CORE INNOVATIONS TM 14.1” Laptop with Windows™ 10 S CLT146401 User Manual 2 1. This laptop works best in non-tropical areas below 6560 feet (2000 meters). 2. Protect your device from impact from bumps and falls. 3. Do not use this device for extended periods of time in environments that are either too cold, too hot, too humid or too dusty. Do not expose the device to direct sunlight. 4. Avoid using this device in strong magnetic and static environments as much as possible. 5. If the device comes into contact with water or any other liquid, power it off immediately and wait for it to dry completely before turning it on again. 6. Do not clean the device with any cleaning products containing chemicals, to avoid damage caused by corrosion and dampness. When cleaning is necessary, use a dry, soft cloth. 7. The company shall not be held responsible for the loss or deletion of material inside the device caused by abnormal software and hardware operation, maintenance or any other accidents. 8. Please regularly back up important data and files to avoid loss. 9. Please do not disassemble the device by yourself; doing so will void the warranty. Read Before Use 3 Unit at a Glance 1. Power Button: Turn your device on or off. Use to set your device to Sleep or to wake it from Sleep. 2. Front Camera: Take photos and videos. 3. Touchpad: Use the touchpad to move your cursor. 2 5 6 6 1 4 3 14 11 12 13 14 7 9 8 10 FRONTTOP BOTTOM LEFTRIGHT 4 4. Keyboard: Use the keyboard for typing. 5. Indicators: 1 - The first light from the left indicates that the Power is on. 2 - The middle light indicates that Caps Lock is on. 3 - The third is the Num Lock indicator. When this light is on, you may use the secondary keys on your keyboard. 6. Microphone: Transmits audio signals. 7. Charging Indicator: Red light illuminates when connected to a power adapter. 8. Charging Port: 12V/2A charger. 9. USB 3.0 Port: Provides a faster transfer rate to USB devices. 10. Mini-HDMI Port: Connect your laptop to a monitor or TV. 11. USB 2.0 Port: Connect external USB devices. 12. Headphone Jack: Transmit audio signals to speakers or headphones. 13. Micro SD Card Slot: Built-in memory card reader slot that supports Micro SD format up to 64GB. 14. Speakers: Built-in 2x1W speakers allow you to playback sound without connecting external devices. Unit at a Glance (Continued) Fully charge your laptop for at least six hours before initial use. Use the included wall charger. The battery indicator will confirm that your device is charging. Turn your laptop on by pressing and holding the power key for two seconds. Once the screen is loaded, connect to your Wi-Fi network. To wake the screen from sleep, press the power key and the lock screen should appear. Next, press the upwards arrow key () and log in. Sign in if your laptop requires a password to log in. Getting Started Use your information to create a user account. You can use this account to create, modify or remove other accounts on this device. 5 Windows 10 S Start Menu You will see many applications fixed on the Start menu. These apps are displayed in the form of magnets, allowing you to easily visit programs at the click of a button. You will need to log in to your Microsoft account before the applications can fully run. Learn more about Windows 10 S at: https:/ /www.microsoft.com/en-us/windows/s-mode Interface Introduction 6 Microsoft-Verified Security With Windows 10 in S mode, your favorite applications, such as Office, Evernote and Spotify are available from the Microsoft Store where they’re Microsoft-verified for security. Feel secure when you’re online. Microsoft Edge, your default browser, gives you more protection against phishing and socially-engineered malware than Chrome or Firefox. Switching out of S Mode Windows 10 in S mode is designed for security and performance, exclusively running apps from the Microsoft Store. If you want to install an app that isn’t available in the Microsoft Store, you’ll need to switch out of S mode. Note: Switching out of S mode is one-way. If you make the switch, you won’t be able to go back to Windows 10 in S mode. You may switch back only if a software upgrade is made available. We recommend that you back up all your files onto an external hard drive before switching OS. Switching out of S mode is free of charge. To switch out of S Mode, follow these steps: 1. Make sure you are logged into the Microsoft Store. Windows 10 in S Mode 7 2. In the Microsoft Store, search for “Switch out of S Mode.” 3. Click on the Get button. Once the software has downloaded, click on the Install button and follow the onscreen instructions to complete the setup. Windows 10 in S Mode (Continued) 8 In addition to the applications already fixed on the Start Menu, all other apps can be accessed from your laptop’s homepage. To add multiple apps to the Start Menu: 1. Right click on the app icon you wish to pin to the Start Menu 2. Select Pin to Start Conversely, if you want to remove an app from the Start Menu: 1. Right click on the app icon 2. Select Unpin from Start Applications Introduction 9 The Menu bar is located within your Windows Start Menu, found at the bottom of your screen. Menu Bar You can download more apps from the Microsoft Store found on the Windows Start Menu. Note: You need a Microsoft account to be able to download apps. You can create an account by logging on to https://account.microsoft.com/account Once you’ve created an account, go to the Microsoft Store app on your laptop and sign in by clicking the icon. Downloading Apps PC: Allows you to set up, lock and sign out Documents: Opens the Documents folder in your laptop Pictures: Opens the Pictures folder in your laptop Settings: Setup and customize your device Power: Sleep, shutdown or restart your device 10 You can see notifications on the Action Center. The Search Bar can be found in your Start Menu. Use it to find documents or files stored in your device. You can also use the Search Bar to search …

Text truncated - open the document above for the full version.

DPAUDIOVIDEOLLC Date:2020-06-16 To:FederalCommunicationsCommission FCCID:2AVRVCLT146401 ToWhomItMayConcern: ThisletteristoascertainthatDPAUDIOVIDEOLLC MODELNo.:CLT146401,CLT146401BL,CLT146401BU,CLT146401PN, CLT146401PR,CLT146401RD HasbeentheunitsusedforconductingFCCcompliancetesting,theSDoCpartwill betestedbyShenzhenBCTCTestingCo.,Ltd. Ifyouhaveanyquestionorconcerns,pls.contactus. Sincerely, Client’ssignature： Client’sname/title：RoyRyan(Manager) Contactinformation/address:DPAUDIOVIDEOLLC

Rev11/20/07 (DPAUDIOVIDEOLLC) FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID: 2AVRVCLT146401 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram, Schematics, OperationalDescription BlockDiagram Schematics OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. Sincerely, (RoyRyan)

DPAUDIOVIDEOLLC ModelDifference 2020-06-16 EUTNAME:14.1inchnotebook FCCID:FCC:2AVRVCLT146401 MODEL:CLT146401 CLT146401BL,CLT146401BU,CLT146401PN,CLT146401PR, CLT146401RD AllthemodelarethesamecircuitandRFmodule,exceptmodelnames. Regards Sincerely Client’ssignature Client’sname/title:RoyRyan(Manager) Contactinformation/address:10660WILSHIREBLVDLOSANGELES, CaliforniaUnitedStates90024

(DPAUDIOVIDEOLLC) FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Date:2020.6.16 SUBJECT:FCCApplicationforFCCID:2AVRVCLT146401 ToWhomItMayConcern: We,theundersigned,herebyauthorizeAlanMeiatShenzhenBCTCTestingCo.,Ltd. onourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment. AnyandallactscarriedoutbyAlanMeiofShenzhenBCTCTestingCo.,Ltd.onour behalfshallhavethesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, (RoyRyan)

ExternalPhotos

Label&labellocation 38*10.8mm

InternalPhotos

Antenna

RFEXPOSUREEVALUATIONMETHOD FCCID:2AVRVCLT146401 SARTestExclusionThresholdsfor100MHz – 6GHzand ≤ 50mm ApproximateSARTestExclusionPowerThresholdsatSelectedFrequenciesandTestSeparation DistancesareillustratedinthefollowingTable. The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparation distances ≤ 50mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)] · [ √ f(GHz)] ≤ 3.0for1-gSARand ≤ 7.5for10-gextremitySAR,where f(GHz)istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis ≤ 50 mmandfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtest exclusion. BT-EDR maxpossibleoutputpower(PK,conducted)：0±1dbm 1dBilogarithmictermsconverttonumericresultisnearly1.259 1dBm=1.26mW 2402MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=1.26/5*√2.402=0.39≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. Modulation Frequency (MHz) OutputPower (dBm) MaxAntenna Gain(dBi) GFSK 2402 -2.08 1 GFSK 2441 -1.63 1 GFSK 2480 -1.89 1 Pi/4DQPSK 2402 -0.66 1 Pi/4DQPSK 2441 -0.38 1 Pi/4DQPSK 2480 -0.71 1 8DPSK 2402 -0.77 1 8DPSK 2441 -0.37 1 8DPSK 2480 -0.55 1 2441MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=1.26/5*√2.441=0.39≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. 2480MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=1.26/5*√2.48=0.40≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. BT-BLE maxpossibleoutputpower(PK,conducted)：1±1dbm 1dBilogarithmictermsconverttonumericresultisnearly1.259 2dBm=1.58mW 2402MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=1.58/5*√2.402=0.49≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. Modulation Frequency (MHz) OutputPower (dBm) MaxAntenna Gain(dBi) GFSK2402 0.51 1 GFSK 2440 0.91 1 GFSK 2480 0.68 1 2440MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=1.58/5*√2.44=0.50≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. 2480MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=1.58/5*√2.48=0.50≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. WIFI Frequency MaximumConductedOutput Power(PK) LIMIT (MHz)(dBm)dBm 802.11b 24129.23 30 24379.28 30 24629.36 30 802.11g 24128.01 30 24378.58 30 24628.75 30 802.11n20 24128.58 30 24379.29 30 24629.13 30 802.11n40 24227.41 30 24378.21 30 24527.83 30 maxpossibleoutputpower(PK,conducted)：8.5±1dbm 1dBilogarithmictermsconverttonumericresultisnearly1.259 9.5dbm=8.91mW 2412MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=8.91/5*√2.412=2.77≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. 2437MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=8.91/5*√2.437=2.78≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. 2462MHz [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]·[√f(GHz)]=8.91/5*√2.462=2.80≤3.0 ThresholdatwhichnoSARrequiredis10mwand≤3.0for1-gSAR,Separation distanceis5mm. Conclusion:NoSARisrequired.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2005000221-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 1 of 69 FCC Part 15C Test Report FCC ID:2AVRVCLT146401 Product Name: 14.1 inch notebook Trademark: CORE INNOVATIONS Model Name : CLT146401 CLT146401BL, CLT146401BU, CLT146401PN, CLT146401PR, CLT146401RD Prepared For : DP AUDIO VIDEO LLC Address : 920 Malcolm Ave Los Angeles, California, USA 90024 Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: May 08, 2020 – May 18, 2019 Date of Report : May 18, 2019 Report No.: BCTC2005000221-2E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2005000221-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 69 TEST RESULT CERTIFICATION Applicant’s name ............. : DP AUDIO VIDEO LLC Address ............................. : 920 Malcolm Ave Los Angeles, California, USA 90024 Manufacture's Name ........ : ShenZhen South Digital Limited Address ............................. : Building 1, Hao'er Jiashitai Industrial Park, Fengtang Rd,. Tangwei, Fuyong Town, Bao'an District, Shenzhen, China Product description Product name .................... : 14.1 inch notebook Trademark ......................... : CORE INNOVATIONS Model and/or type reference .......................................... : CLT146401 CLT146401BL, CLT146401BU, CLT146401PN, CLT146401PR, CLT146401RD Standards ......................... : FCC Part15.247 ANSI C63.10:2013 558074 D01 15.247 Meas Guidance v05r02 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Kelsey Tan Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2005000221-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 69 Table of Contents Test Report Declaration Page 1. TEST SUMMARY ...................................................... 5 2. TEST FACILITY ....................................................... 6 3. MEASUREMENT UNCERTAINTY........................................ 6 4. GENERAL INFORMATION .............................................. 7 4.1 GENERAL DESCRIPTION OF EUT ...................................... 7 4.2 Test Setup Configuration ................................................ 7 4.3 Support Equipment ..................................................... 8 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................ 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 11 6. CONDUCTED EMISSIONS ............................................. 13 6.1 Block Diagram Of Test Setup ........................................... 13 6.2 Limit ................................................................. 13 6.3 Test procedure ........................................................ 13 6.4 Test Result ........................................................... 15 7. RADIATED EMISSIONS ............................................... 17 7.1 Block Diagram Of Test Setup ........................................... 17 7.2 Limit ................................................................. 18 7.3 Test procedure ........................................................ 18 7.4 Test Result ........................................................... 20 7.5 RADIATED Band EMISSION MEASUREMENT ............................ 24 8. CONDUCTED EMISSION .............................................. 27 8.1 Block Diagram Of Test Setup ........................................... 27 8.2 Limit ................................................................. 27 8.3 Test procedure ........................................................ 27 8.4 Test Result ........................................................... 28 9. 20 DB BANDWIDTH .................................................. 37 9.1 Block Diagram Of Test Setup ........................................... 37 9.2 Limit ................................................................. 37 9.3 Test procedure ........................................................ 37 9.4 Test Result ........................................................... 38 10. MAXIMUM PEAK OUTPUT POWER .................................... 43 10.1 Block Diagram Of Test Setup .......................................... 43 10.2 Limit ................................................................ 43 10.3 Test procedure ....................................................... 43 10.4 Test Result .......................................................... 44 11. HOPPING CHANNEL SEPARATION .................................... 49 11.1 Block Diagram Of Test Setup .......................................... 49 11.2 Limit ................................................................ 49 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2005000221-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 69 11.3 Test procedure ....................................................... 49 11.4 Test Result .......................................................... 50 12. NUMBER OF HOPPING FREQUENCY .................................. 55 12.1 Block Diagram Of Test Setup ..........…
