2AXJ4C100V4Home Security Wi-Fi Camera

User Guide Home Security Wi-Fi Camera Tapo C100 © 2021 TP-Link 1910013029 REV2.0.0 Contents About This Guide ····················································1 Introduction ·······························································2 Appearance ·······························································3 Set Up Your Camera ··············································4 Main Camera Controls ·········································6 Motion Detection ····················································8 24-hour Recordings ············································12 Privacy Mode ··························································14 Authentication ························································15 1 About This Guide This guide provides a brief introduction to the Home Security Wi-Fi Camera and the Tapo app, as well as regulatory information. Please note that features available of the Tapo smart camera may vary by model and software version. The availability may also vary by region. All images, steps, and descriptions in this guide are only examples and may not reflect your actual experience. Conventions In this guide, the following convention is used: Convention Description Blue Key information appears in teal, including management page text such as menus, items, buttons and so on. Underline Hyperlinks are in teal and underlined. You can click to redirect to a website. Note: Ignoring this type of note might result in a malfunction or damage to the device. More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. • The setup video can be found at https://www.tp-link.com/support/setup-video/#cloud-cameras. 2 Introduction When you are away home, there are always something you care about. Tapo C100 helps you receive a notification whenever your camera detects movement and check it in detail through the Tapo app. Also, you can personalize your security by setting motion detection zones to only notify you of what happens in areas that you choose. • 1080p High-Definition – Provides greater sharpness and clarity. • Night Vision – Provides a visual distance of up to 30 ft in total darkness. • Live View – Always keep an eye on what matters most to you—anytime, anywhere. • Two-Way Audio – Communicate in real time through a built-in microphone and speaker. • Alarm System – Triggers lights and sounds as an alarm when motion is detected. • Privacy Mode - Temporarily shut down surveillance with a tap in the app. • Sharing - Share interesting and funny videos to everyone on social media. • Easy Setup - Follow in-app instructions to easily set up within minutes. • Local Storage – Store up to 128 GB of video on a microSD card † , equal to 384 hours (16 days) of footage △ . † The SD card is not provided. △ The data comes from TP-Link laboratory. 3 Appearance The Home Security Wi-Fi Camera has a system LED that changes color according to its status, an alert light, lens, microphone, DC power port, RESET button and a microSD card slot. Refer below for details. microSD Card Slot Insert a microSD card and initialize it on the app for local recording. System LED • Solid red: Starting up • Blinking red and green: Ready for setup • Blinking red slowly: Connecting to Wi-Fi • Solid amber: Connected to Wi-Fi • Solid green: Connected to TP-Link Cloud server • Blinking red quickly: Camera resetting • Blinking green quickly: Camera updating RESET Button Press and hold for at least 5 seconds until the LED blinks red to reset your camera. Alert Light Blinks to alert you when the activity detected. DC Power Port Connect the power cord provided. Lens Microphone Built-in internal microphone. Note: Do NOT insert objects into the hole. 4 Set Up Your Camera Follow the steps below to get started with your new camera. Step 1. Download App Get the Tapo app from the App Store or Google Play, or by scanning the QR code below. OR Step 2. Log In Open the app, and log in with your TP-Link ID. If you don't have an account, create one first. Step 3. Add Your Camera Tap the button in the app and select your model. 5 Step 4. Configure Camera Follow app instructions to configure your camera and add it to your home network. Step 5. Place Camera Place your camera on a flat surface, or install it on a wall or ceiling with the provided mounting screws. 1. Mark Position Place the mounting template where you want the camera. For wall mounting, drill two holes through two circles. 2. Mount Base Affix two mounting screws with the help of mounting template. For wall mounting, insert two anchors into holes and screw the screws into the anchors. 3. Secure Camera Hang your camera on the screws. 6 Home Page This page lists all your cameras you've added and you can view them directly and manage them easily. Tap the camera or go to Camera Preview > Manage to enter the Live View page. Main Camera Controls After you successfully set up the camera, you will see your camera listed on the home page. You can view and manage your camera from anywhere at any time with the Tapo app. Live View Tap Talk or Voice Call to communicate with loved ones, turn on Alarm to get noticed when motion detected, enable the Privacy Mode to temporarily shut down the surveillance for privacy, or go to Playback & Memory to check all recordings and saved moments. Multi-Screen View live videos from multiple cameras at the same time Screenshot Full Screen Volume Record Camera Settings Day/Night Mode 7 Camera Settings On Live View page, tap to enter the Camera Settings page. You can change the settings of your camera to meet various needs, such as change your camera name, customize detection settings and recording schedules, turn on or off notifications, set activity zones, etc. Me On this page, you can edit your account, quickly check the memorable moments you saved, or find the FAQs of using smart camera and basic info related to t…

Text truncated - open the document above for the full version.

Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. Product: Home Security Wi-Fi Camera FCC ID: 2AXJ4C100V4 Model: Tapo C100 Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2022-07-13

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2AXJ4C100V4 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2022-07-13

Declaration of Authorization We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Home Security Wi-Fi Camera FCC ID: 2AXJ4C100V4 Model: Tapo C100 Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2022-07-13

Declaration of Conformity We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Product: Home Security Wi-Fi Camera FCC ID: 2AXJ4C100V4 Model: Tapo C100 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2022-07-13

Report No.: 2206TW0112-U1~U2 Product: Home Security Wi-Fi Camera Brand Name: tp-link Model Number: Tapo C100 1 of 7 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2206TW0112-U1~U2 2 of 7 (3) EUT Photo (4) EUT Photo Report No.: 2206TW0112-U1~U2 3 of 7 (5) EUT Photo (6) EUT Photo Report No.: 2206TW0112-U1~U2 4 of 7 (7) EUT Photo (8) EUT Photo_Adapter Report No.: 2206TW0112-U1~U2 5 of 7 (9) EUT Photo_Adapter (10) EUT Photo_Adapter Report No.: 2206TW0112-U1~U2 6 of 7 (11) EUT Photo_Adapter (12) EUT Photo_Adapter Report No.: 2206TW0112-U1~U2 7 of 7 (13) EUT Photo_Adapter (14) EUT Photo_Adapter

Report No.: 2206TW0112-U1~U2 Product: Home Security Wi-Fi Camera Brand Name: tp-link Model Number: Tapo C100 1 of 5 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2206TW0112-U1~U2 2 of 5 (3) EUT Photo (4) EUT Photo Report No.: 2206TW0112-U1~U2 3 of 5 (5) EUT Photo (6) EUT Photo Report No.: 2206TW0112-U1~U2 4 of 5 (7) EUT Photo (8) EUT Photo Report No.: 2206TW0112-U1~U2 5 of 5 (9) EUT Photo

MRT Technology (Taiwan) Co., Ltd Report No.: 2206TW0112-U2 Phone: +886-3-3288388 Report Version 1.0 Web: www.mrt-cert.com Issue Date: 2021-07-15 FCC ID: 2AXJ4C100V4 Page Number: 1 of 13 RF Exposure Evaluation Declaration FCC ID : 2AXJ4C100V4 Applicant : TP-Link Corporation Limited Application Type : Certification Product : Home Security Wi-Fi Camera Model No. : Tapo C100 Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : FCC Part 2.1091 Received Date : June 17 ,2022 Test By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2206TW0112-U2 FCC ID: 2AXJ4C100V4 Page Number: 2 of 13 Revision History Report No. Version Description Issue Date Note 2206TW0112-U2 1.0 Original Report 2022-07-15 Valid Report No.: 2206TW0112-U2 FCC ID: 2AXJ4C100V4 Page Number: 3 of 13 CONTENTS Description Page 1. INTRODUCTION .................................................................................................................... 5 1.1. Scope .......................................................................................................................... 5 1.2. MRT Test Location ....................................................................................................... 5 2. PRODUCT INFORMATION .................................................................................................... 6 2.1. Feature of Equipment under Test ................................................................................. 6 2.2. Product Specification Subjective to this Report ............................................................ 6 2.3. Applied Standards ........................................................................................................ 6 3. RF Exposure Evaluation ...................................................................................................... 7 3.1. Limits ........................................................................................................................... 7 3.2. MPE Exemptions ......................................................................................................... 8 3.3. Test Result of RF Exposure Evaluation ....................................................................... 11 Appendix A : External Photograph ...........................................................................................12 Appendix B : Internal Photograph ............................................................................................13 Report No.: 2206TW0112-U2 FCC ID: 2AXJ4C100V4 Page Number: 4 of 13 General Information Applicant TP-Link Corporation Limited Applicant Address Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Manufacturer TP-Link Corporation Limited Manufacturer Address Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Test Site MRT Technology (Taiwan) Co., Ltd Test Site Address No. 38, Fuxing Second Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C) MRT FCC Registration No. 291082 Test Device Serial No. #1-1 Production Pre-Production Engineering Test Facility / Accreditations 1. MRT facility is a FCC registered (Reg. No. 291082) test facility with the site description report on file and is designated by the FCC as an Accredited Test Firm. 2. MRT facility is an IC registered (MRT Reg. No. 21723) test laboratory with the site description on file at Industry Canada. 3. MRT Lab is accredited to ISO 17025 by the Taiwan Accreditation Foundation (TAF Cert. No. 3261) in EMC, Telecommunications and Radio testing for FCC (Designation Number: TW3261), Industry Taiwan, EU and TELEC Rules. Report No.: 2206TW0112-U2 FCC ID: 2AXJ4C100V4 Page Number: 5 of 13 1. INTRODUCTION 1.1. Scope Measurement and determination of electromagnetic emissions (EMC) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission and the Innovation, Science and Economic Development Canada and Certification and Engineering Bureau. 1.2. MRT Test Location The map below shows the location of the MRT LABORATORY, its proximity to the Taoyuan City. These measurement tests were conducted at the MRT Technology (Taiwan) Co., Ltd. Facility located at No.38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 33377, Taiwan (R.O.C). Report No.: 2206TW0112-U2 FCC ID: 2AXJ4C100V4 Page Number: 6 of 13 2. PRODUCT INFORMATION 2.1. Feature of Equipment under Test 2.2. Product Specification Subjective to this Report 2.3. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⚫ FCC Part 2.1091 & KDB 447498 D04 Interim General RF Exposure Guidance v01 Product Name: Home Security Wi-Fi Camera Model No.: Tapo C100 Brand Name: tp-link Wi-Fi Specification: 802.11b/g/n Adapter BRAND: tp-link MODEL: T090060-2B1 INPUT: 100 - 240V ~ 50/60Hz 0.3A. OUTPUT: DC 9V 0.6A Frequency Range: 802.11b/g/n-HT20: 2412 ~ 2462MHz Channel Number: 802.11b/g/n-HT20: 11 Type of Modulation: 802.11b: DSSS 802.11g/n: OFDM Data Rate: 802.11b: 1/2/5.5/11Mbps 802.11g: 6/9/12/18/24/36/48/54Mbps 802.11n: up to 72.2Mbps Antenna Type: IFA Antenna Antenna Gain: 1.93dBi Report No.: 2206TW0112-U2 FCC ID: 2AXJ4C100V4 Page Number: 7 of 13 3. RF Exposure Evaluation 3.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits For Maximum Perm…

Text truncated - open the document above for the full version.

MRT Technology (Taiwan) Co., Ltd Report No.: 2206TW0112-U1 Phone: +886-3-3288388 Report Version: 1.0 Web: www.mrt-cert.com Issue Date: 2022-07-15 FCC ID: 2AXJ4C100V4 Page Number: 1 of 106 FCC ID : 2AXJ4C100V4 Applicant : TP-Link Corporation Limited Application Type : Certification Product : Home Security Wi-Fi Camera Model No. : Tapo C100 Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : Part15 Subpart C (Section 15.247) Received Date : June 17 ,2022 Test Date : June 22~28 ,2022 RF MEASUREMENT REPORT The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Tested By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) Report No.: 2206TW0112-U1 FCC ID: 2AXJ4C100V4 Page Number: 2 of 106 Revision History Report No. Version Description Issue Date Note 2206TW0112-U1 1.0 Original Report 2022-07-15 Valid Report No.: 2206TW0112-U1 FCC ID: 2AXJ4C100V4 Page Number: 3 of 106 CONTENTS Description Page 1. INTRODUCTION ...................................................................................................................... 6 1.1. Scope ............................................................................................................................. 6 1.2. MRT Test Location ......................................................................................................... 6 2. PRODUCT INFORMATION ...................................................................................................... 7 2.1. Feature of Equipment under Test ................................................................................... 7 2.2. Product Specification Subjective to this Report ............................................................... 7 2.3. Working Frequencies for this report ................................................................................ 7 2.4. Test Mode ....................................................................................................................... 8 2.5. Configuration of Test System .......................................................................................... 8 2.6. Test System Details ........................................................................................................ 8 2.7. Description of Test Software ........................................................................................... 8 2.8. Applied Standards .......................................................................................................... 9 2.9. Duty Cycle ...................................................................................................................... 9 2.10. EMI Suppression Device(s)/Modifications .................................................................. 10 2.11. Labeling Requirements .............................................................................................. 10 3. DESCRIPTION of TEST ......................................................................................................... 11 3.1. Evaluation Procedure .................................................................................................... 11 3.2. AC Line Conducted Emissions ....................................................................................... 11 3.3. Radiated Emissions ...................................................................................................... 12 4. ANTENNA REQUIREMENTS................................................................................................. 13 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................. 14 6. MEASUREMENT UNCERTAINTY ......................................................................................... 15 7. TEST RESULT ....................................................................................................................... 16 7.1. Summary ...................................................................................................................... 16 7.2. 6dB Bandwidth Measurement ....................................................................................... 17 7.2.1. Test Limit ................................................................................................................... 17 7.2.2. Test Procedure used.................................................................................................. 17 7.2.3. Test Setting ............................................................................................................... 17 7.2.4. Test Setup ................................................................................................................. 17 7.2.5. Test Result ................................................................................................................ 18 7.3. Output Power Measurement ......................................................................................... 21 7.3.1. Test Limit ................................................................................................................... 21 7.3.2. Test Procedure Used ................................................................................................. 21 Report No.: 2206TW0112-U1 FCC ID: 2AXJ4C100V4 Page Number: 4 of 106 7.3.3. Test Setting ............................................................................................................... 21 7.3.4. Test Setup ................................................................................................................. 21 7.3.5. Test Result ..…

Text truncated - open the document above for the full version.

Product Number: Product Name: Antenna Product Number: Product Name: Antenna COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2011 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com Product Number: Product Name: Antenna Specification For Approval Date: 2019.08.19 File No. : Version: 1.0 Customer: / Customer P/N : / TP-LINK P/N: Description: Antenna|2.4-2.5GHz|1.93dBi TP-LINK Checked By: Customer Approved By: TP-LINK TECHNOLOGIES CO., LTD. South Buiding, No.5 Keyuan Road, Central Zone, Science&Technology Park, Nanshan, Shenzhen, P.R.China TEL: + 86 755 26612350 + 86 755 26504400 http:// www.tp-link.com Product Number: Product Name: Antenna Index I. Specification ..................................................................................................... 1 II. Characteristics and Reliability Test ................................................................ 1 III. Antenna – S Parameter Test Data ................................................................... 2 IV. Antenna – Radiation Pattern Test Data .......................................................... 2 Product Number: Product Name: Antenna Page 1 Version:1.0 Issue Date: I. Specification Sample Photo A. Electrical Characteristics Frequency 2400~2500MHz Impedance 50 Ohm S.W.R. <= 2.0 Antenna Type IFA Antenna Gain [email protected]; Max Input Power Polarization Linear Radiation pattern Omni-Directional II. Characteristics and Reliability Test Test Items Test Condition and Procedure Requirements C1 S.W.R. Set DUT on Network Analyzer; make individual calibration to test Directive DUT specification C2 Antenna Gain Set DUT on Antenna Chamber; make individual calibration to test Directive DUT specification M4 Solderability MIL-STD-202G, 210F, cond. A Solder iron: 350+- 10°C； Duration: 5 seconds 1. Mounted on PCB 2. No Visual Damage M7 Dimension Inspection of dimension, color, material, package, surface process Directive DUT specification Product Number: Product Name: Antenna Page 2 Version:1.0 Issue Date: III. Antenna – S Parameter Test Data IV. Antenna – Radiation Pattern Test Data Testing Equipment Specification Microwave Chamber Satimo SG24-S Testing Equipment Agilent 5071B Freq.(MHz) 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 Peak Gain(dBi) 1.42 1.50 1.55 1.73 1.84 1.75 1.93 1.83 1.73 1.66 1.57 Product Number: Product Name: Antenna Page 3 Version:1.0 Issue Date:

Report No.: 2206TW0112-U1~U2 Product: Home Security Wi-Fi Camera Brand Name: tp-link Model Number: Tapo C100 1 of 3 Test Photograph Description: Front View of Conducted Emission Test Setup Description: Back View of Conducted Emission Test Setup Report No.: 2206TW0112-U1~U2 2 of 3 Description: Radiated Emission Test Setup for below 1GHz Description: Radiated Emission Test Setup for above 1GHz Report No.: 2206TW0112-U1~U2 3 of 3 Description: Conducted Test Setup
