2AXJ4HX510V2AX3000 Whole Home Mesh Wi-Fi AP

© 2022 TP-Link 1910020936 REV1.0.0 User Guide BBA Mesh Contents About This Guide 1 Chapter 1 Get to Know About Your Device 3 1. 1. Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Chapter 2 Connect the Device 6 2. 1. Position the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2. 2. Connect Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Chapter 3 Log In to Your Device 10 Chapter 4 Set Up Internet Connection 12 4. 1. Use Quick Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 4. 2. Quick Setup Via TP-Link Aginet App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 4. 3. Manually Set Up Your Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 4. 4. Set Up the Mesh Device as an Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 4. 5. Set Up an IPv6 Internet Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 4. 6. IPv6 Tunnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Chapter 5 Setup Your Network via TP-Link Aginet App 25 5. 1. Set Up Your Mesh Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 5. 2. Dashboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 5. 3. Add More Mesh Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 5. 4. Check Mesh Device Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 5. 5. Remove/Reboot Mesh Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 5. 6. Manage Connected Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 5. 7. Create a New Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 5. 8. Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38 5. 9. Wi-Fi Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 5. 10. Guest Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 5. 11. Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41 5. 12. Block List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 5. 13. Upgrade Your Mesh Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 5. 14. Advanced Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Chapter 6 Customize Your Network Settings 49 6. 1. Configure LAN Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 6. 1. 1. Change the LAN IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 6. 1. 2. Use the Mesh Device as a DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 6. 1. 3. Reserve LAN IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52 6. 2. Configure IPv6 LAN Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52 6. 2. 1. Configure the RADVD Address Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53 6. 2. 2. Configure the DHCPv6 Server Address Type . . . . . . . . . . . . . . . . . . . . . . . . .53 6. 3. Set Up a Dynamic DNS Service Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 6. 4. Create Static Routes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 6. 5. RIP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 6. 6. Specify Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59 6. 6. 1. Change Basic Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59 6. 6. 2. Advanced Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 6. 6. 3. View Wireless Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64 6. 7. Schedule Your Wireless Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 6. 8. Use WPS for Wireless Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66 Chapter 7 Multi-SSID 69 Chapter 8 TP-Link Cloud Service 71 8. 1. Register a TP-Link ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72 8. 2. Change Your TP-Link ID Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72 8. 3. Manage the User TP-Link IDs . . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

33 Chapter 5 Setup Your Network via TP-Link Aginet App 2. Tap a mesh device to check more details. 3. Check download/upload speed of the mesh device. 34 Chapter 5 Setup Your Network via TP-Link Aginet App 4. Tap and change or customize the location/name of the mesh device. 5. Check the clients connected to the mesh device. 35 Chapter 5 Setup Your Network via TP-Link Aginet App 6. Tap the client’s name. Change or customize client’s information. 5 5 Remove/Reboot Mesh Devices You can reset your mesh device to factory default settings or reboot your mesh device to clear cache and enhance running performance easily in the Aginet app. Follow the steps below. Note: Rebooting your mesh device will keep the current settings on it. Removing your mesh device will reset it to factory default settings and you will need to set up your mesh device again. You can also press and hold the Reset button for at least 5 second to quickly reset your mesh device to factory default settings. In Network, tap . Select a mesh device. 7. Tap to remove or reboot the mesh device. 36 Chapter 5 Setup Your Network via TP-Link Aginet App Note: If the LED light of mesh device does not turn flashing blue after tapping Remove, press and hold the Reset button for at least 5 second to reset it. 5 6 Manage Connected Devices In Network, you can mange your connected devices easily, such as changing the device name and type. 1. Tap a connected device to check the details (e.g. real-time upload and download speeds, device name/profile, etc.). 2. Change the Device Type and Device Name as needed. 37 Chapter 5 Setup Your Network via TP-Link Aginet App 5 7 Create a New Network In the Aginet app, you can create different mesh networks with your TP-Link ID and manage them conveniently from the Aginet app with one account. You can also help family or friends manage their networks with your Aginet app. Two methods are provided as below to create a new network. Method 1. Create a new network from the Overview page 1. Tap + > Create a Network. 2. Then follow app instructions to complete the setup. Method 2. Create a new network from the Menu page 1. Tap to open the menu. Tap > Add a Network. 38 Chapter 5 Setup Your Network via TP-Link Aginet App 2. Then follow app instructions to complete the setup. 5 8 Parental Controls Parental Controls helps you set time limits and filter content to flexibly control your kids when they’re online. 1. In Family, tap Create a Profile. 2. Then follow app instructions to complete the setup. 39 Chapter 5 Setup Your Network via TP-Link Aginet App 5 9 Wi-Fi Settings You can change the network name and password of your main network at any time and share the network easily with family and friends. 1. In More, Tap Wi-Fi Settings. 2. Manage main network (e.g. change your main network’s Wi-Fi name and password, hide the network from Wi-Fi list, etc.). 3. Tap Advanced. For better Wi-Fi performance, set the channel width for 2.4GHz and 5GHz Wi-Fi as needed. (It is recommended to use the default settings.) 40 Chapter 5 Setup Your Network via TP-Link Aginet App 5 10 Guest Network You can create and share a separate network for guests to guarantee the security and privacy of your main network. 1. In More, Tap Guest Network. 2. Set a Wi-Fi name and password for the guest network. 41 Chapter 5 Setup Your Network via TP-Link Aginet App 5 11 Internet Connection In Internet Connection, You can modify WAN settings (IPv4 & IPv6), enable MAC Clone mode. 1. In More, Tap Internet Connection. 2. View IPv4 details or change the internet connection type. 42 Chapter 5 Setup Your Network via TP-Link Aginet App 3. Enable IPv6 to set up an IPv6 internet connection. 43 Chapter 5 Setup Your Network via TP-Link Aginet App 4. Tap Advanced and enable MAC Clone as needed. Tip: For more about MAC Clone, refer to https://www.tp-link.com/support/faq/2925/ 5 12 Block List Add devices to the block list to prevent the devices from accessing your network, ensuring the safety of your personal information shared in the network. 1. In More, Tap Block List. 44 Chapter 5 Setup Your Network via TP-Link Aginet App 2. Tap + and add clients or other devices to the block list. 5 13 Upgrade Your Mesh Device TP-Link is dedicated to improving product features and providing a better customer experience. An up-to-date firmware provides better and more stable network performance. Always update your mesh device to the latest firmware version when prompted in the Aginet app. 1. In More, Tap System and Firmware Update. 45 Chapter 5 Setup Your Network via TP-Link Aginet App 2. Download and install the firmware (if any) and follow app instructions to update your mesh device to the latest version. 5 14 Advanced Features Additional features are available under the Advanced menu. You can control mesh device’s LED, enable reboot schedule, bind your TP-Link ID, change the operation mode, configure system settings. 1. In More, Tap LED Control. 46 Chapter 5 Setup Your Network via TP-Link Aginet App 2. Toggle off LED to turn off the light on mesh device. Configure the LED Off Time to turn off the LED light at bedtime only. 3. Enable Reboot Schedule as needed. 47 Chapter 5 Setup Your Network via TP-Link Aginet App 4. Bind your TP-Link ID. 5. Change the Operation Mode as needed. 48 Chapter 5 Setup Your Network via TP-Link Aginet App Chapter 6 Customize Your Network Settings This chapter introduces how to change the default settings or adjust the basic configuration of the mesh device using the web management page. It contains the following sections: • Configure LAN Settings • Configure IPv6 LAN Settings • Set Up a Dynamic DNS Service Account • Create Static Routes • RIP Settings • Specify Wireless Settings • Schedule Your Wireless Function • Use WPS for Wireless Connection 50 Chapter 6 Customize Your Network Settings 6 1 Configure LAN Settings 6 1 1 Change the LAN IP Address The mesh device is preset with a default LAN IP 192.168.88.1, which you can use to log in to its web managem…

Text truncated - open the document above for the full version.

75 Chapter 8 TP-Link Cloud Service 8 4 Manage the Mesh Device via the TP-Link Aginet App The Aginet app runs on iOS and Android devices, such as smartphones and tablets. 1. Launch the Apple App Store or Google Play store and search “TP-Link Aginet” or simply scan the QR code to download and install the app. OR 2. Launch the Aginet app and log in with your TP-Link ID. Note: If you don’t have a TP-Link ID, create one first. 3. Connect your device to the mesh device’s wireless network. 4. Go back to the Aginet app, select the model of yourmesh device and log in with the password you set for the mesh device. 5. Manage your mesh device as needed. Note: If you need to remotely access your mesh device from your smart devices, you need to: • Log in with your TP-Link ID. If you don’t have one, refer to Register a TP-Link ID. • Make sure your smartphone or tablet can access the internet with cellular data or a Wi-Fi network. Chapter 9 EasyMesh with Seamless Roaming This chapter introduces the TP-Link EasyMesh feature. It contains the following sections: • Set Up a EasyMesh Network • Manage Devices in the EasyMesh Network 77 Chapter 9 EasyMesh with Seamless Roaming TP-Link EasyMesh Controller and TP-Link EasyMesh Agent work together to form one unified Wi-Fi network. Walk through your home and stay connected with the fastest possible speeds thanks to EasyMesh’s seamless coverage. Unified Wi-Fi Network Controller and agents share the same wireless settings, including network name, password, access control settings and more. Seamless Roaming Devices automatically switch between your controller and agents as you move through your home for the fastest possible speeds. Easy Setup and Management Set up a EasyMesh network with a push of WPS buttons. Manage all network devices on the Aginet app or at your mesh device’s web management page. 9 1 Set Up a EasyMesh Network 1. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with your TP-Link ID or the password you set for the mesh device. 1. Go to Basic > Mesh or Advanced > Wireless > Mesh. 78 Chapter 9 EasyMesh with Seamless Roaming 2. Connect a EasyMesh agent to this controller by following the setup instructions in the agent’s manual. The agent will be listed on the controller’s Mesh page. Note: To check full list of TP-Link EasyMesh devices, visit https://www.tp-link.com. 3. If you have set up the agent to join the EasyMesh network, it will be listed on the controller’s EasyMesh page. Otherwise, you need to find it in the Add Mesh Device list and click Add to add it to the EasyMesh network. 79 Chapter 9 EasyMesh with Seamless Roaming Done! Now your controller and agents successfully form a EasyMesh network! 9 2 Manage Devices in the EasyMesh Network In a EasyMesh network, you can manage all mesh devices and connected clients on your mesh device’s web page. • To view mesh devices and connected clients in the network: 1. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with your TP-Link ID or the password you set for the mesh device. 2. Go to Basic > Network Map. 3. Click to view all mesh devices, and click to view all connected clients. 80 Chapter 9 EasyMesh with Seamless Roaming • To manage a EasyMesh device in the network: 1. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with your TP-Link ID or the password you set for the mesh device. 2. Go to Basic > Network Map. 3. Click the Mesh device’s IP Address to redirect to the web management page of this device and view detailed information. 4. Manage the EasyMesh device as needed. You can: • Change device information. • Delete this device from the EasyMesh network. Chapter 10 Guest Network This function allows you to provide Wi-Fi access for guests without disclosing your main network. When you have guests in your house, apartment, or workplace, you can create a guest network for them. In addition, you can customize guest network options to ensure network security and privacy. It contains the following sections: • Create a Network for Guests • Customize Guest Network Options 82 Chapter 10 Guest Network 10 1 Create a Network for Guests 1. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with your TP-Link ID or the password you set for the mesh device. 2. Go to Advanced > Guest Network. Locate the Wireless section. 3. Create a guest network as needed. 1 ) Tick the Enable checkbox for the 2.4GHz or 5GHz wireless network. 2 ) Customize the SSID. Don‘t select Hide SSID unless you want your guests to manually input the SSID for guest network access. 3 ) Select the Security type and customize your own password. If No security is selected, no password is needed to access your guest network. 4. Click Save. Now your guests can access your guest network using the SSID and password you set! Tips: To view guest network information, go to Network Map and locate the Guest Network section. You can turn on or off the guest network function conveniently. 10 2 Customize Guest Network Options 1. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with your TP-Link ID or the password you set for the mesh device. 2. Go to Advanced > Guest Network. Locate the Settings section. 3. Customize guest network options according to your needs. 83 Chapter 10 Guest Network • Allow guests to see each other Tick this checkbox if you want to allow the wireless clients on your guest network to communicate with each other via methods such as network neighbors and Ping. 4. Click Save. Now you can ensure network security and privacy! Chapter 11 NAT Forwarding The mesh device’s NAT (Network Address Translation) feature makes devices on the LAN use the same public IP address to communicate with devices on the internet, which protects the local network by hiding IP addresses of the devices. However, it also brings about the problem that an external host cannot initiatively communicate with a specified device on the local network. With the forwarding feature the mesh device can penetr…

Text truncated - open the document above for the full version.

124 Chapter 15VPN Server&Client 9. Find the VPN connection you created, then double-click it. 10. Enter the User name and Password you have set for the IPSec VPN server on your mesh device, and click Properties. 125 Chapter 15VPN Server&Client 11. Switch to the Security tab, select Layer 2 Tunneling Protocol with IPsec (L2TP/ IPSec) and click Advanced settings. 12. Select Use preshared key for authentication and enter the IPSec Pre-Shared Key you have set for the IPSec VPN server on your mesh device. Then click OK. Done! Click Connect to start VPN connection. 126 Chapter 15VPN Server&Client 15 4 VPN Connections VPN Connections page displays the clients that are currently connected to the OpenVPN servers, PPTP VPN servers and IPSec VPN hosted on the mesh device. 1. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with your TP-Link ID or the password you set for the mesh device. 2. Go to Advanced > VPN > VPN connections. Chapter 16 Manage Your Mesh Device This chapter introduces how to change the system settings and administrate your mesh device’s network. This chapter contains the following sections: • Set System Time • Control the LED • Test Internet Connectivity • Update the Firmware • Back Up and Restore Configuration Settings • Reboot the Mesh Device • Administration Management • System Log • CWMP Settings • SNMP Settings • Monitor the Internet Traffic Statistics • Port Mirror 128 Chapter 16 Manage Your Mesh Device 16 1 Set System Time System time is the time displayed while the mesh device is running. The system time you configure here will be used for other time-based functions like Parental Controls and Wireless Schedule. You can manually set how to get the system time. Follow the steps below to set your system time. 1 Visit http://tplinkwifi.net or http://192.168.88.1, and log in with the password you set for the mesh device. 2 Go to Advanced > System Tools > Time Settings page. 3 Configure the system time using the following methods: Get from PC: Click this button if you want to use the current time of your PC. Get from the Internet: Click this button if you want to get time from the internet. Make sure your mesh device can access the internet before you select this way to get system time. 4 Click Save. 5 After setting the system time, you can set Daylight Saving Time according to your needs. Enable Daylight Saving Time, and set the start and end time and then click Save to make the settings effective. 129 Chapter 16 Manage Your Mesh Device 16 2 Control the LED The LED of the mesh device indicates its activities and status. You can enable the Night Mode feature to specify a time period during which the LED is off. 1. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with your TP-Link ID or the password you set for the mesh device. 2. Go to Advanced > System > LED Control. 3. Enable Night Mode. 4. Specify the LED off time, and the LED will be off during this period every day. 5. Click S AV E. 16 3 Test Internet Connectivity Diagnostics function is used to test the connectivity between the mesh device and the host or other network devices. 1 Visit http://tplinkwifi.net or http://192.168.88.1, and log in with the password you set for the mesh device. 2 Go to Advanced > System Tools > Diagnostics page. ¾To test the internet connection of the mesh device: Locate the Diagnostic Tools section, and click the Start to test the internet connectivity and you will find the test results in the gray box. 130 Chapter 16 Manage Your Mesh Device ¾To run ping and traceroute tools: 1 ) Locate the Diagnostic Tools section. 2 ) Select Ping or Traceroute or Nslookup as the diagnostic tool to test the connectivity. • Ping is used to test the connectivity between the mesh device and the tested host, and measure the round-trip time. • Traceroute is used to display the route (path) your mesh device has passed to reach the tested host, and measure transit delays of packets across an internet Protocol network. • Nslookup is used to queries the Domain Name System (DNS) to obtain the mapping between a domain name and IP address, or other DNS records. 3 ) Enter the Target IP Address/Domain Name of the tested host. You can change the default test options if necessary. 131 Chapter 16 Manage Your Mesh Device 4 ) Click Start to begin the diagnostics, and you will find the test results in the gray box. 16 4 Update the Firmware TP-Link is dedicated to improving product features, giving you a better network experience. We will inform you through the web management page if there’s any update firmware available for your mesh device. The latest firmware can also be downloaded from the Support page of our website www.tp-link.com for free. Note: 1. Make sure that you have a stable connection between the mesh device and your computer. It is NOT recommended to upgrade the firmware wirelessly. 2. Back up your mesh device configuration before upgrading the firmware. 3. DO NOT turn off the mesh device during the firmware upgrade. ¾Follow the steps below to upgrade the firmware online: 1. Click Check for Upgrades. 2. If a new firmware is displayed, click Upgrade and click Yes when prompted, then the mesh device will automatically download the latest firmware file and upgrade. ¾Follow the steps below to manually update the firmware: 1. Download the latest firmware file for the mesh device from our website www.tp-link. com. 2. Visit http://tplinkwifi.net or http://192.168.88.1, and log in with the password you set for the mesh device. 3. Go to Advanced > System Tools > Firmware Upgrade. 4. Focus on the Device Information section. Make sure the downloaded firmware file matches with the Hardware Version. 5. Focus on the Local Upgrade section. Click Browse to locate the downloaded new firmware file, and click Upgrade. 132 Chapter 16 Manage Your Mesh Device 6. Wait a few minutes for the upgrading and rebooting. 16 5 Back Up and Restore Configuration Settings The configuration settings are stored as a config…

Text truncated - open the document above for the full version.

012423-17 rev2 TP-Link Corporation Limited Certification Application Attestation Statements Date: March 1, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 T o Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______ TP-Link Corporation Limited______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______ TP-Link Corporation Limited______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ■- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: _________________________ Sarah Wang (Signature 2 ) (Print name) Title: __ Regulatory Compliance Manager __ Company: __ TP-Link Corporation Limited_ Telephone: ___ 00852-37585053 ______ 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that the device does not support channel 12 ~ 13 in 2.4GHz band, any non-US channels in all the operational mode(s) for the following product. Product: AX3000 Whole Home Mesh Wi-Fi AP FCC ID: 2AXJ4HX510V2 Model: HX510 Brand: tp-link Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-12-18

TP-LinkCorporationLimited 050222-17 AuthoritytoActasAgent Date:April24,2023 AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch,VA22046 ToWhomItMayConcern: ULVerificationServices(Guangzhou)Co.,Ltd,SongShanLakeBranch__isauthorizedtoactonour behalf,untilotherwisenotified,forapplicationstoAmericanCertificationBody,Inc.(ACB). Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludesFCCbenefits,pursuantto Section5301oftheAnti-DrugAbuseActof1988,21U.S.C.862.Further,noparty,asdefinedin47 CFR1.2002(b),totheapplicationissubjecttodenialoffederalbenefits,thatincludesFCCbenefits. WealsodeclarethattheinformationprovidedtotheFCCistrueandcorrecttothebestofour knowledge(47CFR2.911(d))andwehavebeeninformedofthegranteeresponsibilities(47CFR 2.909)withregardtocertifiedequipment. Thankyou, AgencyAgreementExpirationDate:____4 /24/2024 By:_____________________________________SarahWang_____________ (Signature 1 )(Printname) Title:__________LeadofProductCertificationTeam________________ Onbehalfof:_________TP-LinkCorporationLimited._________________________________ (CompanyName) Telephone:_______________+8675526615494___________________ 1 -MustbesignedbyapplicantcontactgivenforapplicantontheFCCsite,orbytheauthorizedagentifanappropriateauthorizedagent letterhasbeenprovided.Lettersshouldbeplacedonappropriateletterhead.

TP-Link Corporation Limited. 050222-17 Request for Confidentiality Date: December 26, 2023 Subject: Confidentiality Request for: ___ 2AXJ4HX510V2 _____ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term --------------------------- External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term --------------------------- Test Setup Photos ☐ Short Term ☐ Permanent * 1 User’s Manual TP-Link Corporation Limited.has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __ (specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as sho…
