NM 3015 QuickInstallation Guid e AX3000 Dual Band WiFi6 Mesh Router Pac kage Con tent  NM3015 x 1  Ethern et Cable x 1 Power Adapter x 1Quick In stallation Guide x 1 Portsandindicators 1. Con necting the mas ter mesh rou ter 1 Take out the ro uter fro mthe box. Connect one end of the networkcable to the Modemor bro adband networkport , and the other end of the networkcable to the WANport of the ro uter. 2 Use the power adapter included in the package to connect NM3015tothepower socket. Wait for about 60seconds.The systemfinishes the startup pro cess and the Wi-F i LEDindicator lights blue. 3 Connect the mesh ro uter to your wire less or wire d device. Wire less: You can find your SSIDand wire less passwordon the device label. Wire d: Use the Ethern et cable to connect a LANport of the mesh ro uter to your computer. 2.Add a slave mesh rou ter 1 Power on a new mesh ro uter. Place it in the wire less covera ge of another mesh ro uter. The best distance is not morethan 20 meters . Please re fer to the following suggestions: Do not exceed two walls between the master mesh ro uter and the slave mesh ro uter, and the maximumdistance should not exceed 20 meters .  Keep away fro minterf ere nce sourc es such as micro wave ovens, induction cookers , re fri gera tors , etc. Better to higher fro mthe gro und and less obstru ctions aro und. 2When the newmesh ro uter is powere d on. Wait for about 60 seconds when it finish the start up pro cess. 3 Make surethe master mesh ro uter is online, pre ss the WPS buttonofthemastermeshro uteandtheslavemeshro ute successively, then the Wi-F i indicator and WPS indicator will start blinking. 4About 2-5minutes later, the WPSindicator of the master mesh ro uter and the newmesh ro uter will go out, and the Wi-F i indicator will turnwhite, meaning that the networkis successfu l. Note :Ifyou want to add another newset of mesh ro uter, please re peat the above steps. LED Indicat or an d Exp lan at ion Name Sta tu sEx planati on Power OnThe ro uter has been turned on. OffThe ro uter has not been turn ed on. Wi-F i Solid re dThe ro uter is off-l ine. Bl inking re dMesh network ing is under way. Solid blueThe ro uter is on-l ine. WPS Off Connect the device successfu lly thro ugh the WPS function, or the mesh networkis successfu l. Bl inking The device is being connected thro ugh WPS function, or Mesh network ing is under way. Button Exp lan at ion NameEx planati on WPSPre ss the button to build mesh network . Hold down the WPS button for about 5 seconds andre leaseit tousetheWPSconnect the device. ResetHold down for about 6 seconds to re storethe factorysettings. FAQ Q1 ： How can I remove a mesh route r fr om my Wi-F i mesh netw ork? A1 ： You can re move your ro uter fro myour networkby re stori ng it to factorysettings. Q2： How to resto re my mesh route r to fa cto ry setti ngs? A2： With your ro uter powere d on, hold down the re set button for about 6 seconds. The LEDindicator light will go out. Then the ro uter will re start automatically and re storeto factorysettings. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules.

Shenzhen SDMC Technology Co.,Ltd. Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3 rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen SDMC Technology Co.,Ltd. Address: Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China Product Name:AX3000 Dual Band WiFi6 Mesh Router，AX3000Dual Band WiFi Mesh Router，Router Mesh Wi-Fi 6 de doble banda AX3000 FCC ID: 2AW68‐NM3015 Model(s):NM3015、NM3015B 2.911(d)(5)(i) Equipment Type We, Shenzhen SDMC Technology Co.,Ltd. certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name:Ryan Yan Date: 2023.4.12 Title and Company name: Manager/Shenzhen SDMC Technology Co.,Ltd. NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen SDMC Technology Co.,Ltd. Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3 rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen SDMC Technology Co.,Ltd. Address:: Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China Product Name:AX3000 Dual Band WiFi6 Mesh Router，AX3000Dual Band WiFi Mesh Router，Router Mesh Wi-Fi 6 de doble banda AX3000 FCC ID: 2AW68‐NM3015 Model(s): NM3015、NM3015B 2.911(d)(5)(ii) Applicant filing We, Shenzhen SDMC Technology Co.,Ltd. certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name:Ryan Yan Date:2023.4.12 Title and Company name: Manager/Shenzhen SDMC Technology Co.,Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen SDMC Technology Co.,Ltd. Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China Agent Authorization Company: Shenzhen SDMC Technology Co.,Ltd. Address: Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China Product Name: AX3000 Dual Band WiFi6 Mesh Router，AX3000Dual Band WiFi Mesh Router，Router Mesh Wi-Fi 6 de doble banda AX3000 Model Number(s): NM3015、NM3015B Product Description:AX3000 Dual Band WiFi6 Mesh Router，AX3000Dual Band WiFi Mesh Router，Router Mesh Wi-Fi 6 de doble banda AX3000 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.4.12 Name: Ryan Yan Title: Manager Company: Shenzhen SDMC Technology Co.,Ltd.

Model Difference Statement Hereby have our company: Shenzhen SDMC Technology Co.,Ltd. Product name：AX3000 Dual Band WiFi6 Mesh Router, AX3000 Dual Band WiFi Mesh Router，Router Mesh Wi‐Fi 6 de doble banda AX3000 Product number：NM3015 ，Series model：NM3015B. Declare that: The above series models are consistent with the main model in terms of schematic diagram, circuit design, circuit layout, hardware version, software version and internal structure, The difference is mainly due to the inconsistency of model name and sales area. Signature： Company：Shenzhen SDMC Technology Co.,Ltd. Date：2023.4.12

Shenzhen SDMC Technology Co.,Ltd. Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China FCC Software Configuration Control Declaration Date: June 8, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: AX3000 Dual Band WiFi6 Mesh Router，AX3000Dual Band WiFi Mesh Router，Router Mesh Wi-Fi 6 de doble banda AX3000/NM3015、NM3015B Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Ryan Yan Date:2023.4.12 Title: Manager Signature of applicant:

1.EUTPHOTO ExternalPhotos EUT-1 EUT-2 EUT-3 EUT-4 EUT-5 EUT-6 EUT-7 EUT-8 EUT-9 EUT-10 EUT-11 EUT-12 EUT-13

贴于机器底部此处 49.4mm 22.5mm Made in China S/N: xxxxxxxxxxxxxxxx MAC: xxxxxxxxxxxx AX3000 Dual Band WiFi6 Mesh Router Model: NM3015 HWV2.0 Default IP: 192.168.1.1 Username: admin Password: admin Input: 12.0V 1.0A SSID: xxxxxx_xxxx Password: 1234567890 5mm 3.2mm 7mm 8mm FCC ID: 2AW68-NM3015 SUBTEL: XXXX

InternalPhotos EUT-1 EUT-2 5GWiFiAntenna1 5GWiFiAntenna2 2.4GWiFiAntenna2 2.4GWiFiAntenna1 EUT-3 EUT-4 EUT-5 EUT-6 EUT-7 EUT-8 EUT-9 -----------EndofReport----------- RFIC

Page 1 of 12 Test Report Verified code: Report No.: E20230322442901-5 Customer: Shenzhen SDMC Technology Co.,Ltd. Address: Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China Sample Name: AX3000 Dual Band WiFi6 Mesh Router Sample Model: NM3015 Receive Sample Date: Mar.23,2023 Test Date: Mar.28,2023 ~ Jun.21,2023 Reference Document: CFR 47, FCC Part 2.1091 Radio frequency radiation exposure evaluation: mobile devices. Test Result: Pass Prepared by: Reviewed by: Approved by: Lu Wei Wu Haoting Xiao Liang GRG METROLOGY & TEST GROUP CO., LTD. Issued Date: GRG METROLOGY & TEST GROUP CO., LTD. Address: No.163,Pingyun Road, West of Huangpu Avenue, Guangzhou, Guangdong, China Tel：（+86）400-602-0999 FAX：（+86）020-38698685 Web：http://www.grgtest.com 487024 2023-06-30 Report No.: E20230322442901-5 Page 2 of 12 Statement 1. The report is invalid without "special seal for inspection and testing"; some copies are invalid; The report is invalid if it is altered or missing; The report is invalid without the signature of the person who prepared, reviewed and approved it. 2. The sample information is provided by the client and responsible for its authenticity; The content of the report is only valid for the samples sent this time. 3. When there are reports in both Chinese and English, the Chinese version will prevail when the language problems are inconsistent. 4. If there is any objection concerning the report, please inform us within 15 days from the date of receiving the report. 5. Without the agreement of the laboratory, the client is not authorized to use the test results for unapproved propaganda. ------------ The following blanks ------------ Report No.: E20230322442901-5 Page 3 of 12 TABLE OF CONTENTS 1. GENERAL DESCRIPTION OF EUT .......................................................................................................... 5 1.1 APPLICANT ................................................................................................................................ 5 1.2 MANUFACTURER ..................................................................................................................... 5 1.3 BASIC DESCRIPTION OF EQUIPMENT UNDER TEST ......................................................... 5 2. LABORATORY AND ACCREDITATIONS .............................................................................................. 7 2.1. LABORATORY ........................................................................................................................... 7 2.2. ACCREDITATIONS .................................................................................................................... 7 3. LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE ............................................ 8 4. CALCULATION METHOD ........................................................................................................................ 9 5. ESTIMATION RESULT ............................................................................................................................ 11 5.1 MEASUREMENT RESULTS .................................................................................................... 11 6. CONCLUSION ........................................................................................................................................... 12 ------------ The following blanks ------------ Report No.: E20230322442901-5 Page 4 of 12 REPORT ISSUED HISTORY Report Version Report No. Description Compile Date 1.0 E20230322442901-5 Original Issue 2023-06-21 ------------ The following blanks ------------ Report No.: E20230322442901-5 Page 5 of 12 1. GENERAL DESCRIPTION OF EUT 1.1 APPLICANT Name: Shenzhen SDMC Technology Co.,Ltd. Address: Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China 1.2 MANUFACTURER Name: Shenzhen SDMC Technology Co.,Ltd. Address: Room 1022, Floor 10, Building A, Customs Building, No. 2, Xin'an 3rd Road, Dalang Community, Xin'an Street, Bao'an District, Shenzhen,China 1.3 BASIC DESCRIPTION OF EQUIPMENT UNDER TEST Product Name: AX3000 Dual Band WiFi6 Mesh Router Adding Product Name: AX3000 Dual Band WiFi Mesh Router, Router Mesh Wi-Fi 6 de doble banda AX3000 Model No.: NM3015 Adding Model: NM3015B Model difference description: The above series models are consistent with the main model in terms of schematic diagram, circuit design, circuit layout, hardware version, software version and internal structure, The difference is mainly due to the inconsistency of model name and sales area. Trade Name: SDMC, D FIBRA FCC ID: 2AW68-NM3015 Power Supply: DC 12.0V power supplied by adapter Adapter Specification: Adapter 1: MODE: SA12BV-120100U INPUT:100-240V~50/60Hz 0.4A OUTPUT:12V 1A 12.0W Adapter 2: MODE:F12L33-120100SPAU INPUT:100-240V~50/60Hz 0.3A OUTPUT:12.0V 1.0A 12.0W Frequency Range: 2412MHz-2462MHz for 802.11b/g/n HT20/ax HE20 2422MHz-2452MHz: 802.11n HT40/ax HE40 U-NII-1: 5180 MHz~5240 MHz U-NII-2A: 5260 MHz~5320 MHz U-NII-2C: 5500 MHz~5720 MHz U-NII-3: 5745 MHz~5825 MHz Transmit Power: Reference Section 4 Table 2 Modulation type: 2.4G wifi: DSSS for 802.11b mode; OFDM for 802.11g/n mode; OFDM , OFDMA for 802.11ax mode; 5G wifi: OFDM, OFDMA. Report No.: E20230322442901-5 Page 6 of 12 Antenna Specification: Reference Section 4 Table 1 Temperature Range: 0°C~40°C Hardware Version: V2.0 Software Version: S09.09.01.002 Sample No: E20230322442901-0002 Note: The EUT antenna gain is provided by the applicant. This report is made solely on the basis of such data and/or information. We accept no responsibility for the authenticity and completeness of the above data and information and the validity of the results and/or conclusions. ------------ The following blanks ------------ Report No.: E20230322442901-5 Page 7 of 12 2. LABORATORY AND ACCREDITATIONS 2.1. LABORATORY The tests & …
