2ATOT90011LEXI Smart Art and Ambiance Light

User Manual LEXI - Art and Ambiance Light 20016 Camino (9"x12.5") WELCOME TO LEXIUSER GUIDEOPERATION1. In order to add new devices to your Lexi Mobile App, first follow the instructions for connecting your Lexi Portable Hub to your wireless network. 2. Power on your light(s), you'll see the light(s) flashing with cool white color 3. Select "ADD NEW DEVICE" on the LEXI Mobile App and follow the instruction to complete adding the light(s). During this process you'll see the light transition to warm white then Blue color flashing as it goes through the association process until it stops flashing and remains on blue color. 4. Your light has been added to the LEXI Mobile App successfully and ready to use.5. Remember to pair the Ambiance Light one by one to the LEXI Mobile App so that they can be individually controlled afterwards. 6. To learn more about detail function and special effect, Please go to www.lexidevices.com CHARGING THE AMBIANCE LIGHT1. Turn on the switch under the Ambiance light (You may see the light is flashing with white color, this is the normal state when the light has not been paired).2. Connect the DC 5V 1A adapter (provided). Plug-in the 5.5mm connector to the socket at the bottom of Ambiance light. The LED indicator light on the bottom will turn red while its charging.3. Charging will take approximately 6-8hours, once charged, indicator LED will turn green.4. Battery will charge regardless of whether the Ambiance light is in the on or off position. WARNINGS AND CAUTIONS:- Only use the adapter supplied: using a different adapter can damage the product.- Keep away from liquids and humidity. - The product is for indoor use only. Do not use in wet locations, directly exposed to water or outdoors. - This product is not a toy designed to be played with by children. - Do not place on hot surfaces. - Do not be exposed to extreme temperatures, direct sunlight and moisture.- For safety reasons and under the terms of the warranty, none of the enclosed devices should be opened. WARRANTY: LEXI provided one-year warranty is valid if the product is used in accordance with the instructions and for its intended purpose. Claims will only be accepted on submission of the original proof of purchase (invoice, sales slip or receipt) stating the purchase date, the name of the dealer and a description of the product with product ID labeled at the products.The LEXI’s warranty lapses if: a. Anything has been changed, crossed out, deleted or rendered illegible on the purchase docket or product description. b. The failure is caused by damage, faulty connections or abuse. c. A defect is caused by extreme circumstances not inherent to the product, for example, lighting, flooding, fire, incorrect use or negligence. d. The product has been opened or disassembled.e. using a different adapter other than we provided TROUBLESHOOTING- Ensure your device is within 45 feet of the Lexi Portable Hub without obstacles - Make sure the light is charged or has a good connection to the DC Adaptor (provided).- Confirm your smart phone is paired with LEXI Portable Hub- To un-pair the lights turn the light on/off 6 times in quick succession using the LEXI Mobile App. Afterwards, you'll see a cool white flashing. ( A warm white will be flashing at the 5th power cycle which is a warning signal for you. If you don't want to un-pair it, stop the power cycle. The light will go back to the last st ate). Then, re-pair this light in the User Guide section. WIRELESS SPECIFICATION: BLE Frequency: 2402-2480MHzWireless communication protocol: IEEE 802.15.4Channel: 0 -39 channelsRadio frequency: 915MHz center frequencyBandwidth: 1.19MHzModulation: 2-GFSKENVIRONMENTAL SPECIFICATION: Temperature (operation): -5...40°C Temperature (storage): -25...60°C Relative humidity: 5-90% non-condensing CLEANING AND MAINTENANCE: Do not clean when the product is on and connected to mains power. To avoid scratching, the product should only be cleaned with a soft dry cloth. Do not use cleaning agents.PLEASE KEEP THIS PACKAGING FOR FUTURE REFERENCE AS IT CONTAINS IMPORTANT INFORMATION. DISPOSAL OF YOUR OLD PRODUCT:Your product is designed and manufactured with high quality materials and component, contains non-removable Lithium-Ion battery, which can be recycled and reused. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. Please find out for yourself about the local separate collection system for electrical and electronic products. Please act according to your local rules and do not dispose of your old products with your normal household wa ste. The correct disposal of your old product will help prevent potential negative consequences for the environment and human health. FCC WARNING AND CAUTION:- This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and FCC WARNING AND CAUTION:(2) this device must accept any interference received, including interference that may cause undesired operation.- Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to op erate the equipment. - This device meets the FCC and IC requirements for RF exposure in public or controlled environments . The end user is advised to maintain a distance 20 cm from the timer and any personnel to ensure compliance with RF exposure regulations.FCC ID : 2ATOT90011 - Shielded Cables must be used with this unit to ensure complaince with the Class B FCC limits NOTE: This equipment ha s been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordan…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE Report No.:19020252HKG-003 19020252HKG-004 FCC ID: 2ATOT90011 Equipment Photographs (External)

INTERTEK TESTING SERVICE Report No.: 19020252HKG-003/4 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 19020252HKG-003/4 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 19020252HKG-003/4 Equipment Photographs (Internal)

Technical Description The Equipment Under Test (EUT) is a Bluetooth device with 915MHz. The EUT can operate with mobile app and 915MHz remote. The Bluetooth portion occupies frequency range of 2402MHz to 2480MHz (39 channels with channel spacing of 2MHz). The 915MHz portion occupies frequency 915MHz single channel. For 2.4GHz BLE: Antenna Type: Internal integral antenna Antenna Gain: 0dBi Maximum rated field strength: 99.6d BμV / m at 3m For 915MHz 2‐GFSK: Antenna Type: Internal integral antenna Antenna Gain: 0dBi Maximum conducted output power:10.4dBm U1 CSR1010 act as the Bluetooth module of this unit. X1 (16MHz) and X2 (32.768kHz) act as the crystal of the U1 U5 is the 915MHz module of this unit.

INTERTEK TESTING SERVICE FCC ID: 2ATOT90011 For Maximum Permissible Exposure (MPE) evaluation of the unit, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. 1) For the Bluetooth portion of the unit, the measured powers among all the measured channels were within its production tolerance. The antenna gain is 2 dBi = 1.58 (num gain) and its maximum source-based time-averaging duty factor is 100%. From these data and its operating configuration, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: EUT(FCC ID: 2ATOT90011) BLE: The EIRP radiated power = 4.4 dBm = 2.51 mW The radiated (EIRP) source-based time-averaging output power = (2.75 * 1) mW = 2.75 mW The power density at 20cm = 2.75 / 4R 2 = 0.00055 mW cm -2 EUT(FCC ID: 2ATOT90011) 915MHz: The EIRP radiated power= maximum conducted output power(10.96dBm)+antenna gain(0dBi) = 10.96dBm = 12.47 mW The radiated (EIRP) source-based time-averaging output power = (12.47 * 1) mW = 12.47 mW The power density at 20cm = 12.47 / 4R 2 = 0.0025 mW cm -2 “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the Internet Music System at least 20cm from nearby persons.” INTERTEK TESTING SERVICE FCC ID: 2ATOT90011 In addition, for this product with multiple transmitter and antenna Bluetooth (BLE) and 915MHz transmittert he requirement of Simultaneous Transmission evaluation has also been considered and has complied with the following conditions of the worst case; MPE1/Limit1 + MPE2/Limit2  1 Thus, 0.00055 + 0.0025= 0.0031 It is concluded that no Simultaneous Transmission evaluation is required.

<Drawn By> <Checked By> <QC By> <Released By> <Drawn Date> <Checked Date> <QC Date> <Release Date> <Company Name> <Title> <Code> B <Drawing Number> <Revision> <Scale> 1 1 REV: SIZE: CODE: DRAWN: DATED: DATED: CHECKED: QUALITY CONTROL: DATED: DATED: RELEASED: COMPANY: TITLE: DRAWING NO: SHEET: OF SCALE: REVISION RECORD APPROVED: ECO NO: A B D DATE: 1 2 3 4 5 6 D C A B C LTR 1 AIO[2] 2 AIO[1] 3 AIO[0] 4 PIO[0]/UART_TX 5 PIO[1]/UART_RX 6 PIO[3]/SF_DIN 7 GND1 8 PIO[4]/SF_CS# 9 PO[5]/CLK 10 PIO[6]/CS# 11 PIO[7]/MOSI 12 PIO[8]/MISO 13 PIO[9] 14 PIO[10] 15 GND2 16 PIO[11] 17 SPI_PIO# 18 PIO[2] 19 I2C_SCL 20 I2C_SDA 21 WAKE 22 GND3 23 GND4 24 RF 25 GND5 26 GND6 27 VDD U1 CSR1010_MODULE U2 Q3 Q1 Q2 Q4 Q5 1 GND 2 VDDS 3 DIO_0 4 DIO_1 5 DIO_2 6 DIO_3 7 DIO_4 8 JTAG_TMS 9 JTAG_TCK 10 DIO_5 11 DIO_6 12 DIO_7 13 DIO_8 14 DIO_9 15 DIO_10 16 DIO_11 17 DIO_12 18 DIO_13 19 DIO_14 20 GND 21 RF 22 GND 23 RESET U5 915MHz Module C10 C11 L1 900_JTAG C3 C9 0.75p L2 2.7n TEMP PROG GND VCC CE /CHRG /STDBY BAT DIE_PAD U3 C7 10u H2 H14 + C8 10uF VIN VOUT GND U4 ANT1 Spring Coil Antenna R25 1k R26 1k R27 1k R17 10k R15 10k R19 10k R21 NC R23 NC R11 NC R22 NC R20 NC R12 NC R2 47R R10 47R R1 120R C4 100n C5 100n R9 1k R24 1k R13 1k C6 100n R4 2k C2 100n C12 100n CSR_SPI R5 1k R6 1k R3 1k R7 1k R8 1k R14 2k D1 D2 3V3_BLE CSR_SPI_SCLK CSR_SPI_CS CSR_SPI_MOSI CSR_SPI_MISO CSR_SPI/PIO LED_G LED_R LED_B LED_B LED_G LED_R CSR_SPI_MISO CSR_SPI_MOSI LED_WWOUT LED_CWOUT LED_GOUT LED_ROUT JTAG_TDI JTAG_TDO JTAG_TCK JTAG_TMS 915_TX 915_RX 3V3_BLE 900_/RST 3V3_BLE JTAG_TMS JTAG_TCK JTAG_TDO JTAG_TDI 900_/RST 4.2V 4.2V 3V3_BLE 915_RX 915_TX CSR_SPI/PIO CSR_SPI_CS CSR_SPI_SCLK CSR_SPI_MOSI CSR_SPI_MISO LED_R LED_G LED_B LED_CW LED_WW LED_WW LED_CW LED_BOUT 1 1 2 2 3 3 4 4 5 5 AA BB CC DD DCDC_SW DCDC_SW CC1310_VDD VDDR VDDS VDDR VDDS VDDS CC1310_RESETCC1310_TCK CC1310_TMS Title: Drawn: Checked: Size:Rev:Sheet: of Date: LAUNCHXL-CC1310 1 41.3.0A4 TER, KHT KHT Thursday, January 21, 2016 Standard Title: Drawn: Checked: Size:Rev:Sheet: of Date: LAUNCHXL-CC1310 1 41.3.0A4 TER, KHT KHT Thursday, January 21, 2016 Standard Title: Drawn: Checked: Size:Rev:Sheet: of Date: LAUNCHXL-CC1310 1 41.3.0A4 TER, KHT KHT Thursday, January 21, 2016 Standard P11 MM5829-2700 12 M1M2 Y1 32.768kHz C8 22uF C7 100nF C4 100nF C9 100nF C13 6.2pF C16 100nF C11 3.6pF C5 100nF C12 2.7pF R1 100k C14 3pF L12 7.5nH 12 L22 27nH 1 2 C17 12pF R13 DNM C58 DNM R12 1.8pF C24 DNM L1 6.8uH 12 C19 1uF C20 100nF C22 3.6pF L14 6.8nH 12 C21 100pF C18 12pF FL1 BLM18HE152SN1 12 L13 6.8nH 12 L23 7.5nH 1 2 C15 100pF C3 100nF Y2 24MHz 1 24 3 C6 22uF CC1310F128RGZT U1A JTAG_TMSC 24 JTAG_TCKC 25 RESET_N 35 DCDC_SW 33 RX_TX 3 DCOUPL 23 EGP/GND 49 VDDS2 13 VDDS3 22 VDDS 44 VDDS_DCDC 34 VDDR 45 VDDR_RF 48 RF_P 1 RF_N 2 X24M_N 46 X24M_P 47 X32K_Q1 4 X32K_Q2 5 A1 DNM 1 1 1 2 2 3 3 4 4 5 5 AA BB CC DD DIO18_RTS/SWO DIO14_BTN2 DIO13_BTN1 DIO29_Analog DIO30_Analog DIO2_RXD DIO3_TXD DIO4_SCL DIO10_SCLK DIO18_RTS/SWO DIO1 DIO11_CS DIO9_MOSI DIO8_MISO DIO17_TDI DIO10_SCLK DIO9_MOSI DIO11_CS DIO2_RXD DIO3_TXD DIO23_Analog DIO24_Analog DIO25_Analog DIO26_Analog DIO27_Analog DIO28_Analog DIO29_Analog DIO7_GLED DIO6_RLED DIO15 DIO5_SDA DIO1 DIO21 DIO22 DIO8_MISO DIO12 LP_RESET DIO20_Flash_CS DIO19_CTS DIO30_Analog DIO24_Analog DIO23_Analog DIO19_CTS DIO20_Flash_CS DIO7_GLED DIO6_RLED DIO12 DIO13_BTN1 DIO14_BTN2 DIO15 DIO22 DIO21 DIO28_Analog DIO27_Analog DIO26_Analog DIO25_Analog DIO5_SDA DIO4_SCL BP_RESET DIO16_TDO CC1310_VDD CC1310_VDD CC1310_VDD CC1310_VDD +5V +5V CC1310_VDD CC1310_VDD CC1310_TXD CC1310_RESET CC1310_SWO CC1310_RXD CC1310_TMS CC1310_TCK DIO16_TDO DIO17_TDI Title: Drawn: Checked: Size:Rev:Sheet: of Date: LAUNCHXL-CC1310 2 41.3.0A3 TER KHT Thursday, January 21, 2016 Standard Title: Drawn: Checked: Size:Rev:Sheet: of Date: LAUNCHXL-CC1310 2 41.3.0A3 TER KHT Thursday, January 21, 2016 Standard Title: Drawn: Checked: Size:Rev:Sheet: of Date: LAUNCHXL-CC1310 2 41.3.0A3 TER KHT Thursday, January 21, 2016 Standard MH5 DNM R11 2.2k J1 SSQ-110-23-L-D 2 4 6 8 10 12 14 16 18 20 1 3 5 7 9 11 13 15 17 19 P1 BB02-HC031-KB1-603000 1 2 3 MH1 DNM R46 DNM FIDU1 CR1 R48 DNM P2 BB02-HC031-KB1-603000 1 2 3 R59 DNM FIDU6 M14 R60 DNM FIDU3 J2 SSQ-110-23-L-D 2 4 6 8 10 12 14 16 18 20 1 3 5 7 9 11 13 15 17 19 R14 220 MH3 DNM R52 0 M13 R15 180 1188E-1K2-V SW2 FIDU5 1188E-1K2-V SW1 R3 3.3k R2 3.3k CR2 R47 DNM FIDU4 P6 BB02-HJ041-KB1-603000 2 4 1 3 R49 DNM MH4 DNM U4 MX25R8035FZUIL0 nCS 1 SO/SIO1 2 nWP/SIO2 3 GND 4 SI/SIO0 5 SCLK 6 nRST/SIO3 7 VCC 8 EGP 9 CC1310F128RGZT U1B DIO_1 6 DIO_2 7 DIO_3 8 DIO_4 9 DIO_5 10 DIO_6 11 DIO_7 12 DIO_8 14 DIO_9 15 DIO_10 16 DIO_11 17 DIO_12 18 DIO_13 19 DIO_14 20 DIO_15 21 DIO_16 26 DIO_17 27 DIO_18 28 DIO_19 29 DIO_20 30 DIO_21 31 DIO_22 32 DIO_23 36 DIO_24 37 DIO_25 38 DIO_26 39 DIO_27 40 DIO_28 41 DIO_29 42 DIO_30 43 R51 DNM MH2 DNM R56 100 FIDU2 C30 100nF R55 100

INTERTEK TESTING SERVICE Report No:19020252HKG-003/4 FCC ID: Configuration Photographs Worst-Case Radiated Emissions (Front View) INTERTEK TESTING SERVICE Report No:19020252HKG-003/4 FCC ID: Configuration Photographs Worst-Case Radiated Emissions (Back View)

INTERTEK TESTING SERVICE Report No:19020252HKG-003/4 Configuration Photographs Worst-Case Line-Conducted Emissions (Front View) INTERTEK TESTING SERVICE Report No:19020252HKG-003/4 Configuration Photographs Worst-Case Line-Conducted Emissions (Back View)
