2AVYA-FD24G20RC CLAW TUMBLING WHEELER (Controller)

1234 A B C D 4 321 D C B A ANTENNA 2.4G-TX MCU Crystal oscillator Power Supply=3.0v Functional socket Antenna transmission· 2405~2475MHz 16MHz ESOP8

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Antenna

Function Description: Launch: 1. Power supply 3V to 2.4G main control chip, crystal oscillator to 2.4G main control to provide external frequency. 2. Before operation, after operation, left and right functions are coded by the master control, the signal is modulated and amplified by 2.4G, and then transmitted by the antenna. Frequency Range2405-2475MHz Channel Frequency (MHz) 1 2405 2 2440 3 2475 Frequency list

1234 A B C D 4 321 D C B A VDD3V X1 16MHZ PA3 PA4 PA6 PA3 R1 10K PA4 PA6 VDD 1 PA6 2 PA5 3 PA3 4 PA4 5 XC2 6 XC1 7 ANT 8 GND 9 U1 2.4G TX ESOP8 PA5 560 560 PA6 ANT C1 0.75PF C2 0.75PF L1 4.7NH L2 1NH R2 R3 C3 104 3V VCC SW1 SW-SPDT RZ1 VDD3V SW3SW4 SW1SW2 LED`1
