2AW3IF400TPMS Diagnostic Tool

Shenzhen Xtooltech Intelligent Co., Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Sep 01, 2023
Application Purpose: Original Equipment
Date of Application: Sep 01, 2023
Equipment Note: TPMS Diagnostic Tool
Frequency Range: 2412.00000000 - 2462.00000000
Company: Shenzhen Xtooltech Intelligent Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

ShenzhenXtooltechIntelligentCo.,LTD UserManual Version3.0 Revisedate2023/07 HVIN:TP150 0 TPMS Diagnostic Tool I PleasereadthisusermanualcarefullybeforeusingTP-seriesTPMSDiagnosticTool,referredtoasthe“thetool” throughoutthisdocument.Whenreadingthemanual,pleasepayattentiontothewords“Note”or“Caution”andreadthem carefullyforappropriateoperation.Duetotechnicalupdates,softwareupdate,etc.,someofthepicturesshownonthe manualmightnotbefullyaccurate.Productimagesanddescriptiononlyforreferencepurpose,sopleaseseethesubject produce. O PERATION I NSTRUCTIONS Forsafeoperation,pleasefollowtheinstructionsbelow: Keepthedeviceawayfromheatorfumeswheninuse. Ifthevehiclebatterycontainsacid,pleasekeepyourhandsandskinorfiresourcesawayfromthebatteryduring testing. Theexhaustgasofthevehiclecontainsharmfulchemicals.Pleaseensureadequateventilation. Donottouchthevehiclecoolingsystemcomponentsorexhaustmanifoldswhentheengineisrunningduetothe hightemperaturesreached. Makesurethecarissecurelyparked,NeutralisselectedortheselectorisatthePorNpositiontopreventthe vehiclefrommovingwhentheenginestarts. Makesurethe(DLC)DiagnosticLinkConnectorisfunctioningproperlybeforestartingthetesttoavoiddamageto theDiagnosticComputer. Donotswitchoffthepowerorunplugtheconnectorsduringtesting.DoingsomaydamagetheECU(Electronic ControlUnit)and/ortheDiagnosticComputer. C AUTIONS ! Avoidshaking,droppingordismantlingthescantoolasitmaydamagetheinternalcomponents. Donotuseexcessiveforce; Donotexposethescreentostrongsunlightforalongperiod. Pleasekeepthescantoolawayfromwaterandmoisture. StoreandusethescantoolonlywithinthetemperaturerangesidentifiedintheTechnicalSpecificationssection. Keeptheunitawayfromstrongmagneticfields. Pleaseusesoftandnon-abrasivecleanerandsoftcottonclothtocleankeyboardanddisplayscreen.Donotuse solvent(likealcohol)tocleandevice. AFTERSALES-SERVICES XTOOLstrivestoprovidebest-in-classsupport! E-Mail:[email protected] Tel:+8675521670995or+8675586267858(China) OfficialWebsite:www.xtooltech.com i C ONTENT OPERATIONINSTRUCTIONS.............................................................................................................................I CAUTIONS!...........................................................................................................................................................I AFTERSALES-SERVICES...................................................................................................................................I CONTENT..............................................................................................................................................................I 1.GENERALINTRODUCTION...........................................................................................................................3 MainUnits..........................................................................................................................................................................3 VehicleCommunication.....................................................................................................................................................4 SensorTriggering..............................................................................................................................................................5 ChargingtheDevice..........................................................................................................................................................5 2.TPMSFUNCTIONS..........................................................................................................................................6 MainMenu&ModelSelection...........................................................................................................................................6 SensorCheck&Triggering...............................................................................................................................................7 TPMSDiagnostics.............................................................................................................................................................7 SensorProgramming.........................................................................................................................................................8 Auto-createID...................................................................................................................................................................8 ManuallyinputID...............................................................................................................................................................9 CopyIDviaActivation.......................................................................................................................................................9 CopyIDviaECUInfo......................................................................................................................................................10 TPMSRelearn.................................................................................................................................................................11 SensorInformation..........................................................................................................................................................11 RecentTest.....................................................................................................................................................................11 3.SETTINGS......................................................................................................................................................12 WiFiSettings...................................................................................................................................................................12 Update..........................................................................................................…

Text truncated - open the document above for the full version.

Attestation Statements

Shenzhen Xtooltech Intelligent Co., Ltd Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/30/2023 U.S. Agent Designation Shenzhen Xtooltech Intelligent Co., Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AW3IF400): Name and company of U.S. agent: TianHeng Consulting, LLC Physical U.S. address of agent: 392 Andover Street, Wilmington, MA 01887, United States FRN of U.S. agent: 0033401258 Email address of U.S. agent: [email protected] TianHeng Consulting, LLC acknowledges their obligation to accept service of process on behalf of Shenzhen Xtooltech Intelligent Co., Ltd. Shenzhen Xtooltech Intelligent Co., Ltd with the FRN 0029799749 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Darby Tan Overseas Sales Director Shenzhen Xtooltech Intelligent Co., Ltd Signature Hualing Dong President TianHeng Consulting, LLC 48_[mo del] US_Agent_2.911(d)(7) - U, V05

Cover Letter(s)

Sincerely, Name/Title： Darby Tan/Overseas Sales Director Company: Shenzhen Xtooltech Intelligent Co., Ltd Address: 17&18/F, A2 Building, Creative City, Liuxian Avenue, Nanshan District, Shenzhen China Phone: 0755-83467556 Fax: 0755-83461644 E-Mail: [email protected]

External Photos

ID Label/Location Info

Page1of1FCCID:2AW3IF400 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity LABELANDLOCATION (Size:L3.5cmx4.0cm) TPMSDiagnosticTool TestModel:TP150 FCCID:2AW3IF400 LabelLocation

Internal Photos

RF Exposure Info

Page1of6FCCID:2AW3IF400 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCRFExposureEvaluation 1.ProductInformation FCCID: 2AW3IF400 EUT: TPMSDiagnosticTool TestModel: TP150 AdditionalModelNo.: TP200,TPMS200.F400 ModelDeclaration : PCBboard,structureandinternalofthesemodel(s)arethesame, Sonoadditionalmodelsweretested PowerSupply:Input:DC5V,1A DC3.7VbyRechargeableLi-ionBattery,3000mAh ForACAdapterModel:MX15Z-0502000VU Input:100-240V~,50/60Hz,0.4A Output:5.0V2.0A,10.0W HardwareVersion: / SoftwareVersion: / WIFI(2.4GBand): FrequencyRange:2412MHz-2462MHz ChannelSpacing:5MHz ChannelNumber:11Channelsfor20MHzbandwidth(2412~2462MHz) ModulationType:IEEE802.11b:DSSS(CCK,DQPSK,DBPSK) IEEE802.11g:OFDM(64QAM,16QAM,QPSK,BPSK) IEEE802.11n:OFDM(64QAM,16QAM,QPSK,BPSK) Antenna Description : FPC Antenna, 2.22dBi(Max.) 433MHz Operation frequency : 433.92MHz ModulationType: ASK ChannelNumber: 1 AntennaType: SpringAntenna AntennaGain: -4.58dBi(Max) 315MHzOperationfrequency: 315MHz NumberofChannels: 1 ModulationType: ASK AntennaDescription: SpringAntenna,-5.56dBi(Max.) Exposurecategory: Generalpopulation/uncontrolledenvironment EUTType: ProductionUnit DeviceType: PortableDevice 2.EvaluationmethodandLimit AccordingtoKDB447498D01GeneralRFExposureGuidancev06Section4.3.1StandaloneSAR testexclusionconsiderations:“UnlessspecificallyrequiredbythepublishedRFexposureKDB procedures,standalone1-gheadorbodyand10-gextremitySARevaluationforgeneralpopulation exposureconditions,bymeasurementornumericalsimulation,isnotrequiredwhenthe correspondingSARTestExclusionThresholdcondition,listedbelow,issatisfied.Thesetest Page2of6FCCID:2AW3IF400 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity exclusionconditionsarebasedonsource-basedtime-averagedmaximumconductedoutputpower oftheRFchannelrequiringevaluation,adjustedfortune-uptolerance,andtheminimumtest separationdistancerequiredfortheexposureconditions.22Theminimumtestseparationdistance isdeterminedbythesmallestdistancefromtheantennaandradiatingstructuresoroutersurfaceof thedevice,accordingtothehostformfactor,exposureconditionsandplatformrequirements,toany partofthebodyorextremityofauserorbystander(see5)ofsection4.1).ToqualifyforSARtest exclusion,thetestseparationdistancesappliedmustbefullyexplainedandjustifiedbythe operatingconfigurationsandexposureconditionsofthetransmitterandapplicablehostplatform requirements,typicallyintheSARmeasurementorSARanalysisreport,accordingtotherequired publishedRFexposureKDBprocedures.WhennootherRFexposuretestingorreportingis required,astatementofjustificationandcompliancemustbeincludedintheequipmentapproval,in lieuoftheSARreport,toqualifyfortheSARtestexclusion.Whenrequired,thedevicespecific conditionsdescribedintheotherpublishedRFexposureKDBproceduresmustbesatisfiedbefore applyingtheseSARtestexclusionprovisions;forexample,handheldPTTtwo-wayradios,handsets, laptops&tabletsetc.“ [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gextremitySAR,where: •f(GHz)istheRFchanneltransmitfrequencyinGHz •PoweranddistanceareroundedtothenearestmWandmmbeforecalculation •Theresultisroundedtoonedecimalplaceforcomparison •3.0and7.5arereferredtoasthenumericthresholdsinthestep2below Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50mm andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmaccordingtof)insection4.1isappliedto determineSARtestexclusion. Whenoneofthefollowingtestexclusionconditionsissatisfiedforallcombinationsof simultaneoustransmissionconfigurations,furtherequipmentapprovalisnotrequiredto incorporatetransmittermodulesinhostdevicesthatoperateinthemixedmobileandportablehost platformexposureconditions.ThegranteeisresponsiblefordocumentingthisaccordingtoClassI permissivechangerequirements.AntennasthatqualifyforstandaloneSARtestexclusionmust applytheestimatedstandaloneSARtodeterminesimultaneoustransmissiontestexclusion. a)The[∑of(thehighestmeasuredorestimatedSARforeachstandaloneantennaconfiguration, adjustedformaximumtune-uptolerance)/1.6W/kg]+[∑ofMPEratios]is≤1.0. b)TheSARtopeaklocationseparationratiosofallsimultaneouslytransmittingantennapairs operatinginportabledeviceexposureconditionsareall≤0.04,andthe[∑ofMPEratios]is≤ 1.0. 3.ReferEvaluationMethod ANSIC95.1–1999:IEEEStandardforSafetyLevelswithRespecttoHumanExposuretoRadio FrequencyElectromagneticFields,3kHzto300GHz. FCCKDBpublication447498D01GeneralRFExposureGuidancev06:MobileandPortableDevices RFExposureProceduresandEquipmentAuthorizationPolicies. FCCCFR47part11.1310:Radiofrequencyradiationexposurelimits. FCCCFR47part22.1093:Radiofrequencyradiationexposureevaluation:portabledevices Page3of6FCCID:2AW3IF400 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 4.ConductedPowerResults [2.4GWIFIMaxConductedPower] ModeChannel Frequency (MHz) MaxConducted Power(dBm) 11B 12412-1.83 62437-2.25 112462-2.75 11G 12412-1.97 62437-2.24 112462-3.01 11N20SISO 12412-3.03 62437-3.34 112462-2.32 5.ManufacturingTolerance 2.4GWIFI 11B(Peak) ChannelChannel1Channel6Channel11 Target(dBm)-1.0-2.0-2.0 Tolerance±(dB)1.01.01.0 11G(Peak) ChannelChannel1Channel6Channel11 Target(dBm)-1.0-2.0-3.0 Tolerance±(dB)1.01.01.0 11N20SISO(Peak) ChannelChannel1Channel6Channel11 Target(dBm)-3.0-3.0-2.0 Tolerance±(dB)1.01.01.0 Page4of6FCCID:2AW3IF400 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201…
