2AVRVANT800BARINDOOR ANTENNA

80-Mile Range Amplified Indoor TV Antenna with Signal Level Indicator ANT800BAR User Manual 1 II. Getting Started 234 Power Supply 2 /16’’ x 1’’ Screws Anchors Digital Converter Box (sold separately - for analog TVs only) TV Here’ s what you’ll need to get set up: I. Included Parts 1 Antenna with Attached Coaxial Cable (9.8’) 2 Make sure the distance between your location and TV transmitter tower is within 80 miles, and set up your antenna as high as possible in the direction of the TV tower for better reception. You can search for available channels in your area by visiting dtv.gov/maps or www.tvfool.com. 80 miles 100 miles Outdoor antenna series Indoor antenna series Weaker signal reception area Weaker signal reception area Strong receivingarea Indoor & Outdoor antenna series III. Key Considerations For Your Installation Site • Be sure that installation is in accordance with all local, city and state electrical and building codes. • Understand where broadcast towers are located in your area. Visit www.antennapoint.com or www.antennaweb.org and enter your zip code to identify the channels you can expect to receive. 3 Step 1: Connect Your Antenna to Your TV Plug the barrel end of the power supply into the DC input on the antenna, and the AC end into an electrical outlet. If your TV has a digital tuner: Simply connect the antenna’s coaxial output cable directly to your TV’s antenna input port. If your TV does not have a digital tuner: Connect the antenna’s coaxial output cable to your digital converter box, and then connect your converter box output cable to your TV. TV ANT IN Coaxial Cable 4 Step 2: Check the LED Signal Indicator The built-in LED signal indicator assists in locating the best channel reception. The LED lights indicate ideal signal strength. Note: You must re-scan for channels anytime you move or reposition your antenna. GOODBETTERBEST To perform a TV channel scan: • Set the tuner mode to “Antenna” or “Air” on your TV’s setup menu. • Set your TV to scan for channels. This may be listed as auto-program, auto-scan, channel search or channel scan. • Move and rotate your antenna, and note which locations receive the most channels and best channel reception. Note: Running a channel scan is not the same as pressing Channel UP/ DOWN on your remote. • Refer to your TV’s user manual for further details. Step 3: Scan for Channels Tuner Mode AB Antenna Channel Search Scanning for Channels 5 Once you have found the optimal location for your antenna, you may choose Step 4: Place Your Antenna 1. Tabletop Placement Place your antenna on a console, table or near your TV. 2. Wall Mounted Use the included 2 /16’’ x 1’’ screws and plastic anchors to mount your antenna to the wall. 34 6 Troubleshooting I am not getting any channels, or channels are missing. Keep your antenna away from sources of interference, including air conditioners, hair dryers and microwave ovens. Move or rotate your antenna and re-run a channel scan on your TV. Refer to your TV’s user manual for more information. Picture or sound freezes while I am watching a channel. Picture quality is weak. This is often caused by a weak or intermittent signal. Try moving or rotating your antenna to a different location or angle. When do I need to run a channel scan? Run a channel scan after setting up or adjusting your antenna. Visit www.antennaweb.org/address to calculate the strength of each station. You may then run a channel scan on an as-needed basis. How do I know where the signal is strongest? Test your antenna in different locations or at different angles, making sure to run a channel scan every time you move your antenna. Sometimes moving a few feet can make a difference. The fewer obstructions between the antenna and the tower, and the higher the antenna is mounted, the better the chance of receiving a strong signal. Some HDTVs have a signal strength indicator that shows how strong your signal is. Refer to your TV’s user manual for more information. Where should I place my antenna? The antenna is designed for indoor use. We recommend placing your antenna on a flat surface or mounting it on a wall near a window. 7 Does my antenna work with any HDTV? Your antenna works with any HDTV or device that has an ATSC tuner. Any TV manufactured after March 1, 2007 is required by US government to have an ATSC tuner. If your TV menu has an option to scan for digital channels, your TV has an ATSC tuner. How many channels will I receive with my antenna? The number of channels will vary from location to location. Generally, if you live in or near a metropolitan area, you will receive more channels than if you live outside a metropolitan area. Keep in mind that antenna reception may vary based on terrain (including trees, buildings, hills and mountains). The fewer the obstructions, the better your chance of receiving strong digital signals. How do I confirm that my antenna is working properly? Connect your antenna to the power supply. Make sure the indicator light is on. Then, plug your antenna into your TV’s tuner, and make sure there are input signals. What should I do if my antenna indicator light is off? If the light does not turn on, please check whether the connector is loose, the plug is not fully inserted or if it is placed incorrectly. Are all broadcasts now in High Definition? Not all digital signals are in High Definition. Make sure your digital receiver is an HD receiver, otherwise HD channels cannot be viewed. Troubleshooting 8 Specifications Need Help? For customer support regarding your device, please submit a request by emailing [email protected]. You will be provided a ticket number regarding your inquiry, which you can refer to when contacting us further. You may also reach a Core Innovations customer service representative by calling 1-833-909-CORE (1-833-909-2673). We are available Monday - Friday, 9am - 5pm PST, except major holidays. Core Innovations strongly urges customers to email their inquiry prior …
