2ASTR-W1AP01Smart Visual Fish Finder

Ningbo Pelican Smart Fishing Tackle Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 01, 2022
Application Purpose: Original Equipment
Date of Application: Dec 01, 2022
Equipment Note: Smart Visual Fish Finder
Frequency Range: 2412.00000000 - 2462.00000000
Company: Ningbo Pelican Smart Fishing Tackle Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

USERMANUAL SmartFishFinder V9:2022/11/11 Catalogue 1.“Rippton”AppDownloading......................................................................1 2.DirectionsforUse......................................................................................1 3.OtherSetting...........................................................................................11 4.HowtoCharge........................................................................................13 5.Specification............................................................................................14 6.OtherTips................................................................................................14 7.Disposal...................................................................................................15 8.FCCCompliance.....................................................................................16 1 1.“Rippton”AppDownloading Searchfor“RIPPTON”ontheGooglePlayStore,SamsungGalaxyApps orAppStoreorscanthisQRcodetoinstalltheapponyourmobiledevice. Youcanfindthe“Rippton”appontheGooglePlayStore,Samsung GalaxyAppsandAppStore.InstallingtheapprequiresAndroidSystem 8.0oraboveandiOS9.0orabove. 2.DirectionsforUse ModeRange ClientMode(refertopage1-9) BeingusedtogetherwithCatchXProbait boat: https://www.rippton.com/product/catchx-pro 300m APMode(refertopage9-10) Beingusedsolely 80-100m(dependon environment) 2.1 ClientMode(UsedwithCatchXPro) 1)Ensurethatyour“HYDROBAT”smartfishfinder(the“fishfinder”),CatchX Probaitboat(the“boat”)anditsremotecontrolhavebeenfullycharged. 2)Properlyfixthefishfinderontotheboatfollowingthestepsbelow: Step1:ConnectthePole1withtheboatfirst. 2 3)Turntheboaton.Placetheboatandthefishfinderinwaterafterpairing theboatwithitsremotecontrol.Yourfishfinderwillbeautomatically turnedononceplacedinwater. 4)Afterthefishfinderbeingturnedoninwater,pleaseenterSettingsinyour mobiledeviceandgetinto“WLAN”.Find“RIP-*****”inthelistofavailable Wi-FinetworksandtaptoconnectwithPassword:12345678 5)Enter“Rippton”Apponyourmobiledevice,tap“Device”andselectthe “HYDROBATFishFinder”interface. Step2:Assembletheright-angle connectingrodsetaccordingtothe leftpicture;thenscrewthePole2 upwiththetopholeofthefish finder.Donotusethelowerhole, unlessusingthefishfinder solely. 3 6)Afterconnection,pleaseopenSettings,andthenturnoffAPmode. 7)Itisrequiredtoentertheunique6-digitalSSIDcodetoconnectthefish finderwiththeboatasbelow: KindReminder:Theunique6-digitalSSID codecanbefoundinsidethecoveras shownabove. 4 8) GetbacktotheSettingsinyourmobiledevice,re-enter“WLAN”andfind “IN-******”inthelistofavailableWi-Finetworksandtaptoconnectwith Password:12345678 9)Re-enter“Rippton”App,tap “Device”andselectthe “CatchXPro”interface. 10)Tapthe5 th icononthelefttoopenthefishfinderwindow. Tips:Youcanswitchinterfacesbetweenthemapandthefishfinderby tappingthesmallwindow. 5 11)Priortoperforminganytask,pleasesetahomepointaccordingtothe instructionsbelow: 12)Tapthe2 nd iconontheleftandselectthesuitablemissiontypeforyour need. FixedPointScan 1 Longpressthescreentopinspots(upto10)inthegreencycleto formarouteforthefixed-pointscanningmission. 6 2Oncetherouteisformed,tap“Start”onthebottomrightcornerand slidetoconfirm.Theboatwillstraightperformthemissionspotby spot. 3 PleaserefertoSection3.6(p13)abouthowtoauto-generatethe spotswhenalarmrings. ZoneScan 1 Inthegreencycle,pleaseclockwisepinspots(3≤spotnumber≤10) bylongpressthescreenforeachonetosetthezoneofscanning mission. 7 2Oncethezoneisformed,tap“Start”andslidetoconfirm.Theboat willperformakindofgridscanwithinthezonebysailingalongthe auto-generatedgreenline. Mapping Ifyouintendtoknowthedepthofanyfreshwaterarea,themapping functionisagoodchoiceforyou.Theboatequippedwiththefishfinderis abletodetectthewaterdepth,aswellassearchingthefishatthesame time. 8 Tips:AccurateMappinghassmallerlinespacing(1m)forguidedscanningthanthatofQuick Mapping(2m). a.Inthegreencycle, pleaseclockwise pinspots(3 ≤spot number≤10 )by longpressthe screenforeachone tosetthezoneof mapping. b.Oncethezoneisformed,tap“Start”andslidetoconfirm.Theboatwill sailspirallyfromtheoutermostlayertotheinnermost. Tips:Accordingtothespectrumofdepthindicator,“red”standsfortheshallowestplace (around0-0.2m),“deepseablue”meansthedeepestplace(over5meters) 9 c.Tapthe5 th buttonontherighttoshowthehistoryofyourscanning missioninthiswaterarea. TheredpartoftheTimeAxisrepresentsthetimepointinwhichyou haveavailableinformation. 2.2 APMode (UseSolelywithoutBoat) 1)Ensurethatyourfishfinderhasbeenfullycharged. 2)Screwtheboltintoeitherofthetwoholesandattachyourlinetothebolt. TimeAxis 10 Note:Pleaseensureyourlineisingoodconditionbeforecastingoutyour fishfinder.Yourfishfinderwillbeautomaticallyturnedononceplacedin water. 3)Afterthefishfinderbeingturnedoninwater,pleaseenterSettingsinyour mobiledeviceandgetinto“WLAN”.Find“RIP-*****”inthelistofavailable Wi-FinetworksandtaptoconnectwithPassword:12345678. 4)Enter“Rippton”Apponyourmobiledevice,tap“Device”andenter“Fish Finder”interface. 5)Pleasekeepthefishfinderwithintherangeof80-100metersaroundyour mobiledevice. 11 3.OtherSetting 3.1.Switchon/offDisplayFishFigureonthetoprightcorner. 3.2.Tap“Sensitivity”toadjustdetectionsensitivity. 3.3.Tap“Settings”tocustomizeyourpreferences. 12 3.4.SonarMode Tap“SonarMode”toselectthefrequency 3.5.DepthAlarm 13 3.6.FishAlarm 4.HowtoCharge KindReminder:Pleaseusea5VchargingplugwiththeprovidedMicroUSBcable. 14 5.Specification Dimensions:68mm Weight:105g ConnectionMode:WiFi ConnectionRange:80-100m(solely) RangeWhenConnectedwiththeCatchX ProBaitBoat:300m Max/minDetectionDepth:120m/0.6m DetectionAngles:55°/15° Frequency:110KHz/300KHz DataFrameRate:10f/s SensitivityAdjustmentrange:1%-100% RunTimeonaFullCharge:5.5–6hrs WorkingTemperature:-10°C-50°C(±1°C) BatteryCapacity:1500mAh WaterResistanceLevel:fullywaterproof PackageIncludes:1fishfinder,1Micro USBcable,1boltand1usermanual 6.OtherTips WeadviseturningofftheCellularDataofyourphonewhenconnecting withthisfishfinder. DonotforgettoswitchbacktoAPmodeaftery…

Text truncated - open the document above for the full version.

Cover Letter(s)

Ningbo Pelican Smart Fishing Tackle Co., Ltd Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 11/29/2022 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2ASTR-W1AP01 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature [Tina LEI] [Manager] [Ningbo Pelican Smart Fishing Tackle Co., Ltd]

Cover Letter(s)

Ningbo Pelican Smart Fishing Tackle Co., Ltd Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 11/29/2022 Request for Permanent Confidentiality Company name: Ningbo Pelican Smart Fishing Tackle Co., Ltd FCC ID: 2ASTR-W1AP01 FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.457 and CFR 47 § 0.459 Ningbo Pelican Smart Fishing Tackle Co., Ltd hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, These documents contain detailed system and equipment description and related information about the product which Ningbo Pelican Smart Fishing Tackle Co., Ltd considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Ningbo Pelican Smart Fishing Tackle Co., Ltd considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature [Tina LEI] [Manager] [Ningbo Pelican Smart Fishing Tackle Co., Ltd] No.16, Yongchang Road, Chengdong Industrial Park, Xiangshan County, Ningbo City, Zhejiang Province, China

External Photos

ID Label/Location Info

Size:10*5mm FCC ID: 2ASTR-W1AP01 Label Location

ID Label/Location Info

Size:10*5mm FCC ID: 2ASTR-W1AP01 Label Location

Internal Photos

Internal Photos Antenna

RF Exposure Info

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2ASTR-W1AP01 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna, R=0.2m TEST RESULTS Conclusion: For the max Power Density(S)(mW/ cm2) : 0.00471＜1, the SAR testing is not required. Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW/ cm2) Result 802.11b 10±1 11 12.59 1.88 (2.74dBi) 0.00471 1 Pass

Test Report

No.：BCTC/RF-EMC-005 Page: 1 of 71 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2210127937E Applicant: Ningbo Pelican Smart Fishing Tackle Co., Ltd Product Name: Smart Visual Fish Finder Model/Type reference: HF-0000W1AP01 Tested Date: 2022-10-13 to 2022-11-16 Issued Date: 2022-11-18 Report No.: BCTC2210127937E No.：BCTC/RF-EMC-005 Page: 2 of 71 Edition：A.5 FCC ID: 2ASTR-W1AP01 The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Smart Visual Fish Finder Trademark: Model/Type reference: HF-0000W1AP01 Prepared For: Ningbo Pelican Smart Fishing Tackle Co., Ltd Address: No.16, Yongchang Road, Chengdong Industrial Park, Xiangshan County, Ningbo City, Zhejiang Province, China Manufacturer: Ningbo Pelican Smart Fishing Tackle Co., Ltd Address: No.16, Yongchang Road, Chengdong Industrial Park, Xiangshan County, Ningbo City, Zhejiang Province, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2022-10-11 Sample tested Date: 2022-10-13 to 2022-11-16 Issue Date: 2022-11-18 Report No.: BCTC2210127937E Test Standards: FCC Part15.247 ANSI C63.10-2013 Test Results: PASS Remark: This is WIFI-2.4GHz band radio test report. Tested by: Approved by: Eric Yang/Project Handler Zero Zhou/Reviewer Report No.: BCTC2210127937E No.：BCTC/RF-EMC-005 Page: 3 of 71 Edition：A.5 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 9 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List ........................................................................................................ 10 4.5 Test Mode ........................................................................................................... 10 4.6 Table Of Parameters Of Text Software Setting ................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test procedure .................................................................................................... 13 6.4 EUT operating Conditions ................................................................................... 13 6.5 Test Result .......................................................................................................... 14 7. Radiated Emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test procedure .................................................................................................... 18 7.4 EUT Operating Conditions .................................................................................. 19 7.5 Test Result .......................................................................................................... 20 8. Radiated Band Emission Measurement And Restricted Bands Of Operation ..... 26 8.1 Block Diagram Of Test Setup .............................................................................. 26 8.2 Limit .................................................................................................................... 26 8.3 Test procedure .................................................................................................... 27 8.4 EUT Operating Conditions .................................................................................. 27 8.5 Test Result .......................................................................................................... 28 9. Power Spectral Density Test ............................................................................... 29 9.1 Block Diagram Of Test Setup .............................................................................. 29 9.2 Limit .................................................................................................................... 29 9.3 Test procedure .................................................................................................... 29 9.4 EUT Operating Conditio…

Text truncated - open the document above for the full version.

Test Report

深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 Antena TestReport 专业的4G/3G/GPS/WIFI等天线方案设计及供应商客户名称博海深衡客户项目负责人晏工项目名称BHSH-钓鱼声纳BHY调试频段2.4G 天线类型 W ire antenna 测试日期2022-11-05 射频工程师庄工结构工程师黄工深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 Contents 1：Antenna Overview &Dimension 2：The testproject 1.Antenna MatchingNetwork 2.VSWR 3.Gain &Efficiency 4.3D Date 5.The Free Space 3D Date/The Free Space 2D Date 3 : Groundprocessing 深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 Antenna Overview &Dimension HX-RF18-28A2-BHSH 深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 2.4G AatennaGain&Efficiency Frequency ID1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Frequency (MHz)2300.02310.02320.02330.02340.02350.02360.02370.02380.02390.02400.02410.02420.02430.02440.0 Efficiency (dBi)-4.93-4.62-4.43-4.22-3.83-3.70-3.34-3.21-2.93-2.83-2.47-2.41-2.13-2.01-1.86 Gain (dBi)0.310.490.440.400.470.460.891.091.381.431.591.431.641.631.64 Efficiency (%)32.1734.5136.0437.8141.3642.6946.3647.7150.9552.1556.5857.4361.3062.9965.13 Frequency ID16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 Frequency (MHz)2450.02460.02470.02480.02490.02500.02510.02520.02530.02540.02550.02560.02570.02580.02590.02600.0 Efficiency (dBi)-1.70-1.63-1.50-1.44-1.27-1.22-1.05-1.09-0.95-0.94-0.95-0.82-0.98-0.83-1.03-0.91 Gain (dBi)1.911.992.332.522.742.682.662.362.402.472.522.732.582.672.282.21 Efficiency (%)67.5868.6370.7671.7374.6375.5178.6177.8080.3880.5780.3682.7479.8482.5978.9081.04 深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 Free Space 3D Activedata 深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 Free Space 3D Activedata 深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 Free Space 3D Activedata 深圳市红心科技电子有限公司电话：0755-23205219 官网：http://www.hxrf-antenna.com/ 地址：深圳市宝安区西乡街道固兴社区新安第二工业区C10栋西面2楼 THANKS

Test Setup Photos

Conducted emissions Radiated Measurement Photos

Contact Information

Applicant

Tina LEI

[email protected]18801620274Fax: 0574-87139648

Test Firm

Shenzhen BCTC Testing Co., Ltd.Sally He

[email protected]15999690624

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	11.38 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter device.
