2ATEV-BL3385-PWIFI+BT module

World’s leading smart home solution provider Features  Support IEEE802.11 b/g/n standards  Support WEP, WPA and WPA2 encryption  Support UART/PWM/ADC/GPIO/I2C interfaces  Support STA/AP/AP+STA modes  Support SmartConfig  Support TLS/SSL protocols  Support PCB antenna  3.3V power supply  Wi-Fi related features  Support 802.11 b/g/n with 20M  Support station and soft AP  Support Smart Config and AP configuration  Integrated balun/PA/LNA  TCP/IP stack optimized for IoT application  PCB antenna  Peripheral  2x UART  1x I2C  1x SPI  4x PWM  Up to 14GPIOs  Working temperature: -10°C to +85°C  Stamp style SMD for surface mounting production Applications  Smart transportation  Smart home / appliances  Instruments  Health care  Industrial automation  Intelligent security  Smart energy Models Model Antenna type Note BL3385-P PCB antenna Default Version：1.0 Release date： June，16, 20,21 BL3385-P Embedded Pro d u c t - 2 - Content 1. Overview ............................................................................................................................ - 3 - 2. Basic Specifications ............................................................................................................ - 3 - 2.1. Power Consumption ................................................................................................... - 3 - 2.2. Working Environment ................................................................................................ - 4 - 3. Radio Specifications ........................................................................................................... - 4 - 3.1. Basic Radio Specification ............................................................................................ - 4 - 3.2. Radio Performance ..................................................................................................... - 5 - 3.2.1. IEEE 802.11b ........................................................................................................ - 5 - 3.2.2. IEEE 802.11g ........................................................................................................ - 5 - 3.2.3 IEEE802.11n .......................................................................................................... - 6 - 4. BL3385-P Hardware Information ....................................................................................... - 7 - 4.1. Footprint Sequence .................................................................................................... - 7 - 4.2. Footprint Definitions .................................................................................................. - 8 - 4.3. PCB Antenna ............................................................................................................... - 9 - 5. Reference Design ............................................................................................................. - 10 - 5.1. UART Interface Design .............................................................................................. - 10 - 5.2. Power Supply Requirement ...................................................................................... - 12 - Revision History ................................................................................................................... - 13 - Copyrights ............................................................................................................................ - 13 - Contact Us ........................................................................................................................... - 13 - - 3 - 1. Overview BL3385-P is a cost-effective embedded Wi-Fi module designed by BroadLink, which supports 802.11 b/g/n standards and UART communication with other devices. The module integrates radio transceiver, MAC, baseband, all Wi-Fi protocols, configurations and network stack. It can be widely used in applications like smart home devices, remote monitoring devices and medical care instruments. The module integrates an ARM Cortex-M4 processor speed up to 160MHz with 352KB SRAM and 1MB flash. 2. Basic Specifications 2.1. Power Consumption Please refer to Table 1 for power consumption data. Table 1 BL3385-P Power Consumption Data Specifications Min. Typ. Max. Units VDD 1 3.3 3.3 3.6 V VIL(input low voltage) 0 0.8 V VIH(input high voltage) 2.0 3.6 V VOL(output low voltage) 0.4 V VOH(output high voltage) 2.4 3.6 V Io 10 mA Standby (SP mini) 80 85 mA pulse current @TX 11b @13.83dBm 11Mbps 305 mA pulse current @TX 11g @12.45dBm 54Mbps 250 mA pulse current @TX 11n @12.65dBm 65Mbps 225 mA Networking 305 mA Note: Make sure VDD is not lower than 3.3V - 4 - 2.2. Working Environment Please refer to Table 2 for working environment data. Table 2 BL3385-P Working Environment Data Symbol Description Min. Max. Units Ts Storage temperature -40 125 °C TA Ambient operating temperature -10 85 °C Vdd Supply voltage 3.3 4 V Vio Voltage on IO pin 0 VDD V ESD HBM 1000 2000 V 3. Radio Specifications 3.1. Basic Radio Specification Please refer to Table 3 for radio specification. Table 3 BL3385-P Radio Specification Radio range 2.412 GHz - 2.462 GHz Wireless standards IEEE 802.11 b/g/n Radio output 802.11b:13.83dBm 802.11g:12.45dBm 802.11n:12.65dBm BLE:4.81dBm Antenna type Internal: PCB antenna External: Not supported Receiving sensitivity 802.11b<-89dBm@11Mbps 802.11g<-76dBm@54Mbps 802.11n<-73dBm@MCS7 Stack IPv4, TCP/UDP/FTP/HTTP/HTTPS/TLS/mDNS Data rate (max) [email protected], [email protected], [email protected] Security Encryption standard: Open/WEP-Open/WPA/WPA2 Encryption algorithm: WEP64/WEP128/TKIP/AES Network types STA/AP/STA+AP/WIFI Direct - 5 - 3.2. Radio Performance 3.2.1. IEEE 802.11b Table 4 Basic specifications under IEEE802.11b ITEM Specification Modulation Type DSSS Frequency range 2412MHz~2462MHz Channel CH1 to CH11 Data rate 1, 2, 5.5, 11Mbps Table 5 Transmitting performance under IEEE802.11b TX Characteristics Min. Typical Max. Unit Power@11Mbp…

Text truncated - open the document above for the full version.

Hangzhou Broadlink Technology Co , Ltd TO: Fede「al Communication Commission Equipment Authorization Branch 7 435 Oakland Mills Road Columbia, MID 21046 Regarding: 2ATEV-BL3385-P To whom it may concern Date: 7/23/2021 We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own We, the unde「signed,he「eby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) Where our agent signs the application for cert巾cationon our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Hangzhou Broad Link Technology Co., Ltd. This authorization is valid until further written notice from the applicant Name (Printed): meng」iao.yan Title:PM Signature· 曰尸（ 如 On behalf of Company: Hangzhou Broadlink Technology Co.,Ltd Telephone: 18058715209

Hangzhou Broadlink Technology Co , Ltd 2021/7/23 To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States Dear Sir/Madam, Re: Request for FCC module certification FCC ID: 2ATEV-BL3385-P We hereby request a Modular certification for the FCC ID referenced above. The device meets the requirements below. •The module has metal case covering top and sides as its own RF shielding. The shielding at bottom is implemented by the GND copper plane in PCB substrate. Answer: Yes. Please see External Photo.pdf •The module has buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal; Answer: Yes. ARM Cortex-M4F processor speed up to 125MHz,256KB SRAM and 2MB flash as an embedded processor to buffer the data,It's controlled by the chip RTL8720CF •The module has power supply regulation on the module; Answer: Yes. The power supply of this module can be in the range 3.3V to 3.6V. •The module has demonstrated compliance in a stand-alone configuration; Answer ：Yes. please see test report •The module has a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); Answer: Yes. It contains a PCB Antenna. please see test report & Internal Photos. •The module will be labeled with its permanently affixed FCC ID label. Answer: Yes. The label position of module is clearly indicated. Please see the Label & Location.pdf •The module does comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee; Answer: The module is compliant with all applicable FCC rules. Detail instructions are given in the User Manual •The module does comply with RF exposure requirements. Answer: Yes. The modular comply with applicable RF exposure requirements. Please see MPE Report. Sincerely, Name: mengjiao.yan Title: PM Company: Hangzhou Broadlink Technology Co.,Ltd Telephone: 18058715209 曰尸（ 如 Luxshare Electronic Technology (KunShan) Ltd. FCC Modular definitions, From FCC KDB 996369 D01 Module Equip Auth Guide v02 A. Single-modular transmitter is a self-contained, physically delineated, component for which compliance can be demonstrated independent of the host operating conditions, and which complies with all eight requirements of Section 15.212(a)(1) as summarized below. See Section 15.212 for more detailed information, and Section 2.901 (and sub- sections that follow) for general certification requirements. B. Limited single-modular transmitter is a transmitter that does not meet all eight requirements listed in Section 15.212(a) (1), and compliance can be demonstrated only for specific host and applicable operating conditions in which the transmitter will be used. For example, manufacturers have flexibility with respect to requirements such as module shielding, buffered modulation/data inputs and power supply regulation. If one or more of these functions (shielding, buffered modulation/data inputs and power supply regulation) are provided by a specific host or hosts, then the module can be granted as a limited module that is limited to that specific host or hosts. The responsible party must demonstrate how it will retain control over the final installation of the device, such that compliance of the product is ensured by limiting the installation to a specific host or hosts, for example.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 2 Photos Applicant: Hangzhou BroadLink Technology Co.,Ltd Address of Applicant: Unit C,Building 1,No.57 Jiang'er Road, Changhe Street,Binjiang District,Hangzhou,Zhejiang,China Equipment Under Test (EUT): Product Name: WIFI+BT module Model No.: BL-3385-P SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 2 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 3 Photos Applicant: Hangzhou BroadLink Technology Co.,Ltd Address of Applicant: Unit C,Building 1,No.57 Jiang'er Road, Changhe Street,Binjiang District,Hangzhou,Zhejiang,China Equipment Under Test (EUT): Product Name: WIFI+BT module Model No.: BL-3385-P SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 3 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 3 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729303 Page: 1 of 8 Parlam Zhan Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. 1 Cover Page RF Exposure Evaluation Report Application No.: SHEM2107007293CR FCC ID: 2ATEV-BL3385-P IC: 25062-BL3385P Applicant: Hangzhou BroadLink Technology Co.,Ltd Address of Applicant: Unit C,Building 1,No.57 Jiang'er Road, Changhe Street,Binjiang District,Hangzhou,Zhejiang,China Manufacturer: Hangzhou BroadLink Technology Co.,Ltd Address of Manufacturer: Unit C,Building 1,No.57 Jiang'er Road, Changhe Street,Binjiang District,Hangzhou,Zhejiang,China Factory: Hangzhou Gubei Intelligent Manufacturing Co.,Ltd Address of Factory: D218,Building 2,Hangzhou Xiaoshan(China) Hardware Machinery Technology Innovation Park,Liansan Village,Yiqiao Town,Xiaoshan District,Hangzhou,310052 Equipment Under Test (EUT): EUT Name: WIFI+BT module Model No.: BL3385-P Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Date of Receipt: 2021-07-05 Date of Test: 2021-07-09 to 2021-07-27 Date of Issue: 2021-08-05 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729303 Page: 2 of 8 Revision Record Version Description Date Remark 00 Original 2021-08-05 / Authorized for issue by: Bill Wu / Project Engineer Parlam Zhan /Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729303 Page: 3 of 8 2 Contents Page 1 COVER PAGE ................................................................................................................................................. 1 2 CONTENTS ..................................................................................................................................................... 3 3 GENERAL INFORMATION........................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ......................................................................................................... 4 3.2 TECHNICAL SPECIFICATIONS ................................................................................................................... 4 3.3 TEST LOCATION ....................................................................................................................................... 5 3.4 TEST FACILITY .......................................................................................................................................... 5 4 TEST STANDARDS AND LIMITS ............................................................................................................... 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ......................................................................... 6 4.2 IC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ............................................................................. 6 5 MEASUREMENT AND CALCULATION .................................................................................................... 7 5.1 MAXIMUM TRANSMIT POWER ................................................................................................................... 7 5.2 MPE CALCULATION ................................................................................................................................. 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729303 Page: 4 of 8 3 General Information 3.1 General Description of E.U.T. Power supply: DC 3.3V 3.2 Technical Specifications BLE Antenna Gain: 2dBi (Provided by manufacturer) Antenna Type: PCB Antenna Bluetooth Version: V4.0 LE Channel Spacing: 2MHz Data Rate: 1Mbps Modulation Type: GFSK Number of Channels: 40 Operation Frequency: 2402MHz to 2480MHz S/N: c8f742fee236 Firmware version: V1.0 2.4G WiFi Antenna Gain: 2dBi (Provided by manufacturer) Antenna Type: PCB Antenna Channel Spacing: 5MHz Data Rate: 802.11b: 1/2/5.5/11Mbps, 802.11g: 6/9/12/18/24/36/48/54Mbps 802.11n: MCS 0 to 7 for HT20MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz S/N: c8f742fee236 Firmware version: V1.0 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729303 Page: 5 of 8 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch 588 West Jindu Road, Xinqiao, Songjiang, 201612 Shanghai, China Tel: +86 21 6191 5666 Fax: +86 21 6191 5678 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L0599) CNAS has accredited SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for th e competence in the field of testing. • A2LA (Certificate No. 6332.01) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. is accredited by the American Association for Laboratory Accreditation(A2LA). • FCC (Designation Number: CN1301) SGS-CSTC…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 1.6dB Bandwidth Test Mode Test Channel Ant EBW[MHz] Limit Verdict 11B 2412 Ant1 9.10 0.5 PASS 11B 2437 Ant1 9.10 0.5 PASS 11B 2462 Ant1 9.09 0.5 PASS 11G 2412 Ant1 16.55 0.5 PASS 11G 2437 Ant1 16.54 0.5 PASS 11G 2462 Ant1 16.55 0.5 PASS 11N20SISO 2412 Ant1 17.75 0.5 PASS 11N20SISO 2437 Ant1 17.77 0.5 PASS 11N20SISO 2462 Ant1 17.76 0.5 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 6dB Bandwidth_11B_2412_Ant1 6dB Bandwidth_11B_2437_Ant1 6dB Bandwidth_11B_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 6dB Bandwidth_11G_2412_Ant1 6dB Bandwidth_11G_2437_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 6dB Bandwidth_11G_2462_Ant1 6dB Bandwidth_11N20SISO_2412_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 6dB Bandwidth_11N20SISO_2437_Ant1 6dB Bandwidth_11N20SISO_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 2.Occupied Bandwidth Test Mode Test Channel Ant OBW[MHz] Limit[MHz] Verdict 11B 2412 Ant1 14.15 --- PASS 11B 2437 Ant1 14.14 --- PASS 11B 2462 Ant1 14.13 --- PASS 11G 2412 Ant1 16.91 --- PASS 11G 2437 Ant1 16.89 --- PASS 11G 2462 Ant1 16.88 --- PASS 11N20SISO 2412 Ant1 18.01 --- PASS 11N20SISO 2437 Ant1 17.99 --- PASS 11N20SISO 2462 Ant1 17.98 --- PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Occupied Bandwidth_11B_2412 Occupied Bandwidth_11B_2437 Occupied Bandwidth_11B_2462 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Occupied Bandwidth_11G_2412 Occupied Bandwidth_11G_2437 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Occupied Bandwidth_11G_2462 Occupied Bandwidth_11N20SISO_2412 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Occupied Bandwidth_11N20SISO_2437 Occupied Bandwidth_11N20SISO_2462 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 3.Maximum conducted (average) output power Test Mode Test Channel Ant Level [dBm] 10log(1/x) Factor[dB] Power [dBm] Limit [dBm] Verdict 11B 2412 Ant1 13.09 0.00 13.09 30 PASS 11B 2437 Ant1 13.62 0.00 13.62 30 PASS 11B 2462 Ant1 13.83 0.00 13.83 30 PASS 11G 2412 Ant1 11.62 0.00 11.62 30 PASS 11G 2437 Ant1 12.23 0.00 12.23 30 PASS 11G 2462 Ant1 12.45 0.00 12.45 30 PASS 11N20SISO 2412 Ant1 11.82 0.00 11.82 30 PASS 11N20SISO 2437 Ant1 12.41 0.00 12.41 30 PASS 11N20SISO 2462 Ant1 12.65 0.00 12.65 30 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum conducted (average) output power_11B_2412_Ant1 Maximum conducted (average) output power_11B_2437_Ant1 Maximum conducted (average) output power_11B_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum conducted (average) output power_11G_2412_Ant1 Maximum conducted (average) output power_11G_2437_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum conducted (average) output power_11G_2462_Ant1 Maximum conducted (average) output power_11N20SISO_2412_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum conducted (average) output power_11N20SISO_2437_Ant1 Maximum conducted (average) output power_11N20SISO_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 4.Maximum(average) power spectral density Test Mode Test Channel Ant Level [dBm/3kHz] 10log(1/x) Factor[dB] PSD[dBm/3kHz] Limit[dBm/3kHz] Verdict 11B 2412 Ant1 -19.26 0.00 -19.26 8.00 PASS 11B 2437 Ant1 -18.68 0.00 -18.68 8.00 PASS 11B 2462 Ant1 -18.46 0.00 -18.46 8.00 PASS 11G 2412 Ant1 -22.87 0.00 -22.87 8.00 PASS 11G 2437 Ant1 -22.28 0.00 -22.28 8.00 PASS 11G 2462 Ant1 -22.01 0.00 -22.01 8.00 PASS 11N20SISO 2412 Ant1 -23.08 0.00 -23.08 8.00 PASS 11N20SISO 2437 Ant1 -22.56 0.00 -22.56 8.00 PASS 11N20SISO 2462 Ant1 -22.24 0.00 -22.24 8.00 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum(average) power spectral density_11B_2412_Ant1 Maximum(average) power spectral density_11B_2437_Ant1 Maximum(average) power spectral density_11B_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum(average) power spectral density_11G_2412_Ant1 Maximum(average) power spectral density_11G_2437_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum(average) power spectral density_11G_2462_Ant1 Maximum(average) power spectral density_11N20SISO_2412_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 Maximum(average) power spectral density_11N20SISO_2437_Ant1 Maximum(average) power spectral density_11N20SISO_2462_Ant1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix B for SHEM210700729302 5.Band-edge for RF Conducted Emissions Test Mode Test Channel Ant Carrier Power[dBm] Max. Spurious Level [dBm] Limit [dBm] Verdict 11B 2412 Ant1 3.68 -46.03 -26.32 PASS 11B 2462 Ant1 4.53 -54.51 -25.47 PASS 11G 2412 Ant1 -2.59 -33.39 -32.59 PASS 11G 2462 Ant1 -1.58 -53.38 -31.58 PASS 11N20SISO 2412 Ant1 -1.92 -33.26 -31.92 PASS 11N20SISO 2462 Ant1 -1.01 -51.97 -31.01 PASS SGS-CSTC Standards Technical Services (S…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729302 Page: 1 of 57 Parlam Zhan Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. TEST REPORT Application No.: SHEM2107007293CR FCC ID: 2ATEV-BL3385-P IC: 25062-BL3385P Applicant: Hangzhou BroadLink Technology Co.,Ltd Address of Applicant: Unit C,Building 1,No.57 Jiang'er Road, Changhe Street,Binjiang District,Hangzhou,Zhejiang,China Manufacturer: Hangzhou BroadLink Technology Co.,Ltd Address of Manufacturer: Unit C,Building 1,No.57 Jiang'er Road, Changhe Street,Binjiang District,Hangzhou,Zhejiang,China Factory: Hangzhou Gubei Intelligent Manufacturing Co.,Ltd Address of Factory: D218,Building 2,Hangzhou Xiaoshan(China) Hardware Machinery Technology Innovation Park,Liansan Village,Yiqiao Town,Xiaoshan District,Hangzhou,310052 Equipment Under Test (EUT): EUT Name: WIFI+BT module Model No.: BL3385-P Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2, February 2017 RSS-Gen Issue 5 Amendment 2 (February 2021) Date of Receipt: 2021-07-05 Date of Test: 2021-07-09 to 2021-07-27 Date of Issue: 2021-08-05 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729302 Page: 2 of 57 Revision Record Version Description Date Remark 00 Original 2021-08-05 / Authorized for issue by: Bill Wu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729302 Page: 3 of 57 2 Test Summary Radio Spectrum Technical Requirement Item FCC Requirement IC Requirement Method Result Antenna Requirement 47 CFR Part 15, Subpart C 15.203 & 15.247(c) RSS-Gen Clause 6.8 N/A Customer Declaration N/A: Not applicable Radio Spectrum Matter Part Item FCC Requirement IC Requirement Method Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.207 RSS-Gen Clause 8.8 ANSI C63.10 (2013) Section 6.2 N/A Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247a(2) RSS-247 Clause 5.2(a) ANSI C63.10 (2013) Section 11.8.1 Pass Conducted Average Output Power 47 CFR Part 15, Subpart C 15.247(b)(3) RSS-247 Clause 5.4(d) ANSI C63.10 (2013) Section 11.9.2 Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247(e) RSS-247 Clause 5.2(b) ANSI C63.10 (2013) Section 11.10.3 Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247(d) RSS-247 Clause 5.5 ANSI C63.10 (2013) Section 11.13.3.2 Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247(d) RSS-247 Clause 5.5 ANSI C63.10 (2013) Section 11.11 Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.209 & 15.247(d) RSS-247 Section 3.3 & RSS-Gen Section 8.9 ANSI C63.10 (2013) Section 6.10.5 Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.209 & 15.247(d) RSS-247 Section 3.3 & RSS-Gen Section 8.9 ANSI C63.10 (2013) Section 6.4,6.5,6.6 Pass 99% Bandwidth - RSS-Gen Section 6.7 ANSI C63.10 Section 6.9.3 Pass SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729302 Page: 4 of 57 3 Contents Page 1 COVER PAGE.............................................................................................................................................. 1 2 TEST SUMMARY ......................................................................................................................................... 3 3 CONTENTS .................................................................................................................................................. 4 4 GENERAL INFORMATION ......................................................................................................................... 5 4.1 DETAILS OF E.U.T.................................................................................................................................. 5 4.2 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 5 4.3 POWER LEVEL SETTING USING IN TEST: ................................................................................................... 5 4.4 MEASUREMENT UNCERTAINTY ................................................................................................................ 6 4.5 TEST LOCATION ..................................................................................................................................... 7 4.6 TEST FACILITY ....................................................................................................................................... 7 4.7 DEVIATION FROM STANDARDS ................................................................................................................ 7 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 7 5 EQUIPMENT LIST ....................................................................................................................................... 8 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ................................................................................... 9 6.1 ANTENNA REQUIREMENT ........................................................................................................................ 9 7 RADIO SPECTRUM MATTER TEST RESULTS .............................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210700729301 Page: 1 of 55 Parlam Zhan Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufact…

Text truncated - open the document above for the full version.
