emissions, radiated>6G ±5.48dB 6 Conducted Emission (9KHz-150KHz) ±2.79dB 7 Conducted Emission (150KHz-30MHz) ±2.80dB Page 8 of 70 Report No.:STS2101023W03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Tablet PC Trade Name HAOVM Model Name MediaPad P9 Series Model N/A Model Difference N/A Product Description The EUT is a Tablet PC Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz 802.11n(40MHz):24…

Text truncated - open the document above for the full version.
