1 2021-01-29 ISAN10 & ISRL10 User Manual ISAN10 & ISRL10 User Manual v1.1.0 2 2021-01-29 ISAN10 & ISRL10 User Manual ZKISAN10-UG Edition V1.1 May 2021 Copyright © ZeroKey Inc. All rights reserved. This manual is confidential and proprietary, and may not be reproduced, copied, transmitted, or translated into any language, in any form, or by any means, without the express written permission of ZeroKey Inc. (“ZeroKey”). Product warranty or service will not be extended if: (1) the product is repaired, modified, or altered, unless such repair, modification, or alteration is authorized in writing by ZeroKey; or (2) the serial number of the product is defaced or missing. ZEROKEY PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ZEROKEY, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ZEROKEY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ZEROKEY. ZEROKEY ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies and are used only for identification or explanation and to the owners’ benefit, without intent to infringe. 3 2021-01-29 ISAN10 & ISRL10 User Manual Safety Notice, please read before using device. WARNING! The ISAN10 is designed to be operated in hazardous areas where flammable vapours and gases may be present. • Read this user manual before use. • Do NOT expose the device to temperatures above 60 c (140 F) • Do NOT disassemble, modify, or attempt to repair this device. • Do NOT open this device under any circumstances. • Do NOT immerse in liquid(s). • No serviceable parts inside. • Clean only with a damp cloth to prevent static build up. Certification and Compliance The ISAN10 and ISRL10 are certified through SGS Group for use in hazardous locations. Rated as Class 1 Division 1, IP65, The radio used in this device has been certified for use according to Federal Communications Commission (FCC), Industry Canada (IC) and Conformitè Europëenne (CE) rules and regulations. NOTE: Any changes or modifications to this device, not expressly approved by Zerokey, could void the user's authority to operate the equipment. 4 2021-01-29 ISAN10 & ISRL10 User Manual FCC Part 15 Regulatory Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RSS Regulatory Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. RF Exposure Statement This device has been evaluated to, and shown to be compliant with, the FCC, IC, CE Radio Frequency (RF) exposure limits. 5 2021-01-29 ISAN10 & ISRL10 User Manual TABLE OF CONTENTS 1 PREFACE ........................................................................................................................................................ 6 1.1 ABOUT THIS GUIDE ............................................................................................................................................ 6 1.2 WHERE TO FIND MORE INFORMATION ................................................................................................................... 6 2 OVERVIEW ..................................................................................................................................................... 7 3 UNIT .............................................................................................................................................................. 7 3.1 PHYSICAL CHARACTERISTICS .............................................................................................................................. 7 3.1.1 SIZE ........................................................................................................................................................... 7 3.1.2 WEIGHT .................................................................................................................................................... 7 3.1.3 IP RATING ................................................................................................................................................. 7 3.1.4 POWER ..................................................................................................................................................... 7 3.2 FEATURES ...............................…

Text truncated - open the document above for the full version.

3120-12 St NE Calgary, Alberta, Canada T2E 8T3 Ph: (403) 536 – 0775 Web: www.zerokey.com Date: May 20, 2021 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AX6LISAN10 To whom it may concern: We, the undersigned, hereby authorize SGS Consumer and Retail to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with ZEROKEY INC. This authorization is valid until further written notice from the applicant. Name (Printed): DAVID S. MCNAB Title: VP HARDWARE AND PRODUCTION Signature: On behalf of Company: ZEROKEY INC. Telephone: 403 390 5942

SGS North America Inc. Consumer and Retail 620 Old Peachtree Road Suite 100 Suwanee GA 30024 t (770) 570-1800 f (770) 277-1240 www.sgs.com Member of the SGS Group (SGS SA) Attn: Director of Certification Confidentiality Request regarding application for FCC ID: 2AX6LISAN10 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby requests confidential treatment of the documents listed below, associated with the certification application referenced above. Schematics Block Diagram Theory of Operation The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. Internal Photos External Photos Test Setup Photos User Manual Sincerely, Martin Taylor Agent for ZEROKEY Inc. SGS North America Title: RF/EMC Engineer Date: 14 June 2021

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ZEROKEY INCORPORATED Address 3120 12TH ST NE CALGARY ALBERTA, CANADA T2E 8T3 Grantee Code 2AX6L FCC ID 2AX6LISAN10 Authorized Contact Name DAVID MCNAB Contact Email [email protected] Contact Phone 1 (403) 390 5942 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: May 20, 2021 Print Name: DAVID S. MCNAB Title: VP HARDWARE AND PRODUCTION *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

EXTERNAL PHOTOS FCC ID: 2AX6LISAN10 IC: 26679-ISAN10 2 © SGS SA 2016 ALL RIGHTS RESERVED 3 © SGS SA 2016 ALL RIGHTS RESERVED 4 © SGS SA 2016 ALL RIGHTS RESERVED 5 © SGS SA 2016 ALL RIGHTS RESERVED WWW.SGS.COM

LABEL LOCATION FCC ID: 2AX6LISAN10 IC: 26679-ISAN10 2 © SGS SA 2016 ALL RIGHTS RESERVED LABEL LOCATION WWW.SGS.COM

Anchor product ID label Actual Size 1.25” x 2” Actual label has rounded corners. Packaging FCC label Actual Size 3.5” x 2.0” Actual label has rounded corners. Packaging SKU label Actual Size 1.5” x 0.5” FCC ID:2AX6LISAN10 IC: 26679-ISAN10 MODEL: AGISAN10 SN: XX-NNNNNNNN ID: YYYYYYYYYYYY MFG: MM-DD-YYYY Made in Canada Cl 1 Div 1 Gr A, B, C, D, T4 II 1 G Ex ia IIC T4 Gb -40 o C <= T A <= 60 o C 1180 AEGIS INTEGRATED 5CHAR AEGIS INTEGRATED Model: AGISAN10 FCC Declaration: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ZKIS0001 ANCHOR This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

INTERNAL PHOTOS FCC ID: 2AX6LISAN10 IC: 26679-ISAN10 2 © SGS SA 2016 ALL RIGHTS RESERVED 3 © SGS SA 2016 ALL RIGHTS RESERVED 4 © SGS SA 2016 ALL RIGHTS RESERVED 5 © SGS SA 2016 ALL RIGHTS RESERVED 6 © SGS SA 2016 ALL RIGHTS RESERVED 7 © SGS SA 2016 ALL RIGHTS RESERVED 8 © SGS SA 2016 ALL RIGHTS RESERVED WWW.SGS.COM

Test Report Number: 4681230EMC15 Rev:0 ZEROKEY Inc. / Anchor Node Page: 1 of 5 Remarks: This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This document is issued by the Company under its General Conditions of Service accessible at http://www.sgs.com/en/Terms-and- Conditions.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. RF Exposure Report Project Number: 4681230 Proposal Number: 11079 Report Number: 4681230EMC15 Revision Level: 0 Client: ZEROKEY Inc. Equipment Under Test: 50V Ultrasonic Transducer Model Name: Anchor Node Model Numbers: AGISAN10 and ZKISAN10 FCC ID: 2AX6LISAN10 Applicable Standards: 47 CFR §§ 2.1091 FCC KDB 447498 D01 General RF Exposure Guidance v06 Report issued on: 04 June 2021 Result: Compliant FOR THE SCOPE OF ACCREDITATION UNDER CERTIFICATE NUMBER: 3212.01 This report must not be used by the client to claim product certification, approval, or endorsement by A2LA, NIST, or any agency of the Federal Government. Prepared by: Martin Taylor, Project Engineer Reviewed by: Stephen Whalen, EMC Lab Manager Test Report Number: 4681230EMC15 Rev:0 ZEROKEY Inc. / Anchor Node Page: 2 of 5 SGS North America Inc. Connectivity & Products 620 Old Peachtree Road NW, Suite 100, Suwanee, GA 30024 t (770) 570-1800 www.sgs.com Member of the SGS Group (SGS SA) TABLE OF CONTENTS 1 GENERAL INFORMATION ............................................................................................................................................. 3 1.1 CLIENT INFORMATION ................................................................................................................................................... 3 1.2 TEST LABORATORY ....................................................................................................................................................... 3 1.3 GENERAL INFORMATION OF EUT .................................................................................................................................. 3 2 RF EXPOSURE ................................................................................................................................................................... 4 2.1 TEST RESULT ................................................................................................................................................................. 4 2.2 TEST METHOD ............................................................................................................................................................... 4 2.3 SINGLE TRANSMISSION RF EXPOSURE LEVELS (MW/CM 2 ) ............................................................................................ 4 4 REVISION HISTORY ........................................................................................................................................................ 5 Test Report Number: 4681230EMC15 Rev:0 ZEROKEY Inc. / Anchor Node Page: 3 of 5 SGS North America Inc. Connectivity & Products 620 Old Peachtree Road NW, Suite 100, Suwanee, GA 30024 t (770) 570-1800 www.sgs.com Member of the SGS Group (SGS SA) 1 General Information 1.1 Client Information Name: ZEROKEY Inc. Address: 3120 12 Street NE City, State, Zip, Country: Calgary, Alberta T2E 8T3 Canada 1.2 Test Laboratory Name: SGS North America, Inc. Address: 620 Old Peachtree Road NW, Suite 100 City, State, Zip, Country: Suwanee, GA 30024, USA Accrediting Body: A2LA Type of lab: Testing Laboratory Certificate Number: 3212.01 1.3 General Information of EUT Equipment Under Test: 50V Ultrasonic Transducer Model Name: Anchor Node Model Numbers: AGISAN10 and ZKISAN10 Sample ID: SUWES2012000108HZ FCC ID: 2AX6LISAN10 Frequency Range: 2402 – 2480 MHz (one BLE radios) Data Modes: Bluetooth Low Energy (GFSK 1Mbps & 2Mbps) Nordic Enhanced ShockBurst Protocol (GFSK 2Mbps) Antenna: Surface Mount Stamped Metal Antenna (4.9 dBi max gain) Rated Voltage: 3.6 Vdc Lithium Thionyl Chloride Battery Test Voltage: 3.6 Vdc Lithium Thionyl Chloride Battery Sample Received Date: 02 February 2021 Dates of testing: 07 April 2021 Test Report Number: 4681230EMC15 Rev:0 ZEROKEY Inc. / Anchor Node Page: 4 of 5 SGS North America Inc. Connectivity & Products 620 Old Peachtree Road NW, Suite 100, Suwanee, GA 30024 t (770) 570-1800 www.sgs.com Member of the SGS Group (SGS SA) 2 RF Exposure 2.1 Test Result Test Description Product Specific Standard Test Result RF Exposure FCC Part 1.1310 Compliant 2.2 Test Method Using the maximum conducted power, the power density was calculated. Maximum antenna gain was assumed for this exercise. 2.3 Single transmission RF Exposure Levels (mW/cm 2 ) Conducted Power w/tolerance Antenna Gain Cable Loss Distance (R) Power Density EIRP Avg /(4πR 2 ) FCC% of LimitVerdict TypeMHzdBmdBmmWcmmW/cm 2 mW/cm 2 Bluetooth LE (Anchor)2400-2483.55.04.90.09.910200.0021.000%Pass Average EIRP Band of Operation Test Report Number: 4681230EMC15 Rev:0 ZEROKEY Inc. / Anchor Node Page: 5 of 5 SGS North America Inc. Connectivity & Products 620 Old Peachtree Road NW, Suite 100, Suwanee, GA 30024 t (770) 570-1800 www.sgs.com Member of the SGS Group (SGS SA) 4 Revision H…
