JOYROOM 2-in-1 15W Wireless Charger Instruction Manual Please read this instructions carefully and keep it properly. Product Description Thanks for your choosing JOYROOM, this is a 2-in-1 wireless charger, which supports charging two devices simultaneously or one smartphone & iPods. It adopts PC fireproof material, strong power with faster charging efficiency, with a blue indicator light to monitor the charging status from time to time. It uses high-end chipset and has over-temperature. Over-current, over-discharge, overcharge and other multiple protections. Brand：JOYROOM Name：2-in-1 15W wireless charger Model：JR-A26 Material：PC + ABS fireproof material Port：Type-C Input Input：5V-2.4A 9V-2A 12V-1.5A (It is recommended to match a high-power adapter with 18W above) Output：5W/7.5W/10W/15W Compatibility：Support wireless charging equipment that meets QI standards Size：17*8.5*9.5mm Net weight：129g Note: The above parameters are derived from the actual measurement of the product, the actual parameters will vary due to the product or other factors. Packing list wireless charger*1 Data cable*1 Manual*1 Warranty Card*1 Instructions 1. The blue LED indicator light will be on after power-on. 2. Put on the wireless receiving device that supports QI standard, enter the charging state after the product is aligned, the blue indicator light flashes ,the Indicator light is always on when it is full. 3. When charging, you need to keep the center of the phone aligned with the center of the wireless charger to perform wireless charging. If it can’t work normally, please adjust the position of the phone until the phone shows normal charging. 4. When wireless charging encounters a metal foreign body, the wireless charger will automatically activate the FOD foreign body alarm function, and the indicator light will flash quickly, remove the metal foreign body, you can charge normally. 1. It is recommended to use a high-power adapter with18W above for better experience. 2. Please try to avoid placing metal objects on the contact surface during charging, such as patches, finger rings, metal protective shells, etc. 3. If you find intermittent charging or severe heating while charging the mobile phone, it is likely that the receiving coil of the mobile phone and the wireless charging coil are not accurately aligned, please try to cool the mobile phone, and then perform the correct position alignment. 4. This product has input over-current and over-voltage protection function, if improper use will shut down or reduce the output power, please check whether the equipment is abnormal or improper use. 5. When using, keep the ambient temperature at 0-25°C as much as possible. Please avoid putting the product in water, fire, high (>40°C) and too low temperature (<-20°C) environment, and keep children away from accessories. 6. Please use a dry soft cloth to clean the surface and avoid cleaning with chemicals, soap or detergent. 7. The user's improper use or improper placement of this product may cause the product's life to be reduced or damaged, and the resulting liability does not belong to the scope of the warranty or the manufacturer's responsibility, please understand. Brand name:JOYROOM Brand Manufacturer:Shen zhen Nito Power Technology Co.,Ltd Address:RF1.2,No.8Building,No.49Wu he Nan Rd.,Jin fang hua Electricity Industrial Park,Ban tian St.,Long gang District,Shen zhen,China Executive standard:GB4943.1-2011 Tel:400-830-3321 Website:www.joyroom.com This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

SHENZHEN NITO POWER SOURCE TECHNOLOGY CO., LTD. 201, No.8 Building, Jinfanghua Electricity Industrial par k, Bantian St., Longgang Dist., Shenzhe， China Confirmation letter· Hereby declaration: For this application product: 2-in-1 15W Wireless Charger, Between models: JR-A26, JR-A23, JR-A20, JR-A 15, JR-A 12, JR-A16, JR-A27, JR”A28, JR-A29, JR-A30, JR-A3 1, JR-A32, JR-A33, JR-A35, JR-A36, JR-A37, JR-A39 only the color and model name is different, the electrical circuit design, layout, components used and internal wiring are identical. Signature:

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E1 Page 31 of 36 9 Photos of the EUT Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E1 Page 32 of 36 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E1 Page 33 of 36

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E1 Page 34 of 36 wireless charger antenna Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E1 Page 35 of 36 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E1 Page 36 of 36 END OF REPORT

Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R20081721-1E2 Page 1 of 11 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : SHENZHEN NITO POWER SOURCE TECHNOLOGY CO.,LTD. Address : 201, No.8 Building, Jinfanghua Electricity Industrial park, Bantian St., Longgang Dist., Shenzhen, China Equipment under Test : 2-in-1 15W Wireless Charger Model No. : JR-A26, JR-A23, JR-A20, JR-A15, JR-A12, JR-A16, JR-A27, JR-A28, JR-A29, JR-A30, JR-A31, JR-A32, JR-A33, JR-A35, JR-A36, JR-A37, JR-A39 Trade Mark : JOYROOM FCC ID : 2AWL2-JR-A26 Manufacturer : SHENZHEN NITO POWER SOURCE TECHNOLOGY CO.,LTD. Address : 201, No.8 Building, Jinfanghua Electricity Industrial park, Bantian St., Longgang Dist., Shenzhen, China Report No.: DDT-R20081721-1E2 Issued Date: Nov. 04, 2020 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-R20081721-1E2 Page 2 of 11 Table of Contents Test report declares........................................................................................................3 1. General Information ....................................................................................................... 5 1.1. Description of equipment ............................................................................................... 5 1.2. Assistant equipment used for test .................................................................................. 5 1.3. Assess laboratory ........................................................................................................... 5 2. Equipment used during test ........................................................................................... 5 3. Method of Measurement ................................................................................................ 6 3.1. Applicable standard ........................................................................................................ 6 3.2. Block diagram of test setup ............................................................................................ 6 3.3. Test procedure ............................................................................................................... 6 3.4. Equipment approval considerations:.............................................................................. 7 3.5. E and H Field Strength ................................................................................................... 8 4. Test Setup Photo ............................................................................................................ 9 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT -R20081721-1E2 Pag e 3 of 11 Test Report Declare Assess Standard Used: FCC CFR 47 part1, 1.1307(b), 1.1310; KDB680106 D R03 -44118 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd and i n the configuration assessed the equipment complied with the standards specified above. The asse ssed res ults are contained in this report and Dongguan Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above stan dard. Report No: DDT -R20081721-1E2 Date of Receipt: Aug . 1 9, 20 20 Date of Test: Aug. 19, 2020 ~ Nov . 04 , 20 20 Prepared By: Approved By: _______________ ____________________ Sam Li/ Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : SHENZHEN NITO POWER SOURCE TECHNOLOGY CO.,LTD. Address : 201, No.8 Building, Jinfanghua Electricity Industrial park, Bantian St., Longgang Dist., Shenzhen, China Equipment : 2-in -1 15W Wireless Charger Model No. : JR-A26, JR-A23, JR-A20, JR-A15, JR-A12, JR-A16, JR-A27, JR-A28, JR-A29, JR-A30, JR-A31, JR-A32, JR-A33, JR-A35, JR-A36, JR-A37, JR-A39 Trade Mark : JOYROOM Manufacturer : SHENZHEN NITO POWER SOURCE TECHNOLOGY CO.,LTD. Address : 201, No.8 Building, Jinfanghua Electricity Industrial park, Bantian St., Longgang Dist., Shenzhen, China Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E2 Page 4 of 11 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Nov. 04, 2020 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R20081721-1E2 Page 5 of 11 1. General Information 1.1. Description of equipment Note: EUT is the ab. of equipment under test. 1.2. Assistant equipment used for test Description of Accessories Manufacturer Model number Serial No. Other Mobile phone 1 / / / / Mobile phone 2 / / / / 1.3. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected] CNAS Registration No. CNAS L6451; A2LA Certificate Number: 3870.01; FCC Designation Number: CN1182; FCC Test Firm Registration Number: 540522 Industry Canada Site Registration Number: 10288A-1 2. Equipment used during test Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval Electric and Magnetic Field Analyzer narda EHP-200A 170WX91016 Dec. 18, 2019 1 Year EUT* Name : 2-in-1 15W Wireless Charger Model Number : JR-A26, JR-A23, JR-A20, JR-A15, JR-A12, JR-A16, JR-A27, JR-A28, JR-A29, JR-A30, JR-A31, JR-A32, JR-A33, JR-A35, JR-A36, JR-A37, JR-A39 Difference of model number : All models are identical except the colors and model number, therefore the test performed on the model JR-A26. EUT function description : Please reference user manual of this device Power supply : DC 5V/9V/12V from external adapter Wireless charging Operation frequency : 120 kH…
