2AT9T-3286Tablet

This information has to be presented in such a way that the user can readily understand ii. Typically, this will necessitate translation into every local language (required by national consumer laws) of the markets where the equipment is intended to be sold. Illustrations, pictograms and using international abbreviations for country names may help reduce the need for translation Restrictions in the 5 GHz band: Acco「ding to Article 10 (10) of Directive 2014/53/EU, the packaging shows that this radio equipment will be subject to some「estrictionswhen placed on the market in Belgium (BE), Bulgaria (BG), the Czech Republic (CZ),Denma「k (DK), Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain(ES), France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV), Lithuania(LT), Luxembourg (LU), Hungary (HU), Malta (MT), Netherlands (NL), Austria(AT), Poland (PL), Portugal (PT), Romania (RO), Slovenia (SI), Slovakia (SK),Finland (Fl), Sweden (SE), the United Kingdom (UK), Turkey (TR), Norway(NO), Switzerland (CH), Iceland (IS), and Liechtenstein (LI). The WLAN function for this device is restricted to indoor use only when operating in the 5150 to 5250 MHz frequency range l 81 FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions· (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This Product meets the government's requirements for ex posu「e to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through pe廿odic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. F CC RF Exposure Info「mation and Statement the SAR limit of USA (FCC) is1 .6 W/kg averaged over one g「am of this Device GQ3286(FCC ID: 2AT9T-3286) has been tested against this SAR limit. SAR information on this can be viewed on-line at http://www.fcc.gov/oet/ea/fc­ cid/. Please use the device FCC ID number for search. This device was tested for typical operations 0mm from the body. To maintain compliance with FCC RF exposu飞 「equi「ements, 0mm separation distance should. maintained to the user's bodies l gl

Shenzhen Ulefone Technology Co., Ltd. Family models difference declaration Tablet Model: GQ3286, Tab A8, Tab A8 Pro, Tab A8 Lite, Tab A8P, Tab A8E, Tab A8S Difference declaration: All the model are the same circuit and RF module,except the model names. Regards, Signature Chen Hongchi/ Manager Date/City: 2022-12-26 / Shenzhen Phone: 86-0755-83892089 Fax: 86755-83584541 E-mail: [email protected]

Shenzhen Ulefone Technology Co., Ltd. Agent Authorization Letter (2022-12-26) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District, Shenzhen, Guangdong, China Alex.li [email protected] to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Chen Hongchi/ Manager Date/City: 2022-12-26 / Shenzhen Phone: 86-0755-83892089 Fax: 86755-83584541 E-mail: [email protected]

Shenzhen Ulefone Technology Co., Ltd. Long Term Confidentiality Request Letter (2022-12-26) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product: Tablet Model: GQ3286, Tab A8, Tab A8 Pro, Tab A8 Lite, Tab A8P, Tab A8E, Tab A8S FCC ID: 2AT9T-3286 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Schematic Diagram Block Diagram Part List / BOM List / PCB Layout Operational Description Tune-up Procedure FCC Software Security Requirements for UNII devices Required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Please contact me if there is any information you may need. Sincerely, Chen Hongchi/ Manager Date/City: 2022-12-26 / Shenzhen Phone: 86-0755-83892089 Fax: 86755-83584541 E-mail:[email protected]

Shenzhen Ulefone Technology Co., Ltd. Short Term Confidentiality Request Letter (2022-12-26) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For Product: Tablet Model: GQ3286, Tab A8, Tab A8 Pro, Tab A8 Lite, Tab A8P, Tab A8E, Tab A8S FCC ID: 2AT9T-3286 To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, < Shenzhen Ulefone Technology Co., Ltd. >. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which < Shenzhen Ulefone Technology Co., Ltd. > considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, < Shenzhen Ulefone Technology Co., Ltd. > feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Chen Hongchi/ Manager Date/City: 2022-12-26 / Shenzhen Phone: 86-0755-83892089 Fax: 86755-83584541 E-mail: [email protected]

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

Tablet Model Name: GQ3286 FCC ID: 2AT9T-3286 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label & Location

Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18 Photo 19 Photo 20 Photo 21 Photo 22 Photo 23 Photo 24 4G AUX ANT 2/3/4G Main ANT BT/WIFI ANT

Report No.: STR221108003007E Version.1.2 Page 1 of 19 FCC Test Report FCC ID: 2AT9T-3286 Product: Tablet Trade Mark: ulefone Model No.: GQ3286 Family Model: Tab A8, Tab A8 Pro, Tab A8 Lite, Tab A8P, Tab A8E, Tab A8S Report No.: STR221108003007E Issue Date: Dec 14, 2022 Prepared for Shenzhen Ulefone Technology Co., Ltd. 7A01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website:http://www.ntek.org.cn Report No.: STR221108003007E Version.1.2 Page 2 of 19 TEST RESULT CERTIFICATION Applicant’s name.................. : Shenzhen Ulefone Technology Co., Ltd. Address .................................. : 7A01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Manufacturer's Name ........... : Shenzhen Ulefone Technology Co., Ltd. Address .................................. : 7A01, Building A, Block 1, Anhongji Tianyao Plaza, Longhua District, Shenzhen City, Guangdong Province China Product description Product name ......................... : Tablet Trade Mark ............................. : ulefone Model and/or type reference : GQ3286 Family Model : Tab A8, Tab A8 Pro, Tab A8 Lite, Tab A8P, Tab A8E, Tab A8S Standards .............................. : FCC Part 15B ANSI C63.4:2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Test Sample Number................: T221108002R003 Date of Test ........................................... : Date (s) of performance of tests ............. : Nov 08, 2022 ~ Dec 14, 2022 Date of Issue .......................................... : Dec 14, 2022 Test Result .............................................. : Pass Testing Engineer : (Mukzi Lee) Authorized Signatory : (Alex Li) Report No.: STR221108003007E Version.1.2 Page 3 of 19 Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 TEST RESULTS 17 3.2.5 TEST RESULTS(1000~10000MHz) 19 Report No.: STR221108003007E Version.1.2 Page 4 of 19 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC Part15B ANSI C63.4: 2014 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Report No.: STR221108003007E Version.1.2 Page 5 of 19 1.1 TEST FACILITY Shenzhen NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. IC-Registration The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited Test Firm Registration Number: 463705. Designation Number: CN1184 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKC01 ANSI 150 KHz ~ 30MHz ±2.80dB B. Radiated Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKA01 ANSI 30MHz~1000MHz ±2.64dB 1GHz~6GHz ±2.40dB 6GHz~26.5GHz ±2.52dB Report No.: STR221108003007E Version.1.2 Page 6 of 19 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet Trade Mark ulefone Model Name GQ3286 Family Model Tab A8, Tab A8 Pro, Tab A8 Lite, Tab A8P, Tab A8E, Tab A8S Model Difference All the model are the same circuit and RF module,except the model names. Product Description Connecting I/O port: Micro USB, Earphone Operation Frequency: 5.8GHz Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Adapter Model: HJ-0502000W2-US Input: 100-240V~50/60Hz 0.3A Output: 5V2000mA Battery DC 3.8V, 6580mAh, 25Wh Power supply DC 3.8V from battery or DC 5V from adapter HW Version WT_F31-Y_6762_BJJ_MB_V3.0_20220823 SW Version Tab_A8_SH1_EEA_V01 Report No.: STR221108003007E Version.1.2 Page 7 of 19 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Model 1 USB Data Transmission Model 2 TF card Playing Model 3 REC Model 4 FM Model 5 GPS For Conducted Test Final Test Mode Description Model 1 USB Data Transmission Model 2 TF card Playing Model 3 REC Model 4 FM Model 5 GPS For Radiated Test Final Test Mode Description Model …

Text truncated - open the document above for the full version.

Radiated Measurement Photos AC Conducted Measurement Photos
