2AX76-PIR-WIRemote radio emitter for lighting control

MANUALE DI INSTALLAZIONE E USO INSTALLATION MANUAL INSTALLATIONSHANDBUCH MANUEL D'INSTALLATION MANUAL DE INSTALACIÓN IT EN DE FR ES Ref. 3488500_ r1 PIR WI-XD DOMUS LINE Srl Via Maestri del Lavoro, 1 33080 PORCIA _ PN _ Italy phone fax e-mail website 0039 0434 595911 0039 0434 923345 [email protected] www.domusline.com Apparecchio in classe di protezione III. Protection class III device. Appareil avec classe de protection III. Leuchte mit Schutzklasse III. Il prodotto deve essere smaltito separatamente dai rifiuti urbani consegnandolo ai centri di raccolta previsti dalla normativa in vigore. L'adeguata raccolta differenziata contribuisce ad evitare possibili effetti negativi sull'ambiente e sulla salute e favorisce il reimpiego e/o il riciclo dei materiali. Lo smaltimento abusivo comporta l'applicazione delle sanzioni amministrative previste dalla normativa vigente. The product must be disposed of separately from urban waste, delivering it to the collection centres established by the prevailing standard. Adequate sorted waste collection contributes to preventing negative effects on the environment and health and favours reuse and/or recycling materials. Incorrect disposal of the product implies the application of the administrative sanctions envisaged by the prevailing regulation. Die Leuchte muss getrennt vom Hausmüll entsorgt und entsprechend der geltenden Richtlinien, an den vorgesehenen Sammelstellen abgegeben werden. Die angemessene getrennte Sammlung trägt dazu bei, eventuelle negative Auswirkungen auf die Umwelt und die Gesundheit zu vermeiden und die Wiederverwendung und/oder das Recycling der Materialien zu begünstigen. Die unsachgemäße Entsorgung bringt die Anwendung administrativer Strafen mit sich, die in den geltenden Richtlinien vorgesehen sind. Le produit doit être collecté séparément et non jeté avec les déchets ménagers en le portant dans les déchetteries prévues par la réglementation en vigueur. Un tri sélectif approprié contribue à éviter des possibles effets négatifs sur l'environnement et sur la santé et favorise la réutilisation et/ou le recyclage des matériaux. L'élimination abusive entraîne l'application des sanctions administratives prévues par la réglementation en vigueur. Aparato de clase de protección III. Se debe desechar el producto de forma separada de los residuos urbanos; se lo debe entregar en los centros de recolección previstos por la norma en vigor. La recolección diferenciada adecuada contribuye a evitar posibles efectos negativos en el medioambiente y en la salud y favorece la reutilización y/o el reciclaje de los materiales. Si se lo desecha en forma abusiva tendrá como consecuencia la aplicación de sanciones administrativas previstas por la normativa vigente. Apparecchio per sola installazione in ambiente interno. Device only for indoor installation. L'appareil doit être uniquement installé à l'intérieur. Leuchte nur für die Installation im Innenbereich. Aparato para un solo uso en un ambiente interior. A B C Fig.1 Fig.2 E B D CM2-XD X-DRIVER LED profile LED spotlight max. 8mt PIR WI XD G I H F X-Driver set up example CM2-XDTW X-DRIVER TW LED profile TW LED spotlight TW G X-Driver TW set up example max. 8mt PIR WI XD I H F Fig.3Fig.4 Remote radio emitter for lighting control Model PIR WI-XD IC: 26 690-PIRWI FCC ID: 2AX76-PIR-WI OK NO OK Battery: CR2450 CR2450 + CR2450 + CR2450 + suggestion max 10cm 100cm Detection area Area di rilevamento ~ 2 2 0 c m WARNING detection field must not be obstructed by shelves positioned too close of the sensor 160cm 1 0 0 c m s u g g e s t i o n m a x 1 0 c m Top view vista dall’alto Fig.5Fig.6 INSTALLATION MANUAL EN COUPLING WITH DYNAMIC TW LIGHT X-DRIVER WITH MODULE CM2- XDTW (Fig.4): - Remove the insulating tab (F) from the transmitter. - Press the X-Driver button until the blue signalling LED (G) comes on and then press the PIR WI-XD (H) button until the signalling LED (I) remains on steady, then briefly press the button (H) again twice until the signalling LED (I) flashes twice. - A dynamic control remote control (example TW remote controller) to control the light colour temperature can be coupled REPLACING THE BATTERY (Fig.5): - Remove the support cap, levering with a screwdriver - Replace the battery with a model with the same characteristics, respecting the correct polarity - Replace the cap, matching up the notches printed on the casings. OPERATION (Fig.6): The sensor detects changes in temperature combined with the movement of persons, animals and objects with a temperature of approximately 36°C within the radius of action, as shown in figure 6. The system remains in operation for the required time, after which, if no other movements are detected, it switches off automatically. The switch- off delay time can be selected by pressing the button (H) once until the signalling LED (I) flashes once for a 16 second delay (default selection), flashes twice for a 3 minute delay, or flashes 3 times for a 16 minute delay. TECHNICAL DATA - Maximum operating distance 8 metres. - Battery mod. CR2450 (3V) lithium (Fig.1). INSTALLATION (Fig.1): - Drill a Ø 40 mm hole at least 14 mm deep. - Insert the support (A) in the hole (Fig.1). - Fit the PIR WI-XD (B) into the support (A) rotating clockwise until the notches (fig. 1) match, using the special key (C) supplied INSTALLATION SUPPORT SP (fig. 2): - Fix the support for Call-me (E) using the supplied screw (D). - Insert the transmitter (B) into the holder (E). CAUTION: the detection field must not be hindered by shelving too close to the sensor The sensor must not be installed near electromagnetic or heat sources or be exposed to direct sunlight. Max. 7 PIR WI-XD sensors can be applied to a single X-Driver. COUPLING WITH STATIC LIGHT X-DRIVER WITH MODULE CM2-XD (Fig.3): - Remove the insulating tab (F) from the transmitter. - Press the X-Driver button until the blue signalling LED (G) comes on and then press the PIR WIRELESS (H) button until the signalling LED (I) remains o…
