rd Address: 23Floor, Block B4, Building NO.9, Shenzhen Bay Eco-Technology Park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Tel: +86-755-36995888 Fax: +86-755-33104777 Web site: http://en.tvt.net.cn E-mail: [email protected] TVT DIGITAL TECHNOLOGY CO., LTD. en.tvt.net.cn For more information, please visit our website. WDR AWB Motion Detection VCA Defog IP67 H.265 PoE -30~60°° PoE BLCHLC H.265 Secure The World With You rd Address: 23Floor, Block B4, Building NO.9, Shenzhen Bay Eco-Technology Park, Nanshan District, Shenzhen, Guangdong Province, P.R.China Shenzhen TVT DIGITAL TECHNOLOGY CO., LTD. Tel: +86-755-36995888 Fax: +86-755-33104777 Web site: http://en.tvt.net.cn E-mail: [email protected] en.tvt.net.cn For more information, please visit our website CAMERA TD-9441S3 4MP Water-proof Bullet Network Camera IR 4× H.265/H.264 coding Max.resolution: MP ( 2560 1440) ICR auto switch, true day / night vision 3D DNR, digital WDR, HLC, BLC, defog ROI coding 20~30m IR night view distance Built-in micro SD card slot, up to 256GB DC12V/PoE power supply P2P function optional Support Wi-Fi IP 67 ingress protection Support three streams Support remote monitoring by smart phones& tablet PCs with iOS and Android OS Intelligent analytics: object removal detection, video exception detection, line crossing and intrusion detection Wi-Fi Wi-Fi IP FCC ID: H.264 H.265 / Main [email protected] High Tier 64 Kbps ~ 5 Mbps VBR / CBR 167.6 × 74.7 × 148.2 Approx. KG0.465 20 ~ 30 m IP67 TD-9441S3 < 5W DC12V/PoE Object removal (object left/missing detection), scene change and video blur detection, intrusion and line crossing 60Hz : 720P(1~15fps)/D1/CIF (1~30fps); 50Hz: 720P(1~12fps)/D1(1~25fps)/CIF (1~25fps); (1~30fps) 60Hz : D1/CIF/480x240 (1~30fps); 50Hz: D1/CIF/480x240 (1~25fps) Specifications Model Camera Image Size Image Sensor Electronic Shutter Iris Type Min. Illumination Lens Mount Day&Night Focus Wide Dynamic Range BLC HLC Defog Angle Adjustment Lens Digital NR Image Video Compression H.265 Compression Standard Resolution Main Stream Sub Stream Third Stream Bit Rate Bit Rate Type Image Settings ROI Interfaces Network Storage Reset Functions Remote Monitoring Online Connection Network Protocol Interface Protocol Storage Smart Alarm Smart Events PoE IR Distance Ingress Protection Others Power Supply Operating Environment Dimensions ( mm ) Weight ( net ) Installation Power Consumption 1 / 2.7 "CMOS 2560×1440 1 / 25 s ~ 1 / 100000 s Fixed Iris M12 Digital WDR Pan: 0~360; Tilt: °°0°~80°; Rotation: 0°~360° 3D DNR ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser Each ROI to be configured separately RJ45 Built-in micro SD card slot, up to 256GB Web browsing, CMS remote control Support simultaneous monitoring for up to 4 users; Support multi-stream real time transmission UDP, DHCP, PPPoE, DDNS, SMTP, FTP, 802.1x, UPnP, HTTP, HTTPs, QoS IPv4, IPv6, NTP, RTSP, RTP, RTCP, ICMP, IGMP, Network remote storage; micro SD card storage Motion detection, SD card full, SD card error Yes - 30 °C ~ 60 (-22 Humidity: less than 95 %noncondensing °C (-) °F~140°F) General Function Watermark, IP address filtering, video mask, heartbeat, password protection Yes Yes Yes Ceiling mounting; Wall mounting 0.011 lux @F1.2, AGC ON; 0 lux with IR 0.04 lux @ F2.2, AGC ON; 0 lux with IR [email protected], Horizontal FoV: °;Vertical FoV:77.6 [email protected], Horizontal FoV: 89°;Vertical FoV:58°; Diagonal FoV:97° 110°; Diagonal FoV:117° 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240 4MP ( 2560 × 1440 ), 3MP ( 2304 × 1296 ), 60Hz : 50Hz : 4MP/3MP/1080P(1~30fps); 4MP/3MP/1080P(1~25fps) ONVIF Yes Available Model TD-9441S3(D/PE/WF/AR2) TD-9441S3 4MP IR Water-proof Bullet Network Camera SPECIFICATIONS DIMENSIONS AVAILABLE ACCESSORIES AVAILABLE MODEL en.tvt.net.cn *All pictures and specifications are for reference only and are subject to change without prior notice. TD-YXH0301TD-YXH0103TD-YXH0104 TD-YXH0301+ TD-YZJ0501 TD-YXH0301+ TD-YZJ0601 TD-YXH0301+ TD-YZJ0810 Fixed ICR Wi-Fi Wireless StandardsIEEE802.11b/g/n 2.4GHz ~ 2.4835 GHz 20MHz WEP, WPA-PSK/WPA2-PSK Frequency Range Channel Bandwidth Security Wireless Range 80m Transfer Rates 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps TD-9441S3 4MP IR Water-proof Bullet Network Camera en.tvt.net.cn *All pictures and specifications are for reference only and are subject to change without prior notice. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.• Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radia…

Text truncated - open the document above for the full version.

SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Date: Oct. 26, 2020 Dear Sir/Madam, We, SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Camera Model no.: TD-9441S3, TD-94v1wxyz;TD-74v1wxyz; (v=1-8; w=A-Z;x=1-8, A-Z, or blank; y=1-8, A-Z, or blank; z=1-8, A-Z, or blank) Sincerely, Name / Title: Gong Xie/ Manager Company: SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Address: F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Phone: 0755-36995888 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 < Oct. 26, 2020 > TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: Name Camera FCC ID 2ATOW-TD For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (Signed) Name / Title: Gong Xie/ Manager Company: SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Address: F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Phone: 0755-36995888 E-Mail: [email protected]

SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Date: Oct. 26, 2020 Name Camera FCC ID 2ATOW-TD To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. declare that this EUT (FCC ID: 2ATOW-TD) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Gong Xie/ Manager Company: SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Address: F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Phone: 0755-36995888 E-Mail: [email protected]

FCC ID: 2ATOW-TD FCC ID: 2ATOW-TD

FCC ID: 2ATOW-TD

FCC ID: 2ATOW-TD FCC ID: 2ATOW-TD FCC ID: 2ATOW-TD FCC ID: 2ATOW-TD FCC ID: 2ATOW-TD

RF Exposure evaluation FCC ID: 2ATOW-TD 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. Manufacturing tolerance 802.11b(PK) Channel Channel 01 Channel 6 Channel 11 Target (dBm) 18.0 18.0 18.0 Tolerance ±(dB) 1.0 1.0 1.0 802.11g(PK) Channel Channel 01 Channel 6 Channel 11 Target (dBm) 21.0 21.0 21.0 Tolerance ±(dB) 1.0 1.0 1.0 802.11n(HT20)(PK) Channel Channel 01 Channel 6 Channel 11 Target (dBm) 21.0 21.0 21.0 Tolerance ±(dB) 1.0 1.0 1.0 802.11n(HT40)(PK) Channel Channel 03 Channel 6 Channel 9 Target (dBm) 21.0 19.0 19.0 Tolerance ±(dB) 1.0 1.0 1.0 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 3.00 dBi, the RF power density can be obtained. Modulation Type Max tune up power tolerance(dBm) Max Output power to antenna (mW) Antenna Gain (Numeric) Power Density at R=20cm (mW/cm2) Limit (mW/cm2) Result 802.11b 19.0 79.43 1.995 0.031541 1.0 Pass 802.11g 22.0 158.49 1.995 0.062935 1.0 Pass 802.11n (HT20) 22.0 158.49 1.995 0.062935 1.0 Pass 802.11n (HT40) 22.0 158.49 1.995 0.062935 1.0 Pass 6. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20201022016-1-1 2ATOW-TD Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Oct.26, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Applicant’s name ............................ : SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Address ............................................ : F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Camera Trade Mark ....................................... : TVT Manufacturer ................................... : SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Model/Type reference....................... : TD-9441S3 Listed Models .................................. : TD-94v1wxyz;TD-74v1wxyz; (v=1-8; w=A-Z;x=1-8, A-Z, or blank; y=1-8, A-Z, or blank; z=1-8, A-Z, or blank) Ratings ............................................. : DC 12V From External circuit Modulation ....................................... : CCK/DSSS, OFDM Hardware version ............................. : S3A-5MR15_MB_V1.0 Software version .............................. : V1.0 Frequency .......................................... From 2412MHz-2462MHz Result................................................ : PASS Report No.: GTS20201022016-1-1 Page 2 of 40 T E S T R E P O R T Test Report No. : GTS20201022016-1-1 Oct.26, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Camera Model /Type : TD-9441S3 Listed Models : TD-94v1wxyz;TD-74v1wxyz; (v=1-8; w=A-Z;x=1-8, A-Z, or blank; y=1-8, A-Z, or blank; z=1-8, A-Z, or blank) Applicant : SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Address : F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Manufacturer : SHENZHEN TVT DIGITAL TECHNOLOGY CO.,LTD. Address : F 23rd Building B4 Block 9,Shenzhen Bay Science And Technology Ecological Garden,Nanshan District, Shenzhen China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20201022016-1-1 Page 3 of 40 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Test Description 8 3.4 Statement of the measurement uncertainty 9 3.5 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emission 14 4.3 Maximum Conducted Output Power 20 4.4 Power Spectral Density 21 4.5 6dB Bandwidth 24 4.6 Out-of-band Emissions 27 4.7 Antenna Requirement 34 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 35 6 P H O T O S O F T H E E U T ........................................................... 36 Report No.: GTS20201022016-1-1 Page 4 of 40 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: GTS20201022016-1-1 Page 5 of 40 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Sep. 20, 2020 Testing commenced on : Sep. 21, 2020 Testing concluded on : Oct. 26, 2020 2.2 Product Description Product Description: Camera Model/Type reference: TD-9441S3 Power supply: DC 12V from External circuit Adaper information (The auxiliary test equipment is provided by th…
