2AX76-KINYULkinetic switch

Wireless Kinetic Switch Instruction DESCRIPTION: The Wireless Kinetic Switch is a push-button self-powered switch with MEA (Micro Energy Acquisition) module inside to transform mechanical energy into electricity to drive RF chipset work. It is able to power on/off after the pairing with Ebelong Wireless receiving controller OPERATION: The Wireless Kinetic Switch shall work with Wireless Receiving Controller. Press and hold the function button of controller for 3 seconds and the indicator light will start to flash. Then release the button to enter pairing mode. Press the switch and the indicator light of controller will go out, which means the paring is successful. Difference Shape of the base one is rectangle, one is octagon The installation method one is with magnetic, another without SPECIFICATIONS Item Spec Switch type Push button Power mode Self-powered Modulation mode FSK Work frequency 433.3 MHz Button 2 gang Work range 80m Outdoor, 30m Indoor Lifetime >100,000 times Dimensions L33*W16*H65mm Tray L56*W4*H107mm Work temperature -20~ +55°C FCC Warning NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. IC warning This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1)This device may not cause interference. (2)This device must accept any interference, including interference that may cause undesired operation of the device Portable device statements The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. L’émetteur/récepteur exempt de licencecontenudans le présentappareilestconforme aux CNR d’Innovation, Sciences et Développementéconomique Canada applicables aux appareils radio exempts de licence. L’exploitationestautorisée aux deux conditions suivantes : 1.L’appareil ne doit pas produire de brouillage; 2.L’appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d’encompromettre le fonctionnement. L’appareil a été évalué pour répondre aux exigences générales en matière d’exposition aux RF. L’appareil peut être utilisé en condition d’exposition portable sans restriction.

< DOMUS LINE SRL > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: 2024-07-24 Subject; Request for Long Term Confidentiality FCC ID: 2AX76-KINYUL To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Alberto Zannese Title: Compliance Manager

Page 1 of 13 Page 2 of 13 Model No.: KINY UL Page 3 of 13 Page 4 of 13 Page 5 of 13 Model No.: KINY UL F03 Page 6 of 13 Page 7 of 13

Page 8 of 13 Model No.: KINY MAG UL F01 Page 9 of 13 Page 10 of 13 Page 11 of 13 Model No.: KINY MAG UL F03 Page 12 of 13 Page 13 of 13

Label Model No.: KINY UL FCC ID: 2AX76-KINYUL IC:26690-KINYUL HVIN:KINY UL Model No.: KINY ULF03 FCC ID: 2AX76-KINYUL IC:26690-KINYUL HVIN:KINY UL F03 Model No.: KINY MAG UL F01 FCC ID: 2AX76-KINYUL IC:26690-KINYUL HVIN:KINY MAG UL F01 Model No.: KINY MAG UL F03 FCC ID: 2AX76-KINYUL IC:26690-KINYUL HVIN:KINY MAG UL F03 Label location

Page 1 of 12 Model No.: KINY UL Page 2 of 12 Page 3 of 12 Page 4 of 12 Model No.: KINY UL F03 Page 5 of 12 Page 6 of 12

Page 7 of 12 Model No.: KINY MAG UL F01 Page 8 of 12 Page 9 of 12 Page 10 of 12 Model No.: KINY MAG UL F03 Page 11 of 12 Page 12 of 12

FCC ID: 2AX76-KINYUL RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 Frequency(MHz) Field Strength (dBuv/m) erp(mW) limit (mW) 433.3 70.04 0.00305 23.21 According to ANSI C63.10 Where: 30MHz＜F＜1GHz: EIRP[dBm] =E[dBuV/m] - 95.2 So EIRP=70.04-95.2=-25.16dBm Then SAR evaluation is not required

ANTENNA SPECIFICATION Summary ITEM ANT SPEC Model Name ANT_U1 Polarization Horizontal and Vertical Azimuth Beam Pattem Omni-directional Impedance 50 Ohm Antenna Lenght 62mm Manufacture Shenzhen Hualiansheng Wire and Cable Co., Ltd 增益值： 频率/Mhz 433.2 433.3 433.4 增益/dbi -1.75 -1.88 -2.03 效率/% 40.70 40.40 39.98 天线尺寸： 方向图：

Global United Technology Services Co., Ltd. Report No.: GTS2024070021F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 20 TEST REPORT Applicant: DOMUS LINE SRL Address of Applicant: VIA MAESTRI DEL LAVORO 1, PORCIA PN, Italy Manufacturer/Factory: DOMUS LINE SRL Address of Manufacturer/Factory: VIA MAESTRI DEL LAVORO 1, PORCIA PN, Italy Equipment Under Test (EUT) Product Name: kinetic switch Model No.: KINY UL, KINY MAG UL F01, KINY MAG UL F03, KINY UL F03 Trade Mark: FCC ID: 2AX76-KINYUL Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.231 Date of sample receipt: July 02, 2024 Date of Test: July 03-30, 2024 Date of report issued: July 30, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2024070021F01 Global United Technology Services Co., Ltd. No.123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 20 2 Version Version No. Date Description 01 July 30, 2024 Original Prepared By: Date: July 30, 2024 Project Engineer Check By: Date: July 30, 2024 Reviewer Report No.: GTS2024070021F01 Global United Technology Services Co., Ltd. No.123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 20 3 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 6 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.4 TEST FACILITY .................................................................................................................................... 6 5.5 TEST LOCATION ................................................................................................................................. 6 5.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER ......................................................................... 6 5.7 ADDITIONAL INSTRUCTIONS ................................................................................................................. 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2 RADIATED EMISSION METHOD ........................................................................................................... 10 7.2.1 Field Strength of The Fundamental Signal ................................................................................ 12 7.2.2 Spurious Emissions ................................................................................................................... 13 7.3 20DB OCCUPY BANDWIDTH .............................................................................................................. 18 7.4 DEACTIVATION TESTING .................................................................................................................... 19 8 TEST SETUP PHOTO ............................................................................................................................ 20 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 20 Report No.: GTS2024070021F01 Global United Technology Services Co., Ltd. No.123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 20 4 Test Summary Test Item Section in CFR 47 Result Antenna Requirement 15.203 Pass Conduction Emission 15.207 N/A Field strength of the Fundamental Signal 15.231 (b) Pass Spurious Emissions 15.231 (b)/15.209 Pass 20dB Bandwidth 15.231 (c) Pass Deactivation Testing 15.231 (a)(2) Pass Pass: The EUT complies with the essential requirements in the standard. N/A: Not applicable. 4.1 Measurement Uncertainty No. Item Measurement Uncertainty 1 Radio Frequency ±7.25×10 -8 2 Duty cycle ±0.37% 3 Occupied Bandwidth ±3% 4 RF conducted power ±0.75dB 5 RF power density ±3dB 6 Conducted S…

Text truncated - open the document above for the full version.

Page 1 of 1 Test Model No.: KINY UL Radiated Emission
