135 • Use another web browser or computer to log in again. • Reset the router to factory default settings and try again. If login still fails, please contact the technical support. Note: You’ll need to reconfigure the router to surf the internet once the router is reset. Q4 What should I do if I can’t access the internet even though the configuration is finished? 1 Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 Go to Advanced> Network > Status to check internet status: If IP Address is a valid one, please try the methods below and try again: • Your computer might not recognize any DNS server addresses. Please manually configure the DNS server. 1 ) Go to Advanced > Network > DHCP Server. 2 ) Enter 8.8.8.8 as Primary DNS, click S AV E. Tips: 8.8.8.8 is a safe and public DNS server operated by Google. 136 • Restart the modem and the router. 1 ) Power off your modem and router, and leave them off for 1 minute. 2 ) Power on your modem first, and wait about 2 minutes until it gets a solid cable or Internet light. 3 ) Power on the router. 4 ) Wait another 1 or 2 minutes and check the internet access. • Reset the router to factory default settings and reconfigure the router. • Upgrade the firmware of the router. • Check the TCP/IP settings on the particular device if all other devices can get internet from the router. As the picture below shows, if the IP Address is 0 0 0 0, please try the methods below and try again: • Make sure the physical connection between the router and the modem is proper. • Clone the MAC address of your computer. 137 1 ) Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 ) Go to Internet or Advanced > Network > Internet and focus on the MAC Clone section. 3 ) Choose an option as needed (enter the MAC address if Use Custom MAC Address is selected), and click S AV E. Tips: • Some ISP will register the MAC address of your computer when you access the internet for the first time through their Cable modem, if you add a router into your network to share your internet connection, the ISP will not accept it as the MAC address is changed, so we need to clone your computer’s MAC address to the router. • The MAC addresses of a computer in wired connection and wireless connection are different. • Modify the LAN IP address of the router. Note: Most TP-Link routers use 192.168.0.1/192.168.1.1 as their default LAN IP address, which may conflict with the IP range of your existing ADSL modem/router. If so, the router is not able to communicate with your modem and you can’t access the internet. To resolve this problem, we need to change the LAN IP address of the router to avoid such conflict, for example, 192.168.2.1. 1 ) Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 ) Go to Advanced > Network > LAN. 3 ) Modify the LAN IP address as the follow picture shows. Here we take 192.168.2.1 as an example. 4 ) Click S AV E. • Restart the modem and the router. 138 1 ) Power off your modem and router, and leave them off for 1 minute. 2 ) Power on your modem first, and wait about 2 minutes until it get a solid cable or Internet light. 3 ) Power on the router. 4 ) Wait another 1 or 2 minutes and check the internet access. • Double check the internet connection type. 1 ) Confirm your internet connection type, which can be learned from the ISP. 2 ) Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 3 ) Go to Advanced > Network > Internet. 4 ) Select your Internet Connection Type and fill in other parameters. 5 ) Click S AV E. 6 ) Restart the modem and the router again. • Please upgrade the firmware of the router. If you’ve tried every method above but still cannot access the internet, please contact the technical support. Q5 What should I do if I can’t find my wireless network or I cannot connect the wireless network? If you fail to find any wireless network, please follow the steps below: • Make sure the wireless function of your device is enabled if you’re using a laptop with built-in wireless adapter. You can refer to the relevant document or contact the laptop manufacturer. 139 • Make sure the wireless adapter driver is installed successfully and the wireless adapter is enabled. • On Windows 7 1 ) If you see the message No connections are available, it is usually because the wireless function is disabled or blocked somehow. 2 ) Click Troubleshoot and windows might be able to fix the problem by itself. • On Windows XP 1 ) If you see the message Windows cannot configure this wireless connection, this is usually because windows configuration utility is disabled or you are running another wireless configuration tool to connect the wireless. 2 ) Exit the wireless configuration tool (the TP-Link Utility, for example). 3 ) Select and right click on My Computer on desktop, select Manage to open Computer Management window. 4 ) Expand Services and Applications > Services, find and locate Wireless Zero Configuration in the Services list on the right side. 5 ) Right click Wireless Zero Configuration, and then select Properties. 6 ) Change Startup type to Automatic, click on Start button and make sure the Service status is Started. And then click OK. If you can find other wireless network except your own, please follow the steps below: • Check the WLAN LED indicator on your wireless router/modem. • Make sure your computer/device is still in the range of your router/modem. Move it closer if it is currently too far away. • Go to Wireless or Advanced > Wireless > Wireless Settings, and check the wireless settings. Double check your wireless Network Name and SSID is not hided. If you can find your wireless network but fail to connect, please follow the steps below: • Authenticating problem/password mismatch: 1 ) Sometimes you will be asked to type in a PIN number when you connect to the wireless network f…

Text truncated - open the document above for the full version.

© 2023 TP-Link 1910013365 REV1.0.0 User Guide BE19000 Tri-Band Wi-Fi 7 Router Archer BE800 Contents About This Guide 1 Chapter 1 Get to Know About Your Router 3 1. 1. Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. 1. Top Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. 2. Back Panel and Side Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Chapter 2 Connect the Hardware 7 2. 1. Position Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2. 2. Connect Your Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Chapter 3 Log In to Your Router 11 Chapter 4 Set Up Internet Connection 13 4. 1. Use Quick Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 4. 2. Quick Setup Via TP-Link Tether App. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 4. 3. Manually Set Up Your Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 4. 4. Set Up the Router as an Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 4. 5. Set Up an IPv6 Internet Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Chapter 5 TP-Link Cloud Service 23 5. 1. Register a TP-Link ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 5. 2. Change Your TP-Link ID Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 5. 3. Manage the User TP-Link IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 5. 3. 1. Add TP-Link ID to Manage the Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 5. 3. 2. Remove TP-Link ID(s) from Managing the Router. . . . . . . . . . . . . . . . . . . . . .26 5. 4. Manage the Router via the TP-Link Tether App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Chapter 6 Network Map 28 Chapter 7 Use Motorized Antennas 32 7. 1. Device Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 7. 2. Area Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 7. 3. Whole Home Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 7. 4. Advanced Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 Chapter 8 Wireless Settings 41 8. 1. Specify Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 8. 2. Schedule Your Wireless Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 8. 3. Use WPS for Wireless Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 8. 3. 1. Connect via the Client’s PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 8. 3. 2. Connect via the Router’s PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 8. 3. 3. Push the WPS Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 8. 4. Advanced Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 Chapter 9 Guest Network 50 9. 1. Create a Network for Guests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 9. 2. Customize Guest Network Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52 Chapter 10 USB Settings 53 10. 1. Access the USB Storage Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 10. 1. 1. Access the USB Device Locally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 10. 1. 2. Access the USB Device Remotely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 10. 1. 3. Customize the Access Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 10. 2. Media Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59 10. 3. Time Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60 Chapter 11 HomeShield 62 11. 1. Network Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 11. 2. Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 11. 3. QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 11. 4. More Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 Chapter 12 OneMesh with Seamless Roaming 69 12. 1. Set Up a OneMesh Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70 12. 2. Manage Devices in the OneMesh Network . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

28 Chapter 6 Network Map Network Map outlines device connectivity of your network visually and helps you manage general settings of the network. 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Network Map. 3. Click each network device icon to check and manage general network settings. • Click Internet to check internet status. • Click the router to check device status and network settings. You can turn on or off the wireless network or guest network, or click Edit to change related settings. 29 Chapter 6 Network Map • Click Mesh Devices to view the devices that form a mesh network with the router. 30 Chapter 6 Network Map • Click Clients to view the client devices in your network. You can block devices so they cannot access your network, or set Speed Limit to limit their upload and download speeds. To limit the speeds of a device: 1. Click in the Speed Limit column. 2. Enable Speed Limit. 3. Set the download and upload speed limit according to your needs. 4. Click S AV E. The speeds of the device will be limited. Chapter 7 Use Motorized Antennas Archer AXE200 Omni can auto adjust its antennas to boost Wi-Fi signals throughout your whole home or to a specific device or area. You are recommended to use TP-Link Tether app to use the motorized antennas for a better experience. This chapter introduces how to configure the motorized antennas to boost Wi-Fi signals. It contains the following sections: • Device Boost • Area Boost • Whole Home Boost • Advanced Settings 32 Chapter 7 Use Motorized Antennas 7 1 Device Boost When you're gaming, streaming video, or having a conference call on your phone, you can choose to boost Wi-Fi to that device. You'll maintain a constant, stable connection wherever you settle down. 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Antennas > Device Boost. Click START NOW to start the settings. 3. Select the specific device you want to improve its Wi-Fi quality, and set the boost duration. Click S TA R T, then you will see the antennas will move to boost signals to the direction of the specific device. 33 Chapter 7 Use Motorized Antennas 4. You can check the remaining time, or you can click STOP to stop this mode to restore to whole home boost mode. 7 2 Area Boost When you have a family together in a specific area (like movie time or an outdoor gathering), you can choose to boost your Wi-Fi to this area. The devices in the area will receive a strong Wi-Fi signal. 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Antennas > Area Boost. Click Create an Area to start the settings. 34 Chapter 7 Use Motorized Antennas 3. Wait for detecting the area. 4. Name the area and choose an icon. Click S AV E. 35 Chapter 7 Use Motorized Antennas 5. Set the boost duration. Click BOOST to boost the signal to the direction of specific area. 6. You can check the remaining time, or you can click STOP to stop this mode to restore to whole home boost mode. 7 3 Whole Home Boost Omni offers two boost modes for whole home Wi-Fi signals, Layout Boost and AI Boost. You can choose to boost whole home Wi-Fi signals according to the layout of your house, or choose to intelligently boost Wi-Fi signals based on the current device connections to ensure network performance. This is recommended. • To set the Layout Boost mode 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Antennas > Whole Home Boost. Select the Layout Boost mode. 36 Chapter 7 Use Motorized Antennas 3. Click S TA R T. 4. Set the layout of your house. Click S AV E. 37 Chapter 7 Use Motorized Antennas • To set the AI Boost mode 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Antennas > Whole Home Boost. Click Change Mode, then select the AI Boost mode. 38 Chapter 7 Use Motorized Antennas 3. Enable Auto AI Boost. When enabled, Omni will automatically adjust its antennas to boost Wi-Fi signals based on the current device connections to ensure network performance. When disabled, Omni will keep its antennas in the last-adjusted status. You can manually click the RE-ADJUST button to start AI Boost. You can check the details for enhanced devices. 39 Chapter 7 Use Motorized Antennas 7 4 Advanced Settings Identify all of your security and IoT devices to improve the performance of the whole network. We recommend that you identify all of your security and IoT devices, such as baby monitors and security cameras. This helps Omni adopt advanced boost strategies to improve the performance of the whole network, providing a better Wi-Fi boost. 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Antennas > Advanced Settings. Select the Security Devices or IoT Devices mode. 3. Click Add to add the correct type of device. Then click S AV E. Chapter 8 Wireless Settings This chapter guides you on how to configure the wireless settings. It contains the following sections: • Specify Wireless Settings • Schedule Your Wireless Function • Use WPS for Wireless Connection • Advanced Wireless Settings 41 Chapter 8 Wireless Settings 8 1 Specify Wireless Settings The router’s wireless network names (SSIDs), password, and security option are preset in the factory. The preset SSIDs and password can be found on the label of the router. You can customize the wireless settings according to your needs. 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Wireless or Advanced > Wireless > Wireless Settings. 42 Chapter 8 Wireless Settings • To enable or disable OFDMA: OFDMA enables multiple users to transmit data simultaneously, and thus greatly improves speed and efficiency. Noted that only when your clients also support OFDMA, can you fu…

Text truncated - open the document above for the full version.

65 Chapter 11 HomeShield 4 ) Enable Bed Time and use the up/down arrows or enter times in the fields. Devices under this profile will be unable to access the internet during this time period. 5 ) Click S AV E. 6 ) After adding a profile, you can click the Insight icon to check the detailed visited history, and click the pause the network for this profile anytime. Note: You can go to Advanced > HomeShield > More Features for a detailed introduction and download Tether to enjoy full Homeshield Pro feature. 66 Chapter 11 HomeShield 11 3 QoS QoS (Quality of Service) allows you to prioritize connection of specific devices for a set duration. Devices set as high priority will be allocated more bandwidth and so continue to run smoothly even when there is heavy traffic on the network. 1 Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 Go to Advanced > HomeShield > QoS. 3 Enable QoS to set the total bandwidth. Then click S AV E. 4 Enable High Priority for the desired device and set its effective time. 11 4 More Features Download the Tether app and subscribe to enjoy the full features of HomeShield. 1 Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 Go to Advanced > HomeShield > More Features. 3 Follow the web instructions to get full features of HomeShield. 67 Chapter 11 HomeShield Chapter 12 OneMesh with Seamless Roaming This chapter introduces the TP-Link OneMesh TM feature. It contains the following sections: • Set Up a OneMesh Network • Manage Devices in the OneMesh Network 69 Chapter 12 OneMesh with Seamless Roaming TP-Link OneMesh router and TP-Link OneMesh extenders work together to form one unified Wi-Fi network. Walk through your home and stay connected with the fastest possible speeds thanks to OneMesh’s seamless coverage. I N T E R N E T SAME Network Name & Password for seamless roaming Unified Wi-Fi Network Router and extenders share the same wireless settings, including network name, password, access control settings and more. Seamless Roaming Devices automatically switch between your router and extenders as you move through your home for the fastest possible speeds. Easy Setup and Management Set up a OneMesh network with a push of WPS buttons. Manage all network devices on the Tether app or at your router’s web management page. 12 1 Set Up a OneMesh Network 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Advanced > OneMesh. 3. Enable OneMesh. 70 Chapter 12 OneMesh with Seamless Roaming 4. Connect a OneMesh extender to this router by following the setup instructions in the extender’s manual. The extender will be listed on the router’s OneMesh page. Note: To check full list of TP-Link OneMesh devices, visit https://www.tp-link.com/onemesh/compatibility. 5. If you have set up the extender to join the OneMesh network, it will be listed on the router’s OneMesh page. Otherwise, you need to find it in the Available OneMesh Devices list and click Add to add it to the OneMesh network. Done! Now your router and extender successfully form a OneMesh network! 71 Chapter 12 OneMesh with Seamless Roaming 12 2 Manage Devices in the OneMesh Network In a OneMesh network, you can manage all mesh devices and connected clients on your router’s web page. • To view mesh devices and connected clients in the network: 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Network Map. 3. Click to view all mesh devices, and click to view all connected clients. • To manage a OneMesh device in the network: 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Advanced > OneMesh. 3. Click the OneMesh device to view detailed information. 72 Chapter 12 OneMesh with Seamless Roaming 4. Manage the OneMesh device as needed. You can: • Change device information. • Click Manage Device to redirect to the web management page of this device. • Click Leave OneMesh to delete this device from the OneMesh network. Chapter 13 Network Security This chapter guides you on how to protect your home network from cyber attacks and unauthorized users by implementing these three network security functions. You can protect your home network from cyber attacks, block or allow specific client devices to access your network using Access Control, or you can prevent ARP spoofing and ARP attacks using IP & MAC Binding. It contains the following sections: • Protect the Network from Cyber Attacks • Access Control • IP & MAC Binding • ALG *For a more comprehensive home network protection system, refer to the HomeShield chapter. 74 Chapter 13 Network Security 13 1 Protect the Network from Cyber Attacks The SPI (Stateful Packet Inspection) Firewall protects the router from cyber attacks and validate the traffic that is passing through the router based on the protocol. This function is enabled by default. 1 Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 Go to Advanced > Security > Firewall. It’s recommended to keep the default settings. 13 2 Access Control Access Control is used to block or allow specific client devices to access your network (via wired or wireless) based on a list of blocked devices (Blacklist) or a list of allowed devices (Whitelist). I want to: Block or allow specific client devices to access my network (via wired or wireless). How can I do that? 1 Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 Go to Advanced > Security > Access Control. 3 Toggle on to enable Access Control. 4 Select the access mode to either block (recommended) or allow the device(s) in the list. To block specific device(s): 1 ) Select Blacklist. 75 Chapter 13 Network Security 2 ) Click and select devices you want to be blocked and Click ADD. 3 ) The Operation Succee…

Text truncated - open the document above for the full version.

100 Chapter 15 VPN Server&Client 15 4 Use VPN Client to Access a Remote VPN Server VPN Client is used to create VPN connections for devices in your home network to access a remote VPN server. To use the VPN feature, simply configure a VPN connection and choose your desired devices on your router, then these devices can access the remote VPN server. Please follow the steps below: INTERNET Home DevicesRouter (VPN Client)VPN Servers 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Advanced > VPN Client. Note: Firmware update may be required to support VPN Client. 3. Enable VPN Client, then save the settings. 4. Add VPN servers, and enable the one you need. 1 ) In the Server List section, click Add. 2 ) Specify a description for the VPN, and choose the VPN type. 101 Chapter 15 VPN Server&Client 3 ) Enter the VPN information provided by your VPN provider. • OpenVPN: Enter the VPN username and password if required by your VPN provider, otherwise simply leave them empty. Then import the configuration file provided by your VPN provider. • PPTP: Enter the VPN server address (for example: 218.18.1.73) and the VPN username and password provided by your VPN provider. 102 Chapter 15 VPN Server&Client • L2TP/IPSec VPN: Enter the VPN server address (for example: 218.18.1.73), VPN username and password, and IPSec pre-shared key provided by your VPN provider. 4 ) Save the settings. 5 ) In the server list, enable the one you need. 103 Chapter 15 VPN Server&Client 5. Add and manage the devices that will use the VPN function. 1 ) In the Device List section, click Add. 2 ) Choose and add the devices that will access the VPN server you have configured. 6. Save the settings. 104 Chapter 15 VPN Server&Client Done! Now the devices you specified can access the VPN server you enabled. Chapter 16 Customize Your Network Settings This chapter guides you on how to configure advanced network features. It contains the following sections: • Change the Internet Settings • Change the LAN Settings • Configure to Support IPTV Service • Specify DHCP Server Settings • Set Up a Dynamic DNS Service Account • Create Static Routes 106 Chapter 16 Customize Your Network Settings 16 1 Change the Internet Settings After setting up your internet, you can also easily change the internet settings if needed in the future. 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Advanced > Network > Internet. • To change the internet port: 1. Select the desired internet port. Make sure the cable is securely connected to this port on your router. 2. Click S AV E. • To change the internet connection settings: 107 Chapter 16 Customize Your Network Settings 1. Select the internet connection type and configure the settings according to the information provided by your ISP. 2. Optional. Reveal the advanced settings and change the settings if needed. It’s recommended to keep the default settings. 3. Click S AV E. • To change the MAC address of the router: You have three options, Use Default MAC Address, Clone Current Device MAC, Use Custom MAC Address. 108 Chapter 16 Customize Your Network Settings • To change the Internet Port Negotiation Speed Setting You can change the internet port speed mode. Auto Negotiation is recommended. 16 2 Change the LAN Settings The router is preset with a default LAN IP 192.168.0.1, which you can use to log in to its web management page. The LAN IP address together with the Subnet Mask also defines the subnet that the connected devices are on. If the IP address conflicts with another device on your local network or your network requires a specific IP subnet, you can change it. 1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2. Go to Advanced > Network > LAN. 3. Type in a new IP Address appropriate to your needs. And leave the Subnet Mask as the default settings. 4. Click S AV E. Note: If you have set the Port Forwarding, DMZ or DHCP address reservation, and the new LAN IP address is not in the same subnet with the old one, then you should reconfigure these features. 16 3 Configure to Support IPTV Service I want to: Configure IPTV setup to enable Internet/IPTV/Phone service provided by my internet service provider (ISP). How can I do that? 109 Chapter 16 Customize Your Network Settings 1 Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for the router. 2 Go to Advanced > Network > IPTV/VLAN. 3 If your ISP provides the networking service based on IGMP technology, e.g., British Telecom(BT) and Talk Talk in UK: 1 ) Tick the IGMP Proxy and IGMP Snooping checkbox, then select the IGMP Version, either V2 or V3, as required by your ISP. 2 ) Click S AV E. 3 ) After configuring IGMP proxy, IPTV can work behind your router now. You can connect your set-top box to any of the router’s Ethernet port. If IGMP is not the technology your ISP applies to provide IPTV service: 1 ) Tick Enable IPTV/VLAN. 2 ) Select the appropriate Mode according to your ISP. • Select Bridge if your ISP is not listed and no other parameters are required. • Select Custom if your ISP is not listed but provides necessary parameters. 3 ) After you have selected a mode, the necessary parameters, including the LAN port for IPTV connection, are predetermined. If not, select the LAN type to determine which port is used to support IPTV service. 4 ) Click S AV E. 110 Chapter 16 Customize Your Network Settings 5 ) Connect the set-top box to the corresponding LAN port which is predetermined or you have specified in Step 3. Done! Your IPTV setup is done now! You may need to configure your set-top box before enjoying your TV. 16 4 Specify DHCP Server Settings By default, the DHCP (Dynamic Host Configuration Protocol) Server is enabled and the router acts as a DHCP server; it dynamically assigns TCP/IP parameters to client devices from the IP Address Pool. You c…
