2AUOUC6RSmartphone with BT, WIFI, GSM, WCDMA, LTE and NFC

1 C6R User Manual 2 Product Overview Front View Recent Apps Key Home Key Back Key Touch screen Self camera lens Power/Lock Key Volume Keys Optical distance perception Receiver Self camera lens 3 Back View 4 Assembling MicroSD Card (if applicable) 1. Take out the battery cover first. 2. Pull out the card holder on the left side of the phone. 3. Put the microSD card into the microSD card slot of the card tray, and then push the card tray into the phone. Assembling SIM Card (if applicable) 1. Take out the battery cover first. 2. Pull out the card holder on the left side of the phone. 3. Put the SIM card into the SIM card slot of the card tray, and then push the card tray into the phone. 5 Getting Started Turning Phone On/Off To turn on phone 1. Press and hold the power key for a few seconds until you see the RHINO welcome screen. To turn off phone  1. Press and hold the power key and volume up 2. Select Power Off. Unlocking the Screen The screen is locked by default when you turn on the phone. To unlock the screen- 1. Press the power key. 2. Place finger on center of screen and swipe up. 3. If you previously set up an unlock security option, draw a pattern, use your fingerprint, or enter PIN. 6 Locking the Screen To lock the screen, press the power key. Note: It is recommended to lock the screen to protect your information and reduce battery usage. You can set up your phone to automatically lock after a certain period of time. To do so, press finger on bottom-center of screen, and swipe up to open All Apps. Tap Settings → Display → Screen timeout. Using Touch Screen All of the functions of the phone, except for power and volume, are performed on the touch screen. The following finger actions may help you easily understand how to use the touch screen. 7  Tap: With your finger, touch an item (ie: application or widget) to run it, or access a menu or option.  Double tap: Tap an item twice with your finger.  Drag: Tap and hold your finger on an item, then slide it without losing contact with the screen.  Swipe: Place your finger on an empty space of the screen and move the screen up or down or left or right.  Pinch: Place two fingers on the screen and move them apart to zoom into a picture, document or webpage; or move them together to zoom out.  Select and tap: Tap an item in the list of options available.  Press and hold: Press a key or any item for a few seconds until a list of options appears. Cautions:  Do not use sharp tools that can scratch the touch screen. 8 Key Functions Back Key Tap to return to the previous screen and exit the running application. Tap to close the on-screen keyboard in text input mode. Home Key Tap to return to the main screen. Tap and hold to open the Google search. Recent Apps Key Tap to open the applications list used recently. Screen Orientation For optimal viewing experience, the screen orientation changes automatically depending on how you hold the phone. 9 Note: To enable or disable auto-rotate, place finger on top-center of screen, and slide down to view Status and Notification panel, then tap the Auto-rotate icon. Status Bar The Status bar at the top of the screen includes notifications from various apps, current time, and the states of various items such as battery status, WLAN status, Signal status, and so on. 10 Status and Notification Panel The Status panel displays status icons to show the current state of your phone, such as battery charging progress, alarms, Bluetooth, and so on. The Notification panel displays notification icons to inform you of new email, messages, and so on. To view both panels, place finger on top-center of screen, and slide down, then tap an icon to view details. 11 Apps and Widgets Apps: Software that allows you to perform a specific task. Your phone is preloaded with a variety of applications, and additional applications can be downloaded from the Play Store. Widgets: A small application which resides on the home screen and provides quick and easy access to information. Connecting to The Internet Using Wi-Fi Note: The range and quality of the WiFi signal is affected by the distance between the phone and the wireless router, the number of connected devices, infrastructure, and objects through which the signal is transmitted. 1. Press finger on bottom-center of screen and swipe up to open All Apps. 2. Tap Settings → Network & internet → Internet →Wi-Fi. 3. Drag the slider to the On position. 4. Phone will scan for WLAN networks in range. 5. Tap the network you want to connect to. 6. Type a password (if connecting to a secure network). 12 7. Tap Connect to connect to the selected WiFi network. Connecting to The Internet Using Mobile Broadband 1. Press finger on bottom-center of screen and swipe up to open All Apps. 2. Tap Settings → Network & internet → Internet→Wi-Fi. 3. Drag the slider to the Off position. 4. The phone will search for the carrier signal and connect to the network. When the phone is connected to a mobile broadband network, the network type appears in the status bar. Note: On the LTE/HSPA+ models, if both WiFi and mobile broadband networks are available, the phone gives priority to WiFi connection. Phone Maintenance/Safety The following list shows how to maintain your phone, together with precautions to take.  Keep your phone and its accessories out of the reach of pets.  If children use the phone, make sure that they use it properly. 13  Maintain your phone in dry conditions and keep it within normal operating temperatures.  Do not try to dry your phone in a microwave oven. If you do, sparks can occur and cause an explosion or fire.  Do not use or store your phone in dusty, dirty or wet areas.  Do not attempt to disassemble your phone.  Do not drop or cause severe impact to your phone.  Do not sit on or apply pressure to phone.  Do not use chemical products, cleaning solvents or detergents to clean your phone.  Use only authorized batteries, battery chargers and accessories. Any malfunction or…
