2AX6LQTMEAP11Quantum RTLS POE Anchor with Nordic Enhanced ShockBurst

Copyright © 2020 ZeroKey Inc. All rights reserved. Updated: 2022-11-01 QTM-EAP10/QTM-EAP11 Device Manual v1.0.7 Quantum RTLS POE Anchor ii 2021-10-25 QTM-EAP10/QTM-EAP11 Device Manual 05-01-0002 Edition V1 October 2021 Copyright © ZeroKey Inc. All rights reserved. This manual is confidential and proprietary, and may not be reproduced, copied, transmitted, or translated into any language, in any form, or by any means, without the express written permission of ZeroKey Inc. (“ZeroKey”). Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification, or alteration is authorized in writing by ZeroKey; or (2) the serial number of the product is defaced or missing. ZEROKEY PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ZEROKEY, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ZEROKEY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ZEROKEY. ZEROKEY ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies and are used only for identification or explanation and to the owners’ benefit, without intent to infringe. Revision Tracking Rev EC Author Reviewer Approver Change Notes Date V1.0.0 N/A Released to Baseline 2021/10/25 V1.0.1 N/A K. Fulton Update to Regulatory Statements Add revision history table Add system diagram 2021/12/10 V1.0.2 N/A K. Fulton Add power supply usage statement Add references to QTM-EAP10 and QTM-EAP11 Changed daisy chain units (10 for QTM- EAP10, 12 for QTM-EAP11) 2022/01/27 V1.0.3 N/A J. Wolf Update compliance for ‘Class A’ device Updated System Diagram 2022/08/04 V1.0.4 N/A J. Wolf Updated model naming format Added class A warning statement Updated certification wording Updated USB port wording 2022/08/16 V1.0.5 N/A J.Wolf Updated DC Power Supply wording. 2022/09/16 V1.0.6 N/A J. Wolf -Updated regulatory statement wording 2022/10/21 V1.0.7 N/A J. Wolf -Added product name to title page - Added FCC Part 18 statement 2022/11/01 iii 2021-10-25 QTM-EAP10/QTM-EAP11 Device Manual Certification and Compliance The radio used in this device has been certified for use according to Federal Communications Commission (FCC), Industry Canada (IC) and Conformitè Europëenne (CE) rules and regulations. FCC Regulatory Statement Model: QTM-EAP10, FCC ID: 2AX6LQTMEAP10 Model: QTM-EAP11, FCC ID: 2AX6LQTMEAP11 Caution: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Warning: Operation of this equipment in a residential environment could cause radio interference. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. This equipment can be installed and operated with a minimum distance 20 centimeters between the radiator and user’s body. This equipment has been evaluated to meet general RF exposure requirement at 20 centimeters distance. This device complies with Part 18 of the FCC Rules. iv 2021-10-25 QTM-EAP10/QTM-EAP11 Device Manual ISED Regulatory Statement Model: QTM-EAP10, IC: 26679-QTMEAP10 Model: QTM-EAP11, IC: 26679-QTMEAP11 CAN ICES-003(A)/NMB-003(A) This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Warning: Operation of this equipment in a residential environment could cause radio interference. CAN ICES-003(A)/NMB-003(A) Le présent appareil est conforme aux CNR Innovation, Sciences et Développement é…

Text truncated - open the document above for the full version.

Date (08/16/2022) TUV SUD BABT UNLIMITED Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, PO15 5RL United Kingdom Confidentiality Request FCC ID: 2AX6LQTMEAP11 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, ZEROKEY INC. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation] ZEROKEY INC.also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Dave McNab, VP Hardware Telephone Number: 1 (403) 390-5942 Email: [email protected]

Appendix Model: QTM-EAP11 Appendix Appendix Appendix

QTM-EAP11 PRODUCT LABELING Quantum PoE Anchor V1.1 product ID label Actual size 20 x 40 mm (W x L) Label Location MODEL: QTM-EAP11 SN: XX-NNNNNNNN ID: YYYYYYYYYYYY MSIP R-R-ZKY-QTMEAP11 FCC ID: 2AX6LQTMEAP11 IC: 26679-QTMEAP11 ZEROKEY Model: QTM-EAP11 FCC Declaration: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Do not immerse, protect from fluids and dust. FCC ID: 2AX6LQTMEAP11 IC: 26679-QTMEAP11 XXX-XXXXX XXX-XXXXX R-R-ZKY-QTMEAP11 Packaging FCC label Actual Size 3.5” x 2.0” Uline Laser Labels-White, 3 1 ⁄ 2 x 2" S-6944 QR CODE DATA CONTENT AND FORMAT ZZ|AAAAAA|BB|NNNNNNNN|YYYYYYYYYYYY|YYYYYYYYYYYY|MMDDYYYY SegmentLengthFunctionDescription / options ZZTwo CharactersBRANDZK - ZEROKEY AAAAAA6 CharactersMODELQEAP11 BBTwo CharactersTYPE CODEPA – PoE Anchor unit V1.1 NNNNNNNN Eight DigitsSERIAL NUMBER Each unit of each “Type Code” has an 8 digit serial number, 1 to 99,999,999 YYYYYYYYYYYY Twelve Characters MAC ADDRESS 1 Each unit has a Primary Radio MAC address YYYYYYYYYYYY Twelve Characters MAC ADDRESS 2 Not used MMDDYYYYEight Digits DATE OF MANUFACTURE Each unit has a date of manufacture, month, day year ID Label Material & Ribbon Specifications Label Part Number: Identco 1.574x0.7874TT700 Ribbon Part Number: Identco 1011572 (TTRR-B3.27ZL) or 1034489 (TTRR-D3.27ZL) LABEL MATERIALTT700 Thermal Transfer Gloss White Polyester Film Agency Recognitions UL-MH16873/MH16225 CSA-089882_L_000` Adhesion Stainless Steel55 oz/in605 N/m Polycarbonate77 oz/in847 N/m Polypropylene15 oz/in165 N/m Glass69 oz/in759 N/m Material Thickness Face Stock.0020”50.8μ Adhesive.0009’’22.9μ Liner (kraft).0030”76.2μ Total Material.0059’’149.9μ Service Temperature-40 ̊F to 302 ̊F-40 ̊C to 150 ̊C Chemical Resistance AgentMaterialPrint (Resin) Household CleanersPassedPassed OilPassedPassed WaterPassedPassed Isopropyl AlcoholPassedPassed Mild AcidPassedPassed Mineral SpiritsPassedPassed ToluenePassedFailed Ribbon SpecificationsTTRR-DTTRR-B Ink TypeResin Ink Color(s)Black Ink Melting Point110°C Thickness (microns) Ink2.74.5 Thickness (microns) Base4.84.5 Thickness (microns) Total7.59 Image Density>1.9>1.7 Transmission Density>0.90 Print Speed (IPS)610 Max. Service Temp*180°C Max. Intermittent Temp*270°C Storage 4 years @ 45° - 90°F (7° - 32°C) and 20-75% R.H.

Appendix Model: QTM-EAP11 Appendix Antenna 2402-2480MHz Appendix Appendix

Report Number: 60.790.22.003.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 44 of 45 Radiofrequency radiation exposure evaluation This exposure evaluation is intended forFCC ID: 2AX6LQTMEAP11 According to FCC CFR 47 part1 §1.1310, Part 2 §2.1091, and KDB447498 D01 General RF Exposure Guidance v06, As specified in Table 1B of 47 CFR 1.1310 – Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (B) Limits for General Population/Uncontrolled Exposure 0.3-1.346141.63*10030 1.34-30824/f2.19/f*180/f 2 30 30-30027.50.0730.230 300-1,500f/150030 1,500-100,0001.030 MPE calculation method: Pd = (P*G) / (4*Pi* R 2 ), where Pd = power density in mW/cm 2 P = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R= calculation distance in cm >> The limit of Power density in 2402-2480MHz band is 1 mW/cm 2 >> The antenna gain is 3.2dBi (=2.09 in linear scale). Manufacturer specified the separation distance is: 20cm The max. power (calculated power + tune up tolerance) of EUT in 2402-2483.5MHz band is: 3.28mW >> The calculated Pd for the EUT in 2402-2480MHz band is 0.00136mW/cm 2 >> So, the calculated Pd is smaller than the threshold of the limit. Therefore, the device is exempt from stand-alone SAR test requirements. 10AppendixA-General Product Information Report Number: 60.790.22.003.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 45 of 45 Appendix A Calculated Data Maximum peak output power at antenna input terminal (dBm):5.16 Maximum peak output power at antenna input terminal (mW):3.28 Prediction distance (cm):20 Maximum Antenna Gain, typical (dBi):3.2 Maximum Antenna Gain (numeric):2.09 The worst case is power density at predication frequency at 20 cm (mW/cm2): 0.00136 Reviewed by: Prepared by: ______________________ ___________________ Eric LIHosea CHAN EMC Project ManagerEMC Project Engineer

Report Number: 60.790.22.003.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 1 of 45 FCC - TEST REPORT Report Number:60.790.22.003.01R01Date of Issue:October 27, 2022 Model:QTM-EAP11 Product Type:Quantum RTLS POE Anchor Applicant: ZEROKEY INC. Address: 3120 12TH ST NE, CALGARY AB T2E 8T3, CANADA Production Facility1:ZEROKEY INC. Address:3120 12TH ST NE, CALGARYABT2E 8T3,CANADA Production Facility2:DYNAMIC SOURCE MANUFACTURING INC Address: 6285 76 AVE SE, UNIT 130, CALGARY ALBERTA T2C 5L9, CANADA Test Result:nPositiveoNegative Total pages including Appendices : 45 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 60.790.22.003.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 2 of 45 1 Table of Contents 1 Table of Contents ............................................................................................................ 2 2 Description of Equipment Under Test ............................................................................. 3 3 Summary of Test Standards ........................................................................................... 4 4 Details about the Test Laboratory ................................................................................... 5 4.1 Test Equipment Site List ................................................................................................... 6 4.2 Measurement System Uncertainty .................................................................................... 7 5 Summary of Test Results ................................................................................................ 8 6 General Remarks ............................................................................................................ 9 7 Test Setups ................................................................................................................... 10 7.1 Radiated test setups Below 1GHz................................................................................... 10 7.2 Radiated test setups Above 1GHz .................................................................................. 10 7.3 AC Power Line Conducted Emission test setups ............................................................ 11 7.4 Conducted RF test setups............................................................................................... 11 8 Emission Test Results .................................................................................................. 12 8.1 Spurious Radiated Emission ........................................................................................... 12 8.2 Conducted Emission at AC Power line ............................................................................ 16 8.3 6dB & 99% Bandwidth .................................................................................................... 18 8.4 Peak Output Power ......................................................................................................... 21 8.5 Spurious Emissions at Antenna Terminals ...................................................................... 24 8.6 100kHz Bandwidth of band edges................................................................................... 30 8.7 Power Spectral Density ................................................................................................... 32 8.8 Antenna Requirement ..................................................................................................... 35 9 Test setup procedure .................................................................................................... 36 10 Appendix A - General Product Information ................................................................. 44 Report Number: 60.790.22.003.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 3 of 45 2 Description of Equipment Under Test Description of the Equipment Under Test Product:Quantum RTLS POE Anchor Model no.: QTM-EAP11 FCC ID: 2AX6LQTMEAP11 Rating: Input: 56VDC, 30W (POE input) Or 56VDC, 30W (DC Jack input) Output: 56VDC (POEoutput) Operating mode:Enhanced Shockburst Frequency:2402-2480MHz (Tx and Rx) Antenna Info.:Internal Antenna, PCBantenna,3.2dBi gain. Number of operated channels: 79, 1MHz channel space Modulation: GFSK Remark: --- Auxiliary Equipment and Software Used during Test: DESCRIPTIONMANUFACTURERMODEL NO./ SPEC.REMARK POE Injector (AC/DC Adapter) Phihong Techn…

Text truncated - open the document above for the full version.

Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 1 of 8 Inventek Systems OEM Wi-Fi Antennas P/N: W24P-U Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 2 of 8 Table of Contents 1 GENERAL DESCRIPTION ....................................................................................... 3 2 PART NUMBER DETAIL DESCRIPTION .............................................................. 3 Ordering Information................................................................................................. 3 3 GENERAL FEATURES ............................................................................................. 3 3.1 Environmental Specifications ............................................................................. 3 4 Features ....................................................................................................................... 4 5 Applications ................................................................................................................ 4 6 Electrical Specifications.............................................................................................. 4 6.1 Return Loss(S¹¹) .................................................................................................. 4 6.2 Smith Chart(S¹¹) .................................................................................................. 5 7 Antenna Dimensions (unit: mm) ................................................................................. 5 8 Radiation Pattern ......................................................................................................... 6 8.1 3D Gain Pattern (Radiation Pattern at 2442 MHz) ............................................. 6 8.2 9-2 Efficiency Table ........................................................................................... 7 8.3 9-3 Efficiency vs. Frequency .............................................................................. 7 9 Electrical Specifications.............................................................................................. 7 10 REVISION CONTROL .............................................................................................. 8 11 CONTACT INFORMATION ..................................................................................... 8 Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 3 of 8 1 GENERAL DESCRIPTION The Inventek 2400-2500 Mhz Wi-Fi PCB (30 x 5 mm) antennas let you integrate Wi-Fi functionality into your product quickly and easily. It’s suitable for a wide range of applications and recommended for use with Inventek eS-Wi-Fi modules. 2 PART NUMBER DETAIL DESCRIPTION Ordering Information Device Description Ordering Number W24P-U 2400-2500 Mhz Wi-Fi PCB antenna with U.Fl connector and 90 mm cable length W24P-U 3 GENERAL FEATURES Characteristics Specifications Unit Outline Dimensions 30 x 5.0 x .05 mm Center Frequency 2442 MHz Bandwith 100 min. MHz VSWR 2 max. Impedance 50 Ω Polarization Linear Polarization Gain Peak 3.2 (typical) dBi Efficiency 79 (typical) % 3.1 Environmental Specifications Item Description Operating temperature rang -40 deg. C to +80 deg. C Storage temperature range -55 deg. C to +100 deg. C Humidity 95% max non-condensing Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 4 of 8 4 Features  Stable and reliable in performances  PCB antenna has excellent sensitivity to consistently provide high signal reception efficiency  Compact size  RoHS compliance 5 Applications *IEEE802.11 (b/g/n). *Hand-held devices when WiFi (802.11 b/g/n) functions are needed. 6 Electrical Specifications 6.1 Return Loss(S¹¹) Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 5 of 8 6.2 Smith Chart(S¹¹) 7 Antenna Dimensions (unit: mm) Our standard cable length is 90mm long. Minimum order custom cable lengths can be special order by request. Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 6 of 8 8 Radiation Pattern 8.1 3D Gain Pattern (Radiation Pattern at 2442 MHz) 2.4 Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 7 of 8 8.2 9-2 Efficiency Table 8.3 9-3 Efficiency vs. Frequency 9 Electrical Specifications Frequency(GHz) 2.400 2.412 2.417 2.422 2.427 2.432 2.437 2.442 2.447 2.452 2.457 2.462 2.467 2.472 2.484 Efficiency(dB) -1.51 -1.26 -1.21 -1.13 -1.09 -0.99 -0.90 -1.01 -1.06 -1.04 -0.87 -0.79 -0.82 -0.86 -0.98 Efficiency (%) 70.63 74.82 75.68 77.09 77.80 79.62 81.28 79.25 78.34 78.70 81.85 83.37 82.79 82.04 79.80 Gain(dBi) 2.76 2.96 3.02 3.05 3.15 3.24 3.32 3.26 3.23 3.26 3.42 3.55 3.56 3.58 3.48 Confidential Inventek Systems, LLC. DOC-DS-20075-1.0 Page 8 of 8 RoHS: Restriction of Hazardous Substances (RoHS) directive has come into force since 1st July 2006 all electronic products sold in the EU must be free of hazardous materials, such as lead. 10 REVISION CONTROL Document : W24P-U 2.4 Ghz PCB antenna Internal Release DOC-DS-20075 Date Author Revision Comment 10/1/2013 FMT 1.0 Preliminary 11 CONTACT INFORMATION Inventek Systems 2 Republic Road Billerica Ma, 01862 Tel: 978-667-1962 [email protected] www.inventeksys.com Inventek Systems reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or design. The information contained within is believed to be accurate and reliable. However Inventek Systems does not assume any liability arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither does it convey any license under its patent rights nor the rights of others.

Appendix Model: QTM-EAP11 Radiated Emission Below 1GHz Radiated Emission Above 1GHz Conducted Emission
