2AXJ4C420Smart Wire-Free Security Camera

User Guide Wire-Free Security Camera System ©2022 TP-Link 1910013237 REV1.0.0 Contents About This Guide ···········································································1 Introduction ······················································································2 Appearance-Camera ···································································3 Appearance-Hub ·········································································4 Charge the Battery ········································································7 Set Up Your Camera ·····································································8 Install a microSD Card ······························································10 Mount Your Camera···································································11 Main Hub Controls ·····································································12 Main Camera Controls ·····························································16 Check Battery Status ·······························································18 Set Privacy Zones ·······································································19 Night Vision Mode ·····································································20 Camera Detection & Alerts ···················································21 Detection Recordings ······························································24 Manual Recording ·······································································25 Privacy Mode ················································································26 Clips Settings ················································································27 Share Camera ···············································································28 Smart Actions ···············································································29 Check Me Page ···········································································32 Authentication ··············································································33 1 About This Guide This guide provides a brief introduction to the Smart Wire-Free Security Camera System and the Tapo app, as well as regulatory information. Please note that features available in Tapo may vary by model and software version. Tapo availability may also vary by region. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Tapo Camera experience. Conventions In this guide, the following convention is used: Convention Description Blue Key information appears in teal, including management page text such as menus, items, buttons and so on. Underline Hyperlinks are in teal and underlined. You can click to redirect to a website. Note: Ignoring this type of note might result in a malfunction or damage to the device. More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. 2 Introduction Install anywhere with long battery life. Tapo Wire-Free Security Camera System is designed to be used outdoors. Its rechargeable and removable battery with a low-power protocol extends your usage. No wires means you can place the camera wherever you like. The camera is equipped with the high resolution sensor and the fill light, catching more colors. The highly-sensitive starlight sensor captures higher-quality images even in low-light conditions. The integrated spotlights help enhance your security view with vivid colors even at night. • 2K QHD – Now with 1.7 times more pixels than 1080p, providing clearer videos and photos. • 180 Day Long Battery Life – The rechargeable and removable battery with a low-power protocol extends your usage. • Wire-Free Placement – No wires means you can place the cameras almost anywhere inside or outside - whatever works for you. • Smart AI Detection – Detect multiple event types with smart AI algorithms. Adjust the sensitivity according to your needs. • Sound and Light Alarm – Trigger sound and light as an alarm when motion is detected. • Full-Color Night Vision – Enhance your security view with vivid colors even at night with the integrated spotlights. • Starlight Sensor – The highly-sensitive starlight sensor captures higher-quality images even in low-light conditions. • Motion Detection – Get instant notifications when your camera detects motion. • Weatherproof – Helps Tapo cameras perform well even in harsh environments with rain and dust. • Two-Way Audio – Communicate with others with the built-in microphone and speaker. • Flexible Storage Choices – Save recorded videos on the hub-installed microSD card (up to 256 GB) or by uising Tapo Care cloud storage services. *microSD card needs to be purchased separately. **Subscribe for cloud storage at https://www.tapo.com/tapocare/. 3 Appearance-Camera Indicate the status of your camera.While the camera is powered on: Front Back 1 3 Motion Sensor Spotlights 4 Status LED 2 Light Sensor 6 Lens 5 Microphone SYNC/RESET Button 7 Press for 1 second: Pair with the hub Press and hold for about 5 seconds: Reset the camera RES SYNC ET / 7 425 1 1 6 3 4 Appearance-Hub ▲ microSD card not included. 1 SYNC Press to pair with the camera, or silence the hub when it rings. 2 RESET Press and hold for about 5 seconds until the hub LED quickly blinks red to reset the hub. 3 microSD Card Slot Insert a microSD card to record camera videos locally. Initialize the microSD card within the Tapo app first. 4 Status LED Indicate the status of your hub. Micr o SD 123 4 5 Solid amber Blinking red quickly Solid red Solid green Blinking green quickly Starting up Connected to the cloud Connected to router Hub resetting Hub updating Blinking red and greenReady for setup Blinking green slowlyPairing Hub Status LED 6 Camera Status LED Blinking red and green Solid Red Blinking red once a minute Blinking green quicklyCamera updati…

Text truncated - open the document above for the full version.

20 Night Vision Mode Unlike standard cameras’ black and white night view, this smart wire-free camera is equipped with a high-resolution sensor and spotlights, helping enhance your security view with vivid colors even at night. You can choose a preferred night mode and adjust the white light brightness as needed. Select Night Mode Go to Camera Settings > Night Mode Settings, and select your preferred night mode. Infrared Mode Only use the infrared light to create black-and-white images at night. Full Color Mode Only use the spotlights to see things vividly in full color at night. The white light will be on. Smart Mode Typically run on Infrared Mode and switch automatically to Full Color Mode when motion is detected. The white light will be on in Full Color Mode. 21 Step 1: Turn On Detection Go to Camera Settings page and tap Detection & Alerts to turn on the detection and customize motion zones and sensitivity. AI Detection When your camera detects person/pet/vehicle, it will send you notifications or even sound an alarm. You can adjust the detection sensitivity. Camera Detection & Alerts Receive notifications and check feeds when the camera detects a motion or person/pet/vehicle. Insert a microSD card or subscribe to Tapo Care to record the clips when activity detected. Otherwise, you can only receive the notifications. Note: Initialize the SD card on the Tapo app before using it. 22 Wake-up Sensitivity Your battery-powered camera only wakes up and starts recording when motion is detected. You can set how easily the camera wakes up. Camera Alarm Customize Camera Alarm settings to trigger a light/sound alarm to frighten away unwanted visitors when your camera detects activities. You can also set the Alarm Schedule as needed. 23 Turn On Activity Notifications Turn on Activity Notifications to get instant alerts when your camera detects activities. You can customize the time when the camera sends you notifications. Step 5: Check Recordings On the Live View page, tap to find all recordings. Tap the colored sections or the video clips below to check the activity detected. 24 1. On the Live View page, tap to enter the Camera Settings page. 2. Toggle on to enable the microSD Recording function and set the Recording Schedule for 24-hour Recording as needed. Detection Recordings Start recording when events are detected. You need a microSD card or subscribe to Tapo Care to save videos. It’s suggested to initialize the SD card on the app before using it. 25 1. On the Live View or Playback page, tap to take photos and tap to record video clips. 2. Go to LIVE View page, tap and enter Memory page, or go to Me > Camera Memory to view, download, and share photos and videos you take. Manual Recording When watching live or playback, you can take screenshots and record video clips anytime you want. Photos and videos you take will appear in the Memory page, and you can download them to your phone or share with your family. 26 Privacy Mode On the Live View page, tap to enable the Privacy Mode. When enabled, streaming and recording functions will be temporarily disabled to protect your privacy. You can tap Exit Privacy Mode to exit Privacy Mode and the camera will be back to work. You can also go to Camera Settings > Auto Privacy Mode to enable privacy mode when charging the camera. 27 Clips Settings You can set the Retrigger Time, Record Buffer amd Maximum Clip Length as you like. You could extend the battery life by setting longer retrigger time, and reduced record buffer and clip length. 28 Share Camera You can invite your family members to manage your Tapo devices together by entering the TP-Link ID (email) you want to share the devices with. 29 Smart Actions Smart Actions automate repetitive tasks, allowing you to blaze through tedium with utmost ease. Set everything up once and never have to worry about it again. With Smart Actions, giving your home that level of intelligence is a snap. Shortcut lets you perform an action with a simple tap. Automation allows you to automate tasks to be performed at a set time. e.g. Turn on the lamp plugged into your Tapo smart plug when your camera detects motion. Option 1: Edit based on the routine actions 1. Go to the Smart Actions page and you will see the Routine Actions (Shortcut or Automation). 2. Tap on a routine action. Tap EDIT to change the settings as needed and tap APPLY to save changes. 30 Option 2: Create your own shortcuts 1. Go to Shortcuts page. Tap + on the top right to add a simple and smart action. 2. Add an action and choose whether to delay the action. 3. Name your shortcut and choose an icon. Tap Done to save all the settings. 31 Option 3: Create your own actions 1. Go to Automation page. Tap + on the top right to add a simple and smart action. 2. Name the new action. Tap + to add conditions (When) like the trigger time, and tap + to add tasks (Then) like turning on the switch. 3. Name your automation and set the effective time for the automation. Tap Done to save all the settings. 32 Check Me Page On this page, you can edit your account, quickly check the memorable moments you saved, set up connections with third-party services, subscribe to Tapo Care, set useful widgets, or find the FAQs related to the Tapo app. Camera Memory Photos and videos you took will appear here Device Sharing Share your Tapo devices to your family members to manage devices together Camera Preferences You can choose to display the Live or Speed tag on the screen for all your Tapo cameras Third-Party Services Set up connections with third-party services Account Info Change your avatar, edit your name, or modify the password Widgets Set up widgets to quickly control Tapo devices. Tapo Care Subscribe to Tapo Care to enjoy unlimited cloud storage and other advanced features Cloud Storage Videos saved to the cloud after subscribing to Tapo Care will appear here. 33 Authentication FCC compliance information statement Product Name: Smart Wire-Free Security Camera System Model N…

Text truncated - open the document above for the full version.

39 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值 Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the reference percentage value of presence condition. 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence. 備考 3.〝−〞係指該項限用物質為排除項目。 Note 3：The “−” indicates that the restricted substance corresponds to the exemption. Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів та вимогам, що передбачені чинними законодавчими актами України. Safety Information •Do not use damaged charger or USB cable to charge the device. Do not use any other chargers than those recommended. •Do not use the device where wireless devices are not allowed. •Adapter shall be easily accessible. •Use only power supplies which are provided by manufacturer and in the original packing of this product. If you have any questions, please don’t hesitate to contact us. •Keep the device away from fire or hot environments. DO NOT immerse in water or any other liquid. •Do not disassemble, repair or modify the product. •Do not place near automatically controlled devices such as fire alarms. Radio waves emitted from this product may cause such devices to malfunction resulting in an accident. •Observe restrictions on using wireless products in fuel depots, chemical plants or when blasting operations are in progress. The power adapter should be used below 40 °C. • 40 • Do not use liquid to clean the product. Only use a dry cloth. • Never put metal objects inside the product. If a metal object enters the product turn off the circuit breaker and contact an authorised electrician. • This product is not intended to be used when providing medical care. Consult the manufacturer of any personal medical devices, such as pacemakers or hearing aids to determine if they are adequality shielded from external RF (radio frequency) energy. • Do not use this product in health care facilities. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy. • Do not place heavy objects on top of the product. • When you leave the product unused for a long time unplug the product from the power outlet. • Product should be kept away from heat sources such as radiators, cookers etc. - it should not be placed in places where the temperature is less than -20 degrees or greater than 45 degrees. • This product may interfere with other electronic products such as TV, radios, personal computers, phones or other wireless devices. • Always follow the local waste and recycle laws when you get rid of the used battery. • • Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk. 41 Explanation of the symbols on the product label SymbolExplanation DC voltage Indoor use only RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment. User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic equipment.

TP-Link Corporation Limited 030122-15 Authority to Act as Agent Date: September 20, 2022 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2023-09-16 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-Link Corporation Limited (Company Name) Telephone: 00852-37585503 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Corporation Limited 030122-15 Request for Confidentiality Date: September 20, 2022 Subject: Confidentiality Request for: 2AXJ4C420 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-Link Corporation Limited has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent TP-Link Corporation Limited 030122-15 letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Corporation Limited Wi-Fi Channel 12 and 13 Declaration Letter Date: 2022-09-16 We, the undersigned company Company Name: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon,Hong Kong Declare that: Product description: Smart Wire-Free Security Camera Type designation: Tapo C420 Brand: tp-link, tapo FCC ID: 2AXJ4C420 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Sarah Wang Tel: 00852-37585503 Email: [email protected]

TP-Link Corporation Limited Supplier’s Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Manufacturer: TP-Link Corporation Limited, Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon,Hong Kong U.S. Responsible Party: TP-Link USA Corporation, d/b/a TP-Link North America, Inc. 145 South State College Blvd. Suite 400, Brea, CA 92821 Contact Person: Tel.: 00852-37585503 Email: [email protected] Internet: https://www.tp-link.com Model: Tapo C420 Classification: FCC Part 15B We hereby declare that the equipment bearing the trade name and model number specified above was tested conforming to the applicable FCC rule part(s) 15B and the most accurate measurement standards. We confirm that the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commission’s requirements. 2022.09.16 Sarah Wang ------------- -------------------- Date: Signature:

Project No.: 2204C109A Page 2 of 17 Project No.: 2204C109A Page 3 of 17 Project No.: 2204C109A Page 4 of 17 Project No.: 2204C109A Page 5 of 17 Project No.: 2204C109A Page 6 of 17 Project No.: 2204C109A Page 7 of 17

菲林图 尺寸：35.17*25mm 颜色：Pantone Cool Grey 6C (实际效果以打样为准） 尺寸图转曲 14.5±0.5mm 2.47±0.3mm Input Rating: 5V 1.5A Suite 901, New East Ocean Centre, Tsim Sha Tsui, Hong Kong TP-Link Corporation Limited IC: 26583-C420 FCC ID: 2AXJ4C420 MADE IN CHINAIP65 Smart Wire-Free Security CameraModel: Tapo C420 201-220262 IEEE802.11b/g/n 垂直距离 MAC:XX-XX-XX-XX-XX-XX EU/1.0 S/N: XXXXXXXXXXXXX 注： 2. 图示条形码仅为示意，具体以生产实际为准。 1. S/N码、产品型号、MAC码打印至20*5mm空白标贴（7210500368）后粘贴于壳体 指定位置。MAC条码由“XXXXXXXXXXXX”生成，文本打印成：XX-XX-XX-XX-XX-XX。 label location

Project No.: 2204C109A Page 8 of 17 Project No.: 2204C109A Page 9 of 17 Project No.: 2204C109A Page 10 of 17 Project No.: 2204C109A Page 11 of 17 Project No.: 2204C109A Page 12 of 17 Sub 1G Antenna WIFI Antenna Project No.: 2204C109A Page 13 of 17 Project No.: 2204C109A Page 14 of 17 Project No.: 2204C109A Page 15 of 17 Project No.: 2204C109A Page 16 of 17 Project No.: 2204C109A Page 17 of 17

Report No.: BTL-FCCP-3-2204C109A Page 1 of 3 FCC RF EXPOSURE REPORT FCC ID: 2AXJ4C420 Project No. : 2204C109A Equipment : Smart Wire-Free Security Camera Brand Name : tp-link, tapo Test Model : Tapo C420 Series Model : N/A Applicant : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Manufacturer : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Date of Receipt : Jun. 06, 2022 Date of Test : Jun. 08, 2022 ~ Jul. 13, 2022 Issued Date : Sep. 30, 2022 Report Version : R02 Test Sample : Engineering Sample No.: DG2022053170 for WIFI, DG2022053168 for Sub 1G. Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chella Zheng Approved by : Chay Cai BTL Inc. No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People’s Republic of China. Te l : +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-3-2204C109A Page 2 of 3 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-3-2204C109A R00 Original Report Sep. 09, 2022 Invalid BTL-FCCP-3-2204C109A R01 Changed the product name. Sep. 13, 2022 Invalid BTL-FCCP-3-2204C109A R02 Updated the writing of antenna type. Sep. 30, 2022 Valid Report No.: BTL-FCCP-3-2204C109A Page 3 of 3 1. TEST FACILITY The test facilities used to collect the test data in this report is at the location of No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People’s Republic of China. BTL's Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Antenna Specification: For 2.4GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 tp -link Tapo C420(US)1.0 IFA N/A -0.21 Note: The antenna gain is provided by the manufacturer. For Sub 1G: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 tp -link Tapo C420(US)1.0 Monopole N/A -5.04 Note: The antenna gain is provided by the manufacturer. 3. TEST RESULTS For 2.4GHz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Average Output Power (dBm) Max. Average Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result -0.21 0.9528 19.09 81.0961 0.01538 1 Complies For Sub 1G: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result -5.04 0.3133 16.98 49.8884 0.00311 1 Complies For the max simultaneous transmission MPE: Ratio Total Limit of Ratio Test Result 2.4GHz Sub 1G 0.01538 0.00311 0.01849 1 Complies Note: The calculated distance is 20 cm. Output power including tune up tolerance. End of Test Report

Report No.: BTL-FCCP-1-2204C109A Page 1 of 120 FCC Radio Test Report FCC ID: 2AXJ4C420 This report concerns: Original Grant Project No. : 2204C109A Equipment : Smart Wire-Free Security Camera Brand Name : tp-link, tapo Test Model : Tapo C420 Series Model : N/A Applicant : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Manufacturer : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Date of Receipt : Jun. 06, 2022 Date of Test : Jun. 08, 2022 ~ Jul. 13, 2022 Issued Date : Sep. 30, 2022 Report Version : R02 Test Sample : Engineering Sample No.: DG2022053170 for conducted, DG2022053171 for others. Standard(s) : FCC CFR Title 47, Part 15, Subpart C FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chella Zheng Approved by : Chay Cai BTL Inc. No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People’s Republic of China. Te l : +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-1-2204C109A Page 2 of 120 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2204C109A Page 3 of 120 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 12 2.4 DUTY CYCLE 13 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 15 2.6 SUPPORT UNITS 15 3 . AC POWER LINE CONDUCTED EMISSIONS 16 3.1 LIMIT 16 3.…
