1 IRIS CONNECT User Manual 2 Table of Contents Getting To Know Your Phone ............................................................. 6 Getting Started ................................................................................... 9 Connecting to Mobile Networks ........................................... 16 Connecting to Bluetooth Devices ......................................... 16 Connecting to Your Computer via USB ................................ 17 Connecting to Virtual Private Networks................................ 18 Sharing Files With Nearby Devices ..................................... 19 Sharing Your Mobile Data Connection Through Tethering ... 21 Personalize Your Phone ................................................................... 22 Changing the System Language .......................................... 22 Setting the Date and Time ................................................... 22 Using the Notification Panel ................................................. 23 Changing the Ringtone and Notification Sound ................... 23 Switching to Silent or Vibration Mode .................................. 24 Using Do Not Disturb Mode ................................................. 25 Setting the Home Screen Transition Effect .......................... 26 3 Protecting Your Phone With Screen Locks .......................... 27 Using Your Fingerprint ......................................................... 28 Protecting Your Phone With App Pinning ............................. 30 Phone Calls ...................................................................................... 31 Message Options ................................................................. 33 Email ................................................................................................ 34 Setting Up the First Email Account ...................................... 34 Checking Your Emails .......................................................... 34 Camera ............................................................................................ 35 Customizing Camera and Video Settings ............................ 36 Google Apps ..................................................................................... 37 Changing Settings ............................................................................ 38 Apps..................................................................................... 40 Notifications ......................................................................... 40 Battery ................................................................................. 40 Storage ................................................................................ 41 Sound and vibration ............................................................. 41 4 Display ................................................................................. 41 Wallpaper ............................................................................. 42 Applying New Wallpapers .................................................... 42 Accessibility ......................................................................... 42 Security ................................................................................ 43 Location ............................................................................... 44 Safety and emergency ......................................................... 45 Password and Accounts....................................................... 45 Digital Wellbeing and Parental Controls ............................... 45 Google ................................................................................. 46 System ................................................................................. 46 About Phone ........................................................................ 47 Safety Precautions ........................................................................... 48 Hearing Aid Compatibility (HAC) regulations for Mobile Phones ...... 49 FCC RF Exposure Information (SAR) .............................................. 51 Legal ................................................................................................ 55 5 Welcome! Thank you for choosing IRIS CONNECT. This User Manual will help you get the most out of your new phone. You’ll find instructions to help you begin using your device. If you need more assistance, feel free to contact us by using the contact information listed below. We’re always happy to help you! Need More Information? Visit our website at Consumer Cellular.com/Help Call us at (888) 835-6047 6 Getting To Know Your Phone Microphone 3.5 mm Headset Jack Front Camera LED Indicator Earpiece Volume Keys Home Screen Power Key Recent App Keys Back Key 7 Rear Camera Flash Fingerprint Sensor Battery Cover Speaker Microphone Home Key 8 Key Functions Key Description Power key Press and hold to power off or restart. Press to turn off or on the screen display. Home key Press to return to the home screen from any application or screen. Recent apps key Press to see recently used applications. Back key Press to go to the previous screen. Volume keys Press or hold to turn the volume up or down. 9 Getting Started Initial Setup The Setup Wizard built into your phone will help guide you through this process. NOTE: Your setup may be different than the instructions in this User Manual because of software updates or if you choose different options. If the steps are different, just follow your smartphone's on-screen instructions for setup. Activate the eSIM (electronic SIM) Your IRIS Connect comes with an eSIM and no physical SIM is needed to activate your service. To activate your eSIM, turn on your phone and follow these steps: 1. Select your language and select the keyboard. 2. Select your Wi-Fi network from the list. 3. Download the eSIM. 4. If Download eSIM fails. If you are prompted to scan a QR code, find it in your Consumer Cellular packing slip or email …

Text truncated - open the document above for the full version.

Rev 1/26/2023 START USA, INC. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06/15/2023 Company name: START USA, INC. Address: 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Product Name: LTE Smart Phone FCC ID: 2AWF6-SH4650 Model(s): SH4650 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing We, START USA, INC. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Yours Sincerely, Signature of applicant: Name: Tony Lin Title: CEO

START USA, INC. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06/15/2023 Company name: START USA, INC. Address: 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Product Name: LTE Smart Phone FCC ID: 2AWF6-SH4650 Model(s): SH4650 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing We, START USA, INC. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Yours Sincerely, Signature of applicant: Name: Tony Lin Title: CEO

START USA, INC. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06/ 15/2023 Ref: Attestation Statements Part 2.911(d)(7) Filing We, START USA, INC. (“the applicant”) certifies that, as of the date of the filing of the application, designate our self as U.S. agent for service of process. Designated U.S. Agent Information: Name: START USA, INC. Address: 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Contact Person: Tony Lin Tel.: (+1)972 -688- 6888 Email: [email protected] FRN: 0029586336 Sincerely, Applicant signature: Applicant printed name: Tony Lin Name: START USA, INC. Address: 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Email: [email protected]

FCC Software Configuration Control Declaration.docx FCC Software Configuration Control Declaration Date: 06/15/2023 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: LTE Smart Phone / SH4650 FCC ID: 2AWF6-SH4650 Regarding FCC Country Code Selection guidelines identified in KDB 594280 D02 UNII Device Security v01r03. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Signature of applicant: Name: Tony Lin Title: CEO

Difference Declaration Letter To who concern In addition to RF module, MCU and other key parts of the sample, similar to the came ra LED flash has two manufacturers (the component parameters of the two manufactu rers are the same, do not affect the RF test results).The two manufacturers also have the following materials 2 nd source 1、38V Step-Up LED Driver, BROADCHIP 2、1A Buck/Boost charge pump LED driver, BROADCHIP 3、5.5V Maximum Output, 3A Valley Current, 1MHz，Synchronous Boost with Auto Bypass Function, Silergy 4、LDO,IC,output 1.8V IC,2.3-5.5V,300mA,78dB@f=1KHz,DFN1x1-4L, Boardchip 5、LDO,IC,output 1.2V IC,1.4-5.5V,300mA,78dB@f=1KHz,DFN1x1-4L, Boardchip 6、IC,LDO,BCT2036ELS28-TR,2.8V/300mA,UTDFN1x1-4L,Boardchip 7、IC,LDO,WL2820D30-4/TR,3.0V/300mA,DFN1x1-4L,WILL 8、Ambient light sensor and proximity sensor with Built-in IR LED, Sensortek 9、Analog MEMS Microphone，Xingang 10,38.4MHz;CL=8pF;Thermistor,100k,±10ppm,-30°C~105°C,4250K,±1%,4pin 1.25*1.65*0.65mm(max),SIWARD 10、Flash Light LED, Jingnengguangdian 11、Antenna shrapnel, Shneghou 12、Camera 2 nd source,Shijia 13、3G DDR+32G EMMC 2 nd source, Baiwei 14、4G DDR 2 nd source, Shichuangyi 15、AAC Speaker 2 nd source, Hongshengte Signature: Contact Person: Tony Lin Title: CEO Company: START USA, INC. Address: 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Tel: (+1)972-688-6888 E-Mail: [email protected] 2023/05/10

FCC Letter of Authorization Company: START USA, INC. Address: 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Product Name: LTE Smart Phone Model Number: SH4650 FCC ID: 2AWF6-SH4650 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Tony Lin Date: 2023/06/15 Title: CEO Signature of applicant:

START USA, INC. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 06/ 15/2023 Subject; Request for Confidentiality FCC ID: 2AWF6-SH4650 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM List Tune up procedure Software Security Info In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Tony Lin

MAIN ANT WIFI ANT DIV ANT

Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) Page 1 of 100 SAR TEST REPORT Report No.： 20230417G03483X-W2 Product Name： LTE Smart Phone Model Name： SH4650 Marketing Name： Roadrunner Trade Name： START, Consumer Cellular, Verve, IRIS Brand Name： START, Consumer Cellular, Verve, IRIS FCC ID： 2AWF6-SH4650 Applicant： START USA, INC. Address： 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Test Date： 2023/05/30~2023/06/17 Issued by： CCIC Southern Testing Co., Ltd. Lab Location： Electronic Testing Building, No. 43 Shahe Road Xili Street, Nanshan District，Shenzhen, Guangdong 518055，China Tel： 86 755 26627338 Fax：86 755 26627238 Mail： [email protected] Website http://www.ccic-set.com This test report consists of 100 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) Page 2 of 100 Test Report Applicant: START USA, INC. Applicant Address: 6860 Dallas Parkway, Suite 200, Plano, TX 75024, USA Manufacturer: THINKSTART ELECTRONIC TECHNOLOGY CO., LTD. Manufacturer Address: Unit A1-403, Kexing Science Park, 15 Keyuan Road, Nanshan District, Shenzhen, CHINA Test Standards: 47CFR §2.1093- Radiofrequency Radiation Exposure Evaluation: Portable Devices; ANSI C95.1–1992: Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz – 300 GHz.( IEEE Std C95.1-1991) IEEE 1528–2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques Test Result: Pass Tested by: Carl Wei, Test Engineer 2023-06-25 Reviewed by: Chris You, Senior Engineer 2023-06-25 Approved by: Yang Fan, Manager 2023-06-25 Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) Page 3 of 100 Contents Test Report ........................................................................................................................................... 2 1. Administrative Data ................................................................................................................... 4 2. Equipment Under Test (EUT) ................................................................................................... 5 3. SAR Summary ............................................................................................................................ 7 4. Specific Absorption Rate (SAR).............................................................................................. 10 5. Tissue check and recommend Dielectric Parameters ........................................................... 14 6. SAR measurement procedure ................................................................................................. 19 7. Proximity Sensor Triggering Test ........................................................................................... 20 8. Conducted RF Output Power ................................................................................................. 25 9. Antenna Location:.................................................................................................................... 61 10. Scaling Factor calculation ....................................................................................................... 63 11. Test Results ............................................................................................................................... 67 12. Simultaneous Transmissions Analysis .................................................................................... 91 13. Measurement Uncertainty ....................................................................................................... 95 14. Equipment List ......................................................................................................................... 99 ANNEX A: Appendix A: SAR System performance Check Plots................................................... 100 ANNEX B: Appendix B: SAR Measurement results Plots.............................................................. 100 ANNEX C: Appendix C: Calibration reports .................................................................................. 100 ANNEX D: Appendix D: SAR Test Setup ....................................................................................... 100 Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) Page 4 of 100 1. Administrative Data 1.1 Testing Laboratory Test Site: CCIC Southern Testing Co., Ltd. Address: Electronic Testing Building, No. 43 Shahe Road Xili Street, Nanshan District，Shenzhen, Guangdong 518055，China A2LA Lab Code: CCIC-SET is a third party testing organization accredited by A2LA according to ISO/IEC 17025:2017. The accreditation certificate number is 5721.01 FCC Registration: CCIC Southern Testing Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the FCC (Federal Communications Commission). The acceptance letter from the FCC is maintained in our files. Designation Number: CN1283, valid time is until June 30th, 2023. ISED Registration: CCIC Southern Testing Co., Ltd. EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for the performance of radiated measurements with Registration No. 11185A-1 on Aug. 04, 2016, valid time is until June 30th, 2023. Test Environment Condition: Temperature (°C): 18°C ~25°C Relative Humidity (%): 35%~75% RH Atmospheric Pre…

Text truncated - open the document above for the full version.

Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 1 / 11 Appendix A: SAR System performance Check Plots Measurement Liquid Frequency Test Date System Check Head 750 2023/05/30 System Check Head 835 2023/06/08 System Check Head 1800 2023/06/10 System Check Head 1900 2023/06/09 System Check Head 1900 2023/06/17 System Check Head 2450 2023/06/11 System Check Head 5200 2023/06/12 System Check Head 5400 2023/06/12 System Check Head 5600 2023/06/13 System Check Head 5800 2023/06/13 Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 2 / 11 System Performance Check (750MHz) Type: Validation measurement Date of measurement: 05/30/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=8mm dy=8mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Dipole Band 750MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 750 Relative permittivity (real part) 41.76 Conductivity (S/m) 0.89 Variation (%) -0.41 Maximum location: X=1.00, Y=-5.00 SAR Peak: 0.12 W/kg SAR 10g (W/Kg) 0.059010 SAR 1g (W/Kg) 0.087295 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 3 / 11 System Performance Check (835MHz) Type: Validation measurement Date of measurement: 06/08/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=8mm dy=8mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Dipole Band 835MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 835 Relative permittivity (real part) 41.36 Conductivity (S/m) 0.92 Variation (%) -0.34 Maximum location: X=0.00, Y=-9.00 SAR Peak: 0.12 W/kg SAR 10g (W/Kg) 0.059622 SAR 1g (W/Kg) 0.087127 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 4 / 11 System Performance Check (1800MHz) Type: Validation measurement Date of measurement: 06/10/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=8mm dy=8mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Dipole Band 1800MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 1800 Relative permittivity (real part) 39.63 Conductivity (S/m) 1.38 Variation (%) -0.27 Maximum location: X=0.00, Y=7.00 SAR Peak: 0.56 W/kg SAR 10g (W/Kg) 0.196293 SAR 1g (W/Kg) 0.367352 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 5 / 11 System Performance Check (1900MHz) Type: Validation measurement Date of measurement: 06/09/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=8mm dy=8mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Dipole Band 1900MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 1900 Relative permittivity (real part) 40.19 Conductivity (S/m) 1.40 Variation (%) -0.37 Maximum location: X=0.00, Y=0.00 SAR Peak: 0.64 W/kg SAR 10g (W/Kg) 0.210751 SAR 1g (W/Kg) 0.402910 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 6 / 11 System Performance Check (1900MHz) Type: Validation measurement Date of measurement: 06/17/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=8mm dy=8mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Dipole Band 1900MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 1900 Relative permittivity (real part) 38.96 Conductivity (S/m) 1.43 Variation (%) 0.61 Maximum location: X=1.00, Y=-1.00 SAR Peak: 0.68 W/kg SAR 10g (W/Kg) 0.207012 SAR 1g (W/Kg) 0.408135 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 7 / 11 System Performance Check (2450MHz) Type: Validation measurement Date of measurement: 06/11/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=8mm dy=8mm Zoom Scan 7x7x7,dx=5mm dy=5mm dz=5mm Phantom Validation plane Device Position Dipole Band 2450MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 2450 Relative permittivity (real part) 38.64 Conductivity (S/m) 1.79 Variation (%) -0.23 Maximum location: X=2.00, Y=-5.00 SAR Peak: 0.93 W/kg SAR 10g (W/Kg) 0.235311 SAR 1g (W/Kg) 0.508647 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 8 / 11 System Performance Check (5200MHz) Type: Validation measurement Date of measurement: 06/12/2023 A. Experimental conditions. E-Field Probe SATIMO 0523-EPGO-403 Area Scan dx=8mm dy=8mm Zoom Scan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Validation plane Device Position Dipole Band 5200MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 5200 Relative permittivity (real part) 36.07 Conductivity (S/m) 4.70 Variation (%) -0.91 Maximum location: X=9.00, Y=-2.00 SAR Peak: 4.17 W/kg SAR 10g (W/Kg) 0.556197 SAR 1g (W/Kg) 1.474432 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 9 / 11 System Performance Check (5400MHz) Type: Validation measurement Date of measurement: 06/12/2023 A. Experimental conditions. E-Field Probe SATIMO 0523-EPGO-403 Area Scan dx=8mm dy=8mm Zoom Scan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Validation plane Device Position Dipole Band 5400MHz Channels Middle Signal CW(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 5400 Relative permittivity (real part) 35.74 Conductivity (S/m) 4.95 Variation (%) 0.17 Maximum location: X=2.00, Y=-1.00 SAR Peak: 4.73 W/kg SAR 10g (W/Kg) 0.596093 SAR 1g (W/Kg) 1.603032 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 10 / 11 System Performance Check (5600MHz) Type: Validation measurement Date of measurement: 06/13/2023 A. Experimental conditions. E-Field Probe SATIM…

Text truncated - open the document above for the full version.

Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 1 / 48 Appendix B: SAR Measurement results Plots Plot Frequency/Mode Testing Position and Channel Test Date 1 WCDMA 850 ANT 2 Left Cheek Middle 2023/06/08 2 WCDMA 850 ANT 2 Body Back, Middle ,10mm 2023/06/08 3 WCDMA 850 ANT 3 Left Cheek Middle 2023/06/08 4 WCDMA 850 ANT 3 Body Back, Middle ,10mm 2023/06/08 5 WCDMA 1700 ANT 2 Left Cheek Middle 2023/06/10 6 WCDMA 1700 ANT 2 Body Back, Middle ,10mm 2023/06/10 7 WCDMA 1700 ANT 3 Left Cheek Middle 2023/06/10 8 WCDMA 1700 ANT 3 Body Back, Middle ,10mm 2023/06/10 9 WCDMA 1900 ANT 2 Left Cheek Middle 2023/06/09 10 WCDMA 1900 ANT 2 Body Back, Middle ,10mm 2023/06/09 11 WCDMA 1900 ANT 3 Left Cheek Middle 2023/06/17 12 WCDMA 1900 ANT 3 Body Back, Middle ,10mm 2023/06/17 13 LTE Band 2 ANT 2 Left Cheek High 2023/06/09 14 LTE Band 2 ANT 2 Body Back, Middle ,10mm 2023/06/09 15 LTE Band 2 ANT 3 Left Cheek High 2023/06/17 16 LTE Band 2 ANT 3 Body Back, Low ,10mm 2023/06/17 17 LTE Band 2 ANT 3 Body Bottom Repeat, Middle ,13mm 2023/06/17 18 LTE Band 4 ANT 2 Left Cheek Middle 2023/06/10 19 LTE Band 4 ANT 2 Body Back, Middle ,10mm 2023/06/10 20 LTE Band 4 ANT 3 Left Cheek Middle 2023/06/10 21 LTE Band 4 ANT 3 Body Back, Middle ,10mm 2023/06/10 22 LTE Band 5 ANT 2 Right Cheek Middle 2023/06/08 23 LTE Band 5 ANT 2 Body Back, Middle ,10mm 2023/06/08 24 LTE Band 5 ANT 3 Left Cheek Middle 2023/06/08 25 LTE Band 5 ANT 3 Body Back, Middle ,10mm 2023/06/08 26 LTE Band 12 ANT 2 Right Cheek Middle 2023/05/30 27 LTE Band 12 ANT 2 Body Back, Middle ,10mm 2023/05/30 28 LTE Band 12 ANT 3 Left Cheek Middle 2023/05/30 29 LTE Band 12 ANT 3 Body Back, Middle ,10mm 2023/05/30 30 LTE Band 66 ANT 2 Left Cheek Middle 2023/06/10 31 LTE Band 66 ANT 2 Body Back, Middle ,10mm 2023/06/10 32 LTE Band 66 ANT 3 Left Cheek Middle 2023/06/10 33 LTE Band 66 ANT 3 Body Back, Middle ,10mm 2023/06/10 34 WI-FI 2.4G 802.11b ANT 1 Left Cheek Middle 2023/06/11 35 WI-FI 2.4G 802.11b ANT 1 Body Back, Middle ,10mm 2023/06/11 36 WI-FI 2.4G 802.11b ANT 1 Body Top, Middle ,10mm 2023/06/11 37 WI-FI U-NII 1 802.11a ANT 1 Left Tilted Middle 2023/06/12 38 WI-FI U-NII 1 802.11a ANT 1 Body Back, Middle ,10mm 2023/06/12 39 WI-FI U-NII 2a 802.11a ANT 1 Left Tilted Middle 2023/06/12 40 WI-FI U-NII 2a 802.11a ANT 1 Body Back, Middle ,10mm 2023/06/12 41 WI-FI U-NII 2c 802.11a Left Tilted Middle 2023/06/13 Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 2 / 48 ANT 1 42 WI-FI U-NII 2c 802.11a ANT 1 Body Back, Middle ,10mm 2023/06/13 43 WI-FI U-NII 3 802.11a ANT 1 Left Tilted Middle 2023/06/13 44 WI-FI U-NII 3 802.11a ANT 1 Body Back, Middle ,10mm 2023/06/13 45 Bluetooth ANT 1 Left Cheek Middle 2023/06/11 46 Bluetooth ANT 1 Body Back, Middle ,10mm 2023/06/11 Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 3 / 48 Testing result (WDCMA850 ANT 2, Left Cheek, Middle, 0mm) Type: phone measurement Date of measurement: 06/08/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Left Head Device Position Cheek Band WCDMA850 Channels Middle Signal WCDMA(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 836.6 Relative permittivity (real part) 41.36 Conductivity (S/m) 0.92 Variation (%) 0.24 Maximum location: X=-11.00, Y=-27.00 SAR Peak: 0.04 W/kg SAR 10g (W/Kg) 0.023948 SAR 1g (W/Kg) 0.030994 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 4 / 48 Testing result (WCDMA850 ANT 2, Back, Middle, 10mm) Type: phone measurement Date of measurement: 06/08/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Validation plane Device Position Body Band WCDMA850 Channels Middle Signal WCDMA(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 836.6 Relative permittivity (real part) 41.36 Conductivity (S/m) 0.92 Variation (%) -2.12 Maximum location: X=-10.00, Y=15.00 SAR Peak: 0.07 W/kg SAR 10g (W/Kg) 0.029154 SAR 1g (W/Kg) 0.045268 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 5 / 48 Testing result (WDCMA850 ANT 3, Left Cheek, Middle, 0mm) Type: phone measurement Date of measurement: 06/08/2023 A. Experimental conditions. E-Field Probe SATIMO SN 32/22 EPGO383 Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Phantom Left Head Device Position Cheek Band WCDMA850 Channels Middle Signal WCDMA(Crest factor: 1.0) B. SAR Measurement Results Frequency (MHz) 836.6 Relative permittivity (real part) 41.36 Conductivity (S/m) 0.92 Variation (%) -1.65 Maximum location: X=-51.00, Y=-31.00 SAR Peak: 0.34 W/kg SAR 10g (W/Kg) 0.236086 SAR 1g (W/Kg) 0.293323 SURFACE SAR VOLUME SAR Z Axis Scan Report No. 20230417G03483X-W2 CCIC-SET/TRF:ISAR(2021-05-11) 6 / 48 Testing result (WCDMA850 ANT 3, Back, Middle, 10mm) Type: phone measurement Date of measurement: 06/08/2023 A. Experimental …
