2AVSB-DC-23FWireless Charger

Specifications DC-23F 15W 产品说明书 User Manual Attention 1.Please do not vigorously extrude or collide. 2.Please do not dismantle or put it into fire or water when the product is power on,to avoid short circuit or leakage. 3.Please do not use it in severely high temperature,high humidity or corrosive environment,to avoid damage to the circuit leakage. 4.Please do not put the magnetic strip or chip card (Such as ID card, bankcard etc.)on the charging pad to avoid to cause magneticcard lose efficacy. 5.Please do not put the metal (Such as coin etc.) on the chargingpad when charging,to avoid damage from heating. 尺寸：340*100mm 双面印刷 材质：128克铜版纸 Indicators and Protection Model：DC-23F Input： 12V/3A,9V/3A Output：15W Max Product Standard：Qi2 Earphone Output：2.5W Watch Output：2.5W Manufacturer:Shenzhen Mgctech Co.,Ltd. FCC ID:2AVSB-DC-23F Charging Distance：≤ 3mm Charging Efficiency：≤70% Product Dimension： 74.1*74.1*46.3mm Product Material：Aluminum Alloy +Tempered Glass Input interface：Type-C port Wireless Charger Product Introduction Product Usage Guide This is a multifunctional desktop magnetic 3 in 1 auto rotation wireless charger, which can wirelessly charge mobile phones, headphones, and watches at the same time by power supply.Bid farewell wired shackles and start wireless experience. 1.Please connect the product through the Type-C quick charging cable to the QC or PD above power adapter,to ensure that it supports fast wireless charging. 2. The mobile phone charging area is foldable and movable, with built-in magnets, to be compatible with magnetic phones and different sizes of Qi-enabled smartphones. 3. Watch charging area is 2.5W output and a movable charging part, push the watch charging area to the right according to the track. Place the Apple Watch or Samsung Watch to start wireless charging with 2.5W output. 4.Earphone charging area is 2.5W output, place the earphone case to start wireless charging with 2.5W output. Fast Wireless Charging requires PD30W or above adapter. Product Parts Description 1. Standby mode: The white light turns on for 10 seconds and then turns off, start the standby mode. 2. Charging mode: When the earphone/watch/mobile phone is charging, the white light turns on for 10 seconds and then turns off. If you take away any device, the light will not turn on, start the standby state. 3. Indicator light: The three indicator lights from left to right are of the mobile phone, earphones, and watch. The three indicator lights are displayed independently. 4. FOD function: when put metal or magnet objects on the charger, the mobile phone indicator light will flash 6 times and stop charging. 5. Perfect protective function based on over-voltage, over-current, over-temperature and short-circuit protection. 4 5 1 Charging area for phone 1 2 Charging area for watch 2 3 Indicator light for phone 3 Indicator light for earphone 4 6 Indicator light for watch 5 Charging area for earphone 7 Type-C input port 8 Lanyard hole 6 7 8 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC RF exposure statement: The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance between 20cm the radiator your body.

底部镭雕 手表镭雕 5.5mm 图案尺寸 logo居中 文案左右居中 镭雕按线稿上文案 11.2mm 23.3mm 40.5mm Wireless Charger Model：DC-23F Input : DC 9V/3A 12V/3A Output : 15W Max Earphone Output：2.5W Watch Output：2.5W Manufacturer:Shenzhen Mgctech Co.,Ltd. FCC ID:2AVSB-DC-23F Made in China 文案尺寸 6mm 8.7mm

Page 1 of 2 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the test setup Model: DC-23F Conducted Emission at AC power line Emissions in frequency bands (below 30MHz) Page 2 of 2 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Emissions in frequency bands (30MHz - 1GHz) MPE

ter of acceptance SPECIFICATION FOR APPROVAL CUSTOMER's name: enzhen lijing technology youxian compa Customer item (CUSTOMER P/N): Name (DESCRIPTION): watch wireless charging coil DATE:2025/4/23 SPECIFICATION: watch coil+adhesive lead is 10mm loEV.NO.:A0 Hongri Shengwei Technology admits to signing and sealing. departm ent Confirmation/ date Audit/dateApproval/date(official seal of the company) qualityDong wanhongLu HuiWei hanman enginee ring He weihuaWei lihongWei lihong Remarks: Signature and seal of lijing science and technology departm Confirmation/ recognition entdateAudit/dateApproval/dateseal of the Develop ment project purchas e quality Remarks: Shenzhen Hongri Shengwei Technology Limited Company HRSW ELECTRONICS CO.,LTD ADD: Floor 2, Building 1, No.48 Guanlan Huanguan Middle Road, Longhua New Dist TEL：+86-755- 23461055 FAX：+86-0755-28015170 page:1/3 SPECIFICATION FOR APPROVAL 1.MECHANICAL DIMENSION (UNIT:mm) 2.SCHEMATICS: Note: the inner hole of this magnetic disk is 10mm. ABD EGI 21±1.014.2±310±53±1.526MAX10 3.W I NDING： 1.1 botto STE PSTART-FINISHWIRE TYPETURNSTAPE N1S-F Hot air line 0.08 * 24mm 2uew 14TS (Ref) 4.ELECTRICAL SPECIFICATION: ITEMLDCRLQ valueHI-POT TES T CON D l plus magnetic shS-F 100KHz,0.25VAT 25°C SPEC6.8uH±10%40mΩ Max 5.BILF OF MATERIAL： NO.ITEMMATERIAL SPECIFICATIONMANUFACTURER 1 Copper wire0.08*24P NANJINGJINNINGCO,LTD 2 Lead-free tin barLead-free tin bar QIAODO 3 magnetic sheet U52 hard magneticTAIYI CO.,LTD 4 glueYellow gum 9999 LIANCHENG CO.,LTD 5 6 gum ⌀ 25*0.1CUDAK CO.,LTD HRSW ELECTRONICS CO.,LTD PART NO TITLE oil+glue-backed lead is 10m DRAWN BYCHECKED BY APPROVED BY He weihuaWei lihongWei lihong page:2/ 2

Letter of acceptance SPECIFICATION FOR APPROVAL CUSTOMER's name: Shenzhen lijing technology co., ltd Customer material number (CUSTOMER P/N): MPP magnetic coil -QI2.0 Name (DESCRIPTION): QI2.0_A.0.1 DATE: 2025-2-18 SPECIFICATION) ：G42.5 slotting+magnetic coil+small magnetic sheet+glue 7 mm. REV.NO.:A0 Hongri Shengwei Technology admits to signing and sealing. department Confirmation/d ate Audit/dateApproval/date (official seal of the company) qualityDong wanhongLu HuiWei hanman engineeringHe weihuaWei lihongWei lihong Remarks: Shenzhen Lijing Technology Co., Ltd. undertakes to sign and seal. department Confirmation/d ate Audit/dateApproval/date (official seal of the company) Development project purchase quality Remarks: Shenzhen Hongri Shengwei Technology Limited Company HRSW ELECTRONICS CO.,LTD ADD: Floor 2, Building 1, No.48 Guanlan Huanguan Middle Road, Longhua New District, Shenzhen TEL：15112254520 FAX：+86-0755-28015170 page:1/2 SPECIFICATION FOR APPROVAL 1.MECHANICAL DIMENSION (UNIT:mm) 2.SCHEMATICS: Remarks: 1. Add 20MM small magnetic disk 2. Add Glue back. ADC HEB 42.5±0.57±20.8±0.052.1MAX3±220.5±0.3 3.WINDING：1.1 bottom STEPSTART-FINISHWIRE TYPETURNSTAPE REMAR K N1S-F Hot air line 0.08 * 80m2uew 11TS (Ref) 4.ELECTRICAL SPECIFICATION: ITEMLDCRtemperatureHI-POT TEST COND Coil plus magnetic sheet S-FNormal state 100KHz,0.25V AT 25°C SPEC7.9uH±10% 58mΩ Max 80°C 5.BILF OF MATERIAL： NO.ITEMMATERIAL SPECIFICATIONMANUFACTURERSGS NO. 1 Hot air lineHot air line 0.08*80 strands NANJINGJINNINGCO,LTD 2 Lead-free tin barLead-free tin bar QIAODO 3 magnetic sheet 42.5 * 0.8 Mn-Zn hard magnetic sheet with L slot. TAIYI CO.,LTD 4 glueYellow gum 9999 LIANCHENG CO.,LTD 5 High temperature adhesive tape 8mm wide high temperature adhesive tapeCUDAK CO.,LTD HRSW ELECTRONICS CO.,LTD PART NO TITLE G42.5 Slotting+magnetic coil+small magnetic sheet+glue 7MM DRAWN BYCHECKED BY APPROVED BY He weihuaWei lihongWei lihong page:2/2

Acknowledgment Letter SPECIFICATION FOR APPROVAL CUSTOMER: LI Jing Technology Co., Lt CUSTOMER P/N: DESCRIPTION : Headphone coil DATE:2024/12/10 SPECIFICATION ： G43.5 Magnetic Shielding Sheet Grooving/0.07*100/Wiring 140MM Hongri Shengwei Technology acknowledges, signs and seals departm ent confirmto examineratify Stamped with the company seal quality Dong Wanhong Lv HuiWei Hanman enginee ring He WeihuaWei LihongWei Lihong notes： Li Jing Technology acknowledges, signs, and stamps departm ent Confirmation/D ate Review/DateApproved/date Stamped with the company seal develop ment enginee procure quality notes： Shenzhen Hongrishengwei Technology Co., Ltd ADD ： 2nd Floor, Building 1, No. 48 Guanlan Huanguan Middle Road, Longhua New District TEL：15112254520/13682412162 page:1/2 SPECIFICATION FOR APPROVAL 1.MECHANICAL DIMENSION (UNIT:mm) 2.SCHEMATICS: Note: Add adhesive backing ABC D2EHII 43.5±0.0320.5±0.20.8±0.0 140±34±22.5MAX5+0.1 3.WINDING： 1 STEPSTART-FINISHWIRE TYPETURNSTAPEREMARK N1S-Fsilk covered wire ⌀ 0.07*100mm 2UEW10TS (Ref) 4.ELECTRICAL SPECIFICATION: ITEMLDCRLWorking temperatureHI-POT TEST COND Coils with magnetic plates S-F Individual coils at room temperature 100KHz,0.25VAT 25°C100KHz,0.25V SPEC6.5uH±10% 70mΩ Max3.8uH±5% 0-80°C 5.BILF OF MATERIAL： NO.ITEMMATERIAL SPECIFICATIONMANUFACTURERSGS NO. 1 0.07 * 100strands of silk wire Acetone silk wrapped wire 0.07 * 100 strands NANJINGJINNINGCO,LTD 2 Solder BarSolder Bar QIAODO 3 magnetic sheet ⌀43.5*0.8Manganese zinc hard magnetic sheets with L slots TAIYI CO.,LTD 4 glueYellow gum 9999 LIANCHENG CO.,LTD 5 High temperature adhesive paper 7mmWide high-temperature adhesive paperCUDAK CO.,LTD 6 Adhesive backing ⌀ 41.8*0.1/3MCUDAK CO.,LTD HRSW ELECTRONICS CO.,LTD PART NO TITLE DRAWN BYCHECKED BY APPROVED BY He WeihuaWei LihongWei Lihong page:2/2

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 1 of 37 TestReport ReportNo.:MTi250612022-0108E1 Dateofissue:2025-08-28 Applicant:ShenzhenMgctechCo.,Ltd. Product:WirelessCharger Model(s):DC-23F,FT01 FCCID:2AVSB-DC-23F ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi250612022-0108E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 2 of 37 Tableofcontents 1GeneralDescription.......................................................................................................................4 1.1DescriptionoftheEUT.........................................................................................................4 1.2Descriptionoftestmodes....................................................................................................5 1.3EnvironmentalConditions....................................................................................................6 1.4Descriptionofsupportunits.................................................................................................6 1.5Measurementuncertainty....................................................................................................6 2SummaryofTestResult................................................................................................................7 3TestFacilitiesandaccreditations................................................................................................8 3.1Testlaboratory.....................................................................................................................8 4Listoftestequipment....................................................................................................................9 5EvaluationResults(Evaluation).................................................................................................10 5.1Antennarequirement.........................................................................................................10 6RadioSpectrumMatterTestResults(RF).................................................................................11 6.1ConductedEmissionatACpowerline..............................................................................11 6.220dBOccupiedBandwidth................................................................................................16 6.3Emissionsinfrequencybands(below30MHz).................................................................23 6.4Emissionsinfrequencybands(30MHz-1GHz)...............................................................29 Photographsofthetestsetup...........................................................................................................35 PhotographsoftheEUT.....................................................................................................................36 TESTREPORT ReportNo.:MTi250612022-0108E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 3 of 37 TestResultCertification ApplicantShenzhenMgctechCo.,Ltd. ApplicantAddress 401,Bldg.14,No.48-12,FuchengaoRd.,PinghuStreet,LonggangDistrict, Shenzhen,China. ManufacturerShenzhenMgctechCo.,Ltd. Manufacturer Address 201,Bldg.C,No.12,FushengRoadPinghuFuchengaoStreet,Longgang District,Shenzhen,China. FactoryShenzhenMgctechCo.,Ltd. Factory Address 201,Bldg.C,No.12,FushengRoadPinghuFuchengaoStreet,Longgang District,Shenzhen,China. Productdescription ProductnameWirelessCharger TrademarkN/A ModelnameDC-23F SeriesModel(s)FT01 Standards47CFRPart15C TestMethodANSIC63.10-2013 TestingInformation Dateoftest2025-07-14to2025-08-27 TestresultPass Preparedby:LetterLan Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi250612022-0108E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 4 of 37 1GeneralDescription 1.1DescriptionoftheEUT Productname:WirelessCharger Modelname:DC-23F SeriesModel(s):FT01 Modeldifference: Boththemodelsarethesamecircuitandmodule,exceptthemodel name. Electricalrating: Input:9V/3A,12V/3A WirelessOutput: Phone:5W,10W,15W Earphone:2.5W Watch:2.5W Accessories: Cable1: Type-CtoType-Ccable1m Cable2: Type-CtoType-Ccable0.15m Hardwareversion:V1.0 Softwareversion:V1.0 Testsample(s)number:MTi250612022-01-R001 RFspecification Operatingfrequency range: Coil1(Phone):115-205kHz(5W,10W,15WEPP) Coil1(Phone):360kHz(15WMPP) Coil2(Earphone):115-205kHz Coil3(AppleWatch):300-350kHz Coil3(SamsungWatch):115-205kHz Modulationtype:ASK TESTREPORT ReportNo.:MTi250612022-0108E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 5 of 37 1.2Descriptionoftestmodes No.Emissiontestmodes Mode1Wirelessoutput(Phone(5W)+Earphone(2.5W)+SamsungWatch(2.5W)) Mode2Wirelessoutput(Phone(10W)+Earphone(2.5W)+SamsungWatch(2.5W)) Mode3 Wirelessoutput(Phone(15WEPP)+Earphone(2.5W)+Samsung Watch(2.5W)) Mode4 Wirelessoutput(Phone(15WMPP)+Earphone(2.5W)+Samsung Watch(2.5W)) Mode5Wirelessoutput(Phone(5W)+Earphone(2.5W)+AppleWatch(2.5W)) Mode6Wirelessoutput(Phone(10W)+Earphone(2.5W)+AppleWatch(2.5W)) Mode7Wirelessoutput(Phone(15WEPP)+Earphon…

Text truncated - open the document above for the full version.

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 1 of 16 TestReport ReportNo.:MTi250612022-0108E2 DateofIssue:2025-08-28 Applicant:ShenzhenMgctechCo.,Ltd. Product:WirelessCharger Model(s):DC-23F,FT01 FCCID:2AVSB-DC-23F ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi250612022-0108E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page2of16 Tableofcontents 1GeneralDescription.............................................................................................................4 1.1DescriptionoftheEUT..........................................................................................................................4 1.2Descriptionoftestmodes......................................................................................................................5 1.3Descriptionofsupportunits...................................................................................................................6 2Measurementuncertainty...................................................................................................6 3Testfacilitiesandaccreditations.......................................................................................7 3.1Testlaboratory.......................................................................................................................................7 4Listoftestequipment..........................................................................................................8 5Testresult.............................................................................................................................9 5.2Testsetup............................................................................................................................................10 5.3TestProcedures...................................................................................................................................10 5.4Informationoftestequipment..............................................................................................................11 5.5Testresults...........................................................................................................................................12 PhotographsoftheTestSetup................................................................................................15 PhotographsoftheEUT...........................................................................................................15 TESTREPORT ReportNo.:MTi250612022-0108E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page3of16 TestResultCertification ApplicantShenzhenMgctechCo.,Ltd. ApplicantAddress 401,Bldg.14,No.48-12,FuchengaoRd,PinghuStreet,LonggangDistrict. Shenzhen,China. ManufacturerShenzhenMgctechCo.,Ltd. Manufacturer Address 201,Bldg.C,No.12,FushengRoadPinghuFuchengaoStreet,LonggangDistrict, Shenzhen,China. FactoryShenzhenMgctechCo.,Ltd. Factory Address 201,Bldg.C,No.12,FushengRoadPinghuFuchengaoStreet,Longgang District,Shenzhen,China. Productdescription ProductnameWirelessCharger TrademarkN/A ModelnameDC-23F SeriesModel(s)FT01 Standards 47CFRPART1,§1.1310 part2.1091 TestmethodKDB680106D01WirelessPowerTransferv04 TestingInformation Dateoftest2025-07-14to2025-08-09 TestResultPass Preparedby:LetterLan Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi250612022-0108E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 4 of 16 1GeneralDescription 1.1DescriptionoftheEUT Productname:WirelessCharger Modelname:DC-23F SeriesModel(s):FT01 Modeldifference: Boththemodelsarethesamecircuitandmodule,exceptthemodel name. Electricalrating: Input:9V/3A,12V/3A WirelessOutput: Phone:5W,10W,15W Earphone:2.5W Watch:2.5W Accessories: Cable: Type-CtoType-Ccable1m Hardwareversion:V1.0 Softwareversion:V1.0 Testsample(s)number:MTi250612022-01-R001 RFspecification Operatingfrequency range: Coil1(Phone):115-205kHz(5W,10W,15WEPP) Coil1(Phone):360kHz(15WMPP) Coil2(Earphone):115-205kHz Coil3(AppleWatch):300-350kHz Coil3(SamsungWatch):115-205kHz Modulationtype:ASK TESTREPORT ReportNo.:MTi250612022-0108E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE014 Ver./Rev.：A1 Page 5 of 16 1.2Descriptionoftestmodes AllthetestmodeswerecarriedoutwiththeEUTinnormaloperation,thefinaltestmodeofthe EUTwastheworsttestmodeforemissiontest,whichwasshowninthisreportanddefinedas: No.Emissiontestmodes Mode1Wirelessoutput(Phone(5W)+Earphone(2.5W)+SamsungWatch(2.5W)) Mode2Wirelessoutput(Phone(10W)+Earphone(2.5W)+SamsungWatch(2.5W)) Mode3 Wirelessoutput(Phone(15WEPP)+Earphone(2.5W)+Samsung Watch(2.5W)) Mode4 Wirelessoutput(Phone(15WMPP)+Earphone(2.5W)+Samsung Watch(2.5W)) Mode5Wirelessoutput(Phone(5W)+Earphone(2.5W)+AppleWatch(2.5W)) Mode6Wirelessoutput(Phone(10W)+Earphone(2.5W)+AppleWatch(2.5W)) Mode7Wirelessoutput(Phone(15WEPP)+Earphone(2.5W)+AppleWatch(2.5W)) Mode8Wirelessoutput(Phone(15WMPP)+Earphone(2.5W)+AppleWatch(2.5W)) Mode9Wirelessoutput(Phone(15WEPP)+AppleWatch(2.5W)) Mode10Wirelessoutput(Pho…

Text truncated - open the document above for the full version.

Page 1 of 6 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (Internal Photos) Model: DC-23F Coil 1 Coil 2 Page 2 of 6 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 3 of 6 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 4 of 6 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 5 of 6 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Coil 1 Page 6 of 6 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

OasisCompliance,Inc.FCCID:2AVSB-DC-23F CFR47§2.911(d)(7)FCCUSAgentLetterofAttestation Date:08/29/2025 FCCID:2AVSB-DC-23FFRN:0029269446 To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ToWhomItMayConcern, ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSAgentonbehalf of ShenzhenMgctechCo.,Ltd. (“theapplicant”)fortheabovereferencedFCCID. Weareawareoftherequirementsandresponsibilitiesoftheapplicant’sagentforserviceof processasoutlinedintheFCCsection2.911(d)(7)andReportandOrderFCC22-84paragraph 63. U.S.AgentInformation: Companyname:OasisCompliance,Inc./JIANMINHE FRN:0033464157 CEO:JamesHe Address:3313VerdiDr,SanJose,CA95111 Cell:2026028330 Email:[email protected] Sincerelyyours, 08/29/2025 JamesHe

Page 1 of 4 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (External Photos) Model: DC-23F Page 2 of 4 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 3 of 4 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 4 of 4 Report No.: MTi250612022-0108 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Mgctech Co., Ltd. Address: 401, Bldg.14, No. 48-12, Fuchengao Rd., Pinghu Street, Longgang District, Shenzhen, China. Product Name: Wireless Charger Model Number: DC-23F, FT01 FCC Identifier: 2AVSB-DC-23F We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Cici Huang Date: 9/1/2025 Title: Overseas Sales Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Shenzhen Mgctech Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 9/1/2025 Subject: Request for Confidentiality FCC ID: 2AVSB-DC-23F To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information…

Text truncated - open the document above for the full version.
