2AW9J-S300LED Wireless Charging Bluetooth Speaker

Alarm clock setting Press the alarm button to enter the clock / minute setting, press / adjust the hour I minute, press the alarm key and then press I select your favorite alarm, there are 7 groups of alarm bells, and finally press the alarm key to open the alarm clock (the alarm mark appears on the screen after successful setting). When the alarm rings, press any key to close the alarm.When no one turns off, the alarm will automatically turn off for I minute(the alarm will ring normally in the shutdown state, please cancel the alarm clock without the need)Cancel alarm setting long press the alarm key (the alarm sign disappears on the screen after successful cancellation) Instructions for using the wireless charging speaker Wireless charger use: plug in the charger to automatically turn on Long press power/ short press light switchLong press function switch BT/NS /FM mode, short press pause /playShort pressthe timing 15/30/60, long press the Bluetooth coupletShort press the next song, long press to add the volumeShort press the last song, long press to reduce the volumeAlarm clock settingClock Settings Technical parameter:Wireless charging power: 15WBluetooth version: 5.3Model Name: S300Output power: 5W*2Bluetoothfrequency: 2.4GHZ-2.48GHZTransmission distance: 10 metersFrequency sound range: 50 HZ-20 KHZSigto noise ratio of whole machine: greater than 75 dbBuilt-in lithium battery voltage: 3.7V Charging input: DC5V/ 500mAProduct size: 180*100*90mmBattery Specifications: 1800mAhOperation description of the key function Start up: long press the start button for two seconds to start up, start up the default heating light : The Bluetooth functionality is available for use.: 1. This audio supports the use of Bluetooth devices with A2DP function, boot default into the Bluetooth mode, Bluetooth indicator blue light shining,accompanied by voice prompt, when the stereo is waiting for pairingconnection, only in this state, can be paired and connected with the Bluetoothaudio 2. Mobile phone connectionThe first step is to open the phone Bluetooth setting switch in the phone Setings and clickthe search deviceThe second step, when the available device displays the S300 character indicating that the phone finds the Bluetooth stereo, click S300 to enter the pairing mode. After the phone is successfully paired with the stereo, there will be a voice prompt and display the connected : TWS couplet function (this function is suitable for Bluetooth mode only) When you have two S300 Bluetooth speakers, by long pressing one of the keys to match, Bluetooth connected to each other, the two speakers will automatically become the letft and right sound channels to produce stereo surround sound effiect, achieving real wireless stereo. Light use1) The S300 Bluetooth speaker is equipped with 13 lighting effects 2) Start the default warm lamp effect of the equipment, and press the light key to adjust the lightFM radio to use:M key long press to switch to the FM function, connect the charging cable to the product type-c intertace as a radio antenna, the other end does not need to connect any equipment, through the pause button to enter the station automatic search and automatically save, the cable station through + -saved station selectionTF card/U disk function for use:By insering the TF card / U disk into the card slot, the corresponding voice prompt will appear. The product will automatically read the audio file in the card and play it. The use can use the voice to control the music with the speaker +- button, Clock SettingPress the time key to enter the clock/ minute setting, press/adjust the hour/minute White noise use:M to switch to white noise mode, press/ choose your favorite sleep music Safety Instructions:1.Do not expose the product into the water or humid areas, such asbathrooms.2.Please do not hit or drop the product hardly to avoid manual damage.3.When not in use for a long time, please turn off the power.Warranty and After Sales Service :If you have any questions during use, please feel free to contact us, we areresponsible for every customer. FCC StatementThis device complies with Part 15 of the FCC rules. Operation i s subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including in terference that may cause undesired operation.Note: This equipment has been tested and found to comply with t he limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These l imits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency e nergy and, if not installed and used in accordance with the instructions, may cau se harmful interference to radio communications. However, there is no guar antee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which ca n be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:--Reorient or relocate the receiving antenna.--Increase the separation between the equipment and receiver.--Connect the equipment into an outlet on a circuit different f rom that to which the receiver is connected.--Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party re sponsible for compliance could void the user’s authority to operate the equip ment. Radiation Exposure StatementThis device complies with RF radiation exposure limits set fort h for an uncontrolled environment. For BT mode The device can be used in portable exposure condition without restriction; For wireless charge mode, this d evice must operate with a minimum distance of 20 cm between the radiator and user body.

Local Representative Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(7), of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2AW9J-S300 S300 We hereby acknowledge as follows: i. both signees confirm that the point of contact accepts responsibility to act as a US- American Representative on behalf of the applicant ii. the point of contact provides the physical U.S. address and email as listed below iii. both parties maintain the requirements of this agreement for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. iv. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. US-American Point of Contact Applicant/Approval Holder Signature Date: 2025-9-19 Signature Date: 2025-9-19 Company Name: GLOCERTS TECHNOLOGY INC Shenzhen Xindongsheng Electronic Technology Co., Ltd. FRN: 0036339737 0034330175 Contact Name: Huiying Fan Shaorong Lin Address: 19784 SUNKISSED RIDGE DR, RIVERSIDE, CA 92507 Xinzhongtai Science Park, Zhu'ao Third Industrial Zone, Gushu Community, Xixiang street Phone: (626) 588-8039 8613728642627 Email: [email protected] [email protected]

Page 1 of 2 FCC ID: 2AW9J-S300 External Photos Page 2 of 2 FCC ID: 2AW9J-S300

Label 1. The label is silk-screen on the sample FCC ID: 2AW9J-S300

Page 1 of 4 FCC ID: 2AW9J-S300 Internal photos Page 2 of 4 FCC ID: 2AW9J-S300 WPC ANT Page 3 of 4 FCC ID: 2AW9J-S300 BT ANT Page 4 of 4 FCC ID: 2AW9J-S300

Page 1 of 7 Report No.:AiTSZ-250908105FW4 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. RF Exposure evaluation Product Name : LED Wireless Charging Bluetooth Speaker Brand Name : N/A Model : S300 Series Model : N/A FCC ID : 2AW9J-S300 Applicant : Shenzhen Xindongsheng Electronic Technology Co., Ltd. Address : Xinzhongtai Science Park, Zhu'ao Third Industrial Zone, Gushu Community, Xixiang street, Baoan Shenzhen, Guangdong, China Manufacturer : Shenzhen Xindongsheng Electronic Technology Co., Ltd. Address : Xinzhongtai Science Park, Zhu'ao Third Industrial Zone, Gushu Community, Xixiang street, Baoan Shenzhen, Guangdong, China Standard(s) : 47CFR §1.1310, 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt : Sep. 08, 2025 Date of Test : Sep. 09, 2025~ Sep. 18, 2025 Issued Date : Sep. 18, 2025 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Aalen.Ye Allen Wang Page 2 of 7 Report No.:AiTSZ-250908105FW4 Report Revise Record Report Version Issued Date Notes M1 Sep. 18, 2025 Initial Release Page 3 of 7 Report No.:AiTSZ-250908105FW4 Contents 1 GENERAL INFORMATION .......................................................................................................................................... 4 1.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 4 1.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 5 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 2 METHOD OF MEASUREMENT ................................................................................................................................... 6 2.1 APPLICABLE STANDARD.................................................................................................................................................. 6 2.2 EVALUATION METHOD AND LIMIT .................................................................................................................................... 6 2.3 MANUFACTURING TOLERANCE ........................................................................................................................................ 7 2.4 EVALUATION RESULT ..................................................................................................................................................... 7 2.5 CONCLUSION ............................................................................................................................................................... 7 Page 4 of 7 Report No.:AiTSZ-250908105FW4 1 GENERAL INFORMATION 1.1 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: 25°C Relative Humidity: 55 % Air Pressure: 101 kPa 1.2 General Description of EUT Product Name: LED Wireless Charging Bluetooth Speaker Model/Type reference: S300 Serial Model: N/A Power Rating: Input: DC 5V 3A，9V 2A Wireless output:5W, 10W, 15W Hardware Version: N/A Software Version: N/A Sample(s) Status: AiTSZ-250908105-1(Normal sample) AiTSZ-250908105-2(Engineer sample) Bluetooth : Supported type: Bluetooth BR/EDR Modulation: GFSK, π/4DQPSK, 8DPSK Operation frequency: 2402MHz~2480MHz Channel number: 79 Channel separation: 1MHz Antenna type: PCB antenna Antenna gain: 1.7dBi Wireless Charger: Operation frequency: 110kHz-205kHz Modulation Technology: ASK Antenna Type: Loop coil Antenna Antenna gain: 0dBi Remark: The above DUT's information was declared by manufacturer. For more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 5 of 7 Report No.:AiTSZ-250908105FW4 1.3 Test Facility Test Laboratory: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China The test facility is recognized, certified or accredited by the following organizations: FCC-Registration No.: 251906 Designation Number: CN1376 Guangdong Asia Hongke Test Technology Limited has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. IC —Registration No.: 31737 CAB identifier: CN0165 The 3m Semi-anechoic chamber of Guangdong Asia Hongke Test Technology Limited has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 31737 A2LA-Lab Cert. No.: 7133.01 Guangdong Asia Hongke Test Technology Limited has been…
