2AVBN-RD3019PROTrail Camera

Instruction Manual WiFi Wildlife Camera 30 Megapixel IPS TFT-LCD Waterproof 120° total PIR angleTrigger time 0.3S 2.4” 30.0 VIDEO 4K Full HD Video function 1. Contents of box 2. Contents 1 3 5 7 8 8 9 10 10 11 12 13 13 14 15 15 15 17 23 23 26 32 33 34 35 35 36 37 39 40 7.4.3. Exit WiFi 41 41 41 3. Hazard, safety and warning notices 4. Introduction • 30Megapixel photo and 4K Full HD video. • • 2.4-2.5GHz 802.11 b/g/n WiFi high-speed up to 150Mbps. • WiFi function, you can preview, download, delete the taken photos and videos directly, take photos and videos, change settings, check battery and memory capacity in APP. • The unique sensor design offers a 120°wider angle of detection and improves the response time of the camera. • Low comsuption 5.0 Bluetooth to activate the WiFi hotspot. • During day, sharp and clear color images and during night time clear black and white images. • Impressively quick trigger time 0.3 seconds, pre boot 0.2 second. • Spray water protected according to standard IP66. • Lockable and password protection. • Date, time, temperature, battery percentage and moon phase can be displayed on the images. • Using the Camera Name function, locations can be encoded on photos. Where several cameras are used, this function allows easier identification of locations when viewing photos. • Possible use under extreme temperatures of between -20°C to 60°C. • Extremely low power consumption in standby operation providing extremely long operating times. (in standby mode up to 6months with 8AA batteries). 2.4GHz ISM frequency bluetooth. 5. Your camera 5.1. Front view Locking bracket Locking bracket 5.2. Inside views 6. Preparing the camera 6.1. Opening and closing the camera Fig . 1.Fig . 2. 6.2. Inserting the batteries Please use the SD/SDHC memory card for U1 CLASS 10 or above. 6.3. Inserting the memory card 256 6.5. Assembly with strap 6.4. External power supply 2.0 6.6. Operation graphi expression Operation(see figures below): Insert U1 CLASS10 or above SD/SDHC memory card in the memory card slot before switching on the camera and select, SETUP mode to adjust settings. Default seting Default seting Return menu setting to defaults Date / Time Date / Time 2020 / 01 / 01 00 : 40 : 31 YY / MM / DD Format Format All data will be deleted 7.2. Operating buttons 7.1. Mode switch 7. Using the camera Functions of operating buttons in standby mode Below, the operating buttons are described in the recording mode with non activated menu. , , , : No function(in standby mode). Functions of operating buttons in replay mode Below, the operating buttons are described in the replay mode with non activated menu. : Change the working mode. : Open the Settings menu using the MENU button. : Enter into deleting or protecting video or photo files. : Press this button to start the replay mode. : Turn on /turn off WiFi hotspot. : Enter into or exit replay mode. : Take a photo or video, or stop recording. : Zoom out the photos. : Zoom in the photos. : Start and pause replay of videos. : Drag left to view photos ofter zoom and skip back the video. : Drag right to view photos ofter zoom and skip ahead the video. : View existing pictures/videos backwards and drag up wards to view photo. : View existing pictures/videos forwards and drag down wards to view photo. SHOT MODE SHOT MODE : Close the Main menu or any sub menu by pressing the MENU button. : Move backwardly to the data setting. : Move forwardly to the data setting. : Move up one menu point or increment value by 1. : Move down one menu point or decrease value by 1. Functions of operating buttons in MENU setting Below, the operating buttons are described in the replay mode with activated menu. (Recording and Replay mode). : Open selected options or accept selected settings. , , : No function (in MENU mode). Confirm each change to a setting by pressing OK. If the change is not confirmed by pressing the OK button, the new setting are lost when leaving the menu. SHOT MODE 7.3. Settings IR LED: Auto/ Economy/ Off• Set the infrared LEDs brightness. • PIR Interval: Defaulted 30seconds, optional from 5seconds ~60minutes Select the shorsetup period for the camera to wait before it reacts to the successive triggering of the main sensor after an animal has first been detected. The camera does not record any images or videos during the selected interval. This prevents the memory card from being filled with unnecessary shots. • Mode: Photo • PIR Sensitivity: High/ Medium/ Low , Video, Photo + Video Select whether photos or videos should be taken when motion is detected. When in the"Photo + Video" mode, the camera first takes a set number of photos prior to recording a video. Note: • The interval time is short, the camera shooting frequency would be high, and there would be high consumption of batteries. It would effect the usage days of the batteries. It is just on the opposite ,the interval time is long, would be a lower consumption of batteries to guarantee a long time usage. Time lapse: Off/On When “on” has been selected, the camera would automatically takes photos/ videos in the selected time interval, irrespective of whether or not the PIR sensor has detected a motion or not. This is useful for observing cold blooded animals e.g. snakes or plants opening up, etc. As soon as the "On" setting has been confirmed by pressing the OK button, you can enter the interval time after which photos/ videos are to be taken. Note: In this mode, the PIR function would stop working, and the camera would take photos/ videos in the setting interval time. • • • Image size : 30M:7392x4160; 24M:6544x3680; 20M:5888x3312; 16M:5376x3024; 12M:4608x2592; 8M: 3840x2160; 5M:2960x1664; 3M:2400x1344; 2M:1920x1088 Select the desired resolution for photos. We recommend the resolution 8M. A higher resolution produces a somewhat better photo quality but results in larger files requiring more space on the memory card. 30M, 24M, 20M, 16M, 12M and 8M resolutions are generated by interpolation which …

Text truncated - open the document above for the full version.

SHENZHEN REDLEAF TECHNOLOGY CO., LTD. 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Date: 2020-12-24 Dear Sir/Madam, We, SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Model No.: RD3019PRO, RD3009PRO, RD3029PRO, RD3039PRO, RD3049PRO, RD3059PRO, RD3079PRO, RD3009WF, RD3019WF, RD3029WF, RD3039WF, RD3049WF, RD3059WF, RD3079WF, RD1006PRO, RD1006T Product Name: Trail Camera FCC ID: 2AVBN-RD3019PRO Sincerely, Name/Title： Ocean Wang /Manager Company: SHENZHEN REDLEAF TECHNOLOGY CO., LTD Address: 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Phone: 13928456051 Fax: 0755-83208897 E-Mail: [email protected]

SHENZHEN REDLEAF TECHNOLOGY CO., LTD. 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Date: 2020-12-24 Model No.: RD3019PRO FCC ID: 2AVBN-RD3019PRO To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, SHENZHEN REDLEAF TECHNOLOGY CO., LTD declare that this EUT (FCC ID: 2AVBN-RD3019PRO) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Ocean Wang /Manager Company: SHENZHEN REDLEAF TECHNOLOGY CO., LTD Address: 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Phone: 13928456051 Fax: 0755-83208897 E-Mail: [email protected]

SHENZHEN REDLEAF TECHNOLOGY CO., LTD. 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2020/12/24 To whom it may concern: We, SHENZHEN REDLEAF TECHNOLOGY CO., LTD.the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AVBN-RD3019PRO including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Ocean Wang /Manager Company: SHENZHEN REDLEAF TECHNOLOGY CO., LTD Address: 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Phone: 13928456051 Fax: 0755-83208897 E-Mail: [email protected]

FCC ID: 2AVBN-RD3019PRO FCC ID: 2AVBN-RD3019PRO FCC ID: 2AVBN-RD3019PRO

FCC ID: 2AVBN-RD3019PRO Trail Camera Model No.: RD3019PRO FCC ID : 2AVBN-RD3019PRO

FCC ID: 2AVBN-RD3019PRO FCC ID: 2AVBN-RD3019PRO FCC ID: 2AVBN-RD3019PRO FCC ID: 2AVBN-RD3019PRO FCC ID: 2AVBN-RD3019PRO FCC ID: 2AVBN-RD3019PRO

RF Exposure evaluation FCC ID: 2AVBN-RD3019PRO Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information HC500 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Antenna type and antenna number Operate frequency band Maximum antenna gain BT ANT / PCB Antenna 2.4GHz – 2.5 GHz 0 dBi 2.4GWIFI ANT / PIFA Antenna 2.4GHz – 2.5 GHz 2.0 dBi 5. Conducted power [2.4GHz WIFI] Mode Channel Frequency Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 18.27 6 2437 18.32 11 2462 18.48 IEEE 802.11g 1 2412 20.01 6 2437 20.11 11 2462 19.78 IEEE 802.11n HT20 1 2412 19.91 6 2437 19.85 11 2462 18.32 [2.4GHz BLE] Mode Channel Frequency Peak Conducted Output Power (dBm) BLE 00 2402 1.013 19 2440 1.067 39 2480 1.232 6. Manufacturing Tolerance 2.4GHz WLAN Frequency (MHz) IEEE 802.11b (Peak) 2412 2437 2462 Target (dBm) 18.0 18.0 18.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) IEEE 802.11g (Peak) 2412 2437 2462 Target (dBm) 20.0 20.0 20.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) IEEE 802.11n HT20 (Peak) 2412 2437 2462 Target (dBm) 19.0 19.0 19.0 Tolerance ± (dB) 1.0 1.0 1.0 2.4GHz BLE Frequency (MHz) GFSK (Peak) 2402 2440 2480 Target (dBm) 1.0 1.0 1.0 Tolerance ± (dB) 1.0 1.0 1.0 7. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of WIFI antenna is 2.0dBi, the gain of BT antenna is 0dBi.the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW WIFI 21.00 125.8925 2.00 1.584893 0.0397 1.0000 BLE 2.00 1.584893 0.00 1.00000 0.0003 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 8. Summary simultaneous transmission results The sample supports 2 antennas for 2.4G WLAN and BT. The BT antenna and WLAN antenna can transmit simultaneous. According to KDB447498 for Transmitters used in mobile exposure conditions for simultaneous transmission operations; ∑ of MPE ratios ≤ 1.0 BLE and WIFI for simultaneous transmission MPE BLE (mW/cm 2 ) MPE wifi (mW/cm 2 ) ∑MPE ratios Limit Results 0.0003 0.0397 0.04 1.0 PASS 9. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20201219005-1-1 2AVBN-RD3019PRO Compiled by ( position+printed name+signature) . : File administrators Jimmy Wang Supervised by ( position+printed name+signature) . : Test Engineer Aaron Tan Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Dec.19, 2020 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Applicant’s name ............................ : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Address ............................................ : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Trail Camera Trade Mark ....................................... : Victure Manufacturer .................................... : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Model/Type reference ...................... : RD3019PRO Listed Models .................................. : RD3019PRO,RD3009PRO,RD3029PRO,RD3039PRO,RD3049PRO, RD3059PRO,RD3079PRO,RD3009WF,RD3019WF,RD3029WF, RD3039WF,RD3049WF,RD3059WF,RD3079WF,RD1006PRO, RD1006T Modulation Type ............................... : CCK/DSSS/ OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 6V From Battery and DC 5V From external circuit Result ............................................... : PASS Report No.: GTS20201219005-1-1 Page 2 of 39 T E S T R E P O R T Test Report No. : GTS20201219005-1-1 Dec.19, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Trail Camera Model /Type : RD3019PRO Listed Models : RD3019PRO,RD3009PRO,RD3029PRO,RD3039PRO,RD3049PRO, RD3059PRO,RD3079PRO,RD3009WF,RD3019WF,RD3029WF, RD3039WF,RD3049WF,RD3059WF,RD3079WF, RD1006PRO, RD1006T Applicant : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Manufacturer : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20201219005-1-1 Page 3 of 39 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 5 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Maximum Conducted Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 31 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 32 6 P H O T O S O F T H E E U T ........................................................... 33 Report No.: GTS20201219005-1-1 Page 4 of 39 1 TES T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: GTS20201219005-1-1 Page 5 of 39 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Nov. 26, 2020 Testing commenced on : Nov. 27, 2020 Testing concluded on : Dec. 19, 2020 2.2 Product Description Product Name: Trail Camera Model/Type reference: RD3019PRO Power supply: DC 6V From Battery and DC 5V From external circuit Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Testing sample ID： GTS2020121…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20201219005-1-2 2AVBN-RD3019PRO Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Dec.19, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Address ............................................ : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Trail Camera Trade Mark ....................................... : Victure Manufacturer .................................... : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Model/Type reference....................... : RD3019PRO Listed Models .................................. : RD3019PRO,RD3009PRO,RD3029PRO,RD3039PRO,RD3049PRO, RD3059PRO,RD3079PRO,RD3009WF,RD3019WF,RD3029WF, RD3039WF,RD3049WF,RD3059WF,RD3079WF,RD1006PRO, RD1006T Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 6V From Battery and DC 5V From external circuit Result................................................ : PASS Report No.: GTS20201219005-1-2 Page 2 of 29 T E S T R E P O R T Test Report No. : GTS20201219005-1-2 Dec.19, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Trail Camera Model /Type : RD3019PRO Listed Models : RD3019PRO,RD3009PRO,RD3029PRO,RD3039PRO,RD3049PRO, RD3059PRO,RD3079PRO,RD3009WF,RD3019WF,RD3029WF, RD3039WF,RD3049WF,RD3059WF,RD3079WF,RD1006PRO, RD1006T Applicant : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Manufacturer : SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20201219005-1-2 Page 3 of 29 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 22 4.6 Out-of-band Emissions 24 4.7 Antenna Requirement 27 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 28 6 P H O T O S O F T H E E U T ........................................................... 29 Report No.: GTS20201219005-1-2 Page 4 of 29 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r05: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: GTS20201219005-1-2 Page 5 of 29 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Nov. 26, 2020 Testing commenced on : Nov. 27, 2020 Testing concluded on : Dec. 19, 2020 2.2 Product Description Product Description: Trail Camera Model/Type reference: RD3019PRO Power supply: DC 6V From Battery and DC 5V From external circuit Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Testing sample ID： GTS20201219005-1-1-1#(Engineer sample), GTS20201219005-1-1-2#(Normal sample) Software version: V1.0 Hardware version: V1.0 Bluetooth BLE Supported type…

Text truncated - open the document above for the full version.

FCC ID: 2AVBN-RD3019PRO _______________________________________________________________________________________________ 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2AVBN-RD3019PRO _______________________________________________________________________________________________ 1.2. Photo of AC Main Emissions Measurement Fig. 3
