2AXJ4BE95BE33000 Whole Home Mesh Wi-Fi 7 System

Deco BE95 The Ultimate 10 Gbps Connectivity User Guide BE33000 Whole Home Mesh Wi-Fi 7 System 1910013354 REV1.0.0 © 2023 TP-Link Contents About This Guide ····················································1 Appearance ·······························································2 Set Up Your Deco ···················································3 Troubleshooting ······················································8 Authentication ··························································9 1 About This Guide This guide provides a brief introduction to BE33000 Whole Home Mesh Wi-Fi 7 System and regulatory information. Features available in Deco may vary by model and software version. Deco availability may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Deco experience. Conventions In this guide, the following conventions are used: Convention Description Deco Stands for Deco Whole Home Mesh Wi-Fi System/ Unit. Underline Hyperlinks are in teal and underlined. You can click to redirect to a website or a specific section. Teal Key information appears in teal, including management page text such as menus, items, buttons and so on. Note: Ignoring this type of note might result in a malfunction or damage to the device. Tips: Indicates important information that helps you make better use of your device. More Info • Specific product information can be found on the product page at https://www.tp-link.com. • A Technical Community is provided for you to discuss our products at https://community.tp-link.com. • Our Technical Support contact information can be found at the Help center of the Deco app and the Contact Technical Support page at https://www.tp-link.com/support. Speed/Coverage/Device Quantity Disclaimer Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location. MU-MIMO Disclaimer Use of MU-MIMO requires clients to also support MU-MIMO. IoT Compatibility Disclaimer IoT compatibility refers only to smart devices that can be controlled via the Deco app. Other wireless devices can still connect to Deco for normal Wi-Fi use. Seamless Roaming Disclaimer Clients need to support 802.11k/v/r and may require additional set up. Performance may vary depending on the client device. HomeShield Disclaimer HomeShield includes the Free Basic Plan. Fees apply for the Pro Plan. Visit tp-link.com/homeshield for more information. 2 Appearance Each Deco has an LED that changes color according to its status, a WPS button, two 2.5 Gbps WAN/LAN ports, a 10 Gbps WAN/LAN port, a 10 Gbps RJ45/SFP+ WAN/LAN Combo port, a USB 3.0 port, a power slot, and a Reset button. See the explanation below: Tip: The product label can be found at the bottom of the product. Pulse Yellow: Deco is resetting. Solid Yellow: Deco is starting up. Pulse Blue: Deco is ready for setup. Solid Blue: Deco is setting up. Pulse Green: Deco is upgrading firmware. Solid Green: Deco is all set up and connected. Pulse Red: The satellite Deco is disconnected from the main Deco. Solid Red: Deco has an issue. For connecting Deco to your modem, the Ethernet outlet, or for other internet services. Press this WPS button, and immediately press the WPS button on your client device to start the WPS process. For connecting a USB storage device to Deco. For connecting Deco to your modem, the Ethernet outlet, or for other internet services. Use Deco’s Combo pair. The Combo pair includes an Ethernet port and an SFP+ port. Only one port in the pair can be used at a time. For connecting Deco to the power socket via the provided power adapter. 2× 2.5 Gbps WAN/LAN Ports WPS Button Power Slot Press for 1 second and release to reset Deco to factory default settings. The light changing from pulsing yellow to solid yellow indicated a successful reset. Reset Button 10 Gbps WAN/LAN Port 10 Gbps RJ45/SFP+ WAN/LAN Combo Port 1× USB 3.0 Port 3 Set Up Your Deco First let's start by setting up the Deco network. Get the TP-Link Deco app for iOS or Android, then follow the app to walk through the setup. 1. Get the Deco app Scan the QR code below or go to Google Play or the App Store to download the Deco app. Install the app on your Android or iOS smartphone or tablet. or 2. Log in or sign up with TP-Link ID Open the app and log in with your TP-Link ID. If you don’t have a TP-Link ID, create one first. Note: If you forgot your login password, tap Forgot Password?. The app will help you reset your password. 3. Select your Deco model Search for and select your Deco model. If you have more than one Deco model, tap the question below the search box to check how to maximize the overall network. 4 4. Plug in your Deco Power off your modem. Connect your Deco to the modem and power them both on. If you don't have a modem, connect your Deco directly to the Ethernet outlet. 5. Wait until Deco's LED pulses blue Wait until your Deco's LED pulses blue, then your phone/tablet will connect to the Deco's default Wi-Fi automatically. 6. Specify your Deco's location Select or custom a location for your Deco. The location will be used as the name of your Deco. 5 9. Create your MLO network Set a network name and a password. The MLO network enables Wi-Fi 7 clients to connect to multiple bands simultaneously. 8. Create your Wi-Fi network Set a network name and a password. These will be the name and password you use to connect your devices to Wi-Fi. 7. Connect your Deco to the internet Select the internet connection type and enter the information. If you are not sure, contact your internet service provider. 6 10. Keep your Deco up-to-date Set auto update time. This allows your Deco to a…

Text truncated - open the document above for the full version.

TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong 012423-17 rev2 Certification Application Attestation Statements Date: March 7, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) _____TP-Link Corporation Limited______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ____ TP-Link Corporation Limited_______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is /- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ____Sarah Wang__ (Signature 2 ) (Print name) Title: Compliance manager Company: TP-Link Corporation Limited_____ Telephone: +86 755 21534921 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

ConfidentialityRequestLetter FederalCommunicationsCommission AuthorizationandEvaluationDivision FCCID:2AXJ4BE95 ConfidentialityRequest PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequest confidentialtreatmentofinformationaccompanyingthisapplicationasoutlinedbelow: 1.BlockDiagram 2.Schematics 3.OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesemattersmightbeharmfultothe applicantandprovideunjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoRule0.457,disclosureofthisapplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthis application. Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2023-02-09

DeclarationofAuthorization We Name:TP-LinkCorporationLimited Address:Room901,9/F.,NewEastOceanCentre,9ScienceMuseumRoad,TsimShaTsui, Kowloon,Hongkong Declarethat: NameRepresentativeofagent:MarlinChen AgentCompanyname:MRTTechnology(Suzhou)Co.,Ltd Address:D8Building,YouxinIndustrialPark,No.2Tian'edangRd., WuzhongEconomicDevelopmentZone City:Suzhou Country:China isauthorizedtoapplyforCertificationofthefollowingproduct(s): Product:BE33000WholeHomeMeshWi-Fi7System FCCID:2AXJ4BE95 Model:DecoBE95 Brand:tp-link Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2023-02-09

DeclarationofConformity We Name:TP-LinkCorporationLimited Address:Room901,9/F.,NewEastOceanCentre,9ScienceMuseumRoad,TsimShaTsui, Kowloon,Hongkong Declarethat: Product:BE33000WholeHomeMeshWi-Fi7System FCCID:2AXJ4BE95 Model:DecoBE95 Brand:tp-link ProductwhichbearstheaboveFCCIDisalsocompliantwiththeFCCrequirementsforsDOC. AndthesDOCprocedureshallbecarriedoutpriortomarketingthedeviceintheUS. Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2023-02-09

AttestationLetter FederalCommunicationsCommission AuthorizationandEvaluationDivision We Name:TP-LinkCorporationLimited Address:Room901,9/F.,NewEastOceanCentre,9ScienceMuseumRoad,TsimShaTsui, Kowloon,Hongkong Declarethatthedevicedoesnotsupportchannel12~13in2.4GHzbandandanynon-US channelsinalltheoperationalmode(s)forthefollowingproduct. Product:BE33000WholeHomeMeshWi-Fi7System FCCID:2AXJ4BE95 Model:DecoBE95 Brand:tp-link Sincerely, _________________ Name:SarahWang Position:RegulatoryComplianceManager Date:2023-02-09

Report No.: 2212RSU044-U1 1 of 5 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2212RSU044-U1 2 of 5 (3) EUT Photo (4) EUT Photo Report No.: 2212RSU044-U1 3 of 5 (5) EUT Photo (6) EUT Photo Report No.: 2212RSU044-U1 4 of 5 (7) EUT Photo (8) EUT Photo Report No.: 2212RSU044-U1 5 of 5 (9) EUT Photo

Label and Label Location

Report No.: 2212RSU044-UE 1 of 23 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2212RSU044-UE 2 of 23 (3) EUT Photo (4) EUT Photo Report No.: 2212RSU044-UE 3 of 23 (5) EUT Photo (6) EUT Photo Report No.: 2212RSU044-UE 4 of 23 (7) EUT Photo (8) EUT Photo Report No.: 2212RSU044-UE 5 of 23 (9) EUT Photo (10) EUT Photo Report No.: 2212RSU044-UE 6 of 23 (11) EUT Photo (12) EUT Photo Report No.: 2212RSU044-UE 7 of 23 (13) EUT Photo (14) EUT Photo Report No.: 2212RSU044-UE 8 of 23 (15) EUT Photo (16) EUT Photo Report No.: 2212RSU044-UE 9 of 23 (17) EUT Photo (18) EUT Photo Report No.: 2212RSU044-UE 10 of 23 (19) EUT Photo (20) EUT Photo Report No.: 2212RSU044-UE 11 of 23 (21) EUT Photo (22) EUT Photo Report No.: 2212RSU044-UE 12 of 23 (23) EUT Photo (24) EUT Photo Report No.: 2212RSU044-UE 13 of 23 (25) EUT Photo (26) EUT Photo Report No.: 2212RSU044-UE 14 of 23 (27) EUT Photo (28) EUT Photo Report No.: 2212RSU044-UE 15 of 23 (29) EUT Photo (30) EUT Photo Report No.: 2212RSU044-UE 16 of 23 (31) EUT Photo (32) EUT Photo Report No.: 2212RSU044-UE 17 of 23 (33) EUT Photo (34) EUT Photo Report No.: 2212RSU044-UE 18 of 23 (35) EUT Photo (36) EUT Photo Report No.: 2212RSU044-UE 19 of 23 (37) EUT Photo (38) EUT Photo Report No.: 2212RSU044-UE 20 of 23 (39) EUT Photo (40) EUT Photo Report No.: 2212RSU044-UE 21 of 23 (41) EUT Photo (42) EUT Photo Report No.: 2212RSU044-UE 22 of 23 (43) EUT Photo (44) EUT Photo Report No.: 2212RSU044-UE 23 of 23 (45) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2212RSU044-U3 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2023-03-20 Template Version:0.0 1 of 10 RF Exposure Evaluation Declaration FCC ID: 2AXJ4BE95 Applicant: TP-Link Corporation Limited Product: BE33000 Whole Home Mesh Wi-Fi 7 System Model No.: Deco BE95 Brand Name: tp-link FCC Classification: Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): FCC Part 2.1091 Received Date: 2023-03-14 Result: Complies Reviewed By: Kevin Guo Approved By: Robin Wu The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2212RSU044-U3 2 of 11 Revision History Report No. Version Description Issue Date Note 2212RSU044-U3 V01 Initial Report 2023-03-20 Valid Report No.: 2212RSU044-U3 3 of 11 CONTENTS Description Page 1. General Information ................................................................................................................................ 4 1.1. Applicant ........................................................................................................................................ 4 1.2. Manufacturer ................................................................................................................................. 4 1.3. Testing Facility ............................................................................................................................... 4 1.4. Product Information ....................................................................................................................... 5 1.5. Antenna Details ............................................................................................................................. 5 1.6. Device Classification ..................................................................................................................... 5 1.7. Applied Standards ......................................................................................................................... 6 2. RF Exposure Evaluation ......................................................................................................................... 7 2.1. Test Limits ..................................................................................................................................... 7 2.2. MPE Exemptions ........................................................................................................................... 8 2.3. Calculated Result ......................................................................................................................... 11 Report No.: 2212RSU044-U3 4 of 11 1. General Information 1.1. Applicant TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong 1.2. Manufacturer TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025 G-20034 C-20020 T-20020 R-20141 G-20134 C-20103 T-20104 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: L3261-190725 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2212RSU044-U3 5 of 11 1.4. Product Information Product Name BE33000 Whole Home Mesh Wi-Fi 7 System Model No. Deco BE95 Wi-Fi Specification 802.11a/b/g/n/ac/ax/be Antenna Information Refer to selection 1.5 Working Voltage By Adapter Accessory Adapter Model: T150500-2-DT INPYUT: 100-240~50/60Hz 2.0A OUTPUT: DC15.0V, 5.0A Note: The information of EUT was provided by the manufacturer, and the accuracy of the information shall be the responsibility of the manufacturer. 1.5. Antenna Details Antenna Type Frequency Band (MHz) T X Paths Number of spatial streams Antenna Gain (dBi) CDD Directional Gain (dBi) Ant 0 Ant 1 Ant 2 Ant 3 For Power For PSD Dipole Antenna 2412 ~ 2462 4 1 1.90 1.90 1.96 1.95 1.96 7.98 5150 ~ 5250 5725 ~ 5850 4 1 2.59 2.63 2.83 2.97 2.97 8.99 Remark: 1. The EUT supports Cyclic Delay Diversity (CDD) mode, and CDD signals are correlated. Directional gain = Max. G ANT + Array Gain, where Array Gain is as follows. • For power spectral density (PSD) measurements on all devices, Array Gain = 10 log (N ANT / N SS ) dB; • For power measurements on IEEE 802.11 devices, Array Gain = 0 dB for N ANT ≤ 4; 2. The information as above is from the antenna specifications. 1.6. Device Classification According to the user manual, the antenna of this device is at least 20cm away from the body of the user, this device is classified as a Mobile Device. So, the RF exposure evaluation requirements of § 2.1091 for mobile device exposure conditions subject to MPE limits. Report No.: 2212RSU044-U3 6 of 11 1.7. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⚫ FCC Part 2.1091 & KDB 447498 D04 Interim General RF Exposure Guidance v01 Report No.: 2212RSU044-U3 7 of 11 2. RF Exposure Evalu…

Text truncated - open the document above for the full version.

Report No.: 2212RSU044-U1 43 of 196 802.11n-HT20 - AVGPSD - Ant 2 Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) 802.11n-HT40 - AVGPSD - Ant 2 Channel 03 (2422MHz) Channel 06 (2437MHz) Channel 09 (2452MHz) Report No.: 2212RSU044-U1 44 of 196 802.11ax-HE20 - AVGPSD - Ant 2 Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) 802.11ax-HE40 - AVGPSD - Ant 2 Channel 03 (2422MHz) Channel 06 (2437MHz) Channel 09 (2452MHz) Report No.: 2212RSU044-U1 45 of 196 802.11b - AVGPSD - Ant 3 Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) 802.11g - AVGPSD - Ant 3 Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) Report No.: 2212RSU044-U1 46 of 196 802.11n-HT20 - AVGPSD - Ant 3 Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) 802.11n-HT40 - AVGPSD - Ant 3 Channel 03 (2422MHz) Channel 06 (2437MHz) Channel 09 (2452MHz) Report No.: 2212RSU044-U1 47 of 196 802.11ax-HE20 - AVGPSD - Ant 3 Channel 01 (2412MHz) Channel 06 (2437MHz) Channel 11 (2462MHz) 802.11ax-HE40 - AVGPSD - Ant 3 Channel 03 (2422MHz) Channel 06 (2437MHz) Channel 09 (2452MHz) Report No.: 2212RSU044-U1 48 of 196 A.5 Conducted Band Edge and Out-of-Band Emissions Test Result Test Site WZ-SR5 Test Engineer Jeff Yang Test Date 2023-02-01~2023-02-02 Test Mode Data Rate / MCS Channel No. Frequency (MHz) Limit 11b 1Mbps 01 2412 30dBc 11b 1Mbps 06 2437 30dBc 11b 1Mbps 11 2462 30dBc 11g 6Mbps 01 2412 30dBc 11g 6Mbps 06 2437 30dBc 11g 6Mbps 11 2462 30dBc 11n-HT20 MCS0 01 2412 30dBc 11n-HT20 MCS0 06 2437 30dBc 11n-HT20 MCS0 11 2462 30dBc 11n-HT40 MCS0 03 2422 30dBc 11n-HT40 MCS0 06 2437 30dBc 11n-HT40 MCS0 09 2452 30dBc 11ax-HE20 MCS0 01 2412 30dBc 11ax-HE20 MCS0 06 2437 30dBc 11ax-HE20 MCS0 11 2462 30dBc 11ax-HE40 MCS0 03 2422 30dBc 11ax-HE40 MCS0 06 2437 30dBc 11ax-HE40 MCS0 09 2452 30dBc Report No.: 2212RSU044-U1 49 of 196 802.11b Out-of-Band Emissions – Ant 0 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 50 of 196 802.11b Out-of-Band Emissions – Ant 0 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 51 of 196 802.11g Out-of-Band Emissions – Ant 0 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 52 of 196 802.11g Out-of-Band Emissions – Ant 0 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 53 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 0 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 54 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 0 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 55 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 0 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 56 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 0 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 57 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 0 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 58 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 0 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission

Report No.: 2212RSU044-U1 59 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 0 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 60 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 0 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 61 of 196 802.11b Out-of-Band Emissions – Ant 1 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 62 of 196 802.11b Out-of-Band Emissions – Ant 1 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 63 of 196 802.11g Out-of-Band Emissions – Ant 1 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 64 of 196 802.11g Out-of-Band Emissions – Ant 1 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 65 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 1 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 66 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 1 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 67 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 1 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 68 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 1 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 69 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 1 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 70 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 1 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 71 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 1 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 72 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 1 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 73 of 196 802.11b Out-of-Band Emissions – Ant 2 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 74 of 196 802.11b Out-of-Band Emissions – Ant 2 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 75 of 196 802.11g Out-of-Band Emissions – Ant 2 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission

Report No.: 2212RSU044-U1 76 of 196 802.11g Out-of-Band Emissions – Ant 2 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 77 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 2 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 78 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 2 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 79 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 2 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 80 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 2 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 81 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 2 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 82 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 2 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 83 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 2 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 84 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 2 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 85 of 196 802.11b Out-of-Band Emissions – Ant 3 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 86 of 196 802.11b Out-of-Band Emissions – Ant 3 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 87 of 196 802.11g Out-of-Band Emissions – Ant 3 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 88 of 196 802.11g Out-of-Band Emissions – Ant 3 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 89 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 3 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 90 of 196 802.11n-HT20 Out-of-Band Emissions – Ant 3 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 91 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 3 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 92 of 196 802.11n-HT40 Out-of-Band Emissions – Ant 3 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission

Report No.: 2212RSU044-U1 93 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 3 Channel 01 (2412MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 94 of 196 802.11ax-HE20 Out-of-Band Emissions – Ant 3 Channel 11 (2462MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 95 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 3 Channel 03 (2422MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437MHz) Reference Level Spurious Emission Report No.: 2212RSU044-U1 96 of 196 802.11ax-HE40 Out-of-Band Emissions – Ant 3 Channel 09 (2452MHz) Reference Level High Band Edge Spurious Emission Report No.: 2212RSU044-U1 97 of 196 A.6 Radiated Spurious Emission Test Result Test Site WZ-AC1 Test Engineer Charles Zhang Test Date 2023-01-19 Test Mode: 802.11b Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20dB below limit line within 1-18GHz, there is not show in the report. Test Channel Frequency (MHz) Reading Level (dBμV) Factor (dB/m) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detect or Polarizatio n 01 4825.000 37.7 2.8 40.5 74.0 -33.5 Peak Horizontal 8284.500 40.2 8.3 48.5 74.0 -25.5 Peak Horizontal 10936.500 36.5 13.6 50.1 74.0 -23.9 Peak Horizontal 4782.500 39.0 2.7 41.7 74.0 -32.3 Peak Vertical 8284.500 40.2 8.3 48.5 74.0 -25.5 Peak Vertical 10936.500 36.5 13.6 50.1 74.0 -23.9 Peak Vertical 06 4876.000 39.9 2.8 42.7 74.0 -31.3 Peak Horizontal 8284.500 41.7 8.3 50.0 74.0 -24.0 Peak Horizontal 11540.000 36.9 12.9 49.8 74.0 -24.2 Peak Horizontal 4876.000 41.7 2.8 44.5 74.0 -29.5 Peak Vertical 7451.500 37.0 8.2 45.2 74.0 -28.8 Peak Vertical 11327.500 37.1 12.7 49.8 74.0 -24.2 Peak Vertical 11 4927.000 38.9 2.9 41.8 74.0 -32.2 Peak Horizontal 8284.500 40.6 8.3 48.9 74.0 -25.1 Peak Horizontal 10817.500 36.0 13.3 49.3 74.0 -24.7 Peak Horizontal 4927.000 39.1 2.9 42.0 74.0 -32.0 Peak Vertical 8284.500 40.7 8.3 49.0 74.0 -25.0 Peak Vertical 12228.500 38.7 12.0 50.7 74.0 -23.3 Peak Vertical Note: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB/m) Factor (dB/m) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: 2212RSU044-U1 98 of 196 Test Site WZ-AC1 Test Engineer Charles Zhang Test Date 2023-01-19 Test Mode: 802.11g Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20dB below limit line within 1-18G…
