2AX76-CONTROL3Radio receiver for lighting control

MANUALE DI INSTALLAZIONE E USO INSTALLATION MANUAL INSTALLATIONSHANDBUCH MANUEL D'INSTALLATION MANUAL DE INSTALACIÓN IT EN DE FR ES DOMUS LINE Srl Via Maestri del Lavoro, 1 33080 PORCIA _ PN _ Italy phone fax e-mail website 0039 0434 595911 0039 0434 923345 [email protected] www.domusline.com RECEIVER CONTROLLER TWF Apparecchio in classe di protezione III. L'alimentazione deve essere fornita da un alimentatore di sicurezza. Protection class III device. Power must be supplied by a safe power supply. Appareil avec classe de protection III. L'alimentation doit être fournie par un transformateur de sécurité. Leuchte mit Schutzklasse III. Die Stromversorgung muss mit einem Sicherheits-Anschlusskabel geliefert werden. Il prodotto deve essere smaltito separatamente dai rifiuti urbani consegnandolo ai centri di raccolta previsti dalla normativa in vigore. L'adeguata raccolta differenziata contribuisce ad evitare possibili effetti negativi sull'ambiente e sulla salute e favorisce il reimpiego e/o il riciclo dei materiali. Lo smaltimento abusivo comporta l'applicazione delle sanzioni amministrative previste dalla normativa vigente. The product must be disposed of separately from urban waste, delivering it to the collection centres established by the prevailing standard. Adequate sorted waste collection contributes to preventing negative effects on the environment and health and favours reuse and/or recycling materials. Incorrect disposal of the product implies the application of the administrative sanctions envisaged by the prevailing regulation. Die Leuchte muss getrennt vom Hausmüll entsorgt und entsprechend der geltenden Richtlinien, an den vorgesehenen Sammelstellen abgegeben werden. Die angemessene getrennte Sammlung trägt dazu bei, eventuelle negative Auswirkungen auf die Umwelt und die Gesundheit zu vermeiden und die Wiederverwendung und/oder das Recycling der Materialien zu begünstigen. Die unsachgemäße Entsorgung bringt die Anwendung administrativer Strafen mit sich, die in den geltenden Richtlinien vorgesehen sind. Le produit doit être collecté séparément et non jeté avec les déchets ménagers en le portant dans les déchetteries prévues par la réglementation en vigueur. Un tri sélectif approprié contribue à éviter des possibles effets négatifs sur l'environnement et sur la santé et favorise la réutilisation et/ou le recyclage des matériaux. L'élimination abusive entraîne l'application des sanctions administratives prévues par la réglementation en vigueur. Apparecchio per sola installazione in ambiente interno. Device only for indoor installation. L'appareil doit être uniquement installé à l'intérieur. Leuchte nur für die Installation im Innenbereich. Aparato de clase de protección III. La alimentación debe realizarse mediante un alimentador seguro. Se debe desechar el producto de forma separada de los residuos urbanos; se lo debe entregar en los centros de recolección previstos por la norma en vigor. La recolección diferenciada adecuada contribuye a evitar posibles efectos negativos en el medioambiente y en la salud y favorece la reutilización y/o el reciclaje de los materiales. Si se lo desecha en forma abusiva tendrá como consecuencia la aplicación de sanciones administrativas previstas por la normativa vigente. Aparato para un solo uso en un ambiente interior. Fig 1 18mm 9 8 7 NO OK OK 10 Fig 2 Fig 5 blueblue Remote controller TW 5 sec. Max.number of receiver connected for one remote controller: 7pcs Remote range max. 15m Remote controller TW 5 sec. Max.number of remote controllers connected for one receiver: 7pcs blueblue blue Remote Control matched transmitter 1x Fig 4 Fig 3 RF remote Control TW distributor Recever unit MOS distributor 2 1 3 11 TW Led lamp TW Led lamp Remote radio emitter for lighting control Model REMOTE CONTROL TW IC: 26690-REMOTE1 FCC ID: 2AX76-REMOTE1 Radio receiver for lighting control Model RECEIVER CONTROLLER TWF IC: 26690-CONTROL3 FCC ID: 2AX76-CONTROL3 Fig 6 Press to decrase brightness. Press to increase brightness. ON/OFF 6 5 4 3 10% 100% 100% 10% Reset matched transmitter 1x 1x blue 3x 2x blue Fig 7 RESET OK 2 OPERATION (fig. 6): - Key 3 = ON/OFF - Key 4 = Increase the brightness - Key 5 = Decrease the brightness - Switch 6 = Light colour temperature adjustment RECEIVER PROGRAMMING RESET (fig.7): It is possible to cancel the programming of the transmitters paired with the receiver proceeding as follows: - Press button (2) briefly, the blue LED flashes once. - Press button (2) in quick succession three times; the LED flashes twice; at this point the receiver is completely reset. WARNING: After 60 sec. of inactivity, the control system goes in "STAND-BY" mode, during which it is not possible to make any adjustments until one of the buttons on the transmitter (1) is pressed. BATTERY-POWERED DEVICES: Dispose of batteries according to local regulations. Some batteries can be recycled and it can be possible to dispose of them at the local recycling center. If it is not possible to find the applicable regulations in your area, check the instructions of the battery manufacturer. IMPORTANT: The installation must be performed by qualified personnel following the instructions attached and those in fig.3 WARRANTY The warranty on the device is valid only if powered by a power supply provided by DOMUS Line. The warranty general terms and conditions for this device are available at www.domusline.com TECHNICAL DATA: FOR RECEIVER CONTROLLER TWF: Power supply: 24Vdc Max power: 60Watt FOR REMOTE CONTROL TW : Remote control range 15 meters. Battery type used: CR2032 (3V) lithium. WARNINGS Safety is guaranteed if these instructions are followed and therefore they must be kept. Installation may require qualified personnel to be involved. Before proceeding with installation of the device ensure that the environmental conditions are in compliance with and suitable for the product characteristics. Before any operation on the device remove mains power. INSTALLATION: - Fix the supp…

Text truncated - open the document above for the full version.

DOMUS LINE SRL Date: 2020-12-05 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AX76-CONTROL3 To Whom It May Concern: This letter is to ascertain that DOMUS LINE SRL EUT : Radio receiver for lighting control Model Name : RECEIVER CONTROLLER TWF We will apply for FCC SDOC. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Alberto Zannese/Compliance Manager Contact information / address: DOMUS LINE SRL /VIA MAESTRI DEL LAVORO 1, 33080 Porcia (Pn) Italy

(DOMUS LINE SRL) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AX76-CONTROL3 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram .pdf, Schematics .pdf , Operation Description .pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Short-term confidentiality requested: 180 days Exhibit Type File Name External Photos, Internal Photos, Test Setup Photos, Manual External Photos.pdf, Internal Photos .pdf, Test Setup Photos .pdf, User Manual.pdf Sincerely, Name: Alberto Zannese Title: Compliance Manager Company: DOMUS LINE SRL

C:\Users\lenovo\Desktop\宁波处理案件\赛尔富\EN200831036W(ES200831085W)(RECEIVER CONTROLLER TWF)-进度1\2.Technical Document\Timco\POA.docx (DOMUS LINE SRL) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: December 05, 2020 SUBJECT: FCC Application for FCC ID: 2AX76-CONTROL3 To Whom It May Concern: We, the undersigned, hereby authorize Tony Wei at EMTEK(NINGBO) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK(NINGBO) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Name: Alberto Zannese Title: Compliance Manager Company: DOMUS LINE SRL

External photos: ---The End---

Label Location

Internal photos: ---The End--- Antenna

Report No.ES200831085W Page 1 of 28 Ver.1.0 TEST REPORT Product Name : Radio receiver for lighting control Model Number : RECEIVER CONTROLLER TWF FCC ID : 2AX76-CONTROL3 $二维码$ Prepared for : DOMUS LINE SRL Address : VIA MAESTRI DEL LAVORO 1, 33080 Porcia (Pn) Italy Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES200831085W Date(s) of Tests : August 31, 2020 to December 22, 2020 Date of Issue : December 23, 2020 Report No.ES200831085W Page 2 of 28 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ..................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ................................................................................................................... 5 3 SUMMARY OF TEST RESULT ........................................................................................................................ 6 4 TEST METHODOLOGY ................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................ 7 4.2 MEASUREMENT EQUIPMENT USED .......................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................. 8 4.4 TEST SOFTWARE ......................................................................................................................... 8 5 FACILITIES AND ACCREDITATIONS ............................................................................................................. 9 5.1 FACILITIES .................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ..................................................................... 9 6 TEST SYSTEM UNCERTAINTY .................................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................ 11 7.1 RADIO FREQUENCY TEST SETUP 1 ......................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ......................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ..................................................................................... 13 7.4 SUPPORT EQUIPMENT .............................................................................................................. 13 8 TEST REQUIREMENTS ................................................................................................................................. 14 8.1 BANDWIDTH TEST ..................................................................................................................... 14 8.2 RADIATED SPURIOUS EMISSION ............................................................................................. 16 8.3 CONDUCTED EMISSIONS TEST ............................................................................................... 24 8.4 ANTENNA APPLICATION ............................................................................................................ 27 Report No.ES200831085W Page 3 of 28 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : DOMUS LINE SRL Address : VIA MAESTRI DEL LAVORO 1, 33080 Porcia (Pn) Italy Manufacturer : SELF ELECTRONICS CO., LTD Address : No.1345, JuXian Road, Hi-tech Park, Ningbo, China EUT : Radio receiver for lighting control Model Name : RECEIVER CONTROLLER TWF Trademark : DOMUS LINE Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.249 The test results of this report relate only to the tested sample identified in this report. Date of Test : August 31, 2020 to December 22, 2020 Prepared by : Sewen Guo/Editor Reviewer : Mill Chen /Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No.ES200831085W Page 4 of 28 Ver.1.0 Modified History Version Report No. Revision Date Summary Ver.1.0 ES200831085W / Original Report Report No.ES200831085W Page 5 of 28 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product: Radio receiver for lighting control Model Number: RECEIVER CONTROLLER TWF Sample Number: 1# Power Supply: DC 12V/24V Test Voltage: AC 120V/60Hz (For support device) Modulation: GFSK Frequency Range: 2436.199 MHz Max Transmit Power: 88.10 dBuV/m Antenna: PCB antenna Antenna Gain: 0.0 dBi Temperature Range: -20°C ~ 35°C Date of Received: August 31, 2020 Note: for more details, please refer to the user’s manual of the EUT. Report No.ES200831085W Page 6 of 28 Ver.1.0 3 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.207 Conducted Emission PASS 15.209 Radiated Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Band edge test PASS 15.249 20dB Bandwidth PASS 15.203 Antenna Requirement PASS NOTE1: N/A is an abbreviation for not applicable NOTE2: The report use radiated measurements in the restricted frequency bands. In addition, the radiated test is also performed to ensure the emissions emanating from the device cabinet also comply with the applicable limits. RELATED SUBMITTAL(S) / GRAN…

Text truncated - open the document above for the full version.

Conducted Radiated ---The End---
