2AUVM-CIR615AContactless Smart Card Reader with Keyboard Emulation

CIR615A Contactless Smart Card Reader with Keyboard Emulation User Manual Page 1 of 1 Version 1.01 Jul 2022 CIR615A Contactless Smart Card Reader with Keyboard Emulation User Manual Driver installation Procedure The driver package is already signed by Microsoft so that the user can install the driver directly via Windows Update. Otherwise, please follow the steps below to do manual installation. Hardware requirement(s): • 1 x CIR615A • 1 x PC with OS Windows 7 or above Software requirement(s): • 1 x CIR615 Driver Package Steps: 1. Connect CIR615 to PC 2. On PC, open “Control Panel > System” 3. Open “Device Manager” 4. Select and open “Smart card readers” if “Microsoft Usbccid ... (WUDF)” is shown, continue with step 5 if “CIR615 PICC” and “CIR615 SAM” are shown, it means driver installation is completed 5. Right click on the “Microsoft Usbccid ... (WUDF)” and select “Update driver” 6. Select “Browse my computer for drivers...” 7. Select “Let me pick from a list ...” 8. Select “Browse...” 9. Select “CIR615.inf” 10. Follow the steps on the screen to complete the driver installation 11. Then the device is ready to use Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.

(date) AB CIRCLE LIMITED Room 609, Cross Office Uchisaiwaicho, 1-18-6, Nishi-Shimbashi, Minatoku, Tokyo, Japan 105-003 AUG 2 2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR: EUT NAME: Contactless Smart Card Reader with Keyboard Emulation MODEL : CIR615A FCC ID:2AUVM-CIR615A To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Contactless Smart Card Reader with Keyboard Emulation Model: CIR615A required to be submitted with this application be permanently withheld from public review. Block Diagram, Schematic, BOM, Operational Description / Architecture, the above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, M Okuda, Manager

. AB CIRCLE LIMITED, Room 609, Cross Office Uchisaiwaicho, 1-18-6, Nishi- Shimbashi, Minatoku, Tokyo, Japan 105-003 Date : AUG 2 2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize The Hong Kong Standards and Testing Centre Ltd. Mr. KC Lee to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Product name : Contactless Smart Card Reader with Keyboard Emulation Model : CIR615A This agreement expires one year from the current date. Sincerely, M Okuda, Manager

External Unit Photos:

Label Position

Internal Photos

CIR615A Contactless Smart Card Reader with Keyboard Emulation – Antenna Information Version 1.01 Page 1 of 1 www.acs.com .hk CIR615A Contactless Smart Card Reader with Keyboard Emulation Antenna Information NFC Antenna Detail ⚫ Dimension: 49.9mm * 48.5mm ⚫ Number of Loop: 3 ⚫ Trace Width: 0.5mm ⚫ Trace Gap: 0.5mm ⚫ Antenna Gain: -38.1dBi NFC Antenna

Test Report Date : 2022-08-11 Page 1 of 25 No. : HM22050022 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Applicant: AB CIRCLE LIMITED Room 609, Cross Office Uchisaiwaicho, 1-18-6, Nishi-Shimbashi, Minatoku, Tokyo, Japan 105-003 Manufacturer: AB CIRCLE LIMITED Room 609, Cross Office Uchisaiwaicho, 1-18-6, Nishi-Shimbashi, Minatoku, Tokyo, Japan 105-003 Description of Sample(s): Product: Contactless Smart Card Reader with Keyboard Emulation Brand Name: AB Circle Limited Model Number: CIR615A FCC ID: 2AUVM-CIR615A Date Sample(s) Received: 2022-05-31 Date Tested: 2022-06-20 to 2022-07-07 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.10:2013 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): --- Dr. CHAN Kwok Hung, Brian Authorized Signatory CONTENT: Test Report Date : 2022-08-11 Page 2 of 25 No. : HM22050022 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Cover Page 1 of 25 Content Page 2 of 25 1.0 General Details 1.1 Equipment Under Test [EUT] Page 3 of 25 Description of EUT operation 1.2 Description of EUT Operation 1.3 Date of Order Page 3 of 25 1.4 Submitted Sample Page 3 of 25 1.5 Test Duration Page 3 of 25 1.6 Country of Origin Page 3 of 25 2.0 Technical Details 2.1 Investigations Requested Page 4 of 25 2.2 Test Standards and Results Summary Page 4 of 25 3.0 Test Results 3.1 Emission Page 5-19 of 25 Appendix A List of Measurement Equipment Page 20 of 25 Appendix B Photographs of EUT Page 21 of 25 Appendix C RF Exposure Evaluation Page 24 of 25 Test Report Date : 2022-08-11 Page 3 of 25 No. : HM22050022 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.0 General Details 1.1 Equipment Under Test [EUT] Description of Sample(s) Product: Contactless Smart Card Reader with Keyboard Emulation Manufacturer: AB CIRCLE LIMITED Room 609, Cross Office Uchisaiwaicho, 1-18-6, Nishi-Shimbashi, Minatoku, Tokyo, Japan 105-003 Brand Name: AB Circle Limited Model Number: CIR615A Operating Frequency 13.56MHz +/- 7KHz Modulation ASK Antenna / Gain Integral ( inductive type ), Gain : -38.1dBi Rating: 5Vd.c. of USB port of EUT 1.2 Description of EUT Operation The Equipment Under Test (EUT) is 13.56MHz Contactless Smart Card Reader with Keyboard Emulation, which is 13.56MHz transceiver fixed transmit at 13.56MHz, the modulation is ASK type which is provided by IC. The module RF transmission configuration is controlled by software APDU.exe. 1.3 Date of Order 2022-05-31 1.4 Submitted Sample(s): 4 Samples 1.5 Test Duration 2022-06-20 to 2022-07-07 1.6 Country of Origin Not Provided Test Report Date : 2022-08-11 Page 4 of 25 No. : HM22050022 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 Regulations and ANSI C63.10:2013 for FCC Certification. 2.2 Test Standards and Results Summary Tables Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail Field Strength of Fundamental & Harmonics Emissions FCC 47CFR 15.225(a-d) ANSI C63.10:2013 N/A The Frequency Tolerance of Carrier Signal FCC 47CFR 15.225(e) ANSI C63.10:2013 N/A 20 dB Bandwidth FCC 47CFR 15.215 ANSI C63.10:2013 N/A Radio Frequency powered Tags FCC 47CFR 15.225(f) ANSI C63.10:2013 N/A N/A Radiated Emissions FCC 47CFR 15.209 ANSI C63.10:2013 N/A Antenna requirement FCC 47CFR 15.203 N/A N/A AC power-line conducted emissions FCC 47CFR 15.207 ANSI C63.10:2013 N/A Note: N/A - Not Applicable Test Report Date : 2022-08-11 Page 5 of 25 No. : HM22050022 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website.…

Text truncated - open the document above for the full version.

Conducted Emission: Radiated Emission:

Test Setup Photos
