2AWNK-PLV-S300LED Video Light or Professional Video Light

FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Appendix II EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Appendix IFCC ID&IC Label FCCID:2AWNK-PLV-S300 Model: PLV-S300 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION Size for the label: 10mm X 10mm

FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Appendix III EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Photo 9 Internal of EUT Photo 10 Internal of EUT FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Photo 11 Appearance of PCB & Battery Photo 12 Appearance of PCB & Battery FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Photo 13 Battery parameters Photo 14 Appearance of PCB FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Photo 15 Appearance of PCB Photo 16 Appearance of PCB Antenna

version01 Shenzhen Apeman Innovations Technology Co.,Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: PLV-S300 FCC ID: 2AWNK-PLV-S300 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type(s) described below: Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: 2.4GHz / PCB Antenna 1dBi for 2403-2442MHz; The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Apeman Innovations Technology Co.,Ltd. Address: 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Place: Jack Wang Date: 2022-8-30 Signature:

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2450MHz 2500MHz 2400MHz 2450MHz 2500MHz Center Frequency 0.26-0.761.00-0.250.460.86 MAX. Gain 1dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture Life.augmented Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) MaxMinAvg 2400 0. 26174 -30.0801-7.18716 2450-0.765802-36.5604-7.48023 2500 1.005582 -22.0315-6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) MaxMinAvg 2400 -0.2537 -22.1424-12.4294 2450 0. 4652 -24.5837-10.4702 2500 0. 86120 -29.5214-9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

version01 Shenzhen Apeman Innovations Technology Co.,Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: PLV-S300 FCC ID: 2AWNK-PLV-S300 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type(s) described below: Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: 2.4GHz / PCB Antenna 1dBi for 2403-2442MHz; The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Apeman Innovations Technology Co.,Ltd. Address: 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Place: Jack Wang Date: 2022-8-30 Signature:

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2450MHz 2500MHz 2400MHz 2450MHz 2500MHz Center Frequency 0.26-0.761.00-0.250.460.86 MAX. Gain 1dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture Life.augmented Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) MaxMinAvg 2400 0. 26174 -30.0801-7.18716 2450-0.765802-36.5604-7.48023 2500 1.005582 -22.0315-6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) MaxMinAvg 2400 -0.2537 -22.1424-12.4294 2450 0. 4652 -24.5837-10.4702 2500 0. 86120 -29.5214-9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

version01 Shenzhen Apeman Innovations Technology Co.,Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: PLV-S300 FCC ID: 2AWNK-PLV-S300 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type(s) described below: Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: 2.4GHz / PCB Antenna 1dBi for 2403-2442MHz; The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Apeman Innovations Technology Co.,Ltd. Address: 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Place: Jack Wang Date: 2022-8-30 Signature:

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-4 Page:1 of 3 TB-RF-074-1.0 1 A/F., Building.6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao’an, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 RF Exposure Evaluation FCC ID: 2AWNK-PLV-S300 1. Client Information Applicant : Shenzhen Apeman Innovations Technology Co., Ltd. Address : 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Manufacturer : Shenzhen Apeman Innovations Technology Co., Ltd. Address : 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China 2. General Description of EUT EUT Name : LED Video Light or Professional Video Light Model(s) No. : PLV-S300, VL-S300K, RGB-S116, RGB-S116K, RGB-S300, RGB-S300K Model Different : All PCB boards and circuit diagrams are the same, the only difference is that the exterior color. Product Description : Operation Frequency: 2.4GHz: 2403MHz~2442MHz Number of Channel: 40 channels Antenna Gain: 1dBi PCB Antenna Modulation Type: GFSK Power Supply : DC 3.7V250mAh Rechargeable Li-ion battery Software Version : V1.0 Hardware Version : V1.0 Remark: The antenna gain provided by the applicant, the adapter and verified for the RF conduction test and adapter provided by TOBY test lab. Note: More test information about the EUT please refer the RF Test Report. Report No.: TBR-C-202208-0005-4 Page: 2 of 3 TB-RF-074-1.0 SAR Test Exclusion Calculations 1. FCC: According to KDB 447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v06. (1) Clause 4.3: General SAR test reduction and exclusion guidance Sub clause 4.31: Standalone SAR test exclusion considerations 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6GHz at test separation distance≤5 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤3.0 for 1-g SAR [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤7.5.0 for 10-g SAR 2. Summary simultaneous transmission for SAR Exclusion The SAR exemption limits outlined in clause 4.3.2(b) of KDB 447498 have been derived based on an approximate SAR value of 0.4 W/kg using half-wave dipole antennas Footnote 1. As such, when simultaneous transmitter SAR evaluations include transmitters that have been exempt from routine SAR evaluation, the SAR must be estimating based on the ratio between the maximum tune-up tolerance limit of the transmitter that has been exempt and the exemption limit at the specific distance and frequency for that transmitter. This ratio must be multiplied by 0.4 W/kg(2.0 W/kg for controlled use and 1.0 W/kg for limb worn devices) in order to calculate the estimated SAR level. The estimate SAR value is calculated based the following equation: (maximum power level including tune-up tolerance for transmitter A / maximum power level of exemption at the same frequency and distance) * 0.4W/kg The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. Report No.: TBR-C-202208-0005-4 Page: 3 of 3 TB-RF-074-1.0 3. Calculation: Test separation: 5mm 2.4GHz Mode (GFSK) Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.403 1.043 1±1 2 1.585 0.491 3.0 2.422 1.636 2±1 3 1.995 0.621 3.0 2.442 1.891 2±1 3 1.995 0.624 3.0 Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06. -----END OF REPORT-----

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-4 Page:1 of 3 TB-RF-074-1.0 1 A/F., Building.6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao’an, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 RF Exposure Evaluation FCC ID: 2AWNK-PLV-S300 1. Client Information Applicant : Shenzhen Apeman Innovations Technology Co., Ltd. Address : 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Manufacturer : Shenzhen Apeman Innovations Technology Co., Ltd. Address : 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China 2. General Description of EUT EUT Name : LED Video Light or Professional Video Light Model(s) No. : PLV-S300, VL-S300K, RGB-S116, RGB-S116K, RGB-S300, RGB-S300K Model Different : All PCB boards and circuit diagrams are the same, the only difference is that the exterior color. Product Description : Operation Frequency: 2.4GHz: 2403MHz~2442MHz Number of Channel: 40 channels Antenna Gain: 1dBi PCB Antenna Modulation Type: GFSK Power Supply : DC 3.7V250mAh Rechargeable Li-ion battery Software Version : V1.0 Hardware Version : V1.0 Remark: The antenna gain provided by the applicant, the adapter and verified for the RF conduction test and adapter provided by TOBY test lab. Note: More test information about the EUT please refer the RF Test Report. Report No.: TBR-C-202208-0005-4 Page: 2 of 3 TB-RF-074-1.0 SAR Test Exclusion Calculations 1. FCC: According to KDB 447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v06. (1) Clause 4.3: General SAR test reduction and exclusion guidance Sub clause 4.31: Standalone SAR test exclusion considerations 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6GHz at test separation distance≤5 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤3.0 for 1-g SAR [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤7.5.0 for 10-g SAR 2. Summary simultaneous transmission for SAR Exclusion The SAR exemption limits outlined in clause 4.3.2(b) of KDB 447498 have been derived based on an approximate SAR value of 0.4 W/kg using half-wave dipole antennas Footnote 1. As such, when simultaneous transmitter SAR evaluations include transmitters that have been exempt from routine SAR evaluation, the SAR must be estimating based on the ratio between the maximum tune-up tolerance limit of the transmitter that has been exempt and the exemption limit at the specific distance and frequency for that transmitter. This ratio must be multiplied by 0.4 W/kg(2.0 W/kg for controlled use and 1.0 W/kg for limb worn devices) in order to calculate the estimated SAR level. The estimate SAR value is calculated based the following equation: (maximum power level including tune-up tolerance for transmitter A / maximum power level of exemption at the same frequency and distance) * 0.4W/kg The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. Report No.: TBR-C-202208-0005-4 Page: 3 of 3 TB-RF-074-1.0 3. Calculation: Test separation: 5mm 2.4GHz Mode (GFSK) Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.403 1.043 1±1 2 1.585 0.491 3.0 2.422 1.636 2±1 3 1.995 0.621 3.0 2.442 1.891 2±1 3 1.995 0.624 3.0 Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06. -----END OF REPORT-----

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 1 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 RF Test Data for 2.4GHz (Conducted Measurements) General Description of EUT Product Name: LED Video Light or Professional Video Light Test Model: PLV-S300 Sample ID: 202208-0005-3-2# Environmental Conditions Temperature: 25°C Relative Humidity: 55% Test Voltage: DC 3.7V Test Engineer: Huang jian ping Note: For a more detailed features description, please refer to the report TBR-C-202208-0005-3 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 2 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Contents 1. Duty Cycle ............................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ..................................................................................................................................................... 6 3. -6dB Bandwidth ....................................................................................................................................................................................... 9 5. Maximum Power Spectral Density Level ............................................................................................................................................ 12 6. Band Edge ............................................................................................................................................................................................. 15 7. Conducted RF Spurious Emission ...................................................................................................................................................... 18 8. Restrict Band ......................................................................................................................................................................................... 22 9. Duty Cycle, Tx Sequence, Tx Gap, Medium Utilisation ..................................................................................................................... 25 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 3 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT 2.4GHz 2403 Ant1 100 0 0 NVNT 2.4GHz 2422 Ant1 100 0 0 NVNT 2.4GHz 2442 Ant1 100 0 0 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 4 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Test Graphs Duty Cycle NVNT 2.4GHz 2403MHz Ant1 Duty Cycle NVNT 2.4GHz 2422MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 5 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Duty Cycle NVNT 2.4GHz 2442MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 6 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT 2.4GHz 2403 Ant1 1.043 30 Pass NVNT 2.4GHz 2422 Ant1 1.636 30 Pass NVNT 2.4GHz 2442 Ant1 1.891 30 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 7 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Test Graphs Power NVNT 2.4GHz 2403MHz Ant1 Power NVNT 2.4GHz 2422MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 8 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Power NVNT 2.4GHz 2442MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 9 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT 2.4GHz 2403 Ant1 0.81 0.5 Pass NVNT 2.4GHz 2422 Ant1 0.81 0.5 Pass NVNT 2.4GHz 2442 Ant1 0.84 0.5 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 10 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Test Graphs -6dB Bandwidth NVNT 2.4GHz 2403MHz Ant1 -6dB Bandwidth NVNT 2.4GHz 2422MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 11 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 -6dB Bandwidth NVNT 2.4GHz 2442MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 12 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 5. Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Max PSD (dBm) Limit (dBm) Verdict NVNT 2.4GHz 2403 Ant1 -6.61 8 Pass NVNT 2.4GHz 2422 Ant1 -6.243 8 Pass NVNT 2.4GHz 2442 Ant1 -6.01 8 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 13 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Test Graphs PSD NVNT 2.4GHz 2403MHz Ant1 PSD NVNT 2.4GHz 2422MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 14 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 PSD NVNT 2.4GHz 2442MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 15 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 6. Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT 2.4GHz 2403 Ant1 -47.5 -20 Pass NVNT 2.4GHz 2442 Ant1 -51.71 -20 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 16 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Test Graphs Band Edge NVNT 2.4GHz 2403MHz Ant1 Ref Band Edge NVNT 2.4GHz 2403MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 17 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Band Edge NVNT 2.4GHz 2442MHz Ant1 Ref Band Edge NVNT 2.4GHz 2442MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 18 of 26 FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 7. Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT 2.4GHz 2403 Ant1 -29.41 -20 Pass NVNT 2.4GHz 2422 Ant1 -31.14 -20 Pass NVNT 2.4GHz 2442 Ant1 -32.09 -20 Pass Shenzhen Toby Technology Co., Ltd. Report No.…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202208-0005-3 Page: 1 of 34 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Radio Test Report FCC ID: 2AWNK-PLV-S300 Report No. : TBR-C-202208-0005-3 Applicant : Shenzhen Apeman Innovations Technology Co., Ltd. Equipment Under Test (EUT) EUT Name : LED Video Light or Professional Video Light Model No. : PLV-S300 Series Model No. : VL-S300K, RGB-S116, RGB-S116K, RGB-S300, RGB-S300K Brand Name : RALENO Sample ID : 202208-0005-3-1#&202208-0005-3-2# Receipt Date : 2022-08-10 Test Date : 2022-08-10 to 2022-08-25 Issue Date : 2022-08-25 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Witness Engineer : Seven Wu Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202208-0005-3 Page: 2 of 34 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION ....................................................................................................... 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 12 5.3 Test Procedure ................................................................................................................... 12 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 13 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 6.2 Test Setup ........................................................................................................................... 15 6.3 Test Procedure ................................................................................................................... 16 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Mode ........................................................................................................ 17 6.6 Test Data ............................................................................................................................. 17 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 Deviation From Test Standard ......................................................................................... 20 7.5 EUT Operating Mode ........................................................................................................ 20 7.6 Test Data ............................................................................................................................. 20 8. BANDWIDTH TEST ................................................................................................................. 21 8.1 Test Standard and Limit .…

Text truncated - open the document above for the full version.

FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) FCC ID:2AWNK-PLV-S300 TB-RF-074-1.0 Photo of Setup for Conducted Emission ----TX -----END OF REPORT-----
