2AUHEPRXONEAll-in-One Column PA System

DRAFT QUICKSTART GUIDE PORTABLE P.A. SYSTEM | ONE HAND CARRY | BLUETOOTH AUDIO | LEGENDARY JBL SOUND 2. POWER ON THE UNIT 1. Connect the power cord to the Power Receptacle (J). 2. Press the Power Button [A] for .5 of a second to engage power. 1. LISTENING CONFIGURATIONS Linear Array 1Linear Array 2 3. PLUG IN THE INPUTS 1. Turn the Channel Volumes (C) all the way to the lef t before connecting any inputs. 2. Connect your devices to the Input Jacks (K) (L] (M) (N). 21 4. SET UP THE CHANNELS 1. Inert input into desired channel 2. Determine the CH1 thru CH6 (C] source. For microphone set to 3 o’clock. For line source set to 9 o’clock. 3. Slowly turn the Master /Menu Encoder (G) to the right until the desired volume is reached. This device supports Bluetooth audio streaming. To connect your device: 1. Turn on Bluetooth on your source device. 2. Press the Bluetooth Pair Button (O). 3. Find PRX ONE on your device and select Bluetooth. 6. PAIR AUDIO 5. EDIT A CHANNEL 1. Depress the knob of the channel (E) you wish to edit 2. The CH LED (F) above the respective channel will light 3. You can now edit Bass, Treble, Mid and Reverb for that respective channel. 4. Press the knob again to return to mix mode. DRAFT A B C J K D LM E F G H I N Power Button LCD Display CH Volume Effects LED Power Inlet USB Ports Limit LED Power Operating Modes Master/Menu Encoder Back Button XLR Male Loop Thru XLR-1/4” Combo Inputs 6.3mm Hi-Z Balanced Input 3.5mm Stereo Un-Balanced Input For complete documentation, visit http://www.jblpro.com/prxone JBL Professional 8500 Balboa Blvd. Northridge, CA 91329 USA © 2020 Harman International Industries, Incorporated PRX ONE Quickstart Guide – 09/2020 Pour la version française de ce document, veuillez visiter le site www.jblpro.com/prxone Die deutsche Version dieses Dokuments finden Sie unter www.jblpro.com/prxone Para la versión en español de este documento, por favor visite www.jblpro.com/prxone Para a versão em português deste documento, visite www.jblpro.com/prxone Per la versione italiana di questo documento, visitare www.jblpro.com/prxone 이 문서의 한국어 버전은 www.jblpro.com/prxone 를 방문하십시오 有關本文檔的中文版，請訪問 www.jblpro.com/prxone The PRX ONE speaker system covered by this manual is not intended for use in high moisture environments. Moisture can damage the IMPORTANT SAFETY INSTRUCTIONS 1. READ these instructions. 2. KEEP these instructions. 3. HEED all warnings. 4. FOLLOW all instructions. 5. DO NOT use this apparatus near water. 6. CLEAN ONLY with dry cloth. 7. DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. produce heat. 9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wider blade or the third prong are outlet. 10. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. 12. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. UNPLUG this apparatus during lightning storms or when unused for long periods of time. 14. way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. placed on the apparatus. 16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from the AC receptacle. 17. Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. 18. 19. Product ventilation should not be impeded by covering the ventilation openings with items such as newspaper, tablecloths, curtains, etc. The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. of electrical shock to persons. WARNING: WARNING: WARNING: Equipment shall be connected to a MAINS socket outlet with a protective earthing connection. speaker cone and surround and cause corrosion of electrical contacts and metal parts. Avoid exposing the speakers to direct moisture. degraded by long-term exposure to intense ultra-violet (UV) light. The PRX ONE system can generate considerable energy. When placed on a slippery surface such as polished wood or linoleum, the speaker may move due to its acoustical energy output. Precautions should be taken to assure that the speaker does not fall off a stage or table on which it is placed. 1Rev. A4 WEEE Notice The Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), which entered into force as European law on 14/02/2014, resulted in a major change in the treatment of electrical equipment at end-of-life. The purpose of this Directive is, as a first priority, the prevention of WEEE, and in addition, to promote the reuse, recycling and other forms of recovery of such wastes so as to reduce disposal. The WEEE logo on the product or on its box indicating collection for electrical and electronic equipment consists of the crossed-out wheeled bin, as shown below. This product must not be disposed of or dumped with your other household waste. You are liable of dispose of all your electronic or electrical waste equipment by relocating over to the specified collection point for recycling of such hazardous waste. Isolated collection and proper recovery of your electronic and electrical waste equipment at the time of disposal will allow us to help conserving natural resources. Moreover, proper recycling of the electronic and electrical waste equipment will ensure safety of human health and environment. For more information about electronica and electrical waste equipment disposal, recovery, and collecti…

Text truncated - open the document above for the full version.

External Photos M/N: PRX ONE External Photos M/N: PRX ONE External Photos M/N: PRX ONE External Photos M/N: PRX ONE External Photos M/N: PRX ONE External Photos M/N: PRX ONE External Photos M/N: PRX ONE

6.1

Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Internal Photos M/N: PRX ONE Bluetooth Antenna

FCC ID: 2AUHEPRXONE EST Technology Co. ,Ltd Report No. ESTE-R2011040 Page 1 of 4 FCC 47 CFR MPE REPORT Harman Professional, Inc. All-in-One Column PA System Model Number: PRX ONE FCC ID: 2AUHEPRXONE Prepared for: Harman Professional, Inc. 8500 Balboa Blvd., Northridge, CA 91329 USA Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2011040 Date of Test: Oct. 12~Nov. 04, 2020 Date of Report: Nov. 05, 2020 FCC ID: 2AUHEPRXONE EST Technology Co. ,Ltd Report No. ESTE-R2011040 Page 2 of 4 Maximum Permissible Exposure 1. Applicable Standards Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. 1.1. Limits for Maximum Permissible Exposure (MPE) (a) Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-10000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-10000 1.o 30 Note: f=frequency in MHz; *Plane-wave equivalent power density FCC ID: 2AUHEPRXONE EST Technology Co. ,Ltd Report No. ESTE-R2011040 Page 3 of 4 1.2. MPE Calculation Method E (V/m) = d G×P×30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d×377 G×P×30 From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained FCC ID: 2AUHEPRXONE EST Technology Co. ,Ltd Report No. ESTE-R2011040 Page 4 of 4 2. Conducted Power Result Mode Frequency (MHz) Peak output power (dBm) Peak output power (mW) Target power （dBm） Antenna gain (dBi) (Linear) BT GFSK 2402 7.40 5.495 7 ±1 2.83 1.919 2441 7.05 5.070 7 ±1 2.83 1.919 2480 6.97 4.977 6 ±1 2.83 1.919 BT 8-DPSK 2402 9.70 9.333 9 ±1 2.83 1.919 2441 9.74 9.419 9 ±1 2.83 1.919 2480 9.81 9.572 9 ±1 2.83 1.919 BLE GFSK 1M 2402 1.30 1.349 1 ±1 2.83 1.919 2440 1.23 1.327 1 ±1 2.83 1.919 2480 1.17 1.309 1 ±1 2.83 1.919 BLE GFSK 2M 2402 0.55 1.135 0 ±1 2.83 1.919 2440 0.52 1.127 0 ±1 2.83 1.919 2480 0.45 1.109 0 ±1 2.83 1.919 3. Calculated Result and Limit Mode Target power （dBm） Antenna gain Power Density (S) (mW /cm2) Limited of Power Density (S) (mW /cm2) Test Result (dBi) (Linear) 2.4G Band BT GFSK 8 2.831.9190.00241 1 Compiles BT 8-DPSK 10 2.831.9190.00382 1 Compiles BLE GFSK 1M 2 2.831.9190.00060 1 Compiles BLE GFSK 2M 1 2.831.9190.000481 Compiles End of Test Report

FCC ID: 2AUHEPRXONE EST Technology Co., Ltd Report No. ESTE-R2011038 Page 1 of 66 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Harman Professional, Inc. All-in-One Column PA System Model Number: PRX ONE FCC ID: 2AUHEPRXONE Prepared for: Harman Professional, Inc. 8500 Balboa Blvd., Northridge, CA 91329 USA Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2011038 Date of Test: Oct. 12~Nov. 04, 2020 Date of Report: Nov. 05, 2020 FCC ID: 2AUHEPRXONE EST Technology Co., Ltd Report No. ESTE-R2011038 Page 2 of 66 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION......................................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................. 5 1.1. Description of Device (EUT) ........................................................................................................... 5 1.2. Antenna Information ........................................................................................................................ 5 2. SUMMARY OF TEST ......................................................................................................................... 6 2.1. Summary of test result ...................................................................................................................... 6 2.2. Test Facilities ................................................................................................................................... 7 2.3. Measurement uncertainty ................................................................................................................. 8 2.4. Assistant equipment used for test ..................................................................................................... 8 2.5. Block Diagram ................................................................................................................................. 8 2.6. Test mode ......................................................................................................................................... 9 2.7. Channel List ................................................................................................................................... 10 2.8. Power Setting of Test Software ...................................................................................................... 10 2.9. Test Equipmen ................................................................................................................................ 11 3. MAXIMUM PEAK OUTPUT POWER ................................................................................................. 12 3.1. Limit ............................................................................................................................................... 12 3.2. Test Setup ....................................................................................................................................... 12 3.3. Spectrum Analyzer Setting ............................................................................................................. 12 3.4. Test Procedure ................................................................................................................................ 12 3.5. Test Result ...................................................................................................................................... 13 4. 20 DB BANDWIDTH ....................................................................................................................... 18 4.1. Limit ............................................................................................................................................... 18 4.2. Test Setup ....................................................................................................................................... 18 4.3. Spectrum Analyzer Setting ............................................................................................................. 18 4.4. Test Procedure ................................................................................................................................ 18 4.5. Test Result ...................................................................................................................................... 19 5. CARRIER FREQUENCY SEPARATION .............................................................................................. 24 5.1. Limit ............................................................................................................................................... 24 5.2. Test Setup ....................................................................................................................................... 24 5.3. Spectrum Analyzer Setting ............................................................................................................. 24 5.4. Test Procedure ................................................................................................................................ 24 5.5. Test Result ...................................................................................................................................... 25 6. NUMBER OF HOPPING CHANNEL .................................................................................................. 30 6.1. Limit ............................................................................................................................................... 30 6.2. Test Setup ....................................................................................................................................... 30 6.3. Spectrum Analyzer Setting .........................................................................................................…

Text truncated - open the document above for the full version.

Conducted Test Radiated Test (30-1000 MHz) Radiated Test (Above 1GHz)
