2AWLG-T3P1165GV1Laptop

Evolve 3 Holdings Pty Ltd

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Feb 18, 2024
Application Purpose: Original Equipment
Date of Application: Feb 18, 2024
Equipment Note: Laptop
Frequency Range: 5745.00000000 - 5825.00000000
Company: Evolve 3 Holdings Pty Ltd
Country: Australia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

T3P1165GV1 user manual Explanation This manual is mainly aimed at Windows 11 Home, and if you use other Windows systems, it may be slightly different. This manual contains common features for most models, which may not match your model in some aspects, or some of your model features may not be included in this manual. The illustrations in this manual may differ from the actual product, please refer to the actual product. ■ Please read safety precautions and important tips carefully and patiently Before using the computer! Ports and Connectivity: 1 Attention: When turning off the monitor, be careful not to leave a pen or any other object between the monitor and keyboard. Otherwise, it may damage the display 2 Keyboard Function Key Description The following keyboard shortcuts provide easy access to these functions：【Fn+ESC】Lock/Unlock Touchpad 【Fn+F1】 Mute device 【Fn+F2】 Reduce volume 【Fn+F3】 Increase volume 【Fn+F4】 Reduce screen brightness 【Fn+F5】 Increase screen brightness 【Fn+F6】 Move the cursor to the Front of the text 【Fn+F7】 Cursor Up 【Fn+F8】 Cursor Down 【Fn+F9】 Move the cursor to the End of the text 【Fn+F10】Text Overlay&Text Insertion 【Fn+F11】 Scroll Lock 【Fn+F12】 Pause 。 3 Warning! The adapter may become hot during use. Please ensure that nothing covers the adapter and keep it away from your body. Using battery power This laptop is designed to be powered by a removable battery pack. A battery pack consists of multiple batteries assembled together. After being fully charged, the battery pack can provide several hours of battery life, if further extended by setting. Warning! For safety reasons, do not throw the battery into the fire. Do not short-circuit the positive and negative terminals of the battery. Do not disassemble the battery yourself. If any abnormal operation or damage occurs to the battery pack due to a collision, please turn off the laptop and contact the authorized service center. There is a risk of explosion when replacing with an incorrect battery type. Please dispose of waste batteries according to the relevant instructions. FCC Statement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the 4 equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. SAR tests are cond ucted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value, in general, the closer you are to a wireless base station anten na, the lower the power output. Before a new model device is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the exposure limit established by the FCC, Tests for each device are performed in positions and locations (e.g. at the ear and worn on the body)as required by the FCC. For body worn operation, this model device has been tested and meets the FCC RF exposure g uidelines when used with an accessory designated for this product or when used with an accessory that Contains no metal and that positions the device with a minimum of 0 cm from the body. Non-compliance with the ab ove restrictions may result in violation of RF exposure guidelines.

Attestation Statements

U.S. AGENT LETTER OF ATTESTATION Date: 2023-12-05 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2AWLG- T3P1165GV1 E volve 3 Holdings Pty Ltd certifies that, as of the date of the filing of the application, Evolve III USA LLC is our designated U.S. agent for service of process for the above referenced FCC ID. Evolve 3 Holdings Pty Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Evolve III USA LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Evolve III USA LLC Address: 24200 S 211th St Queen Creek, AZ 85142 United States FRN:0034404376 Tel.: (480)242-4837 Email: [email protected] Signed by (printed name): Mr Matthew W Rollins Signature: A pplicant: Evolve 3 Holdings Pty Ltd Add: PO BOX 6222, NARRAWEENA, NSW, Australia FRN: 0029625803 Tel: +61400665466 Email: [email protected] Signed by (printed name): RAY PAOLA Signature:

Cover Letter(s)

Evolve 3 Holdings Pty Ltd Add: PO BOX 6222, NARRAWEENA, NSW, Australia Tel: +61400665466 Fax: +61400665466 Email: [email protected] Date: 2023-12-05 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, Evolve 3 Holdings Pty Ltd, hereby authorize China Certification ICT Co., Ltd (Dongguan). to act as a laboratory for testing and test report generation for the following project(s): (Product description: Laptop, Model name: T3P1165GV1, FCC ID: 2AWLG-T3P1165GV1) The product supports Bluetooth BDR(GFSK), EDR(π/4-DQPSK, 8DPSK) and BLE, 2.4G wifi(2412-24 72 MHz) ,5G wifi(5150-5250 MHz,5250-5350 MHz ,5470-5725 MHz, 5725-5850 MHz), WCDMA Band 2/4/5, LTE Band 2/4/5/12/13/14/17/25/26/30/41/66/71, 5G NR n2/n5/n41/n66/n71/n77, the other was disabled by software,the end user doesn’t h av e the cap actity to activate it. Sincerely, Signature: Prin ted Name: RAY PAOLA Title: CEO

Cover Letter(s)

ATTESTATION STATEMENT Evolve 3 Holdings Pty Ltd Add: PO BOX 6222, NARRAWEENA, NSW, Australia Tel: +61400665466 Fax: +61400665466 Email: [email protected] Date: 2023-12-05 FEDER AL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(5)(i), (ii) Filing FCC ID: 2AWLG-T3P1165GV1 Evolve 3 Holdings Pty Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. And Evolve 3 Holdings Pty Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signed by (printed name): RAY PAOLA Title: CEO Si gnature:

Cover Letter(s)

Declaration of Frequency Stability We Evolve 3 Holdings Pty Ltd ensure that the product (FCC ID: 2AWLG-T3P1165GV1) meets e-CFR Title 47 section 15.407(g) and KDB 789033 D02v02r01 frequency stability such that the emissions are maintained within the band of operation under all conditions of normal operation as specified in the user's manual. Sincerely , Signature: Name: RAY PAOLA Position: CEO Date: 2024-1-30

Cover Letter(s)

QA-FR-171 -A Evolve 3 Holdings Pty Ltd Add: PO BOX 6222, NARRAWEENA, NSW, Australia Tel: +61400665466 Fax: +61400665466 Email: [email protected] FCC Confidential Authorization Dat e: 2023-12-05 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Su bject: Confidentiality Request regarding application for certification of FCC ID: 2AWLG- T3P1165GV1 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, (Evolve 3 Holdings Pty Ltd) hereby requests long-term confidential treatment of information accompanying this application as outlined below: •Block Diagram •Schematics • Operation Description SOFTWARE SECURITY DESCRIPTION The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Si ncerely, Sig nature: Printed Name: RAY PAOLA Title: CEO •

Cover Letter(s)

Evolve 3 Holdings Pty Ltd Date：2023-12-05 Product Model Number: T3P1165GV1 FCC ID: 2AWLG-T3P1165GV1 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out byORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Title: CEO Email: [email protected] Telephone: +61400665466 On behalf of: Evolve 3 Holdings Pty Ltd

Cover Letter(s)

ShenzhenYishengbangTechnologyCo.,Ltd 1 ShenzhenYishengbangTechnologyCo.,LTD Sampleacceptanceletter SPECIFICATIONFORAPPROVAL Thenameofthecompany：ShenzhenMADIGIElectronicTechnologyCo.,Ltd. Thematerialcode： specifications：N116HJ01 Admittedtodate： Thenameofthesupplier：ShenzhenYishengbangTechnologyCo.,Ltd Supplierstandardtypenumber：5G-0SLK-MDJ-5022-M-110IV-B 5G-1:SLK-MDJ-7219A-R-135IV-W5G-2:SLK-MDJ-4911-R-325IV-G 5G-3:SLK-MDJ-6507-R-365IV-BWIFIMAIN:SLK-MDJ-P3707-R-227IV-B WIFIAUX:SLK-MDJ-P3707-R-273IV-G Thenameofthesupplier：ShenzhenYishengbangTechnologyCo.,LTD Supplieraddress：608,BuildingB,ShenzhenQianwanHardTechnologyIndustrial Park,Bao'anDistrict,Shenzhen telephone：18025305599telephone：18666299104 Admitsignature Foracceptancebythecontractor ShenzhenMADIGIElectronicTechnology Co.,Ltd TheengineerThereviewerapprovedTheengineer The reviewer approved Shilian Chen ZenHuangMeicailin SignedandsealedSignedandsealed date 2021-8-29 date instructions：□accept□Conditionalacceptance note： ShenzhenYishengbangTechnologyCo.,Ltd 2 WIFIMAINAntenna(P3707) 1.ExplanationofProductnumber: SLK-MDJ-P3707-R-227IV-B 12345 ProductCode: (1)Customer: MDJ:MADIGI (2)Project: P3707:SLK-MDJ-P3707(WIFIMAINantenna) (3)WeldingPosition R:Right (4)CableLength: 227IV:227*0.81MMfour-generationterminals (5)CableColor B:Black 2.Features *Stableandreliableinperformances *Compactsize *RoHScompliance 3.Applications *IEEE802.11(a/b/g/n) *Hand-helddeviceswhenWIFI(802.11a/b/g/n)functionsareneeded ShenzhenYishengbangTechnologyCo.,Ltd 3 4.Description Holybond’sPCBantennaseriesarespeciallydesignedforWIFI(802.11 a/b/g/n)applications.BasedonHolybond’sproprietarydesignandprocesses, thisPCBantennahasexcellentstabilityandsensitivitytoconsistently providehighsignalreceptionefficiency. 5.ElectricalSpecifications 5-1 CharacteristicsSpecificationsUnit OutlineDimensions 36.8x7.63x1 mm CenterFrequency 2.4-2.5+5.15-5.90 GHz Bandwidth(under-10dBreturnloss) 130minMHz VSWR 3max 5-2 ． VSWRS11 ShenzhenYishengbangTechnologyCo.,Ltd 4 5-3.WIFIMAINAntennaGain/Efficiency/RadiationPatternof3D ShenzhenYishengbangTechnologyCo.,Ltd 5 6.AntennaDimensions(unit:mm) ShenzhenYishengbangTechnologyCo.,Ltd 6 WIFIAUXAntenna(P3707) 1.ExplanationofProductnumber: SLK-MDJ-P3707-R-273IV-G 12 ProductCode: (1)Customer: MDJ:MADIGI (2)Project: P3707:SLK-MDJ-P3707(WIFIAUXantenna) (3)WeldingPosition R:Right (4)CableLength: 273IV:273*0.81MMfour-generationterminals (5)CableColor G:Grey 2.Features *Stableandreliableinperformances *Compactsize *RoHScompliance ShenzhenYishengbangTechnologyCo.,Ltd 7 3.Description Holybond’sPCBantennaseriesarespeciallydesignedforWIFI(802.11 a/b/g/n)applications.BasedonHolybond’sproprietarydesignandprocesses, thisPCBantennahasexcellentstabilityandsensitivitytoconsistently providehighsignalreceptionefficiency. 4.ElectricalSpecifications CharacteristicsSpecificationsUnit OutlineDimensions 36.8x7.63x1 mm CenterFrequency 2.4-2.5+5.15-5.90 GHz Bandwidth(under-10dBreturnloss) 130minMHz VSWR 3max 5-2 VSWRS11 ShenzhenYishengbangTechnologyCo.,Ltd 8 5-3.WIFIMAINAntennaGain/Efficiency/RadiationPatternof3D ShenzhenYishengbangTechnologyCo.,Ltd 9 6.AntennaDimensions(unit:mm) ShenzhenYishengbangTechnologyCo.,Ltd 10 5G-0Antenna(5022) 1.ExplanationofProductnumber: SLK-MDJ-5022-M-110IV-B 12345 ProductCode: (1)Customer: MDJ:MADIGI (2)Project: 5022:SLK-5022(5G0antenna) (3)WeldingPosition M:Middle (4)CableLength: 110IV:110*0.81MMfour-generationterminals (5)CableColor B:Black 2.Features *Stableandreliableinperformances *Compactsize *RoHScompliance ShenzhenYishengbangTechnologyCo.,Ltd 11 3.Description Holybond’sFPCantennaseriesarespeciallydesignedfor5Gapplications. BasedonHolybond’sproprietarydesignandprocesses,thisFPCantennahas excellentstabilityandsensitivitytoconsistentlyprovidehighsignalreception efficiency. 4.ElectricalSpecifications 4-1 CharacteristicsSpecificationsUnit OutlineDimensions 50.16x22.12x0.12 mm Bandwidth(under-10dBreturnloss) 130minMHz VSWR 5max Impedance 50Ω Polarization LinearPolarization 4-2 VSWRS11 ShenzhenYishengbangTechnologyCo.,Ltd 12 4-3.LTEAntennaGain/Efficiency/RadiationPatternof3D Frequency(MHz)Efficiency(dBi)Gain(dBi)Efficiency(%) 800.0-4.590.4634.73 850.0-4.770.0133.32 900.0-4.220.4937.81 950.0-3.920.6235.55 1700.0-3.741.0832.24 1750.0-3.451.4335.22 1800.0-3.042.4934.65 1850.0-3.082.4630.23 1900.0-3.132.2634.26 1950.0-3.081.9834.24 2050.0-3.490.2234.78 2100.0-3.691.1132.77 2150.0-3.912.2430.64 2200.0-3.792.0431.76 2300.0-3.491.8434.84 2400.0-3.541.1934.26 2500.0-3.432.0635.35 2600.0-3.662.1633.09 2700.0-3.661.3933.01 3300.0-3.680.0734.04 3400.0-3.860.0732.69 3500.0-3.910.1332.29 3600.0-3.361.1128.10 3700.0-3.532.7327.65 3800.0-3.422.3530.83 3900.0-3.660.3127.14 4000.03.270.2529.75 4100.0-3.530.9527.98 4200.03.761.9029.07 ShenzhenYishengbangTechnologyCo.,Ltd 13 ShenzhenYishengbangTechnologyCo.,Ltd 14 5.AntennaDimensions(unit:mm) ShenzhenYishengbangTechnologyCo.,Ltd 15 5G-1Antenna(7219A) 1.ExplanationofProductnumber: SLK-MDJ-7219A-R-135IV-W 12345 ProductCode: (1)Customer: MDJ:MADIGI (2)Project: 7219A:SLK-7219A(5G1antenna) (3)WeldingPosition R:Right (4)CableLength: 135IV:135*0.81MMfour-generationterminals (5)CableColor W:White 2.Features *Stableandreliableinperformances *Compactsize *RoHScompliance ShenzhenYishengbangTechnologyCo.,Ltd 16 3.Description Holybond’sFPCantennaseriesarespeciallydesignedfor5Gapplications. BasedonHolybond’sproprietarydesignandprocesses,thisFPCantennahas excellentstabilityandsensitivitytoconsistentlyprovidehighsignalreception efficiency. 4.ElectricalSpecifications 4-1 CharacteristicsSpecificationsUnit OutlineDimensions 72x19.4x0.12 mm Bandwidth(under-10dBreturnloss) 130minMHz VSWR 5max Impedance 50 Ω Polarization LinearPolarization 4-2 VSWRS11 ShenzhenYishengbangTechnologyCo.,Ltd 17 4-3.LTEAntennaGain/Efficiency/ RadiationPatternof3D Frequency(MHz)Efficiency(dBi)Gain(dBi)Efficiency(%) 800.0-5.69-0.5926.95 850.0-5.68-0.1427.05 900.0-5.28-0.3729.67 950.0-5.22-2.6030.03 1700.0-5.000.0831.65 1800.0-5.22-1.8630.09 1900.0-5.46-1.9528.46 2…

Text truncated - open the document above for the full version.

Cover Letter(s)

Evolve 3 Holdings Pty Ltd FCC Software Configuration Control Declaration D ate: February 1, 2024 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: Laptop/T3P1165GV1 FCC ID:2AWLG-T3P1165GV1 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “ All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: RAY PAOLA Date: February 1, 2024 T itle: CEO S ignature of applicant ：
