2ATZS-BC61Bluetooth FM Transmitter

BC61BluetoothCarCharger Manual ProductFeatures: 1.Bluetooth 、 FMaudiotransmission 2.SupportQC3.0QC2.0、PD、HuaweiFCP、 SamsungAFC、BC1.2、Apple2.4Aandother chargingprotocols 3.SupportWMA，MP3,WAV,APE,FLACmusic format 4.Supportbluetoothhands-free,Voicebroadcast, music,navigation. 5.Supportoutputovervoltageprotection,short circuitprotection,overcurrentprotection,over temperatureprotection 6.Abnormalvoltagealarm 7.Automaticconnect Productspecifications: 1.Bluetoothversion ： 5.3 2.FMfrequency：87.5Mhz-108.0Mhz 3.Bluetootheffectivedistance：10m 4.QC3.0output ： 5V/3A 、 9V/2A 、 12V/1.5A 5.PD output ：5V/3A、9V/2.22A、12V/1.67A 6.Inputvoltage ： 12V-24V ProductDiagram Operationinstructions 1.Inserttheproductintothecigarettelighterofthe caraftervehiclestart. 2.Theproductwillautomaticallypoweronafter insertanddisplayHI--Voltage--FMfrequency 3.TurnonyourcarFMradio,andchoosetheblank FM channel. 4.Adjusttheproductfrequencysameasyourcar radio. 5.Turnonthebluetoothofyourphone,searchfor thebluetoothdevice"BC61",andconnect. 6.Aftertheconnectionissuccessful,youcanplay music,navigateormake/answercalls. FMfrequencyadjustment： Longpress “” keyenterFMstate. 1.Clickthe”“or”“buttonto increaseordecreasethefrequency,waitfor3 secondswillautomaticconfirmandsavethe frequencyorshortpresstoconfirm. Musiccontrol: 1.Pause/Play—click “” button 2.Lastsong--click ”“ button 3.Nextsong--click”“button Dial/Answercall： 1.Answeracall：click“”button 2.Hangupacall：click“”button 3.Redialcalls ： doubleclick “” key 4.Rejectacall ： longpress “” button Lightswitch ： Alwaysbrightwhenpoweron,extinguishedwhen poweroff. LowVoltageAlarm/LowPowerMode Whentheinputvoltageislessthanorequalto11V, thedigitaltubedisplaysthecurrentvoltageand flashesandalarm.Ifitcontinuestoflashfor10 minuteswithoutanyoperation,theBluetoothwill enterthelow-powermode,whichcanbeactivated bypressinganykeyorpoweringonagain. （ This functionistoprotectthecarbattery.Somecarsafter turnedoffandlocked,thecigarettelighterisnot poweredoff ） . Warmtips： 1.Donotturntheradiovolumetoohigh(usually18 orbelow)toavoidtheincreaseofthesoundback noise. 2.Althoughthetransmissionpowerofthisproductis relativelystrong,you’dbetterskipthefrequency withstrongsignalinlocaltogetabettersound quality. 3.Donotusethisproductinadustyandhumid environmentwithextremelyhighandlow temperatures. 4.Donotdroptheproducttoavoidsurfacedamage orbreakdown. 5.Donotdisassembletheproduct,ifyouhaveany questions,pleasecontactyourdealer. 6.Duetocontinuousimprovementand enhancementoftechnology,changesinproduct performanceandfunctionalityaresubjectto changewithoutnotice. Troubleshooting： Poweris not respondin gornot displayed ·Checkifthemachineisingood contactwiththecigaretteport,and thecigaretteholderisnot seriouslyrusted. · Unplugandre-tryagain. ·Checkifthecigaretteholderis powerednormally. Can'tplay · CheckiftheUSBdeviceis connectedtotheplayerornot,or youcantryanotherUSBdevice. ·Pleasemakesurethatthereis copyofthefileintheUSBdevice thatcanbesupportedbythe product. ·Pleasemakesurethevolumeis notsetto0. Thereis noisebut nosound · Whethertheproductplayerisin apausestate? · Isthevolumeadjustedto0or small? Theaudio ofcarcan't receive sound ·MakesurethattheproductFM launchhasbeenturnedon. · Isthetransmissionfrequencyof theproductthesameasthe receptionfrequencyofcar’s? The launching effectis notgood, thereis noise ·Makesurethatthereisnostrong signalstationatthefrequencyof thecurrenttransmission.When usingit,adjusttothefrequencyof noradiostationtogetbetter soundeffect. Packagingaccessories 1.Usermanual2.Maindevice NOTE:Thisequipmenthasbeentestedandfound tocomplywiththelimitsforaClassBdigitaldevice, pursuanttopart15oftheFCCRules.Theselimits aredesignedtoprovidereasonableprotection againstharmfulinterferenceinaresidential installation.Thisequipmentgeneratesusesandcan radiateradiofrequencyenergyand,ifnotinstalled andusedinaccordancewiththeinstructions,may causeharmfulinterferencetoradiocommunications. However,thereisno guaranteethatinterferencewillnotoccurina particularinstallation.Ifthisequipmentdoescause harmfulinterferencetoradioortelevisionreception, whichcanbedeterminedbyturningtheequipment offandon,theuserisencouragedtotrytocorrect theinterferencebyoneormoreofthefollowing measures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipment andreceiver. -Connecttheequipmentintoanoutletonacircuit differentfromthattowhichthereceiverisconnected. -Consultthedealeroranexperiencedradio/TV technicianforhelp.Changesormodificationsnot expresslyapprovedbythepartyresponsiblefor compliancecouldvoidtheuser'sauthorityto operatetheequipment.

SHEN ZHEN LEADINWAY TECHNOLOGY CO.,LTD Jul.29, 2022 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID : 2ATZS-BC61 Model Number: BC61, Ti21, BC76, BC17, BC86, BC87, BC88, BC89, BC90, BC91, BC92, BC93, BC94, BC95, BC96, BC97, BC98, BC99, BC100 To Whom It May Concern: We, The Shenzhen Leadinway Technology Co., Ltd hereby declare that the models are identical except the model name. Except for the different above, no other modification is performed. Sincerely, Signature: SHEN ZHEN LEADINWAY TECHNOLOGY CO.,LTD Contact person: Maria Ma

SHEN ZHEN LEADINWAY TECHNOLOGY CO.,LTD Agent Authorization Company: SHEN ZHEN LEADINWAY TECHNOLOGY CO.,LTD Address: 29 Building, Baotian industrial District Chentian,Xixiang Town, Shenzhen,Guangdong, China Product Name: Bluetooth FM Transmitter Model Number(s): BC61, Ti21, BC76, BC17, BC86, BC87, BC88, BC89, BC90, BC91, BC92, BC93, BC94, BC95, BC96, BC97, BC98, BC99, BC100 Product Description: Bluetooth FM Transmitter We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-07-29 Name: Maria Ma Company: SHEN ZHEN LEADINWAY TECHNOLOGY CO.,LTD

Report No.: AGC08073220701AP02 Page 1 of 3 EXTERNAL PHOTOS TOP VIEW OF EUT BOTTOM VIEW OF EUT Report No.: AGC08073220701AP02 Page 2 of 3 FRONT VIEW OF EUT BACK VIEW OF EUT Report No.: AGC08073220701AP02 Page 3 of 3 LEFT VIEW OF EUT RIGHT VIEW OF EUT ****************************************End of Report****************************************

FCC ID Label Location 15mm&40mm FCC ID: 2ATZS-BC61

Report No.: AGC08073220701AP02 Page 1 of 4 INTERNAL PHOTOS VIEW OF EUT(PORT) OPEN VIEW OF EUT Report No.: AGC08073220701AP02 Page 2 of 4 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 BT Antenna Report No.: AGC08073220701AP02 Page 3 of 4 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 FM Antenna Report No.: AGC08073220701AP02 Page 4 of 4 INTERNAL VIEW OF EUT-5 ****************************************End of Report****************************************

Page 1 of 18 FCC Test Report Report No.: AGC08073220701FE06 FCC ID : 2ATZS-BC61 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Bluetooth FM Transmitter BRAND NAME : N/A MODEL NAME : BC61, Ti21, BC76, BC17, BC86, BC87, BC88, BC89, BC90, BC91, BC92, BC93, BC94, BC95, BC96, BC97, BC98, BC99, BC100 APPLICANT : Shenzhen Leadinway Technology Co., Ltd DATE OF ISSUE : Jul. 28, 2022 STANDARD(S) : FCC Part 15.239 REPORT VERSION : V1.0 Attestation of Global Compliance(Shenzhen) Co., Ltd Report No.: AGC08073220701FE06 Page 2 of 18 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Jul. 28, 2022 Valid Initial Release Report No.: AGC08073220701FE06 Page 3 of 18 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ............................................................................................................ 4 2. GENERAL INFORMATION ......................................................................................................................... 5 2.1. PRODUCT DESCRIPTION ................................................................................................................... 5 2.2 TABLE OF CARRIER FREQUENCYS ................................................................................................... 5 3. MEASUREMENT UNCERTAINTY .............................................................................................................. 5 4. DESCRIPTION OF TEST MODES .............................................................................................................. 6 5. SYSTEM TEST CONFIGURATION ............................................................................................................ 7 5.1. EQUIPMENT USED IN EUT SYSTEM .................................................................................................. 7 5.2. SUMMARY OF TEST RESULTS ........................................................................................................... 7 6. TEST FACILITY ........................................................................................................................................... 8 7. RADIATED EMISSION ................................................................................................................................ 9 7.1. MEASUREMENT PROCEDURE ........................................................................................................... 9 7.2.TEST SETUP ........................................................................................................................................ 11 7.3. TEST RESULTFOR FIELD STRENGTH OF FUNDAMENTAL ........................................................... 12 7.4. TEST RESULT FOR FIELD STRENGTH OF BAND EDGE EMISSION ............................................. 12 7.5. TEST RESULT FOR SPURIOUS EMISSION ..................................................................................... 13 8. BANDWIDTH ............................................................................................................................................. 15 8.1. MEASUREMENT PROCEDURE ......................................................................................................... 15 8.2. TEST SETUP ....................................................................................................................................... 15 8.3. TEST RESULT ..................................................................................................................................... 16 APPENDIX A: PHOTOGRAPHS OF TEST SETUP ..................................................................................... 18 APPENDIX B: PHOTOGRAPHS OF EUT .................................................................................................... 18 Report No.: AGC08073220701FE06 Page 4 of 18 1. VERIFICATION OF CONFORMITY Applicant Shenzhen Leadinway Technology Co., Ltd Address 29 Building, Baotian industrial District Chentian, Xixiang Town, Shenzhen, Guangdong, China Manufacturer Shenzhen Leadinway Technology Co., Ltd Address 29 Building, Baotian industrial District Chentian, Xixiang Town, Shenzhen, Guangdong, China Factory Shenzhen Leadinway Technology Co., Ltd Address 29 Building, Baotian industrial District Chentian, Xixiang Town, Shenzhen, Guangdong, China Product Designation Bluetooth FM Transmitter Brand Name N/A Test Model BC61 Series Model Ti21, BC76, BC17, BC86, BC87, BC88, BC89, BC90, BC91, BC92, BC93, BC94, BC95, BC96, BC97, BC98, BC99, BC100 Difference Description All the same except for the model name. Date of test Jul. 07, 2022 to Jul. 28, 2022 Deviation No any deviation from the test method Condition of Test Sample Normal Test Result Pass Report Template AGCRT-US-BR/RF (2013-03-01) We hereby certify that: The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with radiated emission limits of FCC part 15.239. Prepared By Thea Huang (Project Engineer) Jul. 28, 2022 Reviewed By Calvin Liu (Reviewer) Jul. 28, 2022 Approved By Max Zhang (Authorized Officer) Jul. 28, 2022 Report No.: AGC08073220701FE06 Page 5 of 18 2. GENERAL INFORMATION 2.1. PRODUCT DESCRIPTION A major technical description of EUT is described as following Operation Frequency 88.1MHz-107.9MHz Test Frequency Low: 88.1 MHz; Middle:98.0 MHz; High: 107.9 MHz Field Strength(3m) 46.86dBuV/m(PK)@3m Modulation FM Number of channels 199(Channel spacing 100kHz) Hardware Version YHW-BC61(2853)-V1.0 2022 05 21 Software Version CGBT2366_YHW(BC61)_SDK200_P007_20220426_v1.1.6_att Antenna Designation Built-in Antenna (Met 15.203 Antenna requirement) Antenna Gain 0dBi Power Supply DC 12-24V NOTE: About the EUT, please refer to User’s Manual. 2.2 TABLE …
