2AX76-REMOTE3Remote radio emitter for lighting control

REMOTE CONTROLLER RC3 DOMUS LINE Srl Via Maestri del Lavoro, 1 33080 PORCIA _ PN _ Italy phone fax e-mail website 0039 0434 595911 0039 0434 923345 [email protected] www.domusline.com Ref. 3482400_r4 MANUALE DI INSTALLAZIONE E USO INSTALLATION MANUAL INSTALLATIONSHANDBUCH IT EN DE The product must be disposed of separately from urban waste, delivering it to the collection centres established by the prevailing standard. Adequate sorted waste collection contributes to preventing negative effects on the environment and health and favours reuse and/or recycling materials. Incorrect disposal of the product implies the application of the administrative sanctions envisaged by the prevailing regulation. Die Leuchte muss getrennt vom Hausmüll entsorgt und entsprechend der geltenden Richtlinien, an den vorgesehenen Sammelstellen abgegeben werden. Die angemessene getrennte Sammlung trägt dazu bei, eventuelle negative Auswirkungen auf die Umwelt und die Gesundheit zu vermeiden und die Wiederverwendung und/oder das Recycling der Materialien zu begünstigen. Die unsachgemäße Entsorgung bringt die Anwendung administrativer Strafen mit sich, die in den geltenden Richtlinien vorgesehen sind. Il prodotto deve essere smaltito separatamente dai rifiuti urbani consegnandolo ai centri di raccolta previsti dalla normativa in vigore. L'adeguata raccolta differenziata contribuisce ad evitare possibili effetti negativi sull'ambiente e sulla salute e favorisce il reimpiego e/o il riciclo dei materiali. Lo smaltimento abusivo comporta l'applicazione delle sanzioni amministrative previste dalla normativa vigente. = 2 x CR 2032 - - Inserting - replacing batteries 1x Setting DIMMER mode operation ..... If the channel has already been set to TW or RGB mode, follow steps 1 and 2. If this is the first time that this channel has been used, or it has previously been set to dimmer mode, skip steps 1 and 2. 1 2 whitewhite INSTALLATION MANUAL EN Example: selecting channel Configuring with CALL-ME V17 receiver Channel Channel 5 sec. II blue blue blue 1x Example: selecting channel dimmer operation Channel II blue 1x Example: selecting channel Channel Channel Channel 5 sec. II blueblue Configuration with X-DRIVER II X-DRIVER + CM2-XD MODULE IN OUT The blue LED turns off INSTALLATION MANUAL EN The blue LED turns off Example: selecting channel dimmer operation Long press: store scene 1 Short press: recall scene 1 Press: to increase brightness to decrease brightness Clockwise: Increase brightness Anticlockwise: Decrease brightness Long press: store channel 1 Short press: recall channel 1 ON-OFF General for all channels DIMMER: INSTALLATION MANUAL EN Long press: store scene 2 Short press: recall scene 2 Long press: store scene 3 Short press: recall scene 3 Long press: store channel 2 Short press: recall channel 2 Long press: store channel 3 Short press: recall channel 3 Remote radio emitter for lighting control Model REMOTE CONTROL 3 CHANNEL IC: 26990-REMOTE3 FCC ID: 2AX76-REMOTE3 Setting TW mode operation yellow blue yellow blue ..... 3x Long press: Short press: Press to change the colour temperature change mode between flash mode and fade mode Flash mode: Fade mode : fast = + ↑ slow = + ↓ 1 2 If the channel has already been set to dimmer / RGB mode, follow steps 1 and 2. If it has already been set in the TW channel, skip steps 1 and 2. the colour temperature of the lamp changes without fading (hot, neutral, cold) the colour temperature of the lamp attenuates gradually from one colour hue to the other Hold this button down and press "Dimmer" to select the colour temperature change speed Colour change ON-OFF General for all channels INSTALLATION MANUAL EN Long press: store scene 1 Short press: recall scene 1 Long press: store scene 2 Short press: recall scene 2 Long press: store scene 3 Short press: recall scene 3 Long press: store channel 1 Short press: recall channel 1 Long press: store channel 2 Short press: recall channel 2 Long press: store channel 3 Short press: recall channel 3 Press: to increase brightness to decrease brightness DIMMER: Example: selecting channel Magic Tune receiver blue 1x 5 sec. II blue blue blue 1x Channel 5 sec. blue blue Configuring the MAGIC TUNE receiver Configuring with TW X-DRIVER Channel II II II X-DRIVER TW + CM2-XDTW MODULE Example:selecting channel Magic Tune tunable white operation INSTALLATION MANUAL EN Channel Channel The blue LED turns off The blue LED turns off Example: selecting channel Channel Channel Example: selecting channel X-Driver tunable operation INSTALLATIONSHANDBUCH DE = 2 x CR 2032 - - Einsetzen - Austausch der Batterien 1x Funktionseinstellung des DIMMER-Modus ..... Wenn der Kanal bereits im TW- oder RGB-Modus eingestellt wurde, die Schritte 1 und 2 ausführen. Wenn dieser Kanal zum ersten Mal verwendet oder zuvor auf den Dimmer- Modus eingestellt wurde, die Schritte 1 und 2 überspringen. 1 2 weißweiß INSTALLATIONSHANDBUCH DE Beispiel: Kanal auswählen Konfigurierung mit empfang CALL-ME V17 Kanal Kanal 5 sec. II Blaue Blaue blaue 1x Beispiel: Kanalauswahl Dimmer-Funktion Kanal II blaue 1x Beispiel: Kanal auswählen Kanal Kanal Kanal 5 sec. II Blaue Konfigurierung mit X-Driver II X-DRIVER + CM2-XD MODULE Beispiel: Kanalauswahl Dimmer-Funktion IN OUT Blaue LED geht aus Blaue LED geht aus Blaue INSTALLATIONSHANDBUCH DE Lang gedrückt halten: Speicherung von Szenario 1 Kurz gedrückt halten: Aufrufen von Szenario 1 Press: um die Helligkeit zu erhöhen um die Helligkeit zu verringern Im Uhrzeigersinn: Helligkeit erhöhen Gegen den Uhrzeigersinn: Helligkeit verringern Lang gedrückt halten: Speicherung von Kanal 1 Kurz gedrückt halten: Aufrufen von Kanal 1 ON-OFF Allgemein für alle Kanäle DIMMER: Lang gedrückt halten: Speicherung von Szenario 2 Kurz gedrückt halten: Aufrufen von Szenario 2 Lang gedrückt halten: Speicherung von Szenario 3 Kurz gedrückt halten: Aufrufen von Szenario 3 Lang gedrückt halten: Speicherung von Kanal 2 Kurz gedrückt halten: Aufrufen von Kanal 2 Lang gedrückt halten…

Text truncated - open the document above for the full version.

DOMUS LINE SRL Date: 2020-12-05 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AX76-REMOTE3 To Whom It May Concern: This letter is to ascertain that DOMUS LINE SRL EUT : Remote radio emitter for lighting control Model Name : REMOTE CONTROLLER 3 CHANNEL We will apply for FCC SDOC. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Alberto Zannese/Compliance Manager Contact information / address: DOMUS LINE SRL /VIA MAESTRI DEL LAVORO 1, 33080 Porcia (Pn) Italy

Rev 11/20/07 (DOMUS LINE SRL) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AX76-REMOTE3 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram .pdf, Schematics .pdf , Operation Description .pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Short-term confidentiality requested: 180 days Exhibit Type File Name External Photos, Internal Photos, Test Setup Photos, Manual External Photos.pdf, Internal Photos .pdf, Test Setup Photos .pdf, User Manual.pdf Sincerely, Name: Alberto Zannese Title: Compliance Manager Company: DOMUS LINE SRL

(DOMUS LINE SRL) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: December 05, 2020 SUBJECT: FCC Application for FCC ID: 2AX76-REMOTE3 To Whom It May Concern: We, the undersigned, hereby authorize Tony Wei at EMTEK(NINGBO) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK(NINGBO) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Name: Alberto Zannese Title: Compliance Manager Company: DOMUS LINE SRL

External photos: ---The End---

Label Location Model: REMOTE CONTROLLER 3 CHANNEL FCC ID: 2AX76‐REMOTE3 IC: 26990‐REMOTE3

Internal photos: ---The End--- Antenna

Report No.ES200831075W Page 1 of 26 Ver.1.0 TEST REPORT Product Name : Remote radio emitter for lighting control Model Number : REMOTE CONTROLLER 3 CHANNEL FCC ID : 2AX76-REMOTE3 $二维码$ Prepared for : DOMUS LINE SRL Address : VIA MAESTRI DEL LAVORO 1, 33080 Porcia (Pn) Italy Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES200831075W Date(s) of Tests : August 31, 2020 to December 22, 2020 Date of Issue : December 23, 2020 Report No.ES200831075W Page 2 of 26 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ..................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ................................................................................................................... 5 3 SUMMARY OF TEST RESULT ........................................................................................................................ 6 4 TEST METHODOLOGY ................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................ 7 4.2 MEASUREMENT EQUIPMENT USED .......................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................. 8 4.4 TEST SOFTWARE ......................................................................................................................... 8 5 FACILITIES AND ACCREDITATIONS ............................................................................................................. 9 5.1 FACILITIES .................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ..................................................................... 9 6 TEST SYSTEM UNCERTAINTY .................................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................ 11 7.1 RADIO FREQUENCY TEST SETUP 1 ......................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ......................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ..................................................................................... 13 7.4 SUPPORT EQUIPMENT .............................................................................................................. 13 8 TEST REQUIREMENTS ................................................................................................................................. 14 8.1 BANDWIDTH TEST ..................................................................................................................... 14 8.2 RADIATED SPURIOUS EMISSION ............................................................................................. 16 8.3 CONDUCTED EMISSIONS TEST ............................................................................................... 24 8.4 ANTENNA APPLICATION ............................................................................................................ 25 Report No.ES200831075W Page 3 of 26 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : DOMUS LINE SRL Address : VIA MAESTRI DEL LAVORO 1, 33080 Porcia (Pn) Italy Manufacturer : SELF ELECTRONICS CO., LTD Address : No.1345, JuXian Road, Hi-tech Park, Ningbo, China EUT : Remote radio emitter for lighting control Model Name : REMOTE CONTROLLER 3 CHANNEL Trademark : DOMUS LINE Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.249 The test results of this report relate only to the tested sample identified in this report. Date of Test : August 31, 2020 to December 22, 2020 Prepared by : Sewen Guo /Editor Reviewer : Sevin Li/Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No.ES200831075W Page 4 of 26 Ver.1.0 Modified History Version Report No. Revision Date Summary Ver.1.0 ES200831075W / Original Report Report No.ES200831075W Page 5 of 26 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product: Remote radio emitter for lighting control Model Number: REMOTE CONTROLLER 3 CHANNEL Sample Number: 1# Power Supply: DC 6V for Battery Test Voltage: DC 6V Modulation: GFSK Frequency Range: 2436.199 MHz Max Transmit Power: 93.38 dBuV/m Antenna: PCB antenna Antenna Gain: 0.0 dBi Temperature Range: -20°C ~ 35°C Date of Received: August 31, 2020 Note: for more details, please refer to the user’s manual of the EUT. Report No.ES200831075W Page 6 of 26 Ver.1.0 3 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.207 Conducted Emission N/A 15.209 Radiated Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Band edge test PASS 15.249 20dB Bandwidth PASS 15.203 Antenna Requirement PASS NOTE1: N/A is an abbreviation for not applicable, since the test sample is only battery power supply. NOTE2: The report use radiated measurements in the restricted frequency bands. In addition, the radiated test is also performed to ensure the emissions emanating from the device cabinet also com…

Text truncated - open the document above for the full version.

Radiated ---The End---
