2AXJ4C520WSOutdoor Pan/Tilt Security Wi-Fi Camera

User Guide Outdoor Pan/Tilt Security Wi-Fi Camera ©2023 TP-Link 1910013392 REV1.0.0 Contents About This Guide ···········································································1 Introduction ······················································································2 Appearance ······················································································3 Set Up Your Camera ·····································································5 Set Up Using Amazon Frustration-Free Setup ··············6 Install a microSD Card ······························································10 Mount Your Camera···································································11 Install Waterproof Items ··························································13 How to Reset Your Camera ···················································14 Authentication ··············································································15 1 About This Guide This guide provides a brief introduction to the Outdoor Pan/Tilt Security Wi-Fi Camera and the Tapo app, as well as regulatory information. Please note that features available in Tapo may vary by model and software version. Tapo availability may also vary by region. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Tapo Camera experience. Conventions In this guide, the following convention is used: Convention Description Blue Key information appears in blue, including management page text such as menus, items, buttons and so on. Underline Hyperlinks are in blue and underlined. You can click to redirect to a website. Note: Ignoring this type of note might result in a malfunction or damage to the device. More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. 2 Introduction Tapo C510W is a full-featured weatherproof security camera that you can access from anywhere. Receive instant notifications and check feeds when the motion is detected. Moreover, the automatic siren system will trigger light and sound to frighten away unwanted visitors after the camera detects motion. Day or night, rain or shine, the Tapo camera protects what you love most. • 2K QHD, Starlight Color Night Vision – Equipped with an F1.6 large-aperture lens and starlight sensor, Tapo C520WS enhances your security byrevealing highly-detailed and bright-color images even under low-light conditions. • Person/Pet/Vehicle Detection and Notification – Smart AI identifies people, pets, and vehicles, notifying users as needed. • 360° Visual Coverage – Provides 360° horizontal & 90° vertical view (180° vertical view in Privacy Mode) range to capture everything around. • Local microSD Storage (Up to 512GB)† and Cloud Storage** – Save recorded videos to an installed microSD card (up to 512 GB)† or by using Tapo Care** cloud storage service. *microSD card must be purchased separately. **Subscribe for cloud storage at https://www.tapo.com/tapocare/ • IP66 Weatherproof – Offers excellent waterproof and dustproof performance for outdoor scenarios. • Customizable Sound and Light Alarm – Records your customized audio as an alarm to extend your usage. Set to trigger a light/sound alarm when detecting activity. • Activity Zones – Notifies you when activity is detected in your specific zone. • Tw o -Wa y Audio – Communicate remotely with a delivery person in real time. • Multiple Installation Options – Use the mounting screws, template and loops* to install on any wall, ceiling or pole . *Loops (purchased separately) are needed for pole mounting. • Two-Way Audio – Communicate remotely with a delivery person in real time. • Wired/Wireless Networking – Connect the camera to your network through Ethernet or Wi-Fi for more flexible installation. 3 Appearance 6 Reset Loosen the screws. While the camera is powered on, use a pin to press and hold the Reset button for at least 5 seconds until the System LED blinks red. The camera will reset and reboot. 7 6 microSD 3 2 1 9 10 4 5 7 microSD Card Slot Loosen the screws and insert a microSD card*. Initialize it on the Tapo app for local recording. * microSD card not included 8 5 Microphone 2 3 Lens 4 System LED IR LEDs 1 White Light LEDs 9 Speaker 8 Ethernet Port Used to connect to a network device 10 DC Power Connector Used to connect to a 9V DC power adapter 4 System LED Indication Blinking red and green (for Wi-Fi setup) Blinking red slowly (for Wi-Fi setup) Solid amber Blinking red quickly Solid red Solid green Blinking green quickly Starting up Connected to the cloud Ready for setup Connecting to Wi-Fi Connected to Wi-Fi or wired network Camera resetting Camera updating 5 Set Up Your Camera Follow the steps below to get started with your new camera. Step 1. Download Tapo App Get the Tapo app from the App Store or Google Play, or by scanning the QR code below. Step 2. Log In Open the app, and log in with your TP-Link ID. If you don't have an account, create one first. Step 3. Add Your Camera Tap the button in the app and select your model. OR 6 Step 4. Configure Camera Follow app instructions to set up your camera via wired or wireless connection (for setup only), and add it to your home network. After setup, you can use your camera via wired connection or wirelessly. Note: For Wireless setup, if your camera is connected to your router via an Ethernet cable, please unplug the cable first. 7 Set Up Using Amazon Frustration-Free Setup What is Amazon Frustration-Free Setup? Amazon Frustration-Free Setup can help connect and set up Tapo smart devices in fewer steps, without having to remember and re-enter your Wi-Fi password on each device. To use this feature, confirm the following: ● The new Tapo device supports Amazon FFS. ● The new Tapo device is purchased from Amazon. ● You have an Amazon FFS enabled Alexa device or router. ● You have saved your Wi…

Text truncated - open the document above for the full version.

TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong 012423-17 rev2 Certification Application Attestation Statements Date: March 7, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) _____TP-Link Corporation Limited______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ____ TP-Link Corporation Limited_______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is /- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ____Sarah Wang__ (Signature 2 ) (Print name) Title: Compliance manager Company: TP-Link Corporation Limited_____ Telephone: +86 755 21534921 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. Product: Outdoor Pan/Tilt Security Wi-Fi Camera FCC ID: 2AXJ4C520WS Model: Tapo C520WS Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-04-23

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2AXJ4C520WS Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-4-23

Declaration of Authorization We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Outdoor Pan/Tilt Security Wi-Fi Camera FCC ID: 2AXJ4C520WS Model: Tapo C520WS Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-4-23

Declaration of Conformity We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Product: Outdoor Pan/Tilt Security Wi-Fi Camera FCC ID: 2AXJ4C520WS Model: Tapo C520WS Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-3-17

Report No.: 2303TW0102-UE Product: Outdoor Pan/Tilt Security Wi-Fi Camera Brand Name: tp-link Model Number: Tapo C520WS 1 of 9 External Photograph ( 1 ) EUT Photo ( 2 ) EUT Photo Report No.: 2303TW0102-UE 2 of 9 ( 3 ) EUT Photo ( 4 ) EUT Photo Report No.: 2303TW0102-UE 3 of 9 ( 5 ) EUT Photo ( 6 ) EUT Photo Report No.: 2303TW0102-UE 4 of 9 ( 7 ) EUT Photo ( 8 ) EUT Photo Report No.: 2303TW0102-UE 5 of 9 ( 9 ) EUT Photo ( 10 ) EUT Photo Report No.: 2303TW0102-UE 6 of 9 ( 11 ) EUT Photo ( 12 ) EUT Photo(Brand: tp-link,M/N: T090085-2B1) Report No.: 2303TW0102-UE 7 of 9 ( 13 ) EUT Photo(Brand: tp-link,M/N: T090085-2B1) ( 14 ) EUT Photo(Brand: tp-link,M/N: T090085-2B1) Report No.: 2303TW0102-UE 8 of 9 ( 15 ) EUT Photo(Brand: tp-link,M/N: T090085-2B1) ( 16 ) EUT Photo(Brand: tp-link,M/N: T090085-2B1) Report No.: 2303TW0102-UE 9 of 9 ( 17 ) EUT Photo(Brand: tp-link,M/N: T090085-2B1) ( 18 ) EUT Photo (Brand: tp-link,M/N: T090085-2B1)

Label Label Location

Report No.: 2303TW0102-UI Product: Outdoor Pan/Tilt Security Wi-Fi Camera Brand Name: tp-link Model Number: Tapo C520WS 1 of 10 Internal Photograph ( 1 ) EUT Photo ( 2 ) EUT Photo Report No.: 2303TW0102-UI 2 of 10 ( 3 ) EUT Photo ( 4 ) EUT Photo Report No.: 2303TW0102-UI 3 of 10 ( 5 ) EUT Photo ( 6 ) EUT Photo Report No.: 2303TW0102-UI 4 of 10 ( 7 ) EUT Photo ( 8 ) EUT Photo Report No.: 2303TW0102-UI 5 of 10 ( 9 ) EUT Photo ( 10 ) EUT Photo Report No.: 2303TW0102-UI 6 of 10 ( 11 ) EUT Photo ( 12 ) EUT Photo Report No.: 2303TW0102-UI 7 of 10 ( 13 ) EUT Photo ( 14 ) EUT Photo Report No.: 2303TW0102-UI 8 of 10 ( 15 ) EUT Photo ( 16 ) EUT Photo Report No.: 2303TW0102-UI 9 of 10 ( 17 ) EUT Photo ( 18 ) EUT Photo Report No.: 2303TW0102-UI 10 of 10 ( 19 ) EUT Photo

MRT Technology (Taiwan) Co., Ltd Report No.: 2303TW0102-U2 Phone: +886-3-3288388 Report Version 1.0 Web: www.mrt-cert.com Issue Date: 2023-04-22 Page Number: 1 of 12 RF Exposure Evaluation Declaration FCC ID : 2AXJ4C520WS Applicant : TP-Link Corporation Limited Product : Outdoor Pan/Tilt Security Wi-Fi Camera Model No. : Tapo C520WS Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : FCC Part 2.1091 Result : Complies Test By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2303TW0102-U2 Page Number: 2 of 12 Revision History Report No. Version Description Issue Date Note 2303TW0102-U2 1.0 Original Report 2023-04-22 Valid Report No.: 2303TW0102-U2 Page Number: 3 of 12 CONTENTS Description Page 1. General Information ............................................................................................................... 4 2. INTRODUCTION ...................................................................................................................... 5 2.1. Scope............................................................................................................................. 5 2.2. MRT Test Location ......................................................................................................... 5 3. PRODUCT INFORMATION ...................................................................................................... 6 3.1. Feature of Equipment under Test ................................................................................... 6 3.2. Description of Available Antennas .................................................................................. 6 3.3. Device Classification ...................................................................................................... 6 3.4. Applied Standards .......................................................................................................... 7 4. RF Exposure Evaluation ........................................................................................................ 8 4.1. Limits ............................................................................................................................. 8 4.2. MPE Exemptions ........................................................................................................... 9 4.3. Calculated Result ......................................................................................................... 12 Report No.: 2303TW0102-U2 Page Number: 4 of 12 1. General Information Applicant TP-Link Corporation Limited Applicant Address Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Manufacturer TP-Link Corporation Limited Manufacturer Address Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Test Site MRT Technology (Taiwan) Co., Ltd Test Site Address No. 38, Fuxing Second Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C) MRT FCC Registration No. 291082 Test Facility / Accreditations 1. MRT facility is a FCC registered (Reg. No. 291082) test facility with the site description report on file and is designated by the FCC as an Accredited Test Firm. 2. MRT facility is an IC registered (MRT Reg. No. 21723) test laboratory with the site description on file at Industry Canada. 3. MRT Lab is accredited to ISO 17025 by the Taiwan Accreditation Foundation (TAF Cert. No. 3261) in EMC, Telecommunications and Radio testing for FCC (Designation Number: TW3261), Industry Taiwan, EU and TELEC Rules. Report No.: 2303TW0102-U2 Page Number: 5 of 12 2. INTRODUCTION 2.1. Scope Measurement and determination of electromagnetic emissions (EMC) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission and the Innovation, Science and Economic Development Canada and Certification and Engineering Bureau. 2.2. MRT Test Location The map below shows the location of the MRT LABORATORY, its proximity to the Taoyuan City. These measurement tests were conducted at the MRT Technology (Taiwan) Co., Ltd. Facility located at No.38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 33377, Taiwan (R.O.C). Report No.: 2303TW0102-U2 Page Number: 6 of 12 3. PRODUCT INFORMATION 3.1. Feature of Equipment under Test Product Name: Outdoor Pan/Tilt Security Wi-Fi Camera Model No.: Tapo C520WS Brand Name: tp-link Wi-Fi Specification: 802.11b/g/n Accessory Adapter BRAND: tp-link MODEL: T090085-2B1 INPUT: 100 - 240V ~ 50/60Hz 0.3A. OUTPUT: 9V ⎓ 0.85A 3.2. Description of Available Antennas Antenna Type Frequency Band (MHz) T X Paths Max Antenna Gain (dBi) CDD Directional Gain (dBi) For Power For PSD Dipole 2412 ~ 2462 2 1.00 1.00 4.01 Note: 1. The EUT supports Cyclic Delay Diversity (CDD) mode, and CDD signals are correlated. If all antennas have the same gain, G ANT , Directional gain = G ANT + Array Gain, where Array Gain is as follows. • For power spectral density (PSD) measurements on all devices, Array Gain = 10 log (N ANT / N SS ) dB; • For power measurements on IEEE 802.11 devices, Array Gain = 0 dB for N ANT ≤ 4; 2. All messages of antenna were declared by manufacturer. 3.3. Device Classification According to the user manual, the antenna of this device is at least 20cm away from the body of the user, this device is classified as a Mobile Device. So, the RF exposure evaluation requirements of § 2.1091 for mobile device exposure conditions subject to MPE limits. Report No.: 2303TW0102-U2 Page Number: 7 of 12 3.4. Applied Standards Accordin…

Text truncated - open the document above for the full version.

Specification For Approval Date: File No. : Version: 1.0 Product Model: Tapo C520WS(US) 1.0 Checked By: Index I. Antenna Distribution ........................................................................................ 3 II. Electrical Characteristics ................................................................................ 3 III. Antenna Peak Gain........................................................................................... 3 IV. Antenna Radiation Pattern .............................................................................. 3 Page 3 Version:1.0 Issue Date: I. Antenna Distribution Tapo C520WS(US) 1.0 II. Electrical Characteristics Ant1 Frequency 2400~2500MHz Impedance 50Ohm Antenna Type Dipole Antenna Gain 1.00dBi@2400~2500MHz Radiation pattern Omni-Directional Ant2 Frequency 2400~2500MHz Impedance 50Ohm Antenna Type Dipole Antenna Gain 1.00dBi@2400~2500MHz Radiation pattern Omni-Directional III. Antenna Peak Gain Ant1 Frequency(MHz) 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 Gain(dBi) -0.25 0.07 0.02 -0.24 1.00 0.89 0.69 0.82 0.90 0.93 0.92 Ant2 Frequency(MHz) 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 Gain(dBi) 0.75 0.69 0.71 0.66 0.72 1.00 0.74 0.85 0.91 0.74 0.86 IV. Antenna Radiation Pattern Ant1 Page 4 Version:1.0 Issue Date: Ant2

MRT Technology (Taiwan) Co., Ltd Report No.: 2303TW0102-U1 Phone: +886-3-3288388 Report Version: 1.0 Web: www.mrt-cert.com Issue Date: 2023-04-22 Page Number: 1 of 129 FCC ID : 2AXJ4C520WS Applicant : TP-Link Corporation Limited Product : Outdoor Pan/Tilt Security Wi-Fi Camera Model No. : Tapo C520WS Brand Name : tp-link FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : Part15 Subpart C (Section 15.247) Received Date : March 02 ,2023 Test Date : March 07~28 ,2023 RF MEASUREMENT REPORT The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Tested By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) Report No.: 2303TW0102-U1 Page Number: 2 of 129 Revision History Report No. Version Description Issue Date Note 2303TW0102-U1 1.0 Original Report 2023-04-22 Valid Report No.: 2303TW0102-U1 Page Number: 3 of 129 CONTENTS Description Page 1. INTRODUCTION ...................................................................................................................... 6 1.1. Scope ........................................................................................................................... 6 1.2. MRT Test Location ....................................................................................................... 6 2. PRODUCT INFORMATION ...................................................................................................... 7 2.1. Feature of Equipment under Test ................................................................................. 7 2.2. Product Specification Subjective to this Report ............................................................ 7 2.3. Working Frequencies for this report .............................................................................. 8 2.4. Description of Available Antennas ................................................................................. 8 2.5. Test Mode .................................................................................................................... 8 2.6. Configuration of Test System ....................................................................................... 9 2.7. Test System Details ..................................................................................................... 9 2.8. Description of Test Software ......................................................................................... 9 2.9. Applied Standards ...................................................................................................... 10 2.10. Duty Cycle .................................................................................................................. 10 2.11. EMI Suppression Device(s)/Modifications .................................................................... 11 2.12. Labeling Requirements ................................................................................................ 11 3. DESCRIPTION of TEST ......................................................................................................... 12 3.1. Evaluation Procedure ................................................................................................. 12 3.2. AC Line Conducted Emissions ................................................................................... 12 3.3. Radiated Emissions .................................................................................................... 13 4. ANTENNA REQUIREMENTS................................................................................................. 14 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................. 15 6. MEASUREMENT UNCERTAINTY ......................................................................................... 17 7. TEST RESULT ....................................................................................................................... 18 7.1. Summary .................................................................................................................... 18 7.2. 6dB Bandwidth Measurement ..................................................................................... 19 7.2.1. Test Limit .................................................................................................................... 19 7.2.2. Test Procedure used .................................................................................................. 19 7.2.3. Test Setting ................................................................................................................ 19 7.2.4. Test Setup .................................................................................................................. 19 7.2.5. Test Result ................................................................................................................. 20 7.3. Output Power Measurement ....................................................................................... 23 7.3.1. Test Limit .................................................................................................................... 23 7.3.2. Test Procedure Used .................................................................................................. 23 7.3.3. Test Setting ................................................................................................................ 23 7.3.4. Test Setup .................................................................................................................. 23 Report No.: 2303TW0102-U1 Page Number: 4 of 129 7.3.5. Test Result .....…

Text truncated - open the document above for the full version.

Report No.: 2303TW0102-U1 Page Number: 43 of 129 802.11 n20 CH01 (2412MHz) 802.11 n20 CH01 (2412MHz) 802.11 n20 CH01 (2412MHz) 802.11 n20 CH06 (2437MHz) 802.11 n20 CH06 (2437MHz) 802.11 n20 CH06 (2437MHz) Report No.: 2303TW0102-U1 Page Number: 44 of 129 802.11 n20 CH11 (2462MHz) 802.11 n20 CH11 (2462MHz) 802.11 n20 CH11 (2462MHz) Report No.: 2303TW0102-U1 Page Number: 45 of 129 7.6. Radiated Spurious Emission Measurement 7.6.1.Test Limit All out of band emissions appearing in a restricted band as specified in Section 15.205 of the Title 47CFR must not exceed the limits shown in Table per Section 15.209. FCC Part 15 Subpart C Paragraph 15.209 Frequency [MHz] Field Strength [Uv/m] Measured Distance [Meters] 0.009 - 0.490 2400/F (kHz) 300 0.490 - 1.705 24000/F (kHz) 30 1.705 - 30 30 30 30 - 88 100 3 88 - 216 150 3 216 - 960 200 3 Above 960 500 3 7.6.2.Test Procedure Used ANSI C63.10-2013 Section 11.11 & 11.12. ANSI C63.10-2013 Section 6.3 (General Requirements) ANSI C63.10-2013 Section 6.4 (Standard test method below 30MHz) ANSI C63.10-2013 Section 6.5 (Standard test method above 30MHz to 1GHz) ANSI C63.10-2013 Section 6.6 (Standard test method above 1GHz) 7.6.3.Test Setting Table 1 - RBW as a function of frequency Frequency RBW 9 ~ 150 kHz 200 ~ 300 Hz 0.15 ~ 30 MHz 9 ~ 10 kHz 30 ~ 1000 MHz 100 ~ 120 kHz > 1000MHz 1MHz Report No.: 2303TW0102-U1 Page Number: 46 of 129 Quasi-Peak Measurements below 1GHz 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. Span was set greater than 1MHz 3. RBW = as specified in Table 1 4. Detector = CISPR quasi-peak 5. Sweep time = auto couple 6. Trace was allowed to stabilize Peak Measurements above 1GHz 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW = 3MHz 4. Detector = peak 5. Sweep time = auto couple 6. Trace mode = max hold 7. Trace was allowed to stabilize Average Measurements above 1GHz (Method VB) 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW; If the EUT is configured to transmit with duty cycle ≥ 98%, set VBW = 10 Hz. If the EUT duty cycle is < 98%, set VBW ≥ 1/T. T is the minimum transmission duration. 4. Detector = Peak 5. Sweep time = auto 6. Trace mode = max hold 7. Trace was allowed to stabilize Report No.: 2303TW0102-U1 Page Number: 47 of 129 7.6.4.Test Setup Below 1GHz Test Setup: Above 1GHz Test Setup: Report No.: 2303TW0102-U1 Page Number: 48 of 129 7.6.5.Test Result EUT Outdoor Pan/Tilt Security Wi-Fi Camera Date of Test 2023-03-10 Factor VULB 9162 Temp. / Humidity 20C /60% Polarity Horizontal Site / Test Engineer AC2 / Xuan Test Mode 802.11n-20MHz_TX_CH 6_ANT 0+1 Test Voltage AC 120V/60Hz No Frequency (MHz) Reading (dBuV) C.F (dB/m) Measurement (dBuV/m) Margin (dB) Limit (dBuV/m) Height (cm) Angle (deg) Remark (QP/PK/AV) 1 95.960 18.66 17.72 36.38 -7.12 43.50 150 249 QP 2 208.480 15.80 17.75 33.55 -9.95 43.50 150 3 QP 3 239.520 18.40 19.43 37.83 -8.17 46.00 140 360 QP 4 292.870 16.90 20.39 37.29 -8.71 46.00 100 213 QP 5 * 435.460 16.47 23.41 39.88 -6.12 46.00 200 175 QP 6 720.640 9.77 28.23 38.01 -7.99 46.00 100 204 QP Note: 1. " *", means this data is the worst emission level. 2. C.F (Correction Factor) = Antenna Factor (dB/m) + Cable Loss (dB). 3. Measurement (dBuV/m) = Reading(dBuV) + C.F (Correction Factor). 4. The emission levels of other frequencies are very lower than the limit and not show in test report. Report No.: 2303TW0102-U1 Page Number: 49 of 129 EUT Outdoor Pan/Tilt Security Wi-Fi Camera Date of Test 2023-03-10 Factor VULB 9162 Temp. / Humidity 20C /60% Polarity Vertical Site / Test Engineer AC2 / Xuan Test Mode 802.11n-20MHz_TX_CH 6_ANT 0+1 Test Voltage AC 120V/60Hz No Frequency (MHz) Reading (dBuV) C.F (dB/m) Measurement (dBuV/m) Margin (dB) Limit (dBuV/m) Height (cm) Angle (deg) Remark (QP/PK/AV) 1 30.970 16.99 16.69 33.68 -6.32 40.00 100 18 QP 2 99.840 14.50 18.39 32.90 -10.60 43.50 100 300 QP 3 * 203.630 19.85 17.89 37.74 -5.76 43.50 100 46 QP 4 239.520 17.76 19.43 37.19 -8.81 46.00 200 30 QP 5 435.460 15.19 23.41 38.60 -7.40 46.00 135 360 QP 6 792.420 6.15 29.21 35.36 -10.64 46.00 200 27 QP Note: 1. " *", means this data is the worst emission level. 2. C.F (Correction Factor) = Antenna Factor (dB/m) + Cable Loss (dB). 3. Measurement (dBuV/m) = Reading(dBuV) + C.F (Correction Factor). 4. The emission levels of othe…
