Page 1 of 1 1 Photographs - EUT Constructional Details Model No.: RN934A

Model No: RN934A FCC ID: 2AX2URN934A Remark: It’s hard to put FCC statement on the product due to device’s irregular appearance. FCC statement will be placed in the user manual which the device is marketed.

Page 1 of 1 2 Photographs - EUT Constructional Details Model No.: RN934A

` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SEWA2310000121RG04 Rev.: 01 Page: 1 of 22 Authorized Signature: Well Wei Wireless Laboratory Manager TEST REPORT Application No: SEWA2310000121RG Applicant: Rolling Wireless S.à r.l. Address of Applicant: 15, rue Edward Steichen, 2540 Luxembourg Manufacturer: Rolling Wireless S.à r.l. Address of Manufacturer: 15, rue Edward Steichen, 2540 Luxembourg EUT Description: RN934A Model No.: RN934A Trade Mark: Rolling Wireless FCC ID: 2AX2URN934A Standard(s): FCC 47 CFR Part 15, Subpart B Date of Receipt: 2023/09/28 Date of Test: 2023/10/17 to 2023/10/18 Date of Issue: 2023/10/31 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SEWA2310000121RG04 Rev.: 01 Page: 2 of 22 Revision Record Version Chapter Date Modifier Remark 01 2023/10/31 Original Prepared By (King-p Li) / Test Engineer Checked By (Stone Gu) / Reviewer ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SEWA2310000121RG04 Rev.: 01 Page: 3 of 22 Test Summary Emission Part Item Standard Method Requirement Result Conducted Emissions at Mains Terminals (150kHz-30MHz) FCC 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Radiated Emissions (30MHz-1GHz) FCC 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Radiated Emissions (above 1GHz) FCC 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Internal Source Upper Frequency Below 1.705MHz 30MHz 1.705MHz to 108MHz 1GHz 108MHz to 500MHz 2GHz 500MHz to 1GHz 5GHz Above 1GHz 5th harmonic of the highest frequency or 40GHz, whichever is lower ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SEWA2310000121RG04 Rev.: 01 Page: 4 of 22 Contents 1 General Information ...................................................................................................... 5 1.1 Description of Support Units .................................................................................. 6 1.2 Test Location ......................................................................................................... 6 1.3 Test Facility ........................................................................................................... 6 1.4 Deviation from Standards ...................................................................................... 6 1.5 Abnormalities from Standard Conditions ............................................................... 6 2 Emission Test Results .................................................................................................. 7 2.1 Conducted Emissions at Mains Terminals (150kHz-30MHz) ................................. 7 2.1.1 E.U.T. Operation ................................................................................................ 7 2.1.2 Test Setup Procedures ...................................................................................... 8 2.1.3 Measurement Data ............................................................................................ 8 2.2 Radiated Emissions (30MHz-1GHz) .................................................................... 11 2.2.1 E.U.T. Operation .............................................................................................. 11 2.2.2 Test Setup Procedures .................................................................................... 12 2.2.3 Measurement Data .......................................................................................... 12 2.3 Radiated Emissions (above 1GHz) ...................................................................... 15 2.3.1 E.U.T. Operation .............................................................................................. 15 2.3.2 Test Setup Procedures .................................................................................... 16 2.3.3 Measurement Data .......................................................................................... 16 3 Equipment List ............................................................................................................ 19 4 Measurement Uncertainty ........................................................................................... 21 5 Photographs ............................................................................................................... 22 5.1 Test Setup ........................................................................................................... 22 ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SEWA2310000121RG04 Rev.: 01 Page: 5 of 22 1 General Information Product Name: RN934A Model No. (EUT): RN934A Trade Mark: Rolling Wireless Hardware Version: 1 Software Version: AFPQ52XA_00.11.01.00 IMEI: 354360450001151 Frequency Bands: Band Tx (MHz) Rx (MHz) LTE Band 7 2500~2570 2620~2690 NR Band n78 3450-3550 3450-3550 LTE CA: LTE Band CA_7C ENDC: DC_7A_n78A; GNSS / 1559~1610 Remark: As above information is provided and confirmed by the applicant. SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SEWA2310000121RG04 Rev.: 01 Page: 6 of 22 1.1 Description of Support Units The EUT has been tested as an independent unit. 1.2 Test Location All tests were performed at: Company: SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Address: South of No. 6 Plant, No. 1, Runsheng Road, Suzhou Industrial Park, Suzhou Area, China (Jiangsu) Pilot Free Trade Zone Post code: 215000 Test engineer: King-p Li 1.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6336.01) SGS-CSTC STANDARDS TECHNICAL SERVICES (SUZHOU) CO., LTD. is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 6336.01. • Innovation, Science and Economic Development Canada SGS-…

Text truncated - open the document above for the full version.

` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Rev.: 01 Page: 1 of 5 Appendix A.1 Setup Photos for SEWA2310000121RG04 ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Rev.: 01 Page: 2 of 5 1.1 AC Power Line Conducted Emissions ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Rev.: 01 Page: 3 of 5 1.2 Radiated Emission below 1GHz ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Rev.: 01 Page: 4 of 5 1.3 Radiated Emission above 1GHz 1G-18GHz: ` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Rev.: 01 Page: 5 of 5 Above 18GHz: ---End of Attachment---
