2AWTV-G60LGPS Tracker

M o d e l : G 6 0 G P s Tracker L M anua l FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the follow ing two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, inc luding interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentia l installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televis ion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technic ian for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be insta lled and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

No.：BCTC/KJ-RF-ICT-001 Page 1 of 96 Edition：B.1 Appendix for Band 2 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC2605525578E Applicant: SEEWORLD Technology Co.,ltd Product Name: GPS Tracker Test Model: G60L Tested Date: 2026-05-14 to 2026-06-15 Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 2 of 96 Edition：B.1 Contents Appendix 1.Conducted output power ................................................................................................................................................... 3 Appendix 2.Frequency stability ............................................................................................................................................................. 8 Appendix 3.Peak-to-Average Ratio ..................................................................................................................................................... 23 Appendix 4.Occupied bandwidth ........................................................................................................................................................ 42 Appendix 5.Band edge ......................................................................................................................................................................... 61 Appendix 6.Out-of-band emissions ..................................................................................................................................................... 78 Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 3 of 96 Edition：B.1 Appendix 1.Conducted output power Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Power (dBm) Gain (dBm) EIRP (dBm) Verdict NVNT Band2 1.4 18607 1 #0 QPSK 22.36 0.17 22.53 PASS NVNT Band2 1.4 18607 1 #Mid QPSK 22.26 0.17 22.43 PASS NVNT Band2 1.4 18607 1 #Max QPSK 22.12 0.17 22.29 PASS NVNT Band2 1.4 18607 3 #0 QPSK 22.18 0.17 22.35 PASS NVNT Band2 1.4 18607 3 #Mid QPSK 22.10 0.17 22.27 PASS NVNT Band2 1.4 18607 3 #Max QPSK 22.04 0.17 22.21 PASS NVNT Band2 1.4 18607 6 #0 QPSK 21.21 0.17 21.38 PASS NVNT Band2 1.4 18607 1 #0 16QAM 21.28 0.17 21.45 PASS NVNT Band2 1.4 18607 1 #Mid 16QAM 21.28 0.17 21.45 PASS NVNT Band2 1.4 18607 1 #Max 16QAM 21.29 0.17 21.46 PASS NVNT Band2 1.4 18607 3 #0 16QAM 21.44 0.17 21.61 PASS NVNT Band2 1.4 18607 3 #Mid 16QAM 21.46 0.17 21.63 PASS NVNT Band2 1.4 18607 3 #Max 16QAM 21.53 0.17 21.70 PASS NVNT Band2 1.4 18607 6 #0 16QAM 20.58 0.17 20.75 PASS NVNT Band2 1.4 18900 1 #0 QPSK 22.85 0.17 23.02 PASS NVNT Band2 1.4 18900 1 #Mid QPSK 22.77 0.17 22.94 PASS NVNT Band2 1.4 18900 1 #Max QPSK 22.69 0.17 22.86 PASS NVNT Band2 1.4 18900 3 #0 QPSK 22.59 0.17 22.76 PASS NVNT Band2 1.4 18900 3 #Mid QPSK 22.66 0.17 22.83 PASS NVNT Band2 1.4 18900 3 #Max QPSK 22.64 0.17 22.81 PASS NVNT Band2 1.4 18900 6 #0 QPSK 21.73 0.17 21.90 PASS NVNT Band2 1.4 18900 1 #0 16QAM 22.09 0.17 22.26 PASS NVNT Band2 1.4 18900 1 #Mid 16QAM 22.11 0.17 22.28 PASS NVNT Band2 1.4 18900 1 #Max 16QAM 22.15 0.17 22.32 PASS NVNT Band2 1.4 18900 3 #0 16QAM 22.07 0.17 22.24 PASS NVNT Band2 1.4 18900 3 #Mid 16QAM 22.06 0.17 22.23 PASS NVNT Band2 1.4 18900 3 #Max 16QAM 22.03 0.17 22.20 PASS NVNT Band2 1.4 18900 6 #0 16QAM 21.17 0.17 21.34 PASS NVNT Band2 1.4 19193 1 #0 QPSK 22.06 0.17 22.23 PASS NVNT Band2 1.4 19193 1 #Mid QPSK 22.12 0.17 22.29 PASS NVNT Band2 1.4 19193 1 #Max QPSK 22.07 0.17 22.24 PASS NVNT Band2 1.4 19193 3 #0 QPSK 21.97 0.17 22.14 PASS NVNT Band2 1.4 19193 3 #Mid QPSK 21.92 0.17 22.09 PASS NVNT Band2 1.4 19193 3 #Max QPSK 21.94 0.17 22.11 PASS NVNT Band2 1.4 19193 6 #0 QPSK 21.21 0.17 21.38 PASS NVNT Band2 1.4 19193 1 #0 16QAM 21.44 0.17 21.61 PASS NVNT Band2 1.4 19193 1 #Mid 16QAM 21.51 0.17 21.68 PASS Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 4 of 96 Edition：B.1 NVNT Band2 1.4 19193 1 #Max 16QAM 21.52 0.17 21.69 PASS NVNT Band2 1.4 19193 3 #0 16QAM 21.48 0.17 21.65 PASS NVNT Band2 1.4 19193 3 #Mid 16QAM 21.48 0.17 21.65 PASS NVNT Band2 1.4 19193 3 #Max 16QAM 21.49 0.17 21.66 PASS NVNT Band2 1.4 19193 6 #0 16QAM 20.58 0.17 20.75 PASS NVNT Band2 3 18615 1 #0 QPSK 22.20 0.17 22.37 PASS NVNT Band2 3 18615 1 #Mid QPSK 21.98 0.17 22.15 PASS NVNT Band2 3 18615 1 #Max QPSK 21.84 0.17 22.01 PASS NVNT Band2 3 18615 8 #0 QPSK 21.20 0.17 21.37 PASS NVNT Band2 3 18615 8 #Mid QPSK 21.19 0.17 21.36 PASS NVNT Band2 3 18615 8 #Max QPSK 21.20 0.17 21.37 PASS NVNT Band2 3 18615 15 #0 QPSK 21.20 0.17 21.37 PASS NVNT Band2 3 18615 1 #0 16QAM 21.68 0.17 21.85 PASS NVNT Band2 3 18615 1 #Mid 16QAM 21.67 0.17 21.84 PASS NVNT Band2 3 18615 1 #Max 16QAM 21.59 0.17 21.76 PASS NVNT Band2 3 18615 8 #0 16QAM 20.37 0.17 20.54 PASS NVNT Band2 3 18615 8 #Mid 16QAM 20.39 0.17 20.56 PASS NVNT Band2 3 18615 8 #Max 16QAM 20.37 0.17 20.54 PASS NVNT Band2 3 18615 15 #0 16QAM 20.42 0.17 20.59 PASS NVNT Band2 3 18900 1 #0 QPSK 22.85 0.17 23.02 PASS NVNT Band2 3 18900 1 #Mid QPSK 22.74 0.17 22.91 PASS NVNT Band2 3 18900 1 #Max QPSK 22.67 0.17 22.84 PASS NVNT Band2 3 18900 8 #0 QPSK 21.86 0.17 22.03 PASS NVNT Band2 3 18900 8 #Mid QPSK 21.79 0.17 21.96 PASS NVNT Band2 3 18900 8 #Max QPSK 21.86 0.17 22.03 PASS NVNT Band2 3 18900 15 #0 QPSK 21.81 0.17 21.98 PASS NVNT Band2 3 18900 1 #0 16QAM 22.19 0.17 22.36 PASS NVNT Band2 3 18900 1 #Mid 16QAM 22.13 0.17 22.30 PASS NVNT Band2 3 18900 1 #Max 16QAM 22.08 0.17 22.25 PASS NVNT Band2 3 18900 8 #0 16QAM 21.06 0.17 21.23 PASS NVNT Band2 3 18900 8 #Mid 16QAM 21.07 0.17 21.24 PASS NVNT Band2 3 18900 8 #Max 16QAM 21.08 0.17 21.25 PASS NVNT Band2 3 18900 15 #0 16QAM 21.05 0.17 21.22 PASS NVNT Band2 3 19185 1 #0 QPSK 22.29 0.17 22.46 PASS NVNT Band2 3 19185 1 #Mid QPSK 22.12 0.17 22.29 PASS NVNT Band2 3 19185 1 #Max QPSK 22.04 0.17 22.21 PASS NVNT Band2 3 19185 8 #0 QPSK 21.24 0.17 21.41 PASS NVNT Band2 3 19185 8 #Mid QPSK 21.22 0.17 21.39 PASS NVNT Band2 3 19185 8 #Max QPSK 21.22 0.17 21.39 PASS NVNT Band2 3 19185 15 #0 QPSK 21.20 0.17 21.37 PASS NVNT Band2 3 19185 1 #0 16QAM 21.31 0.17 21.48 PASS NVNT Band2 3 19185 1 #Mid 16QAM 21.22 0.17 21.39…

Text truncated - open the document above for the full version.

Report No.: BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 40 of 41 Edition：B.1 12. EUT Test Setup Photographs Radiated Measurement Photos

Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 38 of 92 Edition：B.1 Band66 QPSK BW=15MHz Channel=132047 RB Size=1 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 39 of 92 Edition：B.1 Band66 QPSK BW=15MHz Channel=132322 RB Size=1 Position=#0 NVNT Band66 QPSK BW=15MHz Channel=132597 RB Size=1 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 40 of 92 Edition：B.1 Band66 QPSK BW=20MHz Channel=132072 RB Size=1 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 41 of 92 Edition：B.1 Band66 QPSK BW=20MHz Channel=132322 RB Size=1 Position=#0 NVNT Band66 QPSK BW=20MHz Channel=132572 RB Size=1 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 42 of 92 Edition：B.1 Appendix 4.Occupied bandwidth Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation 99% OBW (MHz) -26dB EBW (MHz) Verdict NVNT Band66 1.4 131979 6 #0 QPSK 1.096 1.273 PASS NVNT Band66 1.4 131979 6 #0 16QAM 1.096 1.264 PASS NVNT Band66 1.4 132322 6 #0 QPSK 1.104 1.264 PASS NVNT Band66 1.4 132322 6 #0 16QAM 1.091 1.281 PASS NVNT Band66 1.4 132665 6 #0 QPSK 1.096 1.276 PASS NVNT Band66 1.4 132665 6 #0 16QAM 1.097 1.276 PASS NVNT Band66 3 131987 15 #0 QPSK 2.698 2.953 PASS NVNT Band66 3 131987 15 #0 16QAM 2.696 2.918 PASS NVNT Band66 3 132322 15 #0 QPSK 2.698 2.942 PASS NVNT Band66 3 132322 15 #0 16QAM 2.692 2.962 PASS NVNT Band66 3 132657 15 #0 QPSK 2.704 2.940 PASS NVNT Band66 3 132657 15 #0 16QAM 2.697 2.945 PASS NVNT Band66 5 131997 25 #0 QPSK 4.509 4.960 PASS NVNT Band66 5 131997 25 #0 16QAM 4.501 4.893 PASS NVNT Band66 5 132322 25 #0 QPSK 4.507 4.942 PASS NVNT Band66 5 132322 25 #0 16QAM 4.524 4.954 PASS NVNT Band66 5 132647 25 #0 QPSK 4.511 4.937 PASS NVNT Band66 5 132647 25 #0 16QAM 4.522 4.934 PASS Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation 99% OBW (MHz) -26dB EBW (MHz) Verdict NVNT Band66 10 132022 50 #0 QPSK 8.976 9.708 PASS NVNT Band66 10 132322 50 #0 QPSK 9.003 9.685 PASS NVNT Band66 10 132622 50 #0 QPSK 9.004 9.760 PASS NVNT Band66 15 132047 75 #0 QPSK 13.492 14.585 PASS NVNT Band66 15 132322 75 #0 QPSK 13.405 14.357 PASS NVNT Band66 15 132597 75 #0 QPSK 13.463 14.549 PASS NVNT Band66 20 132072 100 #0 QPSK 18.005 19.156 PASS NVNT Band66 20 132322 100 #0 QPSK 17.907 19.024 PASS NVNT Band66 20 132572 100 #0 QPSK 17.895 19.198 PASS Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 43 of 92 Edition：B.1 Band66 QPSK BW=1.4MHz Channel=131979 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 44 of 92 Edition：B.1 Band66 16QAM BW=1.4MHz Channel=131979 RB Size=6 Position=#0 NVNT Band66 QPSK BW=1.4MHz Channel=132322 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 45 of 92 Edition：B.1 Band66 16QAM BW=1.4MHz Channel=132322 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 46 of 92 Edition：B.1 Band66 QPSK BW=1.4MHz Channel=132665 RB Size=6 Position=#0 NVNT Band66 16QAM BW=1.4MHz Channel=132665 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 47 of 92 Edition：B.1 Band66 QPSK BW=3MHz Channel=131987 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 48 of 92 Edition：B.1 Band66 16QAM BW=3MHz Channel=131987 RB Size=15 Position=#0 NVNT Band66 QPSK BW=3MHz Channel=132322 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 49 of 92 Edition：B.1 Band66 16QAM BW=3MHz Channel=132322 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 50 of 92 Edition：B.1 Band66 QPSK BW=3MHz Channel=132657 RB Size=15 Position=#0 NVNT Band66 16QAM BW=3MHz Channel=132657 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 51 of 92 Edition：B.1 Band66 QPSK BW=5MHz Channel=131997 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 52 of 92 Edition：B.1 Band66 16QAM BW=5MHz Channel=131997 RB Size=25 Position=#0 NVNT Band66 QPSK BW=5MHz Channel=132322 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 53 of 92 Edition：B.1 Band66 16QAM BW=5MHz Channel=132322 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 54 of 92 Edition：B.1 Band66 QPSK BW=5MHz Channel=132647 RB Size=25 Position=#0 NVNT Band66 16QAM BW=5MHz Channel=132647 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 55 of 92 Edition：B.1 Band66 QPSK BW=10MHz Channel=132022 RB Size=50 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 56 of 92 Edition：B.1 Band66 QPSK BW=10MHz Channel=132322 RB Size=50 Position=#0 NVNT Band66 QPSK BW=10MHz Channel=132622 RB Size=50 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 57 of 92 Edition：B.1 Band66 QPSK BW=15MHz Channel=132047 RB Size=75 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 58 of 92 Edition：B.1 Band66 QPSK BW=15MHz Channel=132322 RB Size=75 Position=#0 NVNT Band66 QPSK BW=15MHz Channel=132597 RB Size=75 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 59 of 92 Edition：B.1 Band66 QPSK BW=20MHz Channel=132072 RB Size=100 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 60 of 92 Edition：B.1 Band66 QPSK BW=20MHz Channel=132322 RB Size=100 Position=#0 NVNT Band66 QPSK BW=20MHz Channel=132572 RB Size=100 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 61 of 92 Edition：B.1 Appendix 5.Band edge Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict NVNT Band66 1.4 131979 6 #0 QPSK 1710.00 -31.86 -13 PASS NVNT Band66 1.4 131979 6 #0 16QAM 1710.00 -34.16 -13 PASS NVNT Band66 1.4 132665 6 #0 QPSK 1780.01 -32.90 -13 PASS NVNT Band66 1.4 132665 6 #0 16QAM 1780.01 -33.18 -13 PASS NVNT Band66 3 131987 15 #0 QPSK 1710.00 -32.01 -13 PASS NVNT Band66 3 131987 15…

Text truncated - open the document above for the full version.

No.：BCTC/KJ-RF-ICT-001 Page 1 of 92 Edition：B.1 Appendix for Band 66 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC2605525578E Applicant: SEEWORLD Technology Co.,ltd Product Name: GPS Tracker Test Model: G60L Tested Date: 2026-05-14 to 2026-06-15 Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 2 of 92 Edition：B.1 Contents Appendix 1.Conducted output power ................................................................................................................................................... 3 Appendix 2.Frequency stability ............................................................................................................................................................. 8 Appendix 3.Peak-to-Average Ratio ..................................................................................................................................................... 23 Appendix 4.Occupied bandwidth ........................................................................................................................................................ 42 Appendix 5.Band edge ......................................................................................................................................................................... 61 Appendix 6.Out-of-band emissions ..................................................................................................................................................... 74 Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 3 of 92 Edition：B.1 Appendix 1.Conducted output power Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Power (dBm) Gain (dBm) EIRP (dBm) Verdict NVNT Band66 1.4 131979 1 #0 QPSK 23.59 -0.17 23.42 PASS NVNT Band66 1.4 131979 1 #Mid QPSK 23.44 -0.17 23.27 PASS NVNT Band66 1.4 131979 1 #Max QPSK 23.29 -0.17 23.12 PASS NVNT Band66 1.4 131979 3 #0 QPSK 23.23 -0.17 23.06 PASS NVNT Band66 1.4 131979 3 #Mid QPSK 23.17 -0.17 23.00 PASS NVNT Band66 1.4 131979 3 #Max QPSK 23.16 -0.17 22.99 PASS NVNT Band66 1.4 131979 6 #0 QPSK 22.10 -0.17 21.93 PASS NVNT Band66 1.4 131979 1 #0 16QAM 22.14 -0.17 21.97 PASS NVNT Band66 1.4 131979 1 #Mid 16QAM 22.18 -0.17 22.01 PASS NVNT Band66 1.4 131979 1 #Max 16QAM 22.21 -0.17 22.04 PASS NVNT Band66 1.4 131979 3 #0 16QAM 22.34 -0.17 22.17 PASS NVNT Band66 1.4 131979 3 #Mid 16QAM 22.33 -0.17 22.16 PASS NVNT Band66 1.4 131979 3 #Max 16QAM 22.37 -0.17 22.20 PASS NVNT Band66 1.4 131979 6 #0 16QAM 21.45 -0.17 21.28 PASS NVNT Band66 1.4 132322 1 #0 QPSK 23.26 -0.17 23.09 PASS NVNT Band66 1.4 132322 1 #Mid QPSK 23.26 -0.17 23.09 PASS NVNT Band66 1.4 132322 1 #Max QPSK 23.17 -0.17 23.00 PASS NVNT Band66 1.4 132322 3 #0 QPSK 23.12 -0.17 22.95 PASS NVNT Band66 1.4 132322 3 #Mid QPSK 23.09 -0.17 22.92 PASS NVNT Band66 1.4 132322 3 #Max QPSK 23.07 -0.17 22.90 PASS NVNT Band66 1.4 132322 6 #0 QPSK 22.14 -0.17 21.97 PASS NVNT Band66 1.4 132322 1 #0 16QAM 22.45 -0.17 22.28 PASS NVNT Band66 1.4 132322 1 #Mid 16QAM 22.43 -0.17 22.26 PASS NVNT Band66 1.4 132322 1 #Max 16QAM 22.46 -0.17 22.29 PASS NVNT Band66 1.4 132322 3 #0 16QAM 22.41 -0.17 22.24 PASS NVNT Band66 1.4 132322 3 #Mid 16QAM 22.40 -0.17 22.23 PASS NVNT Band66 1.4 132322 3 #Max 16QAM 22.40 -0.17 22.23 PASS NVNT Band66 1.4 132322 6 #0 16QAM 21.59 -0.17 21.42 PASS NVNT Band66 1.4 132665 1 #0 QPSK 22.40 -0.17 22.23 PASS NVNT Band66 1.4 132665 1 #Mid QPSK 22.30 -0.17 22.13 PASS NVNT Band66 1.4 132665 1 #Max QPSK 22.22 -0.17 22.05 PASS NVNT Band66 1.4 132665 3 #0 QPSK 22.16 -0.17 21.99 PASS NVNT Band66 1.4 132665 3 #Mid QPSK 22.13 -0.17 21.96 PASS NVNT Band66 1.4 132665 3 #Max QPSK 22.12 -0.17 21.95 PASS NVNT Band66 1.4 132665 6 #0 QPSK 21.17 -0.17 21.00 PASS NVNT Band66 1.4 132665 1 #0 16QAM 21.53 -0.17 21.36 PASS NVNT Band66 1.4 132665 1 #Mid 16QAM 21.49 -0.17 21.32 PASS Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 4 of 92 Edition：B.1 NVNT Band66 1.4 132665 1 #Max 16QAM 21.53 -0.17 21.36 PASS NVNT Band66 1.4 132665 3 #0 16QAM 21.52 -0.17 21.35 PASS NVNT Band66 1.4 132665 3 #Mid 16QAM 21.51 -0.17 21.34 PASS NVNT Band66 1.4 132665 3 #Max 16QAM 21.51 -0.17 21.34 PASS NVNT Band66 1.4 132665 6 #0 16QAM 20.62 -0.17 20.45 PASS NVNT Band66 3 131987 1 #0 QPSK 23.24 -0.17 23.07 PASS NVNT Band66 3 131987 1 #Mid QPSK 23.03 -0.17 22.86 PASS NVNT Band66 3 131987 1 #Max QPSK 22.86 -0.17 22.69 PASS NVNT Band66 3 131987 8 #0 QPSK 22.04 -0.17 21.87 PASS NVNT Band66 3 131987 8 #Mid QPSK 22.04 -0.17 21.87 PASS NVNT Band66 3 131987 8 #Max QPSK 21.98 -0.17 21.81 PASS NVNT Band66 3 131987 15 #0 QPSK 22.02 -0.17 21.85 PASS NVNT Band66 3 131987 1 #0 16QAM 22.44 -0.17 22.27 PASS NVNT Band66 3 131987 1 #Mid 16QAM 22.49 -0.17 22.32 PASS NVNT Band66 3 131987 1 #Max 16QAM 22.34 -0.17 22.17 PASS NVNT Band66 3 131987 8 #0 16QAM 21.21 -0.17 21.04 PASS NVNT Band66 3 131987 8 #Mid 16QAM 21.22 -0.17 21.05 PASS NVNT Band66 3 131987 8 #Max 16QAM 21.22 -0.17 21.05 PASS NVNT Band66 3 131987 15 #0 16QAM 21.25 -0.17 21.08 PASS NVNT Band66 3 132322 1 #0 QPSK 23.15 -0.17 22.98 PASS NVNT Band66 3 132322 1 #Mid QPSK 23.16 -0.17 22.99 PASS NVNT Band66 3 132322 1 #Max QPSK 23.17 -0.17 23.00 PASS NVNT Band66 3 132322 8 #0 QPSK 22.15 -0.17 21.98 PASS NVNT Band66 3 132322 8 #Mid QPSK 22.15 -0.17 21.98 PASS NVNT Band66 3 132322 8 #Max QPSK 22.22 -0.17 22.05 PASS NVNT Band66 3 132322 15 #0 QPSK 22.15 -0.17 21.98 PASS NVNT Band66 3 132322 1 #0 16QAM 22.36 -0.17 22.19 PASS NVNT Band66 3 132322 1 #Mid 16QAM 22.41 -0.17 22.24 PASS NVNT Band66 3 132322 1 #Max 16QAM 22.46 -0.17 22.29 PASS NVNT Band66 3 132322 8 #0 16QAM 21.28 -0.17 21.11 PASS NVNT Band66 3 132322 8 #Mid 16QAM 21.40 -0.17 21.23 PASS NVNT Band66 3 132322 8 #Max 16QAM 21.41 -0.17 21.24 PASS NVNT Band66 3 132322 15 #0 16QAM 21.38 -0.17 21.21 PASS NVNT Band66 3 132657 1 #0 QPSK 22.40 -0.17 22.23 PASS NVNT Band66 3 132657 1 #Mid QPSK 22.29 -0.17 22.12 PASS NVNT Band66 3 132657 1 #Max QPSK 22.24 -0.17 22.07 PASS NVNT Band66 3 132657 8 #0 QPSK 21.24 -0.17 21.07 PASS NVNT Band66 3 132657 8 #Mid QPSK 21…

Text truncated - open the document above for the full version.

No.：BCTC/KJ-RF-ICT-001 Page 1 of 54 Edition：B.1 Appendix for Band 7 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC2605525578E Applicant: SEEWORLD Technology Co.,ltd Product Name: GPS Tracker Test Model: G60L Tested Date: 2026-05-14 to 2026-06-15 Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 2 of 54 Edition：B.1 Contents Appendix 1.Conducted output power ................................................................................................................................................... 3 Appendix 2.Frequency stability ............................................................................................................................................................. 6 Appendix 3.Peak-to-Average Ratio ..................................................................................................................................................... 14 Appendix 4.Occupied bandwidth ........................................................................................................................................................ 25 Appendix 5.Band edge ......................................................................................................................................................................... 36 Appendix 6.Out-of-band emissions ..................................................................................................................................................... 44 Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 3 of 54 Edition：B.1 Appendix 1.Conducted output power Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Power (dBm) Gain (dBm) EIRP (dBm) Verdict NVNT Band7 5 20775 1 #0 QPSK 23.00 0.27 23.27 PASS NVNT Band7 5 20775 1 #Mid QPSK 22.96 0.27 23.23 PASS NVNT Band7 5 20775 1 #Max QPSK 23.28 0.27 23.55 PASS NVNT Band7 5 20775 12 #0 QPSK 21.96 0.27 22.23 PASS NVNT Band7 5 20775 12 #Mid QPSK 22.14 0.27 22.41 PASS NVNT Band7 5 20775 12 #Max QPSK 22.18 0.27 22.45 PASS NVNT Band7 5 20775 25 #0 QPSK 22.10 0.27 22.37 PASS NVNT Band7 5 20775 1 #0 16QAM 22.61 0.27 22.88 PASS NVNT Band7 5 20775 1 #Mid 16QAM 22.71 0.27 22.98 PASS NVNT Band7 5 20775 1 #Max 16QAM 22.98 0.27 23.25 PASS NVNT Band7 5 20775 12 #0 16QAM 21.23 0.27 21.50 PASS NVNT Band7 5 20775 12 #Mid 16QAM 21.35 0.27 21.62 PASS NVNT Band7 5 20775 12 #Max 16QAM 21.40 0.27 21.67 PASS NVNT Band7 5 20775 25 #0 16QAM 21.28 0.27 21.55 PASS NVNT Band7 5 21100 1 #0 QPSK 22.11 0.27 22.38 PASS NVNT Band7 5 21100 1 #Mid QPSK 22.11 0.27 22.38 PASS NVNT Band7 5 21100 1 #Max QPSK 22.68 0.27 22.95 PASS NVNT Band7 5 21100 12 #0 QPSK 21.08 0.27 21.35 PASS NVNT Band7 5 21100 12 #Mid QPSK 21.27 0.27 21.54 PASS NVNT Band7 5 21100 12 #Max QPSK 21.47 0.27 21.74 PASS NVNT Band7 5 21100 25 #0 QPSK 21.29 0.27 21.56 PASS NVNT Band7 5 21100 1 #0 16QAM 21.53 0.27 21.80 PASS NVNT Band7 5 21100 1 #Mid 16QAM 21.69 0.27 21.96 PASS NVNT Band7 5 21100 1 #Max 16QAM 22.25 0.27 22.52 PASS NVNT Band7 5 21100 12 #0 16QAM 20.33 0.27 20.60 PASS NVNT Band7 5 21100 12 #Mid 16QAM 20.54 0.27 20.81 PASS NVNT Band7 5 21100 12 #Max 16QAM 20.74 0.27 21.01 PASS NVNT Band7 5 21100 25 #0 16QAM 20.63 0.27 20.90 PASS NVNT Band7 5 21425 1 #0 QPSK 21.89 0.27 22.16 PASS NVNT Band7 5 21425 1 #Mid QPSK 21.78 0.27 22.05 PASS NVNT Band7 5 21425 1 #Max QPSK 22.45 0.27 22.72 PASS NVNT Band7 5 21425 12 #0 QPSK 20.86 0.27 21.13 PASS NVNT Band7 5 21425 12 #Mid QPSK 20.89 0.27 21.16 PASS NVNT Band7 5 21425 12 #Max QPSK 21.14 0.27 21.41 PASS NVNT Band7 5 21425 25 #0 QPSK 20.95 0.27 21.22 PASS NVNT Band7 5 21425 1 #0 16QAM 21.45 0.27 21.72 PASS NVNT Band7 5 21425 1 #Mid 16QAM 21.33 0.27 21.60 PASS Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 4 of 54 Edition：B.1 NVNT Band7 5 21425 1 #Max 16QAM 22.05 0.27 22.32 PASS NVNT Band7 5 21425 12 #0 16QAM 20.22 0.27 20.49 PASS NVNT Band7 5 21425 12 #Mid 16QAM 20.27 0.27 20.54 PASS NVNT Band7 5 21425 12 #Max 16QAM 20.49 0.27 20.76 PASS NVNT Band7 5 21425 25 #0 16QAM 20.27 0.27 20.54 PASS Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Power (dBm) Gain (dBm) EIRP (dBm) Verdict NVNT Band7 10 20800 1 #0 QPSK 24.07 0.27 24.34 PASS NVNT Band7 10 20800 1 #Mid QPSK 23.87 0.27 24.14 PASS NVNT Band7 10 20800 1 #Max QPSK 24.09 0.27 24.36 PASS NVNT Band7 10 20800 25 #0 QPSK 22.73 0.27 23.00 PASS NVNT Band7 10 20800 25 #Mid QPSK 22.91 0.27 23.18 PASS NVNT Band7 10 20800 25 #Max QPSK 22.88 0.27 23.15 PASS NVNT Band7 10 20800 50 #0 QPSK 22.82 0.27 23.09 PASS NVNT Band7 10 21100 1 #0 QPSK 22.69 0.27 22.96 PASS NVNT Band7 10 21100 1 #Mid QPSK 22.80 0.27 23.07 PASS NVNT Band7 10 21100 1 #Max QPSK 23.92 0.27 24.19 PASS NVNT Band7 10 21100 25 #0 QPSK 21.55 0.27 21.82 PASS NVNT Band7 10 21100 25 #Mid QPSK 21.96 0.27 22.23 PASS NVNT Band7 10 21100 25 #Max QPSK 22.32 0.27 22.59 PASS NVNT Band7 10 21100 50 #0 QPSK 21.98 0.27 22.25 PASS NVNT Band7 10 21400 1 #0 QPSK 23.05 0.27 23.32 PASS NVNT Band7 10 21400 1 #Mid QPSK 22.30 0.27 22.57 PASS NVNT Band7 10 21400 1 #Max QPSK 23.35 0.27 23.62 PASS NVNT Band7 10 21400 25 #0 QPSK 21.61 0.27 21.88 PASS NVNT Band7 10 21400 25 #Mid QPSK 21.53 0.27 21.80 PASS NVNT Band7 10 21400 25 #Max QPSK 21.67 0.27 21.94 PASS NVNT Band7 10 21400 50 #0 QPSK 21.62 0.27 21.89 PASS NVNT Band7 15 20825 1 #0 QPSK 23.63 0.27 23.90 PASS NVNT Band7 15 20825 1 #Mid QPSK 23.71 0.27 23.98 PASS NVNT Band7 15 20825 1 #Max QPSK 22.99 0.27 23.26 PASS NVNT Band7 15 20825 36 #0 QPSK 22.73 0.27 23.00 PASS NVNT Band7 15 20825 36 #Mid QPSK 22.83 0.27 23.10 PASS NVNT Band7 15 20825 36 #Max QPSK 22.53 0.27 22.80 PASS NVNT Band7 15 20825 75 #0 QPSK 23.18 0.27 23.45 PASS NVNT Band7 15 21100 1 #0 QPSK 22.48 0.27 22.75 PASS NVNT Band7 15 21100 1 #Mid QPSK 22.93 0.27 23.20 PASS NVNT Band7 15 21100 1 #Max QPSK 23.95 0.27 24.22 PASS NVNT Band7 15 21100 36 #0 QPSK 21.56 0.27 21.83 PASS NVNT Band7 15 21100 36 #Mid QPSK 22.04 0.27 22.31 PASS NVNT Band7 15 21100 36 #Max QPSK 22.41 0.27 22.68 PASS Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 5 of 54…

Text truncated - open the document above for the full version.

Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 37 of 73 Edition：B.1 Band5 16QAM BW=1.4MHz Channel=20525 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 38 of 73 Edition：B.1 Band5 QPSK BW=1.4MHz Channel=20643 RB Size=6 Position=#0 NVNT Band5 16QAM BW=1.4MHz Channel=20643 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 39 of 73 Edition：B.1 Band5 QPSK BW=3MHz Channel=20415 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 40 of 73 Edition：B.1 Band5 16QAM BW=3MHz Channel=20415 RB Size=15 Position=#0 NVNT Band5 QPSK BW=3MHz Channel=20525 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 41 of 73 Edition：B.1 Band5 16QAM BW=3MHz Channel=20525 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 42 of 73 Edition：B.1 Band5 QPSK BW=3MHz Channel=20635 RB Size=15 Position=#0 NVNT Band5 16QAM BW=3MHz Channel=20635 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 43 of 73 Edition：B.1 Band5 QPSK BW=5MHz Channel=20425 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 44 of 73 Edition：B.1 Band5 16QAM BW=5MHz Channel=20425 RB Size=25 Position=#0 NVNT Band5 QPSK BW=5MHz Channel=20525 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 45 of 73 Edition：B.1 Band5 16QAM BW=5MHz Channel=20525 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 46 of 73 Edition：B.1 Band5 QPSK BW=5MHz Channel=20625 RB Size=25 Position=#0 NVNT Band5 16QAM BW=5MHz Channel=20625 RB Size=25 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 47 of 73 Edition：B.1 Band5 QPSK BW=10MHz Channel=20450 RB Size=50 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 48 of 73 Edition：B.1 Band5 QPSK BW=10MHz Channel=20525 RB Size=50 Position=#0 NVNT Band5 QPSK BW=10MHz Channel=20600 RB Size=50 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 49 of 73 Edition：B.1 Appendix 5.Band edge Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict NVNT Band5 1.4 20407 6 #0 QPSK 824.00 -34.06 -13 PASS NVNT Band5 1.4 20407 6 #0 16QAM 823.99 -35.05 -13 PASS NVNT Band5 1.4 20643 6 #0 QPSK 849.00 -35.42 -13 PASS NVNT Band5 1.4 20643 6 #0 16QAM 849.00 -36.40 -13 PASS NVNT Band5 3 20415 15 #0 QPSK 824.00 -32.94 -13 PASS NVNT Band5 3 20415 15 #0 16QAM 824.00 -33.80 -13 PASS NVNT Band5 3 20635 15 #0 QPSK 849.00 -34.26 -13 PASS NVNT Band5 3 20635 15 #0 16QAM 849.01 -35.29 -13 PASS NVNT Band5 5 20425 25 #0 QPSK 824.00 -31.06 -13 PASS NVNT Band5 5 20425 25 #0 16QAM 823.99 -33.37 -13 PASS NVNT Band5 5 20625 25 #0 QPSK 849.00 -32.52 -13 PASS NVNT Band5 5 20625 25 #0 16QAM 849.00 -32.31 -13 PASS Condition Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict NVNT Band5 10 20450 50 #0 QPSK 824.00 -35.95 -13 PASS NVNT Band5 10 20600 50 #0 QPSK 849.00 -35.65 -13 PASS Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 50 of 73 Edition：B.1 Band5 QPSK BW=1.4MHz Channel=20407 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 51 of 73 Edition：B.1 Band5 16QAM BW=1.4MHz Channel=20407 RB Size=6 Position=#0 NVNT Band5 QPSK BW=1.4MHz Channel=20643 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 52 of 73 Edition：B.1 Band5 16QAM BW=1.4MHz Channel=20643 RB Size=6 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 53 of 73 Edition：B.1 Band5 QPSK BW=3MHz Channel=20415 RB Size=15 Position=#0 NVNT Band5 16QAM BW=3MHz Channel=20415 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 54 of 73 Edition：B.1 Band5 QPSK BW=3MHz Channel=20635 RB Size=15 Position=#0 NVNT Report No.:BCTC2605525578E No.：BCTC/KJ-RF-ICT-001 Page 55 of 73 Edition：B.1 Band5 16QAM BW=3MHz Channel=20635 RB Size=15 Position=#0 NVNT Band5 QPSK BW=5MHz Ch…

Text truncated - open the document above for the full version.
