2AVBN-RD7000WFTrail Camera

1 2 FCC Warnning: TThis equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. 40

SHENZHEN REDLEAF TECHNOLOGY CO., LTD. 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Date: 2021-05-18 Dear Sir/Madam, We, SHENZHEN REDLEAF TECHNOLOGY CO., LTD. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Model No.: RD7000WF, RD7010WF RD7020WF, RD7030WF,RD7000,RD7010,RD7020, RD7030,T120, T150, T180, H120, H150, H180 Product Name: Trail Camera FCC ID: 2AVBN-RD7000WF Sincerely, Name/Title： Ocean Wang /Manager Company: SHENZHEN REDLEAF TECHNOLOGY CO., LTD Address: 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Phone: 13928456051 Fax: 0755-83208897 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/05/18 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: Model No.: RD7000WF FCC ID: 2AVBN-RD7000WF For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Ocean Wang /Manager Company: SHENZHEN REDLEAF TECHNOLOGY CO., LTD Address: 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Phone: 13928456051 Fax: 0755-83208897 E-Mail: [email protected]

SHENZHEN REDLEAF TECHNOLOGY CO., LTD. 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Date: 2021-05-18 Model No.: RD7000WF FCC ID: 2AVBN-RD7000WF To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, SHENZHEN REDLEAF TECHNOLOGY CO., LTD declare that this EUT (FCC ID: 2AVBN-RD7000WF) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Ocean Wang /Manager Company: SHENZHEN REDLEAF TECHNOLOGY CO., LTD Address: 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Phone: 13928456051 Fax: 0755-83208897 E-Mail: [email protected]

SHENZHEN REDLEAF TECHNOLOGY CO., LTD. 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021/05/18 To whom it may concern: We, SHENZHEN REDLEAF TECHNOLOGY CO., LTD.the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AVBN-RD7000WF including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Ocean Wang /Manager Company: SHENZHEN REDLEAF TECHNOLOGY CO., LTD Address: 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Phone: 13928456051 Fax: 0755-83208897 E-Mail: [email protected]

FCC ID: 2AVBN-RD7000WF FCC ID: 2AVBN-RD7000WF FCC ID: 2AVBN-RD7000WF

FCC ID: 2AVBN-RD7000WF FCC ID:2AVBN-RD7000WF

FCC ID: 2AVBN-RD7000WF FCC ID: 2AVBN-RD7000WF FCC ID: 2AVBN-RD7000WF FCC ID: 2AVBN-RD7000WF

RF Exposure evaluation FCC ID: 2AVBN-RD7000WF Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information RD7000WF can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Antenna type and antenna number Operate frequency band Maximum antenna gain BT ANT / PCB Antenna 2.4GHz – 2.5 GHz 0 dBi 2.4GWIFI ANT / PIFA Antenna 2.4GHz – 2.5 GHz 2.0 dBi 5. Conducted power [2.4GHz WIFI] Mode Channel Frequency Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 18.76 6 2437 18.27 11 2462 17.90 IEEE 802.11g 1 2412 18.10 6 2437 18.64 11 2462 18.60 IEEE 802.11n HT20 1 2412 18.48 6 2437 18.20 11 2462 18.19 [2.4GHz BLE] Mode Channel Frequency Peak Conducted Output Power (dBm) BLE 00 2402 4.31 19 2440 3.80 39 2480 3.60 6. Manufacturing Tolerance 2.4GHz WLAN Frequency (MHz) IEEE 802.11b (Peak) 2412 2437 2462 Target (dBm) 18.0 18.0 18.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) IEEE 802.11g (Peak) 2412 2437 2462 Target (dBm) 18.0 18.0 18.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) IEEE 802.11n HT20 (Peak) 2412 2437 2462 Target (dBm) 18.0 18.0 18.0 Tolerance ± (dB) 1.0 1.0 1.0 2.4GHz BLE Frequency (MHz) GFSK (Peak) 2402 2440 2480 Target (dBm) 4.0 4.0 4.0 Tolerance ± (dB) 1.0 1.0 1.0 7. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of WIFI antenna is 2.0dBi, the gain of BT antenna is 0dBi.the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW WIFI 19.0 79.4328235 2.00 1.584893 0.025058 1.0000 BLE 5.00 3.16227766 0.00 1.000000 0.000629 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 8. Summary simultaneous transmission results The sample supports 2 antennas for 2.4G WLAN and BT. The BT antenna and WLAN antenna can transmit simultaneous. According to KDB447498 for Transmitters used in mobile exposure conditions for simultaneous transmission operations; ∑ of MPE ratios ≤ 1.0 BLE and WIFI for simultaneous transmission MPE BLE (mW/cm 2 ) MPE wifi (mW/cm 2 ) ∑MPE ratios Limit Results 0.025058 0.000629 0.025687 1.0 PASS 9. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20210517026-1-1 2AVBN-RD7000WF Compiled by ( position+printed name+signature) . : File administrators Jimmy Wang Supervised by ( position+printed name+signature) . : Test Engineer Aaron Tan Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : May 17, 2021 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Applicant’s name ............................ : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Address ............................................ : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town, Bao’an District,Shenzhen,China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Trail Camera Trade Mark ....................................... : Trail Camera Manufacturer .................................... : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Model/Type reference ...................... : RD7000WF Listed Models .................................. : RD7010WF RD7020WF, RD7030WF,RD7000,RD7010,RD7020, RD7030,T120, T150, T180, H120, H150, H180 Modulation Type ............................... : CCK/DSSS/ OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 6V From Battery or DC 3.6V From Battery or DC 5V From USB Result ............................................... : PASS Report No.: GTS20210517026-1-1 Page 2 of 40 T E S T R E P O R T Equipment under Test : Trail Camera Model /Type : RD7000WF Listed Models : RD7010WF RD7020WF, RD7030WF,RD7000,RD7010,RD7020, RD7030,T120, T150, T180, H120, H150, H180 Applicant : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Manufacturer : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210517026-1-1 Page 3 of 40 Contents 1 T E S T S T AN D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 5 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Maximum Conducted Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 32 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 33 6 P H O T O S O F T H E E U T ........................................................... 34 Report No.: GTS20210517026-1-1 Page 4 of 40 1 TES T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: GTS20210517026-1-1 Page 5 of 40 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Apr. 24, 2021 Testing commenced on : Apr. 24, 2021 Testing concluded on : May 17, 2021 2.2 Product Description Product Name: Trail Camera Model/Type reference: RD7000WF Power supply: DC 6V From Battery or DC 3.6V From Battery or DC 5V From USB Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Testing sample ID： GTS20210517026-1-1-1#(Engineer sample), GTS20210517026-1-1-2#(Normal sample) Software version: V1.0 Hardware version: V1.0 WIFI : Supported type: 802.11b/802.11g/802.11n(H20) Modulation: 802.11b: DSSS 802.11g/802.11n(H20): OFDM Operation frequency: 802.11b/802.11g/802.11n…

Text truncated - open the document above for the full version.

Report No.: GTS20210517026-1-1 Page 27 of 40 reference 802.11b 802.11g 802.11n(HT20) Report No.: GTS20210517026-1-1 Page 28 of 40 802.11b CH01 CH06 CH11 Report No.: GTS20210517026-1-1 Page 29 of 40 802.11g CH01 CH06 CH11 Report No.: GTS20210517026-1-1 Page 30 of 40 802.11n(HT20) CH01 CH06 CH11 Report No.: GTS20210517026-1-1 Page 31 of 40 Band-edge Measurements for RF Conducted Emissions: 802.11b Left bandedge Right bandedge 802.11g Left bandedge Right bandedge 802.11n(HT20) Left bandedge Right bandedge Report No.: GTS20210517026-1-1 Page 32 of 40 4.7 Antenna Requirement Standard Applicable For intentional device, according to FCC 47 CFR Section 15.203: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited FCC CFR Title 47 Part 15 Subpart C Section 15.247(c) (1) (I): (i) Systems operating in the 2400-2483.5 MHz band that is used exclusively for fixed. Point-to-point operations may employ transmitting antennas with directional gain greater than 6dBi provided the maximum conducted output power of the intentional radiator is reduced by 1 dB for every 3 dB that the directional gain of the antenna exceeds 6dBi. Test Result: The maximum gain of antenna was 2.00 dBi for 2.4GHz WIFI. Report No.: GTS20210517026-1-1 Page 33 of 40 5 T e s t S e t up P h o t os o f t h e EUT Report No.: GTS20210517026-1-1 Page 34 of 40 6 P h o t o s o f t h e E U T Report No.: GTS20210517026-1-1 Page 35 of 40 Report No.: GTS20210517026-1-1 Page 36 of 40 Report No.: GTS20210517026-1-1 Page 37 of 40 Report No.: GTS20210517026-1-1 Page 38 of 40 Report No.: GTS20210517026-1-1 Page 39 of 40 Report No.: GTS20210517026-1-1 Page 40 of 40 ********************** End of Report **********************

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20210517026-1-2 2AVBN-RD7000WF Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : May 17, 2021 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Address ............................................ : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town, Bao’an District,Shenzhen,China Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Trail Camera Trade Mark ....................................... : Trail Camera Manufacturer .................................... : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Model/Type reference....................... : RD7000WF Listed Models .................................. : RD7010WF RD7020WF, RD7030WF,RD7000,RD7010,RD7020, RD7030,T120, T150, T180, H120, H150, H180 Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 6V From Battery or DC 3.6V From Battery or DC 5V From USB Result................................................ : PASS Report No.: GTS20210517026-1-2 Page 2 of 29 T E S T R E P O R T Equipment under Test : Trail Camera Model /Type : RD7000WF Listed Models : RD7010WF RD7020WF, RD7030WF,RD7000,RD7010,RD7020, RD7030,T120, T150, T180, H120, H150, H180 Applicant : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Manufacturer : SHENZHEN REDLEAF TECHNOLOGY CO.,LTD Address : 3F,Building E,Huichao Industrial Park,Gushu Road 2,Xixiang Town,Bao’an District,Shenzhen,China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210517026-1-2 Page 3 of 29 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 22 4.6 Out-of-band Emissions 24 4.7 Antenna Requirement 27 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 28 6 P H O T O S O F T H E E U T ........................................................... 29 Report No.: GTS20210517026-1-2 Page 4 of 29 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: GTS20210517026-1-2 Page 5 of 29 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Apr. 24, 2021 Testing commenced on : Apr. 24, 2021 Testing concluded on : May 17, 2021 2.2 Product Description Product Description: Trail Camera Model/Type reference: RD7000WF Power supply: DC 6V From Battery or DC 3.6V From Battery or DC 5V From USB Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Testing sample ID： GTS20210517026-1-1 -1#(Engineer sample), GTS20210517026-1-1-2#(Normal sample) Software version: V1.0 Hardware version: V1.0 Bluetooth BLE Supported type: Bluetooth low Energy Modulation: GFSK Operation frequency: 2402MHz to 2480MHz Channel number: 40 Channel separation: 2 MHz Antenna type: PCB antenna Antenna gain: 0.0 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / …

Text truncated - open the document above for the full version.

FCC ID: 2AVBN-RD7000WF _______________________________________________________________________________________________ 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2AVBN-RD7000WF _______________________________________________________________________________________________ 1.2. Photo of AC Main Emissions Measurement Fig. 3
