2AXJ4C320WSV2Outdoor Security Wi-Fi Camera

User Guide Outdoor Security Wi-Fi Camera Tapo C320WS ©2021 TP-Link 1910013021 REV1.0.0 Contents About This Guide ···········································································1 Introduction ······················································································2 Appearance ······················································································3 Set Up Your Camera ·····································································5 Quick Setup: Amazon Frustration-Free Setup ··············7 Install Waterproof Items ··························································11 Main Camera Controls ·····························································12 Motion Detection ········································································14 24-hour Recordings ··································································18 Privacy Mode ················································································20 Authentication ··············································································21 1 About This Guide This guide provides a brief introduction to the Outdoor Security Wi-Fi Camera and the Tapo app, as well as regulatory information. Please note that features available in Tapo may vary by model and software version. Tapo availability may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Tapo Camera experience. Conventions In this guide, the following convention is used: Convention Description Blue Key information appears in teal, including management page text such as menus, items, buttons and so on. Underline Hyperlinks are in teal and underlined. You can click to redirect to a website. Note: Ignoring this type of note might result in a malfunction or damage to the device. More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. • The setup video and waterproof cable attachments video can be found at https://www.tp-link.com/support/setup-video/. 2 Introduction Tapo C320WS is a full-featured weatherproof security camera that you can access from anywhere. Receive instant notifications and check feeds when the motion is detected. Moreover, the automatic siren system will trigger light and sound to frighten away unwanted visitors after the camera detects motion. Day or night, rain or shine, the Tapo camera protects what you love most. • 3MP High Definition – Delivers high resolution video helping you never miss a detail. • Wired or Wireless Networking – Connect the camera to your network through Ethernet or Wi-Fi for more flexible installation. • Weatherproof – Helps Tapo C320WS perform well even in harsh environments with rain and dust. • Night Vision – Provides a visual distance of up to 98 ft (30m) even in total darkness to always keep you safe. • Two-Way Audio – Communicate with others with the built-in microphone and speaker. • Local Storage (up to 256 GB) – Stores 3MP video directly to a local microSD card, offering convenient access to your video footage. *microSD card needs to be purchased separately. 3 Appearance MicroSD Card Slot Hold for 5 seconds to reset the camera Speaker RESET MIC DC Power Connector Used to connect to a 9V DC power adapter Ethernet Port Used to connect to a network device System LED Insert a microSD card for local recording IR LED White Light LED Front PanelBottom Panel 4 System LED Description Blinking red and green Blinking red slowly Solid amber Blinking red quickly Solid red Solid green Blinking green quickly Starting up Connected to TP-Link Cloud server Ready for setup Connecting to Wi-Fi Connected to Wi-Fi Camera resetting Camera updating 5 Set Up Your Camera Follow the steps below to get started with your new camera, or you can follow the setup video at https://www.tp-link.com/support/setup-video/. Step 1. Download Tapo App Get the Tapo app from the Apple App Store or Google Play, or by scanning the QR code below. OR Step 2. Log In Open the app, and log in with your TP-Link ID. If you don't have an account, create one first. Step 3. Add Your Camera Tap the button in the app and select your model. 6 Step 4. Configure Camera Follow app instructions to set up your camera via wired or wireless connection, and add it to your home network. Step 5. Place Camera Place your camera on a flat surface, or install it on a wall or ceiling with the provided mounting template and screws. 1. Drill Holes Stick the mounting template to the desired mounting place. Drill 3 screw holes according to the template. 2. Mount Camera Insert three anchors into the holes and use the screws to affix the camera over the anchors. 0° to 70° 0° to 360° 7 Home Page This page lists all your cameras you've added and you can view them directly and manage them easily. Tap the camera or go to Camera Preview > Manage to enter the Live View page. Main Camera Controls After you successfully set up the camera, you will see your camera listed on the home page. You can view and manage your camera from anywhere at any time with the Tapo app. Live View Talk or Voice Call: Communicate with loved ones Privacy Mode: Enable to temporarily shut down the surveillance for privacy Alarm On/Off: Turn on to get noticed when motion detected Playback & Memory: Check all recordings and saved moments 8 Camera Settings On Live View page, tap to enter the Camera Settings page. You can change the settings of your camera to meet various needs, such as change your camera name, customize detection settings and recording schedules, turn on or off notifications, set activity zones, etc. Me On this page, you can edit your account, quickly check the memorable moments you saved, or find the FAQs of using smart camera and basic info related to the Tapo app. 9 1. Go to Camera Settings page and tap Detection & Alerts to customize its current de…

Text truncated - open the document above for the full version.

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2AXJ4C320WSV2 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2022-12-30

Declaration of Authorization We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Outdoor Security Wi-Fi Camera FCC ID: 2AXJ4C320WSV2 Model: Tapo C320WS Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2022-12-30

Report No.: 2211TW0104-U1~U2 Product: Outdoor Security Wi- Fi Camera Brand Name: tp-link Model Number: Tapo C320WS 1 of 8 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2211TW0104-U1~U2 2 of 8 (3) EUT Photo (4) EUT Photo Report No.: 2211TW0104-U1~U2 3 of 8 (5) EUT Photo (6) EUT Photo Report No.: 2211TW0104-U1~U2 4 of 8 (7) EUT Photo (8) EUT Photo Report No.: 2211TW0104-U1~U2 5 of 8 (9) Adapter Photo (10) Adapter Photo Report No.: 2211TW0104-U1~U2 6 of 8 (11) Adapter Photo (12) Adapter Photo Report No.: 2211TW0104-U1~U2 7 of 8 (13) Adapter Photo (14) Adapter Photo Report No.: 2211TW0104-U1~U2 8 of 8 (15) Adapter Photo (16) Adapter Photo

效果图 后视图 菲林图 尺寸图 LOGO与产品中心线居中对齐 M AC : X X-X X-X X-X X-X X-X X S/N:XXXXXXXXXXXXX US/2.6 Outdoor Security Wi-Fi Camera Model: Tapo C320WS Power: 9V 0.6A RoHSIP66 FCC ID: 2AXJ4C320WSV2 IC: 26583-C320WSV2 HVIN: Tapo C320WSV2

Report No.: 2211TW0104-U1~U2 Product: Outdoor Security Wi- Fi Camera Brand Name: tp-link Model Number: Tapo C320WS 1 of 6 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2211TW0104-U1~U2 2 of 6 (3) EUT Photo (4) EUT Photo Report No.: 2211TW0104-U1~U2 3 of 6 (5) EUT Photo (6) EUT Photo Report No.: 2211TW0104-U1~U2 4 of 6 (7) EUT Photo (8) EUT Photo Report No.: 2211TW0104-U1~U2 5 of 6 (9) EUT Photo (10) EUT Photo Report No.: 2211TW0104-U1~U2 6 of 6 (11) EUT Photo (12) EUT Photo

MRT Technology (Taiwan) Co., Ltd Report No.: 2211TW0104-U2 Phone: +886-3-3288388 Report Version 1.0 Web: www.mrt-cert.com Issue Date: 2023-01-10 Page Number: 1 of 11 RF Exposure Evaluation Declaration FCC ID : 2AXJ4C320WSV2 Applicant : TP-Link Corporation Limited Application Type : Certification Product : Outdoor Security Wi-Fi Camera Model No. : Tapo C320WS Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : FCC Part 2.1091 Result : Complies Test By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2211TW0104-U2 Page Number: 2 of 11 Revision History Report No. Version Description Issue Date Note 2211TW0104-U2 1.0 Original Report 2023-01-10 Valid Report No.: 2211TW0104-U2 Page Number: 3 of 11 CONTENTS Description Page 1. General Information ............................................................................................................... 4 2. INTRODUCTION ...................................................................................................................... 5 2.1. Scope............................................................................................................................. 5 2.2. MRT Test Location ......................................................................................................... 5 3. PRODUCT INFORMATION ...................................................................................................... 6 3.1. Feature of Equipment under Test ................................................................................... 6 3.2. Description of Available Antennas .................................................................................. 6 3.3. Applied Standards .......................................................................................................... 6 4. RF Exposure Evaluation ........................................................................................................ 7 4.1. Limits ............................................................................................................................. 7 4.2. MPE Exemptions ........................................................................................................... 8 4.3. Calculated Result ......................................................................................................... 11 Report No.: 2211TW0104-U2 Page Number: 4 of 11 1. General Information Applicant TP-Link Corporation Limited Applicant Address Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Manufacturer TP-Link Corporation Limited Manufacturer Address Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Test Site MRT Technology (Taiwan) Co., Ltd Test Site Address No. 38, Fuxing Second Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C) MRT FCC Registration No. 291082 Test Device Serial No. N/A Production Pre-Production Engineering Test Facility / Accreditations 1. MRT facility is a FCC registered (Reg. No. 291082) test facility with the site description report on file and is designated by the FCC as an Accredited Test Firm. 2. MRT facility is an IC registered (MRT Reg. No. 21723) test laboratory with the site description on file at Industry Canada. 3. MRT Lab is accredited to ISO 17025 by the Taiwan Accreditation Foundation (TAF Cert. No. 3261) in EMC, Telecommunications and Radio testing for FCC (Designation Number: TW3261), Industry Taiwan, EU and TELEC Rules. Report No.: 2211TW0104-U2 Page Number: 5 of 11 2. INTRODUCTION 2.1. Scope Measurement and determination of electromagnetic emissions (EMC) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission and the Innovation, Science and Economic Development Canada and Certification and Engineering Bureau. 2.2. MRT Test Location The map below shows the location of the MRT LABORATORY, its proximity to the Taoyuan City. These measurement tests were conducted at the MRT Technology (Taiwan) Co., Ltd. Facility located at No.38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 33377, Taiwan (R.O.C). Report No.: 2211TW0104-U2 Page Number: 6 of 11 3. PRODUCT INFORMATION 3.1. Feature of Equipment under Test Product Name: Outdoor Security Wi-Fi Camera Model No.: Tapo C320WS Brand Name: tp-link Wi-Fi Specification: 802.11b/g/n Adapter: BRAND: tp-link MODEL: T090060-2B1 INPUT: 100 - 240V ~ 50/60Hz 0.3A. OUTPUT: DC 9.0V 0.6A 3.2. Description of Available Antennas Antenna Type Frequency Band (MHz) T X Paths Max Antenna Gain (dBi) CDD Directional Gain (dBi) For Power For PSD Dipole Antenna 2412 ~ 2462 2 2.04 2.04 5.05 Note: 1. The EUT supports Cyclic Delay Diversity (CDD) mode, and CDD signals are correlated. If all antennas have the same gain, G ANT , Directional gain = G ANT + Array Gain, where Array Gain is as follows. • For power spectral density (PSD) measurements on all devices, Array Gain = 10 log (N ANT / N SS ) dB; • For power measurements on IEEE 802.11 devices, Array Gain = 0 dB for N ANT ≤ 4; 3.3. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⚫ FCC Part 2.1091 & KDB 447498 D04 Interim General RF Exposure Guidance v01 Report No.: 2211TW0104-U2 Page Number: 7 of 11 4. RF Exposure Evaluation 4.1. Limits According to FCC §1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as s…

Text truncated - open the document above for the full version.

Product Number: 3101503989 Product Name: Antenna Product Number: 3101503989 Product Name: Antenna COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2011 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com Product Number: 3101503989 Product Name: Antenna Specification For Approval Date: File No. : Version: 1.0 Customer: / Customer P/N : / TP-LINK P/N: 3101503989 Description: Antenna|2.4-2.5GHz|2.0dBi|LP|Omni|2W|Weld|100mm|D1.13mm|蓝 鲸-70|无|X1020-HW100REV7.2|TP白/PC/蚀纹|防水/IP66|[自制件/白 色PE外被同轴线/硅胶圈线径1.25mm/气密全检] TP-LINK Checked By: Customer Approved By: TP-LINK TECHNOLOGIES CO., LTD. South Buiding, No.5 Keyuan Road, Central Zone, Science&Technology Park, Nanshan, Shenzhen, P.R.China TEL: + 86 755 26612350 + 86 755 26504400 http:// www.tp-link.com Product Number: 3101503989 Product Name: Antenna Index I. Specification ..................................................................................................... 1 II. Characteristics and Reliability Test ................................................................ 1 III. Mechanical Drawing and Material Description .............................................. 3 IV. RoHS Test Report ............................................................................................ 4 V. Antenna – S Parameter Test Data ................................................................... 5 VI. Antenna – Radiation Pattern Test Data .......................................................... 5 VII. Packing Drawing .............................................................................................. 7 Product Number: 3101503989 Product Name: Antenna Page 1 Version:1.0 Issue Date: I. Specification Sample Photo A. Electrical Characteristics Frequency 2400 ~ 2500 MHz Impedance 50 Ohm S.W.R. <= 2.0 Antenna Type Dipole Antenna Gain 2.0dBi Max Input Power <= 2 W Polarization Linear Radiation pattern Omni-Directional B. Material & Mechanical Characteristics Material of Radiator PCB(CEM-1+Cu) Material of Plastic Body: PC Holder: PC Cable Type PE. 1.13mm (White) Connector Type Weld Connector Pull Test 3.0Kg C. Environmental Operation Temperature - 10°C ~ + 60°C Storage Temperature - 40°C ~ + 70°C II. Characteristics and Reliability Test Test Items Test Condition and Procedure Requirements C1 S.W.R. Set DUT on Network Analyzer; Directive DUT specification Product Number: 3101503989 Product Name: Antenna Page 2 Version:1.0 Issue Date: make individual calibration to test C2 Antenna Gain Set DUT on Antenna Chamber; make individual calibration to test Directive DUT specification M1 Vibration MIL-STD-202G, 201 A Amplitude: 0.03 inch (0.76mm); Freq: 10 to 55 Hz 3 directions; 2 hours for each direction 1. No Visual Damage 2.FrequencyTol.<=5% M2 Random Drop Height: 1.5 Meter; 3 directions; 1 time for each direction 1. No parts separated 2. Frequency Tol.<=5% M3 Drop Test Combine DUT with router； Height: 0.6 Meter; 1 direction; 3 times for the direction 1. No parts separated 2. Frequency Tol.<=5% M4 Terminal- Pull Test MIL-STD-202G, 211A, cond. A Holding with individual specification; force applied to axis of terminal 1. Directive DUT specification 2. Frequency Tol.<=5% M5 Dimension Inspection of dimension, color, material, package, surface process Directive DUT specification E1 Salt Spray SE-GS-90T Temp: 35°C; RH: 93%±3%; NaCl solution proportion: 1.026～ 1.041; Time:12 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<=5% E2 Thermal Shock 1Cycle: -20°C (30 minutes) to +70°C (30 minutes) Cycles: 24 After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<=5% E3 Life (HighTemp.) MIL-STD-202G,108A, cond. A Temp: 70°C; Time: 8 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<=5% Product Number: 3101503989 Product Name: Antenna Page 3 Version:1.0 Issue Date: III. Mechanical Drawing and Material Description 100±5 Product Number: 3101503989 Product Name: Antenna Page 4 Version:1.0 Issue Date: RoHS Test Report N O . Product Model Constitu ents Materi al Test Result for RoHS-corresponding Substance PFOS Halogen Series No. Date Title Test Agent Cd Pb Hg Cr(Vl) PBB s PBD Es PFOS F Cl Br I 1 2051500200 PCB CEM-1 2 2 2 2 50mg/kg 50m g/kg 50m g/kg. 50m g/kg. NO.CANEC1601019327 2016/02/01 Sub 广州SGS 2 6142501780 Body 1 ABS N.D. N.D. N.D. N.D. N.D. N.D. N.D. N.D. SCL01G055729002 2014/11/26 GP-1006FMR 上海 SGS PC N.D. N.D. 广州 SGS 3 6142501780 Body 2 ABS N.D. N.D. N.D. N.D. N.D. N.D. N.D. N.D. SCL01G055729002 2014/11/26 GP-1006FMR 上海 SGS PC N.D. N.D. 广州 SGS 4 3110500018 Connecter PBT N.D. N.D. N.D. N.D. N.D. N.D. CE/2012/13508 2012.01.18 - 台湾SGS Copper N.D. 17 N.D. Negative CE/2012/23265 2012.02.21 - 台湾SGS Copper N.D. 19 N.D. Negative CE/2012/25023 2012.03.02 - 台湾SGS 5 3120500035 Cable Cu+Sn 7 N.D. N.D. Negative N.D. N.D. N.D N.D N.D N.D ECL03G00367502E 2014/12/08 Cable CTI FEP N.D. N.D. N.D. N.D. N.D. N.D. >100000 N.D N.D N.D SHAEC1500664109 2015/01/13 Cable SGS PET4CU 8 N.D. N.D. N.D. N.D. N.D. N.D. N.D N.D N.D N.D CANEC1420243205 2014/12/11 Cable SGS Cu+Ag. N.D. N.D. N.D. Negative N.D. N.D. SHAEC1507036516 2015/04/28 Cable CTI Product Number: 3101503989 Product Name: Antenna Page 5 Version:1.0 Issue Date: IV. Antenna – S Parameter Test Data V. Antenna – Radiation Pattern Test Data Testing Equipment Specification Microwave Chamber ETS AMS-8923 Testing Equipment Agilent E5071C Product Number: 3101503989 Product Name: Antenna Page 6 Version:1.0 Issue Date: Product Number: 3101503989 Product Name: Antenna Page 7 Version:1.0 Issue Date: Packing Drawing

MRT Technology (Taiwan) Co., Ltd Report No.: 2211TW0104-U1 Phone: +886-3-3288388 Report Version: 1.0 Web: www.mrt-cert.com Issue Date: 2023-01-10 Page Number: 1 of 118 FCC ID : 2AXJ4C320WSV2 Applicant : TP-Link Corporation Limited Application Type : Certification Product : Outdoor Security Wi-Fi Camera Model No. : Tapo C320WS Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : Part15 Subpart C (Section 15.247) Received Date : November 17, 2022 Test Date : November 18, 2022~December 08, 2022 RF MEASUREMENT REPORT The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Tested By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) Report No.: 2211TW0104-U1 Page Number: 2 of 118 Revision History Report No. Version Description Issue Date Note 2211TW0104-U1 1.0 Original Report 2023-01-10 Valid Report No.: 2211TW0104-U1 Page Number: 3 of 118 CONTENTS Description Page 1. INTRODUCTION ...................................................................................................................... 6 1.1. Scope ........................................................................................................................... 6 1.2. MRT Test Location ....................................................................................................... 6 2. PRODUCT INFORMATION ...................................................................................................... 7 2.1. Feature of Equipment under Test ................................................................................. 7 2.2. Product Specification Subjective to this Report ............................................................ 7 2.3. Working Frequencies for this report .............................................................................. 8 2.4. Description of Available Antennas ................................................................................. 8 2.5. Test Mode .................................................................................................................... 9 2.6. Configuration of Test System ....................................................................................... 9 2.7. Test System Details ................................................................................................... 10 2.8. Description of Test Software ....................................................................................... 10 2.9. Applied Standards ...................................................................................................... 10 2.10. Duty Cycle ................................................................................................................... 11 2.11. Test Configuration ...................................................................................................... 12 2.12. EMI Suppression Device(s)/Modifications ................................................................... 12 2.13. Labeling Requirements ............................................................................................... 12 3. DESCRIPTION of TEST ......................................................................................................... 13 3.1. Evaluation Procedure ................................................................................................. 13 3.2. AC Line Conducted Emissions ................................................................................... 13 3.3. Radiated Emissions .................................................................................................... 14 4. ANTENNA REQUIREMENTS................................................................................................. 15 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................. 16 6. MEASUREMENT UNCERTAINTY ......................................................................................... 17 7. TEST RESULT ....................................................................................................................... 18 7.1. Summary .................................................................................................................... 18 7.2. 6dB Bandwidth Measurement ..................................................................................... 19 7.2.1. Test Limit .................................................................................................................... 19 7.2.2. Test Procedure used .................................................................................................. 19 7.2.3. Test Setting ................................................................................................................ 19 7.2.4. Test Setup .................................................................................................................. 19 7.2.5. Test Result ................................................................................................................. 20 7.3. Output Power Measurement ....................................................................................... 23 Report No.: 2211TW0104-U1 Page Number: 4 of 118 7.3.1. Test Limit .................................................................................................................... 23 7.3.2. Test Procedure Used .................................................................................................. 23 7.3.3. Test Setting .....................................................................................................…

Text truncated - open the document above for the full version.

Report No.: 2211TW0104-U1 Page Number: 41 of 118 802.11 b CH11 (2462MHz) 802.11 b CH11 (2462MHz) 802.11 b CH11 (2462MHz) 802.11 g CH01 (2412MHz) 802.11 g CH01 (2412MHz) 802.11 g CH01 (2412MHz) Report No.: 2211TW0104-U1 Page Number: 42 of 118 802.11 g CH06 (2437MHz) 802.11 g CH06 (2437MHz) 802.11 g CH06 (2437MHz) 802.11 g CH11 (2462MHz) 802.11 g CH11 (2462MHz) 802.11 g CH11 (2462MHz) Report No.: 2211TW0104-U1 Page Number: 43 of 118 802.11 n20 CH01 (2412MHz) 802.11 n20 CH01 (2412MHz) 802.11 n20 CH01 (2412MHz) 802.11 n20 CH06 (2437MHz) 802.11 n20 CH06 (2437MHz) 802.11 n20 CH06 (2437MHz) Report No.: 2211TW0104-U1 Page Number: 44 of 118 802.11 n20 CH11 (2462MHz) 802.11 n20 CH11 (2462MHz) 802.11 n20 CH11 (2462MHz) Report No.: 2211TW0104-U1 Page Number: 45 of 118 7.6. Radiated Spurious Emission Measurement 7.6.1.Test Limit All out of band emissions appearing in a restricted band as specified in Section 15.205 of the Title 47CFR must not exceed the limits shown in Table per Section 15.209. FCC Part 15 Subpart C Paragraph 15.209 Frequency [MHz] Field Strength [Uv/m] Measured Distance [Meters] 0.009 - 0.490 2400/F (kHz) 300 0.490 - 1.705 24000/F (kHz) 30 1.705 - 30 30 30 30 - 88 100 3 88 - 216 150 3 216 - 960 200 3 Above 960 500 3 7.6.2.Test Procedure Used ANSI C63.10 - 2013 - Section 11.11 & 11.12 ANSI C63.10 Section 6.3 (General Requirements) ANSI C63.10 Section 6.4 (Standard test method below 30MHz) ANSI C63.10 Section 6.5 (Standard test method above 30MHz to 1GHz) ANSI C63.10 Section 6.6 (Standard test method above 1GHz) 7.6.3.Test Setting Table 1 - RBW as a function of frequency Frequency RBW 9 ~ 150 kHz 200 ~ 300 Hz 0.15 ~ 30 MHz 9 ~ 10 kHz 30 ~ 1000 MHz 100 ~ 120 kHz > 1000MHz 1MHz Report No.: 2211TW0104-U1 Page Number: 46 of 118 Quasi-Peak Measurements below 1GHz 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. Span was set greater than 1MHz 3. RBW = as specified in Table 1 4. Detector = CISPR quasi-peak 5. Sweep time = auto couple 6. Trace was allowed to stabilize Peak Measurements above 1GHz 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW = 3MHz 4. Detector = peak 5. Sweep time = auto couple 6. Trace mode = max hold 7. Trace was allowed to stabilize Average Measurements above 1GHz (Method VB) 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW; If the EUT is configured to transmit with duty cycle ≥ 98%, set VBW = 10 Hz. If the EUT duty cycle is < 98%, set VBW ≥ 1/T. T is the minimum transmission duration. 4. Detector = Peak 5. Sweep time = auto 6. Trace mode = max hold 7. Trace was allowed to stabilize Report No.: 2211TW0104-U1 Page Number: 47 of 118 7.6.4.Test Setup Below 1GHz Test Setup: Above 1GHz Test Setup: Report No.: 2211TW0104-U1 Page Number: 48 of 118 7.6.5.Test Result EUT Outdoor Security Wi-Fi Camera Date of Test 2022-12-07 Factor VULB 9162 Temp. / Humidity 24C /57% Polarity Horizontal Site / Test Engineer AC2 / Xuan Test Mode 802.11n-20MHz_TX_CH 6_ANT 0+1 Test Voltage AC 120V/…
