Digital Paper System Quick Start Guide Owner’s Record The model and serial number are located at the rear of the device. Record the serial number in the space provided below. Serial No. You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. Getting Started Checking the supplied items Check the following items are present. • Digital Paper device (1) • Stylus (1) • Replacement tips – Felt (gray) (1) – POM (black) (2) • Tip puller (1) • USB cable (1) • Quick Start Guide (this document) (1) • Warranty (1) Initial setup Set up the Digital Paper device (hereafter referred to as “the device”) and your computer according to the instructions displayed. 1 Turn on the device. 2 Set a stylus according to the instructions on the screen. 3 Turn on the computer and connect to the Internet. 4 Download Digital Paper App from the following site and install on the computer. Digital Paper App is required to transfer documents (PDF files). 5 Start Digital Paper App and connect the supplied USB cable to the USB connector of the device and the USB connector of the computer. 6 Set the computer according to the instructions displayed by Digital Paper App. Documents can be transferred only between the device and the computer. 7 Update the app software if a software update is advised. Note Wi-Fi is used only for transferring documents between the device and the computer. The device cannot display Internet content. Charging the device and stylus 1 Turn on the computer. 2 Connect the supplied USB cable to the USB connector of the device or stylus and the USB connector of the computer. Charge indicator Notes • Charge the device within the recommended temperature range of 5 °C to 35 °C (41 °F to 95 °F). If the room is too hot or cold, disconnect the USB cable, adjust the room temperature accordingly, then reconnect the USB cable to charge. • The device will not charge if your computer is turned off, enters sleep mode, standby mode or hibernation mode. Tip The Charge indicator lights up in red while charging. Parts and controls Digital Paper device ̚ (home) button






Touchscreen ̔ USB connector ̕ Æ (power) button ̖ Charge indicator ̗ RESET button ̘ (N-Mark) Troubleshooting The following information will help you remedy problems if you cannot operate the device. 1 Charge the device and the stylus. 2 Reset the device. Press the RESET button with a plastic toothpick, clip, etc. Press the Æ (power) button to restart the device. Notes • Content handwritten within documents, created notes, and settings may be deleted when the device is reset. • Do not press the RESET button with a fragile object (pencil lead, etc.). How to use the system and the support site For more detailed information on using the Digital Paper System, see supportYGDUKVG If you cannot recover the device Consult the Support Center and provide the following information. • Model name (specified on the back panel) • Serial number (specified on the back panel) • Purchase date Replacing the stylus tip The stylus tip may wear out through use. It is recommended to replace the tip when it becomes shorter than 1.5 mm (1/16 in). Replacement tips and a tip puller are supplied with the device. Replace the tip when it becomes shorter than 1.5 mm (1/16 in) 1 Pinch the tip with the supplied tip puller, then pull it out straight. Pinch the base of the tip firmly 2 Check the orientation of the replacement tip, pinch it with the tip puller, then push it straight into the stylus. 3 Push the tip firmly with your finger. Notes • Keep out of reach of children, as the tip may be swallowed. In case the tip is swallowed, please consult your doctor. • Pressing on the tip with excessive pressure will wear it out more quickly. Tips • Replace the stylus tip periodically to prevent damage to the device and maintain consistent operation. • If the stylus tip is lost, contact the Supp ort Center. Important Information Safety Do not expose the battery to fire or heat. Do not disassemble the battery. It may cause electric shock. Do not remove the battery yourself. For battery replacement, internal checking or repair, consult the Support Center. Do not charge the device near fire, heat, or leave it in hot sunlight. Do not leave coins, keys, jewelry, etc., near the USB connector or USB cable. Do not use the device while moving. Do not operate the device or watch the display while driving a vehicle, riding a motor cycle, walking, etc. Do not use the device where it may distract you from danger; for example at a railroad crossing, road, construction site, etc. Be careful not to allow liquid or a foreign object to get into the device, as doing so may cause electric shock or fire. If liquid or a foreign object gets into the device, consult the Support Center. Keep out of reach of children. The stylus or replacement tip may be accidentally swallowed. If the battery is swallowed, consult a doctor immediately. It may cause choking or damage the stomach. Never subject the device to high temperature. Never subject the device to extremes of light, high temperature (more than 60 °C (140°F)), moisture or vibration. For example, if the device is left in a car parked in the sun, excessive heat buildup may result in deformation of the device casing, or other malfunction. Do not cover the device with a blanket when turned on. The device may overheat and deform or catch fire. If you feel discomfort while using the device, stop using it. Do not leave the device on an unstable surface. Do not leave the device on an unstable or sloping surface. Do not stand the device upright, or turn it upside down. The device may drop or be damaged. The device screen is delicate. If heavy weight or force is applied, the screen may be damaged. Precautions Safety Handling the device • If the device causes interference to radio or television reception, turn the device off and move it away from the radio or television. • Refrain from us…
