USER INSTRUCTIONS W IDEX Sound Assist GB 1 1.3 1.5 1.4 1.2 1.1 1.6 1.9 1.8 1.10 1.7 2.1 2.4 2 2.2 2.3 USER INSTRUCTIONS WIDEX Sound Assist 3 4 5 6 GB....................................................................................................... 4 FCC AND ISED STATEMENTS ....................................................................25 3 YOUR WIDEX SOUND ASSIST DEVICE Welcome Thank you for choosing this product to further enrich your audio experience. Before you start using this device, please read these instructions carefully to learn about features and functionalities. NOTE Your device may not look exactly as illustrated. We reserve the right to make any changes considered necessary. Intended use The device is intended to transmit audio from the built-in microphones to supported hearing aids to improve speech understanding in noisy situa- tions. The device can also receive audio from multiple sources (analog and digital) and transmit the audio wirelessly to the supported hearing aids. Further, the device can be used as a remote control to adjust the supported hearing aids to different listening situations. 4 Warnings Strangulation hazard when neck loop or charging cable gets entangled in moving mechanical parts of machines for example. - Use only the delivered breakaway neck loop. It will automatically detach when entangled. - Do not use neck loop or charging cable for children under the age of twelve. Your device should be stored and transported within the temperature of -20 °C to +55 °C (-4 °F to 131 °F) and humidity ranges of 10-95 % RH. Your device is designed to operate at temperatures during charging of +0 °C to +40 °C (32 °F to 104 °F) and during use at temperatures of -10 °C to +40 °C (14 °F to 104 °F), at humidity ranges of 10-95 % and under at- mospheric pressures of 750-1060 mBar. Risk of injury or electrical shock caused by damaged devices. Do not use obviously damaged devices and return them to point of sale. Never dry your devices in the micro-wave or oven. Keep the device protected from dust or external particles. We recommend using a 5 V up to 500 mA micro USB adaptor. Do not leave the device unattended while charging. 5 Do not dispose of this device into fire or a hot oven and do not crush or cut the device, as this can result in an explosion. Do not use or wear the device in mines or other areas with explosive gases, including while refuelling a vehicle. Do not leave the device in an extremely high temperature surrounding environment, as this can result in an explosion or the leakage of flamma- ble liquid or gas. Do not subject the device to extremely low air pressure, as this can result in an explosion or the leakage of flammable liquid or gas. When the device is connected via micro USB cable to external mains-op- erated equipment such as a charger, PC, audio source or similar, this equipment must comply with IEC 60950-1, IEC 62368-1, IEC 60601-1 or equivalent safety standards. Only the accessories and cable that are included in the sales box must be used. Using cables other than those specified or provided may result in increased electromagnetic emissions or decreased electromagnetic im- munity of this equipment and result in improper operation. You can find more information on https://global.widex.com. Sound Assist at a glance Illustration 1 1.1 Volume buttons (+/-) 1.2Program button 6 1.3Microphones 1.4push-button 1.5In-use light indicators 1.6Power/mode button 1.7Battery light indicator 1.8Mode light indicators 1.9Micro USB port 1.10Integrated metal clip for attachment/stability on tabletop Illustration 2 2.1Micro USB cable 2.2Neck loop 2.3User instructions 2.4Power adapter 7 USING SOUND ASSIST All instructions are supported by illustrations found in the folded front and back covers. Pairing the device Sound Assist must be paired to your hearing aids before you pair with other devices. Pairing to your hearing aids: 1.Make sure that Sound Assist is turned off. 2.Restart your hearing aids. The hearing aids will then be in pairing mode for 3 minutes. 3.Press the volume up button (+) and the power/mode button (1.6) si- multaneously for 3 seconds until the in-use light indicators (1.5) are glowing blue. 4. Make sure that the Sound Assist and your hearing aids are within 1 m range of each other. 5.The pairing sequence will start automatically. 6. The in-use light indicators (1.5) will briefly flash green, when the pairing is successfully completed. The Sound Assist can only be paired to one set of hearing aids. To pair a new set of hearing aids, you must perform the same steps and the new pairing will overwrite the existing one. Pairing to your smartphone or other device: 1.Turn off your Sound Assist. 8 2.Activate Bluetooth on your smartphone/device. 3.Press the volume up button (+) and the power/mode button (1.6) si- multaneously for 3 seconds until the in-use light indicators (1.5) are glowing blue. 4. Make sure that Sound Assist and your phone/device are within 1 metre range of each other. 5.Go to the Bluetooth menu on your smartphone/device and pair by se- lecting Sound Assist from the list of available devices. 6. The in-use light indicators (1.5) will briefly flash green, when the pairing is successfully completed. Sound Assist can be paired with up to 8 Bluetooth devices and actively con- nected to 1 Bluetooth device. To reset hearing aid and phone/device pairings: 1.Turn off your Sound Assist. 2.Press the volume down button (-) and the power/mode button (1.6) si- multaneously for 5 seconds. 3.When the pairing list is resetting, the in-use indicators (1.5) will start flashing yellow. 4. When the reset is completed, the Sound Assist will turn off. 9 Range FunctionMax ranges Remote microphone8 m from hearing aid to the device Bluetooth streaming10-15 m from Bluetooth device to the device Partner microphone20 cm from speaker to the device Tabletop microphone1.5 m from speaker to the device Turning Sound Assist on and off To turn on and off, press and ho…

Text truncated - open the document above for the full version.

. Page1 of 1

1 / 1 AGENT LETTER Date: 27/10/2022 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia MD 21046 FCC ID: 2AXDT-WSA To whom it may concern: We, WSAUD A/S Nymoellevej 6, Lynge DK-3540 Denmark hereby authorize, DEKRA Testing and Certification S.A.U. Parque Tecnológico de Andalucía C/Severo Ochoa, 2 & 6 | 29590 | Málaga | Spain Agent: Álvaro Corrales Sedeño e-mail: [email protected] Phone: +34 952 619 198 to act as our agent in the preparation of this application for equipment certification, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to a denial of U.S. Federal benefits, which include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by DEKRA Testing and Certification, S.A.U., still resides with us. This agreement expires one year from the current date. Sincerely, By: Hans-Otto Bindeballe Title: Global Regulatory Affairs Manager Telephone: +45 44355600 e-mail: [email protected]

1 / 2 CONFIDENTIALITY REQUEST Date: 27/10/2022 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia MD 21046 FCC ID: 2AXDT-WSA To whom it may concern: We, WSAUD A/S Nymoellevej 6, Lynge DK-3540 Denmark hereby request requests that a part of the subject FCC application be held confidential to avoid release of sensitive information of the product to the public pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, For the product stated above, we request that the following information be withheld from public disclose: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Operation Description Short Term Permanent Schematics Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Test Setup Photos Short Term User’s Manual Short Term External Photos Short Term Internal Photos Permanent Confidentiality: The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to us and provide unjustified benefits to our competitors. Short-Term Confidentiality: We hereby request short-term confidentiality for the product stated above to avoid premature release of sensitive information prior to marketing or release of the product to the public. Release date of short term confidentiality is: 45 days from grant date marked 90 days from grant date marked 135 days from grant date marked 180 days from grant date marked Specific date: We are also aware that we are responsible to notify DEKRA Testing and Certification S.A.U. in the event information regarding the product or the product is made available to the public. DEKRA Testing and Certification S.A.U. will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: Hans-Otto Bindeballe Title: Global Regulatory Affairs Manager Telephone: +45 44355600 e-mail: [email protected]

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67242RAN.001 2022-10-27 Test report No: NIE: 67242RAN.001 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1093 FCC 47 CFR Part 1.1307 (*) Identification of item under evaluation Device used as remote microphone/audio for hearing aid (*) Trademark Widex (*) Model and /or type reference Sound Assist (*) Other identification of the product Equipment with insulating enclosure and class III of protection against electric shock. Equipment supplied by a 3.7 V secondary battery (*) Features FCC ID: 2AXDT-WSA IC: 26428-WSA HW version: P2.1b SW version: v0.11.136 Features: Bluetooth Classic, Bluetooth LE (*) Manufacturer WSAUD A/S Nymøllevej 6 DK-3540 Lynge, Denmark Test method requested, standard FCC 47 CFR Part 2.1093. Radiofrequency radiation exposure evaluation: portable devices. FCC 47 CFR Part 1.1307: Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2022-10-27 Report template No FAN24_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67242RAN.001 Page 2 of 8 2022-10-27 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 Appendix A: FCC RF Exposure assessment result ..................................................................... 4 General description of the device under evaluation ................................................................ 5 Evaluation Results .................................................................................................................. 5 Appendix B: FCC RF Exposure information ................................................................................ 6 RF Exposure determination of exemption ............................................................................... 7 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67242RAN.001 Page 3 of 8 2022-10-27 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item under evaluation", "Trademark", "Model and/or type reference", “General description of the device”, “Other identification of the product”). 2. Maximum antenna gain and use distance information. 3. The device under evaluation consists of a device used as remote microphone/audio for hearing aid. DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client WSAUD A/S Nymøllevej 6 DK-3540 Lynge, Denmark Document history Report number Date Description 67242RAN.001 2022-10-27 First release DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67242RAN.001 Page 4 of 8 2022-10-27 Appendix A: FCC RF Exposure assessment result DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67242RAN.001 Page 5 of 8 2022-10…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 2022-10-28 ISED CABid: ES1909 Test Report No: NIE: 67242RRF.002 Test Report USA FCC Part 15.247, 15.209 CANADA RSS-247, RSS-Gen (*) Identification of item tested Device used as remote microphone/audio for hearing aid (*) Trademark Widex (*) Model and /or type reference Sound Assist Other identification of the product -- (*) Features Bluetooth LE HW version: P2.1b SW version: v0.11.136 FCC ID: 2AXDT-WSA IC: 26428-WSA Applicant WSAUD A/S Nymøllevej 6 DK-3540 Lynge, Denmark Test method requested, standard USA FCC Part 15.247 (10-1-20 Edition): Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209 (10-1-20 Edition): Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (February 2017). CANADA RSS-Gen Issue 5 amendment 1 (March 2019). Guidance for Performing Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid Systems Devices Operating Under Section 15.247 of the FCC Rules. 558074 D01 Meas Guidance v05r02 dated April 2, 2019. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Summary IN COMPLIANCE Approved by (name / position & signature) Rafael López Martín EMC Consumer & RF Lab. Manager Date of issue 2022-10-28 Report template No FDT08_24 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 2 of 224 2022-10-28 Index INDEX ........................................................................................................................................................................... 2 ACRONYMS ................................................................................................................................................................. 3 COMPETENCES AND GUARANTEES ....................................................................................................................... 3 GENERAL CONDITIONS ............................................................................................................................................. 4 UNCERTAINTY ............................................................................................................................................................ 4 DATA PROVIDED BY THE CLIENT ............................................................................................................................ 4 USAGE OF SAMPLES ................................................................................................................................................. 5 TEST SAMPLE DESCRIPTION ................................................................................................................................... 7 IDENTIFICATION OF THE CLIENT ............................................................................................................................. 8 TESTING PERIOD AND PLACE .................................................................................................................................. 8 DOCUMENT HISTORY ................................................................................................................................................ 8 ENVIRONMENTAL CONDITIONS ............................................................................................................................... 9 REMARKS AND COMMENTS ................................................................................................................................... 10 TESTING VERDICTS ................................................................................................................................................. 11 SUMMARY .................................................................................................................................................................. 12 APPENDIX A: TEST RESULTS. BLUETOOTH LOW ENERGY 5.0 (2M, 1M) ......................................................... 13 APPENDIX B: TEST RESULTS. BLUETOOTH EDR. ............................................................................................... 93 APPENDIX C: PHOTOGRAPHS (SEPARATED DOCUMENT). ................................................................................... DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 3 of 224 2022-10-28 Acronyms Acronym ID Acronym Description # of Tx Chains Number of Transmission Chains 26Ebw Emission Bandwidth BW Bandwidth Detector Detector used Equipment Equipment Type Freq Frequency Freq Rng Frequency Range Inband Peak Lvl Inband Peak Level Lvl Level MP Measurement Point Mod Modulation Occ Ch BW Occupied Channel Bandwidth PSD Power Spectrum Density Peak Power Maximum Peak Conducted Output Power Pol Polarization Port Active Port Unwanted Freq Unwanted Emissions Frequency Unwanted Lvl Unwanted Emissions Level Competences and guarantees DEKRA Testing and Certification S.A.U. is a testing laboratory accredited by the National Accreditation Body (ENAC -Entidad Nacional de Acreditación), to perform the tests indicated in the Certificate No. 51/LE 147. DEKRA Testing and Certification is a FCC-recognized accredited testing laboratory with appropriate scope of accreditation that covers the performed tests in this report. DEKRA Testing and Certification is an ISED-recognized accredited testing laboratory, CABid: ES1909, with the appropriate scope of accreditation that covers the performed tests in this report. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certif…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 93 of 224 2022-10-28 Appendix B: Test results. Bluetooth EDR. Approved by (name / position & signature) Rafael López Martín EMC Consumer & RF Lab. Manager Date of issue 2022-10-28 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 94 of 224 2022-10-28 INDEX TEST CONDITIONS ................................................................................................................................................... 95 TEST CASES DETAILS ............................................................................................................................................. 98 FCC 47 CFR PART 15.247 / RSS-247 ..................................................................................................................... 98 99dBw Occupied Channel Bandwidth 99% ........................................................................................................ 98 RSS-247 5.1 (b) / FCC 15.247 (a) (1) [20dBW] 20 dB Bandwidth ................................................................... 108 RSS-247 5.1 (b) / FCC 15.247 (a) (1) Carrier Frequency Separation .............................................................. 120 RSS-247 5.1 (d) / FCC 15.247 (a) (1) (iii) Time of Occupancy (Dwell Time) ................................................... 126 RSS-247 5.1 (d) / FCC 15.247 (a) (1) (iii) Number of hopping channels ......................................................... 138 RSS-247 5.4 (b) / FCC 15.247 (b) (1) Maximum Peak Conducted output power ............................................ 144 RSS-247 5.5 / FCC 15.247 (d) Band-edge emissions compliance (Transmitter) ............................................ 156 RSS-247 5.5 / FCC 15.247 (d) Emission limitations radiated (Transmitter) ..................................................... 186 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 95 of 224 2022-10-28 TEST CONDITIONS (*): Data provided by the client. POWER SUPPLY (*): Vnominal: 5V Type of Power Supply: External Power supply / Battery ANTENNA (*): Type of Antenna: Internal IFA (muxed) Maximum Declared Antenna Gain: 1.3dBi TEST FREQUENCIES (*): Low Channel: 2402 MHz Middle Channel: 2441 MHz High Channel: 2480 MHz CONDUCTED MEASUREMENTS: The equipment under test was set up in a shielded room and it is connected to the TS8997 using a low loss RF cable. The reading of the spectrum analyser is corrected taking into account the cable loss. RADIATED MEASUREMENTS: All radiated tests were performed in a semi-anechoic chamber. The measurement antenna (Bilog antenna for the range between 30 MHz to 1000 MHz and 1 GHz-17 GHz Double ridge horn antenna) is situated at a distance of 3 m and at a distance of 1.5 m for the frequency range 17 GHz-26 GHz (17 GHz-40 GHz horn antenna). For radiated emissions in the range 17 GHz-26 GHz that is performed at a distance closer than the specified distance, an inverse proportionality factor of 20 dB per decade is used to normalize the measured data for determining compliance. The equipment under test was set up on a non-conductive platform above the ground plane and the situation and orientation was varied to find the maximum radiated emission. It was also rotated 360º and the antenna height (Bilog antenna and Double ridge horn antenna) was varied from 1 to 4 meters to find the maximum radiated emission. Measurements were made in both horizontal and vertical planes of polarization. A resolution bandwidth/video bandwidth of 100 kHz / 300 kHz was used for frequencies below 1 GHz and 1 MHz / 3 MHz for frequencies above 1 GHz. DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 96 of 224 2022-10-28 Radiated measurements setup from 30 MHz to 1 GHz: Radiated measurements setup from 1 GHz to 17 GHz: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 97 of 224 2022-10-28 Radiated measurements setup f > 17 GHz: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 98 of 224 2022-10-28 TEST CASES DETAILS FCC 47 CFR Part 15.247 / RSS-247 99dBw Occupied Channel Bandwidth 99% Results Modulation: BT (GFSK 1-DH5) Freq (MHz) Occ Ch BW (MHz) 2402.00000 0.865 2441.00000 0.865 2480.00000 0.865 Modulation: BT (Pi/4 DQPSK 2-DH5) Freq (MHz) Occ Ch BW (MHz) 2402.00 1.325 2441.00 1.335 2480.00 1.310 Modulation: BT (8DPSK 3-DH5) Freq (MHz) Occ Ch BW (MHz) 2402.00 1.295 2441.00 1.295 2480.00 1.280 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 99 of 224 2022-10-28 Attachments Frequency MHz = 2402.00000, Equipment Type = Frequency Hopping Spread Spectrum systems (DSS), Bandwidth MHz = 1, Modulation = BT (GFSK 1-DH5), Number of Transmission Chains = 1, Active Port = 1 Images: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67242RRF.002 Page 100 of 224 2022-10-28 Frequency MHz = 2441.00000, Equipment Type = Frequency Hopping Spread Spectrum systems (DSS), Bandwidth MHz = 1, Modulation = BT (GFSK 1-DH5), Number of Transmission Chains = 1, Active Port = 1 Images: DEKRA Testing and Certification,…

Text truncated - open the document above for the full version.

Project: Widex Sound Assist (AG5) Project ID: P003677 Doc. ID: D00280234 Version: 1.0 Date: See signatures Title: Antenna Specification Page 1 of 7 Restricted . Print outs are uncontrolled copies. 1 General Information Copyright WSAUD A/S. All rights reserved. 1.1 Document Release Author: Role Name Date & signature RF Design Engineer Jan Zøllner Mølgård Reviewer: Role Name Date & signature HW Design Engineer Claus Pedersen Approver: Role Name Date & signature Project Manager Jens Denborg Project: Widex Sound Assist (AG5) Project ID: P003677 Doc. ID: D00280234 Version: 1.0 Date: See signatures Title: Antenna Specification Page 2 of 7 Restricted . Print outs are uncontrolled copies. 1.2 Table of Content 1 General Information ........................................................................................... 1 1.1 Document Release 1 1.2 Table of Content 2 1.3 Purpose 3 1.4 Change History 3 2 Antenna Parameters ........................................................................................... 4 2.1 Mechanical Structure 4 2.2 Simulated Radiation Pattern 4 3 Measurements .................................................................................................... 6 3.1 Setup 6 3.2 Efficiency 7 3.3 Directivity Pattern 7 3.4 Gain 7 Project: Widex Sound Assist (AG5) Project ID: P003677 Doc. ID: D00280234 Version: 1.0 Date: See signatures Title: Antenna Specification Page 3 of 7 Restricted . Print outs are uncontrolled copies. 1.3 Purpose This document describes the antenna specifications for the Widex Sound Assist. 1.4 Change History Version Description 1.0 Initial release of document. Project: Widex Sound Assist (AG5) Project ID: P003677 Doc. ID: D00280234 Version: 1.0 Date: See signatures Title: Antenna Specification Page 4 of 7 Restricted . Print outs are uncontrolled copies. 2 Antenna Parameters Antenna part no is 30-6100-000 and is an internal part manufactured by Widex. 2.1 Mechanical Structure Material is NICKEL SILVER ALLOY C7521 1/2H with a thickness of 0.2mm. 2.2 Simulated Radiation Pattern Configuration of antenna with added body (purple square): Project: Widex Sound Assist (AG5) Project ID: P003677 Doc. ID: D00280234 Version: 1.0 Date: See signatures Title: Antenna Specification Page 5 of 7 Restricted . Print outs are uncontrolled copies. Maximum simulated gain is 1.9dBi. Project: Widex Sound Assist (AG5) Project ID: P003677 Doc. ID: D00280234 Version: 1.0 Date: See signatures Title: Antenna Specification Page 6 of 7 Restr…
