2AUXS-PSAAIOHead Unit

Registered Office: Stuttgart, Registration Court: Amtsgericht Stuttgart, HRB 14000; Chairman of the Supervisory Board: Franz Fehrenbach; Managing Directors: Dr. Volkmar Denner, Prof. Dr. Stefan Asenkerschbaumer, Filiz Albrecht, Dr. Christian Fischer, Dr. Stefan Hartung, Dr. Markus Heyn, Harald Kröger, Rolf Najork Robert Bosch GmbH Postfach 31132 Hildesheim Visitor: Robert-Bosch-Straße 200 31139 Hildesheim Tel +49 5121 49-0 www.bosch.com Thomas Dargel, XC/QMM-VR2-S Tel +49 5121 49-5599 [email protected] Declaration Warning Statements Ladies and gentlemen, FCC ID: 2AUXS-PSAAIO Model name: PSA AIO FCC § 15.19 Labelling requirements This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC § 15.21 Information to user Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure Requirements To comply with FCC RF exposure compliance requirements, the device must be installed to provide a separation distance of at least 20 cm from all persons. Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 05 July 2021 05 July 2021 Page 2 of 2 The above mentioned statements and paragraphs will be placed in a prominent location in the final user manual. Yours sincerely i.V. Dirk Zamow Listed Point of Contact

Registered Office: Stuttgart, Registration Court: Amtsgericht Stuttgart, HRB 14000; Chairman of the Supervisory Board: Franz Fehrenbach; Managing Directors: Dr. Volkmar Denner, Prof. Dr. Stefan Asenkerschbaumer, Filiz Albrecht, Dr. Christian Fischer, Dr. Stefan Hartung, Dr. Markus Heyn, Harald Kröger, Rolf Najork Robert Bosch GmbH Postfach 31132 Hildesheim Visitor: Robert-Bosch-Straße 200 31139 Hildesheim Tel +49 5121 49-0 www.bosch.com Thomas Dargel, XC/QMM-VR2-S Tel +49 5121 49-5599 [email protected] CONFIDENTIALITY REQUEST for Certification Service in USA TO WHOM IT MAY CONCERN, Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID: 2AUXS-PSAAIO Model name: PSA AIO For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists or Tune Up Information. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely i.V. Dirk Zamow Listed Point of Contact Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 05 July 2021

Sitz: Stuttgart, Registergericht: Amtsgericht Stuttgart, HRB 14000; Aufsichtsratsvorsitzender: Franz Fehrenbach; Geschäftsführung: Dr. Volkmar Denner, Prof. Dr. Stefan Asenkerschbaumer, Dr. Michael Bolle, Dr. Christian Fischer, Dr. Stefan Hartung, Dr. Markus Heyn, Harald Kröger, Christoph Kübel, Rolf Najork, Uwe Raschke, Peter Tyroller Robert Bosch GmbH Postfach 31132 Hildesheim Besucher: Robert-Bosch-Straße 200 31139 Hildesheim Telefon +49 5121 49-0 www.bosch.com Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Certification and Engineering Bureau Innovation, Science and Economic Development Canada Spectrum Engineering Branch 3701 Carling Avenue, Building 94 Ottawa, Ontario K2H 8S2 Tilman Almstedt, XC/QMM-VR2-S Telefon +49 5121 49-4226 [email protected] 02. August 2021 UNII Device Declaration Letter TO WHOM IT MAY CONCERN, We have declared below featured for FCC equipment authorization, Device FCC ID: 2AUXS-PSAAIO CN: (Company Number) 25847 UPN: (Unique Product Number) PSAAIO HVIN: (Hardware Version Id. Number) HW06 PMN: (Product Marketing Name) MyCitroen Play HMN: (Host Marketing Name) n/a FVIN: (Firmware Version Id. Number) n/a 1 Device functionality WLAN 5 GHz DFS: U-NII 2A & 2B (5250 - 5350 MHz & 5470 - 5725 MHz)  Master ☑N/A  Client (slave) with radar detection  Client (slave) without radar detection WLAN 5 GHz Non-DFS: U-NII 1 & 2C) (5150 - 5250 MHz & 5725 - 5850 MHz) ☑Master  N/A  Client According to §15.202, KDB 905462, RSS-247, respectively: A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices. 02. August 2021 Seite 2 von 3 A client (slave) device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode cannot initiate, or be configured to initiate, any transmissions including transmissions from probes, beacons or support ad-hoc modes (or other peer to peer modes) of operation without permission from an approved master device with radar detection capability. 02. August 2021 Seite 3 von 3 2 Operating modes Frequency (MHz) Active scanning: the device can transmit a probe (beacon) Passive scanning: the device can listen only with no probes Ad-hoc mode capability Access point capability 5180 - 5240  Yes  No  Yes  No 5190 - 5230  Yes  No  Yes  No 5260 - 5320  Yes  No  Yes  No  Yes  No  Yes  No 5270 - 5310  Yes  No  Yes  No  Yes  No  Yes  No 5500 - 5700  Yes  No  Yes  No  Yes  No  Yes  No 5510 - 5670  Yes  No  Yes  No  Yes  No  Yes  No 5745 - 5825 N/A N/A ☑Yes  No ☑Yes  No 5755 - 5795  Yes  No  Yes  No Info: DFS bands marked in blue. Dynamic Frequency Selection (DFS) is a mechanism hat dynamically detects signals from other systems and avoids co-channel operation with these systems, notably radar systems. DFS requirements to a master/client device are described in §15.407, RSS-247, respectively. 3 Miscellaneous Has the device the option to set or select country codes or permit similar configuration options through software parameters for different regulatory domains to configure the device transmitter power or frequency or other technical parameters (see KDB 594280)?  Yes ☑No* Is the device capable of transmitting in the band 5600 - 5650 MHz?  Yes ☑No * User can only enable/disable 5.8 GHz channels (only channels in accordance with FCC regulation can be activated) If you have any questions, please feel free to contact us at the address shown above. Best regards, i.V. Dirk Zamow Listed Point of Contact

Annex A 1-2339/21-01-01_AnnexA External photos of the Equipment Under Test This addendum is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Michael Dorongovski Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Photo 1 Photo 2 2021-06-28Document No. 1-2339/21-01-01_AnnexA2/5 Photo 3 Photo 4 2021-06-28Document No. 1-2339/21-01-01_AnnexA3/5 Photo 5 2021-06-28Document No. 1-2339/21-01-01_AnnexA4/5 Document history VersionApplied changesDate of release initial release2021-06-28 - END OF DOCUMENT - 2021-06-28Document No. 1-2339/21-01-01_AnnexA5/5

2AUXS-PSAAIO

Annex B 1-2339/21-01-01_AnnexB Internal photos of the Equipment Under Test This addendum is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Michael Dorongovski Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Photo 1 Photo 2 2021-06-28Document No. 1-2339/21-01-01_AnnexB2/10 Photo 3 Photo 4 2021-06-28Document No. 1-2339/21-01-01_AnnexB3/10 Photo 5 Photo 6 2021-06-28Document No. 1-2339/21-01-01_AnnexB4/10 Photo 7 Photo 8 2021-06-28Document No. 1-2339/21-01-01_AnnexB5/10 Photo 9 Photo 10 2021-06-28Document No. 1-2339/21-01-01_AnnexB6/10 Photo 11 Photo 12 2021-06-28Document No. 1-2339/21-01-01_AnnexB7/10 Photo 13 Photo 14 2021-06-28Document No. 1-2339/21-01-01_AnnexB8/10 Photo 15 Photo 16 2021-06-28Document No. 1-2339/21-01-01_AnnexB9/10 Document history VersionApplied changesDate of release initial release2021-06-28 - END OF DOCUMENT - 2021-06-28Document No. 1-2339/21-01-01_AnnexB10/10

© CTC advanced GmbH Page 1 of 4 BNetzA - CAB - 02/21 - 102 Maximum Permissible Exposure (MPE) & Exposure evaluation Report identification number: 1-2339/21-01-66 MPE (FCC_ISED) Testing Laboratory Applicant CTC advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken/Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://www.ctcadvanced.com e-mail: [email protected] Accredited Test Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Robert Bosch GmbH Robert-Bosch-Platz 1 70839 Gerlingen/GERMANY Phone: -/- Contact: -/- e-mail: -/- Manufacturer Bosch Car Multimedia Portugal, S.A. Rua Max Grundig, 35-Lomar 4705-820 Braga / PORTUGAL Certification numbers and labeling requirements FCC ID 2AUXS-PSAAIO ISED number 25847-PSAAIO HVIN (Hardware Version Identification Number) HW06 PMN (Product Marketing Name) MyCitroen Play FVIN (Firmware Version Identification Number) -/- HMN (Host Marketing Name) -/- This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorised: Alexander Hnatovskiy Marco Scigliano Lab Manager Testing Manager Radio Communications & EMC Radio Communications & EMC Report no.: 1-2339/21-01-66 © CTC advanced GmbH Page 2 of 4 EUT technologies: Technologies: Frequency [MHz] P max conducted [dBm]: Max. antenna gain [dBi]: Tolerance +/- [dB] Max. EIRP [dBm]: BT BDR/DER 2402 - 2480 1.0 0.6 2.0 3.6 WLAN 802.11b 2402 - 2422 13.0 0.6 2.0 15.6 WLAN 802.11g 2402 - 2422 10.0 0.6 2.0 12.6 WLAN 802.11a 5735 - 5775 6.0 4.3 3.0 13.3 WLAN 802.11ac 5735 - 5775 2.0 5.8 4.0 11.8 Collocation overview: Active scenario: Technology 1 2 3 4 BT x x x WLAN 2.4 GHz x x x WLAN 5.8 GHz x x x Report no.: 1-2339/21-01-66 © CTC advanced GmbH Page 3 of 4 Prediction of MPE limit at given distance - FCC Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG / 4π R 2 where: S = Power density P = Power input to the antenna G = Antenna gain R = Distance to the center of radiation of the antenna PG = Output Power including antenna gain The table below is excerpted from Table 1 - Limits for Maximum Permissible Exposure (MPE) of FCC-19-126A1 “Limits for General Population/Uncontrolled Exposure” Frequency Range (MHz) Power Density (mW/cm 2 ) Averaging Time (minutes) 300 -1500 f/1500 30 1500 – 3 000 000 1.0 30 where f = Frequency (MHz) Prediction: worst case Technologies: BT WLAN 2.4 WLAN 5.8 Frequency (MHz) 2402 2402 5735 PG Declared max power (EIRP) 3.6 15.6 13.3 dBm R Distance 20 20 20 cm S MPE limit for uncontrolled exposure 1 1 1 mW/cm 2 Calculated Power density: 0.0005 0.0072 0.0043 mW/cm² Calculated percentage of Limit: 0.05% 0.72% 0.43% Scenario 1: BT + WLAN 2.4 MHz Calculated percentage of Limit: Scenario 2: BT + WLAN 5GHz Calculated percentage of Limit: Scenario 3: BT + WLAN 2.4 + WLAN 5 GHz Calculated percentage of Limit: 0.77% 0.47% Collocation: 1.19% This prediction demonstrates the following: The power density levels for FCC at a distance of 20 cm are below the maximum levels allowed by regulations. Report no.: 1-2339/21-01-66 © CTC advanced GmbH Page 4 of 4 Prediction of MPE limit at given distance - ISED RSS-102, Issue 5, 2.5.2 RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: • below 20 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1 W (adjusted for tune-up tolerance); • at or above 20 MHz and below 48 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 4.49/ƒ 0.5 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 48 MHz and below 300 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 0.6 W (adjusted for tune-up tolerance); • at or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10 -2 ƒ 0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 5 W (adjusted for tune-up tolerance). Prediction: worst case BT 2402 MHz WLAN 2402 MHz WLAN 5.7 GHz Frequency 2402 2402 5735 MHz R Distance 20 20 20 cm P Max power input to the antenna 3 15 9 dBm G Antenna gain 0.6 0.6 4.3 dBi P G Maximum EIRP 3.6 15.6 13.3 dBm P G Maximum EIRP 2.3 36.3 21.4 mW Exclusion Limit from above: 2.68 2.68 4.85 W Calculated percentage of Limit: 0.09 1.36 0.44 % Scenario 1: BT + WLAN 2.4 MHz Calculated percentage of Limit: % Scenario 2: BT + WLAN 5 GHz Calculated percentage of Limit: % Scenario 3: BT + WLAN 2.4 + WLAN 5 GHz Calculated percentage of Limit: % Collocation: 1.44 1.80 1.88 Conclusion: RF exposure evaluation is not required.

TEST REPORT Test report no.: 1-2339/21-01-58 Testing laboratory Applicant CTC advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://www.ctcadvanced.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2018-03) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate starting with the registration number: D-PL-12076-01. Robert Bosch GmbH Robert-Bosch-Platz 1 70839 Gerlingen / GERMANY Contact: Thomas Dargel e-mail: [email protected] Phone: +49 5121 49-5599 Manufacturer Bosch Car Multimedia Portugal, S.A Rua Max Grundig, 35-Lomar 4705-820 Braga /PORTUGAL Test standard/s FCC - Title 47 CFR Part 15 FCC - Title 47 of the Code of Federal Regulations; Chapter I; Part 15 - Radio frequency devices RSS - 247 Issue 2 Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence - Exempt Local Area Network (LE-LAN) Devices For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Radio System Model name: PSA AIO FCC ID: 2AUXS-PSAAIO IC: 25847-PSAAIO Frequency: 5725 MHz to 5850 MHz Technology tested: WLAN Antenna: Integrated antenna Power supply: 9 V to 16 V DC by external power supply / vehicle battery Temperature range: -30°C to +70°C This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorized: Test performed: Marco Bertolino Rene Oelmann Lab Manager Lab Manager Radio Communications Radio Communications Test report no.: 1-2339/21-01-58 © CTC advanced GmbH Page 2 of 65 1 Table of contents 1 Table of contents ............................................................................................................................................. 2 2 General information ......................................................................................................................................... 4 2.1 Notes and disclaimer ............................................................................................................................ 4 2.2 Application details ................................................................................................................................ 4 2.3 Test laboratories sub-contracted ......................................................................................................... 4 3 Test standard/s, references and accreditations .............................................................................................. 5 4 Reporting statements of conformity – decision rule ...................................................................................... 6 5 Test environment ............................................................................................................................................. 7 6 Test item .......................................................................................................................................................... 7 6.1 General description ............................................................................................................................... 7 6.2 Additional information .......................................................................................................................... 7 7 Sequence of testing ......................................................................................................................................... 8 7.1 Sequence of testing radiated spurious 9 kHz to 30 MHz ..................................................................... 8 7.2 Sequence of testing radiated spurious 30 MHz to 1 GHz .................................................................... 9 7.3 Sequence of testing radiated spurious 1 GHz to 18 GHz ................................................................... 10 7.4 Sequence of testing radiated spurious above 18 GHz ....................................................................... 11 8 Description of the test setup.......................................................................................................................... 12 8.1 Shielded semi anechoic chamber ....................................................................................................... 13 8.2 Shielded fully anechoic chamber ........................................................................................................ 14 8.3 Radiated measurements > 18 GHz ...................................................................................................... 15 8.4 Conducted measurements with peak power meter & spectrum analyzer .......................................... 16 9 Measurement uncertainty .............................................................................................................................. 17 10 Summary of measurement results ......................................................................................................... 18 11 Additional comments .............................................................................................................................. 19 12 Measurement results .............................................................................................................................. 22 12.1 Identify worst case data rate ........................................................................................................... 22 12.2 Antenna gain .................................................................................................................................... 23 12.3 Duty cycle .......................................................................…

Text truncated - open the document above for the full version.

Measurement Results No.1-2339/21-01-58_Annex_MR_A1 Test logging This document is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test/s performed: Michael Dorongovski Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Table of Content EUT Information3 FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-34 ISED Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-38 FCC Part 15.407 & ISED Bandwidths ~ WLAN5Gx n-HT20 mode U-NII-312 ISED Max Output Power and PSD ~ WLAN5Gx a mode U-NII-316 FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx a mode U-NII-320 FCC Part 15.407 & ISED Bandwidths ~ WLAN5Gx a mode U-NII-324 FCC Part 15.407 & ISED Minimum Emission BW ~ WLAN5Gx a mode U-NII-328 FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx ac-VHT40 mode U-NII-330 ISED Max Output Power and PSD ~ WLAN5Gx ac-VHT40 mode U-NII-334 FCC Part 15.407 & ISED Bandwidths ~ WLAN5Gx ac-VHT40 mode U-NII-338 FCC Part 15.407 & ISED Minimum Emission BW ~ WLAN5Gx ac-VHT40 mode U-NII-342 FCC Part 15.407 & ISED Minimum Emission BW ~ WLAN5Gx ac-VHT80 mode U-NII-344 FCC Part 15.407 & ISED Bandwidths ~ WLAN5Gx ac-VHT80 mode U-NII-346 ISED Max Output Power and PSD ~ WLAN5Gx ac-VHT80 mode U-NII-350 FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx ac-VHT80 mode U-NII-354 FCC Part 15.407 & ISED Minimum Emission BW ~ WLAN5Gx n-HT20 mode U-NII-358 2021-07-22Document 1-2339/21-01-58_Annex_MR_A12/59 EUT Information EUT DEFINITION ManufacturerRobert Bosch GmbH TypePSA AIO Serial Number815RB0306M0003084 Setup Number1.0 Version SW014D Version FWNI Version HWC2 HW05 Comment 1 Comment 2 Temperature [°C] Min-30 Temperature [°C] Nom20 Temperature [°C] Max70 Voltage [V] Min9 Voltage [V] Nom13.5 Voltage [V] Max16 2021-07-22Document 1-2339/21-01-58_Annex_MR_A13/59 FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-3 Test References TC Start09.06.2021 14:40:27 Ambit Temp [°C] | Humidity [rel%] 27.1 | 43 System Version3.0.1.2 Test SpecificationFCC Part 15.407 Test MethodKDB789033 D02, F., E.2.e. TC Version0.0.1 My DescriptionFCC 15.407 Max Output Power & PSD - WLAN5Gx n-HT20 mode U- NII-3 Add. Information EUT Common Settings WLAN5Gx Number of Antenna Ports1 User InteractionNo Test Parameter Technology to testWLAN5Gx n-HT20 mode U-NII-3 Antenna Port used1 Temperaturenom Voltagenom Frequency low to testTrue | Freq [MHz] 5745 Frequency mid to testFalse | Freq [MHz] 5785 Frequency high to testFalse | Freq [MHz] 5825 Auto Control enabled Power Supply | Climatic Box No | No Additional Path Loss [dB]0 Switched PathEUT - SignalingUnit - SpectrumAnalyzer Test Equipment Signal analyzer,Rohde&Schwarz,FSV-40,1307.9002K40/101042,3.60 Switch matrix,CTCadvanced,SPM-4 NI DAQ,28016133,NI 2021-07-22Document 1-2339/21-01-58_Annex_MR_A14/59 Test at TX 5745 MHz RESULT: Reference Power cond. Test DescriptionLower LimitUpper LimitMeasuredUnitVerdict Ref. Power 1MHz/1MHz cond. ------2.94dBmINFO Ref. Frequency------5743.000MHzINFO Evaluation max. Duty Cycle Duty Cycle evaluation Test DescriptionLower LimitUpper LimitMeasuredUnitVerdict Result Summary Number of detected Bursts:18 Duty Cycle (Burst Ratio) max ------0.467---INFO Duty Cycle max ------3.307dBINFO Duty Cycle (Burst Ratio) min ------0.322---INFO Duty Cycle min ------4.921dBINFO Max TX Burst Length ------1.95msINFO Min Gap Length------2.2msINFO Max Gap Length------4.1msINFO FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-3 5745 MHz - DutyCycle Evaluation Bandwidth RESULT Test DescriptionLower LimitUpper LimitMeasuredUnitVerdict Bandwidth 26dB------20.12MHzINFO T1 26dB------5734.8800MHzINFO T2 26dB------5755.0000MHzINFO 2021-07-22Document 1-2339/21-01-58_Annex_MR_A15/59 FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-3 20dB Maximum Output Power READ SA SETTINGS: RefLevel [dBm] | RefLevelOffset [dB] | InpAtt [dB]14.94 | 17.38 | 15 Start [MHz] | Stop [MHz]5725.000 | 5765.000 RBW [MHz] | VBW [MHz]1.000000 | 3.000000 Detector | TraceModeRMS | MAXH Sweep: Time [ms] | Count | Points per Section | Type53400 | 1 | 160 | SWE RESULT Test DescriptionLower LimitUpper LimitMeasuredUnitVerdict Max Output Power------2.8dBmINFO Duty Cycle Correction ------4.92dBINFO Limit absolute Max Output Power DC corrected ---307.72dBmPASS Limit by: 11 dBm + 10 log Bandwidth Max Output Power DC corrected ---24.047.72dBmnot applicable FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-3 Max OP and PSD 2021-07-22Document 1-2339/21-01-58_Annex_MR_A16/59 Power Spectral Density U-NII-3 READ SA SETTINGS: RefLevel [dBm] | RefLevelOffset [dB] | InpAtt [dB]14.94 | 17.38 | 15 Start [MHz] | Stop [MHz]5725.000 | 5765.000 RBW [MHz] | VBW [MHz]0.500000 | 3.000000 Detector | TraceModeRMS | MAXH Sweep: Time [ms] | Count | Points per Section | Type53400 | 1 | 160 | SWE RESULT Test DescriptionLower LimitUpper LimitMeasuredUnitVerdict Power Spectral Density -------11.56dBm/0.5MHzINFO Duty Cycle Correction ------4.92dBINFO Power Spectral Density DC corrected ---30-6.64dBm/0.5MHzPASS FCC Part 15.407 Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-3 PSD UNII-3 General verdictPASS 2021-07-22Document 1-2339/21-01-58_Annex_MR_A17/59 ISED Max Output Power and PSD ~ WLAN5Gx n-HT20 mode U-NII-3 Test References TC Start09.06.2021 14:43:10 Ambit Temp [°C] | Humidity [rel%] 27.1 | 43 System Version3.0.1.2 Test SpecificationISED Test Method TC Version0.0.1 My DescriptionISED Max Output Power & PSD - WLAN5Gx n-HT20 mode U-NII-3 Add. Information EUT Common Settings WLAN5Gx Number of Antenna Ports1 User InteractionNo Test Parameter Technology to testWLAN5Gx n-HT20 mode U-NII-3 Antenna Port used1 Temperaturenom Voltagenom Frequency low to testTrue | Freq [MHz] 5745 Frequency mid to testFalse | Freq …

Text truncated - open the document above for the full version.

Annex D 1-2339/21-01-01_AnnexD Setup photos of the Equipment Under Test This addendum is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Michael Dorongovski Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Photo 1 Photo 2 2021-06-28Document No. 1-2339/21-01-01_AnnexD2/7 Photo 3 Photo 4 2021-06-28Document No. 1-2339/21-01-01_AnnexD3/7 Photo 5 Photo 6 2021-06-28Document No. 1-2339/21-01-01_AnnexD4/7 Photo 7 Photo 8 2021-06-28Document No. 1-2339/21-01-01_AnnexD5/7 Photo 9 Photo 10 2021-06-28Document No. 1-2339/21-01-01_AnnexD6/7 Document history VersionApplied changesDate of release initial release2021-06-28 - END OF DOCUMENT - 2021-06-28Document No. 1-2339/21-01-01_AnnexD7/7
