2AWNK-VM300RXBaby Monitor

FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF Exposure Information For One Parent Unit The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For One Baby Unit This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Shenzhen Apeman Innovations Technology Co.,Ltd. Add: 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, CHINA Date: 2021-8-10 FCC ID: 2AWNK-VM300RX Dear Sir/Madam, We, Shenzhen Apeman Innovations Technology Co.,Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Baby Monitor Model no.: VM300RX, VM300, VM300S, VM430, VM430S, VM500, VM510, VM550, VM200, VM200S, BM24, BM32, BM24S, BM32S Sincerely, Name/Title： Jack Wang/Manager Company: Shenzhen Apeman Innovations Technology Co.,Ltd. Address: 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, CHINA Phone: +86-769-27280901 Fax: +86-769-27280901 E-Mail: [email protected]

Shenzhen Apeman Innovations Technology Co.,Ltd. 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, CHINA Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-8-10 To whom it may concern: We, Shenzhen Apeman Innovations Technology Co.,Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AWNK-VM300RX including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Jack Wang/Manager Company: Shenzhen Apeman Innovations Technology Co.,Ltd. Address: 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, CHINA Phone: +86-769-27280901 Fax: +86-769-27280901 E-Mail: [email protected]

FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of Adapter FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 3 Appearance of Adapter Photo 4 Appearance of EUT FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 7 Appearance of EUT Photo 8 Appearance of EUT FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 9 Appearance of EUT

FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 10 Internal of EUT Photo 11 Internal of EUT FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 12 Appearance of PCB Photo 13 Appearance of PCB FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 14 Appearance of PCB Photo 15 Appearance of PCB FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 16 Appearance of PCB Photo 17 Appearance of PCB Antenna FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 18 Appearance of PCB Photo 19 Appearance of PCB FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo 20 Appearance of Battery

Shenzhen Toby Technology Co., Ltd. Report No.: TB-MPE180597 Page: 1 of 3 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 RF Exposure Evaluation FCC ID: 2AWNK-VM300RX 1. Client Information Applicant : Shenzhen Apeman Innovations Technology Co., Ltd. Address : 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, CHINA Manufacturer : Shenzhen Apeman Innovations Technology Co., Ltd. Address : 1808, Heng Lu E Times Building, No. 159, North Pingji Road, Hehua Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, CHINA 2. General Description of EUT EUT Name : Baby Monitor Models No. : VM300RX, VM300, VM300S, VM430, VM430S, VM500, VM510, VM550, VM200, VM200S, BM24, BM32, BM24S, BM32S Model Different : All these models are identical in the same PCB, layout and electrical circuit, The only difference is appearance. Product Description : Operation Frequency: 2406MHz~2475MHz Number of Channel: 2.4G: 24 Channels Max Peak Output Power: 8.446dBm Antenna Gain: 3dBi Internal Antenna Modulation Type: GFSK (4Mbps) Power Rating : Adapter (TPQ-236A050100UW01) Input: 100-240V~, 50/60Hz, 0.3A Output: DC 5V1A DC 3.7V by 930mAh Li-ion battery Software Version : VM300-RX-Voger-V1.0 Hardware Version : VM300RX-V01 Note: More test information about the EUT please refer the RF Test Report. Report No.: TB-MPE180597 Page: 2 of 3 TB-RF-074-1.0 SAR Test Exclusion Calculations 1. FCC: According to KDB 447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v06. (1) Clause 4.3: General SAR test reduction and exclusion guidance Sub clause 4.31: Standalone SAR test exclusion considerations 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6GHz at test separation distance≤5 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[ √f (GHz) ] ≤3.0 for 1-g SAR [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤7.5.0 for 10-g SAR Report No.: TB-MPE180597 Page: 3 of 3 TB-RF-074-1.0 2. Calculation: Test separation: 5mm 2.4G Mode Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Calculation Value Threshol d Value 2.406 8.301 8±1 9 7.943 2.464 3.0 2.442 8.446 8±1 9 7.943 2.482 3.0 2.475 8.079 8±1 9 7.943 2.499 3.0 So the worst RF Exposure Evaluation is calculated as 2.499< limit 3.0. The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06. -----END OF REPORT-----

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC180596 Page: 1 of 47 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Te l : +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2AWNK-VM300RX Original Grant Report No. : TB-FCC180596 Applicant : Shenzhen Apeman Innovations Technology Co., Ltd. Equipment Under Test (EUT) EUT Name : Baby Monitor Model No. : VM300RX Series Model No. : VM300, VM300S, VM430, VM430S, VM500, VM510, VM550, VM200, VM200S, BM24, BM32, BM24S, BM32S Brand Name : Voger Sample ID : 20210422-06-01 Receipt Date : 2021-05-26 Test Date : 2021-05-27 to 2021-07-03 Issue Date : 2021-08-05 Standards : FCC Part 15, Subpart C 15.247 Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC requirements Test/Witness Engineer : Wade. Lv Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC180596 Page: 2 of 47 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION TEST ........................................................................................... 13 5.1 Test Standard and Limit .................................................................................................... 13 5.2 Test Setup ........................................................................................................................... 13 5.3 Test Procedure ................................................................................................................... 14 5.4 Deviation From Test Standard ......................................................................................... 14 5.5 EUT Operating Mode ........................................................................................................ 14 5.6 Test Data ............................................................................................................................. 14 6. RADIATED EMISSION TEST ................................................................................................ 15 6.1 Test Standard and Limit .................................................................................................... 15 6.2 Test Setup ........................................................................................................................... 16 6.3 Test Procedure ................................................................................................................... 17 6.4 Deviation From Test Standard ......................................................................................... 18 6.5 EUT Operating Condition ................................................................................................. 18 6.6 Test Data ............................................................................................................................. 18 7. RESTRICTED BANDS AND BAND-EDGE TEST.............................................................. 19 7.1 Test Standard and Limit .................................................................................................... 19 7.2 Test Setup ........................................................................................................................... 19 7.3 Test Procedure ................................................................................................................... 20 7.4 Deviation From Test Standard ......................................................................................... 20 7.5 EUT Operating Condition ................................................................................................. 20 7.6 Test Data ............................................................................................................................. 20 8. NUMBER OF HOPPING CHANNEL .................................................................................... 21 8.1 Test Standard and Limit .…

Text truncated - open the document above for the full version.

FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Appendix V EUT Test Photographs Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Above 1 GHz) FCC ID: 2AWNK-VM300RX TB-RF-074-1.0 Photo of Setup for Radiated Emission (Below 1 GHz) Photo of Setup for Conducted Emission -----END OF REPORT-----
