2AVRVANT801DCRINDOOR ANTENNA

with Signal Level Indicator ANT801DCR User Manual 2 II. Getting Started Digital Converter Box (sold separately - for analog TVs only) TV Here’ s what you’ll need to get set up: I. Included Parts 12 Antenna with Attached Coaxial Cable (9.8’) Power Supply 3 Make sure the distance between your location and TV transmitter tower is within 80 miles, and set up your antenna as high as possible in the direction of the TV tower for better reception. You can search for available channels in your area by visiting dtv.gov/maps or www.tvfool.com. 80 miles 100 miles Outdoor antenna series Indoor antenna series Weaker signal reception area Weaker signal reception area Strong receivingarea Indoor & Outdoor antenna series III. Key Considerations for Your Installation Site • Be sure that installation is in accordance with all local, city and state electrical and building codes. • Understand where broadcast towers are located in your area. Visit www.antennapoint.com or www.antennaweb.org and enter your zip code to identify the channels you can expect to receive. 4 Step 1: Connect Your Antenna to Your TV If your TV does not have a digital tuner: Connect the antenna’s coaxial output cable to your digital converter box, and then connect your converter box output cable to your TV. TV ANT IN Coaxial Cable If your TV has a digital tuner: Simply connect the antenna’s coaxial output cable directly to your TV’s antenna input port. Plug the barrel end of the power supply into the DC input on the antenna, and the AC end into an electrical outlet. 5 To perform a TV channel scan: • Set the tuner mode to “Antenna” or “Air” on your TV’s setup menu. • Set your TV to scan for channels. This may be listed as auto-program, auto-scan, channel search or channel scan. • Move and rotate your antenna, and note which locations receive the most channels and best channel reception. Note: Running a channel scan is not the same as pressing Channel UP/ DOWN on your remote. • Refer to your TV’s user manual for further details. Step 3: Scan for Channels Tuner Mode A B Antenna Channel Search Scanning for Channels Step 2: Check the LED Signal Indicator GOODBETTERBEST The built-in LED signal indicator assists in locating the best channel reception. The LED lights indicate ideal signal strength. Note: You must re-scan for channels anytime you move or reposition your antenna. 6 Troubleshooting I am not getting any channels, or channels are missing. Keep your antenna away from sources of interference, including air conditioners, hair dryers and microwave ovens. Move or rotate your antenna and re-run a channel scan on your TV. Refer to your TV’s user manual for more information. Picture or sound freezes while I am watching a channel. Picture quality is weak. This is often caused by a weak or intermittent signal. Try moving or rotating When do I need to run a channel scan? Run a channel scan after setting up or adjusting your antenna. Visit www.antennaweb.org/address to calculate the strength of each station. You may then run a channel scan on an as-needed basis. How do I know where the signal is strongest? run a channel scan every time you move your antenna. between the antenna and the tower, and the higher the antenna is mounted, the better the chance of receiving a strong signal. Some HDTVs have a signal strength indicator that shows how strong your signal is. Refer to your TV’s user manual for more information. Where should I place my antenna? The antenna is designed for indoor use. We recommend placing your 7 Troubleshooting Does my antenna work with any HDTV? Your antenna works with any HDTV or device that has an ATSC tuner. Any TV manufactured after March 1, 2007 is required by US government to have an ATSC tuner. If your TV menu has an option to scan for digital channels, your TV has an ATSC tuner. How many channels will I receive with my antenna? The number of channels will vary from location to location. Generally, if you live in or near a metropolitan area, you will receive more channels than if you live outside a metropolitan area. Keep in mind that antenna reception may vary based on terrain (including trees, buildings, hills and mountains). The fewer the obstructions, the better your chance of receiving strong digital signals. Connect your antenna to the power supply. Make sure the indicator light is on. Then, plug your antenna into your TV’s tuner, and make sure there are input signals. If the light does not turn on, please check whether the connector is loose, the plug is not fully inserted or if it is placed incorrectly. an HD receiver, otherwise HD channels cannot be viewed. 8 Need Help? For customer support regarding your device, please submit a request by emailing [email protected]. You will be provided a ticket number regarding your inquiry, which you can refer to when contacting us further. You may also reach a Core Innovations customer service representative by calling 1-833-909-CORE (1-833-909-2673). We are available Monday - Friday, 9am - 5pm PST, except major holidays. Core Innovations strongly ur ges customers to email their inquiry prior to calling, as this will enable us to better assist you. Please make sure to note the model number and a description of your inquiry. Thank you for purchasing a Core Innovations product. • 80-Mile Range • 1080P Full HD, 4K Ultra HD Ready • Omni-Directional • 3G/4G/5G LTE Filter • Impedance: 75 Ohm • Connector Type: F Male • Adapter Input: 100-240V 50/60Hz 0.3A • Adapter input: 9V-500mA • Coaxial Cable: 9.8’ • Adapter, User Manual, Warranty Card 9 Limited Warranty Core Innovations (the “Company”) warrants the product purchased and contained in this package (the “Product”) against defects in material or workmanship for 90 Days (Parts & Labor) and 1 Year (Limited). In order for the Company to honor this limited warranty, you must present a valid proof of purchase (i.e. a receipt) of this Product. This warranty is void if the Company deems, in its discretion, that the Produ…

Text truncated - open the document above for the full version.

DP AUDIO VIDEO LLC 03 March 2021 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement DP AUDIO VIDEO LLC FCC ID: 2AVRVANT801DCR To Whom It May Concern: We, DP AUDIO VIDEO LLC, hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 03 March 2021. The Limited Agency Agreement expires on 03 March 2022, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, _________________ Roy Ryan 2AVRVANT801DCR General Manager

1(2) DP AUDIO VIDEO LLC Attention: Certification reviewer RE: Request for Confidentiality FCC ID: 2AVRVANT801DCR To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] Schematics Block Diagrams Operational Description Tune-up Procedure Parts List Internal Photos (see note) Users Manual (see note) Note 1: Internal Photos may be held confidential 1) if the circuit board or internal components are not accessible to users. For example, it is acceptable if the circuit board is enclosed in epoxy. 2) Also, it is acceptable if the device is not accessible to the public, for example, a device mounted on the top of a large tower (or in a fenced enclosure) such that it is only serviceable by professional designated technicians under a Non-Disclosure Agreement (NDA). All sales for these devices must be under a NDA restricting the disclosure of the propriety information, including internal photos. Users Manual may be held confidential only when the manual contains proprietary technical information intended fRU SURfeVViRQal WechQiciaQV RbligaWed XQdeU a NDA. All ValeV aQd diVWUibXWiRQ Rf Whe XVeU¶V maQXal mXVW be XQdeU a NDA that restricts the disclosure of the information. In the application cover letter requesting permanent confidentiality the following additional description and the NDA exhibit is required: 1. Describe in detail how internal photos and/or users manual information are controlled to prevent them from becoming public or disclosed to unauthorized persons. 2. Describe how public access is restricted for products serviceable by professional designated technicians. 3. A statement that all sales of the non-consumer device will be under a NDA to include third party sales and that the final user of the device is subject to the NDA. 4. Provide an example of the NDA between the grantee and a purchaser. The request for confidentiality must Note 2: For scanning receiver, the schematics, block diagrams, operational description, tune-up procedure, parts list and internal photos are always held permanently confidential. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request to withhold from public review for a period of [please enter 1 to 180] days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept short-term confidential for a period above from the date of the grant [Select one or more of items below that are not selected in the list above, as appropriate] Schematics Block diagrams Operational Description 2(2) Tune-up Procedure Parts List Test Setup Photos External Photos Internal Photos Users Manual Rationale for request for confidentiality: We have invested considerable time and materials in research and development to produce the referenced product. Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Short-term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. If you have questions or need further information, please contact the undersigned. Sincerely, _________________ Roy Ryan 03 March 2021 General Manager

Page 1 of 3 TEST REPORT Page 2 of 3 TEST REPORT Page 3 of 3 TEST REPORT

Indoor Fabric Antenna Made in Vietnam FCC ID: 2AVRVANT801DCR Model: ANT801DCR Output impedance: 75 ohm 34.6mm 19.6mm Label Location

Page 1 of 3 TEST REPORT Page 2 of 3 TEST REPORT Page 3 of 3 TEST REPORT
