2AXJ4EAP770BE11000 Ceiling Mount Wi-Fi 7 Access Point

Regulatory Compliance Ceiling Mount EAP For Class A Ceiling Mount EAP with adapter: FCC Compliance Information Statement Product Name: Omada Ceiling Mount Access Point Model Number: EAP660 HD Component NameModel I.T.E. Power SupplyT120200-2B1 (For EAP660 HD) Responsible party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: https://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be colocated or operating in conjunction with any other antenna or transmitter.” Product Name: I.T.E. Power Supply Model Number: T120200-2B1 Responsible party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: https://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: [email protected] This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated. Issue Date: 2023-05-19 CE Mark Warning This is a class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. OPERATING FREQUENCY (the maximum transmitted power) 2412 MHz -2472 MHz (20dBm) 5150 MHz -5250 MHz (23dBm) 5250 MHz -5350 MHz (23dBm) 5470 MHz -5725 MHz (30dBm) EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/. RF Exposure Information This device meets the EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the general public to electromagnetic fields by way of health protection. The device complies with RF specifications when the device used at 20 cm from your body. National Restrictions Attention: This device may only be used indoors in all EU member states, EFTA countries and Northern Ireland. UKCA Mark UK Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca National Restrictions Attention: This device may only be used indoors in Great Britain. UK Canadian Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s…

Text truncated - open the document above for the full version.

012423-17 rev2 TP-Link Corporation Limited Certification Application Attestation Statements Date: March 1, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 T o Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______ TP-Link Corporation Limited______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______ TP-Link Corporation Limited______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ■- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: _________________________ Sarah Wang (Signature 2 ) (Print name) Title: __ Regulatory Compliance Manager __ Company: __ TP-Link Corporation Limited_ Telephone: ___ 00852-37585053 ______ 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

Letter of Declaration on Indoor Access Point (6ID) Operation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXJ4XEAP770 IC: 26583-EAP770 To Whom It May Concern We, TP-Link Corporation Limited (Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong), attest that this Indoor Access Point device complies with the following requirements of Part 15E of the FCC’s rules for 6G bands: Protocol attestation statement: FCC ID: 2AXJ4EAP770 IC: 26583-EAP770 To Whom It May Concern: Indoor Access Point 6ID: We, TP-Link Corporation Limited attest that this low-power indoor access point complies with the following requirements of Part 15E of the FCC' rules for the 5.925~7.125 GHz band: 1. This device’s transmit power spectral density is in accordance with the rules for low- power indoor access points. 2. Contention-based protocol, as demonstrated in the test report, is permanently embedded in the chip (IPQ0518+QCN6102+QCN6122+RTL8367SC-CG+RTL8221B-VB-CG) and is not hostdependent. 3. An 11ax IEEE AP’s Transmit Power Envelope element has information fields for power limits for connecting client/subordinate devices. The TPE information is embedded in this device’s signals and used to tell the connecting clients/subordinate that the max TX powers it is allowed to transmit. There is a regulatory info field in this device’s beacon and probe response frames which details this device type when the client/subordinate associates to this device. Statement acknowledging device restrictions: 1. This device was supplied power from a wired connection, has an integrated antenna, is not battery-powered, and does not have a weatherized enclosure. 2. The operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet in the 5.925-6.425 GHz band. 3. This device is prohibited for control of or communications with unmanned aircraft systems, including drones. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-08-16

TP-LinkCorporationLimited 050222-17 AuthoritytoActasAgent Date:April24,2023 AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch,VA22046 ToWhomItMayConcern: ULVerificationServices(Guangzhou)Co.,Ltd,SongShanLakeBranch__isauthorizedtoactonour behalf,untilotherwisenotified,forapplicationstoAmericanCertificationBody,Inc.(ACB). Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludesFCCbenefits,pursuantto Section5301oftheAnti-DrugAbuseActof1988,21U.S.C.862.Further,noparty,asdefinedin47 CFR1.2002(b),totheapplicationissubjecttodenialoffederalbenefits,thatincludesFCCbenefits. WealsodeclarethattheinformationprovidedtotheFCCistrueandcorrecttothebestofour knowledge(47CFR2.911(d))andwehavebeeninformedofthegranteeresponsibilities(47CFR 2.909)withregardtocertifiedequipment. Thankyou, AgencyAgreementExpirationDate:____4 /24/2024 By:_____________________________________SarahWang_____________ (Signature 1 )(Printname) Title:__________LeadofProductCertificationTeam________________ Onbehalfof:_________TP-LinkCorporationLimited._________________________________ (CompanyName) Telephone:_______________+8675526615494___________________ 1 -MustbesignedbyapplicantcontactgivenforapplicantontheFCCsite,orbytheauthorizedagentifanappropriateauthorizedagent letterhasbeenprovided.Lettersshouldbeplacedonappropriateletterhead.

TP-Link Corporation Limited. 050222-17 Request for Confidentiality Date: August 16, 2023 Subject: Confidentiality Request for: ___ 2AXJ4EAP770 _____ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term --------------------------- External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term --------------------------- Test Setup Photos ☐ Short Term ☐ Permanent * 1 User’s Manual TP-Link Corporation Limited.has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __ (specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: (specify ISED expiration date / date of marketing) . Sincerely, By: __________________________ __________ Sarah Wang ______________ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Declaration of Frequency Stability We [TP-Link Corporation Limited] ensure that the product (FCC ID: 2AXJ4EAP770) meets e- CFR Title 47 section 15.407(g) and KDB 789033 D02v02r01 frequency stability such that the emissions are maintained within the band of operation under all conditions of normal operation as specified in the user's manual. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-8-16

TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kon We, TP-Link Corporation Limited EAP770 have the same technical construction including circuit diagram, PCB Layout, components and component layout, all electrical construction and mechanical construction, with EAP773 The difference lies only the power supply. The power adapter supplied with EAP770 and no power adapter with EAP773 Sincerely, By: __________________________ __________ Sarah Wang ______________ (Signature/Title 1 ) (Print name) 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Declaration of Conformity We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Product: BE11000 Ceiling Mount Wi-Fi 7 Access Point FCC ID: 2AXJ4EAP770 Model: EAP770, EAP773 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-8-16

Non-SDR (Software Defined Radio) Cover Letter Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? Yes - go to 2. No, not an SDR No 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? Yes, must be an SDR. No - go to 3. No 3. Is the device capable of operating in any other in any other way than granted, or will be, granted? Yes, - go to 4. No - go to 5. No 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? Yes, qualifies as a part 15 client devices - go to 5. No, must be an SDR. 5. Does the manufacturer elect SDR? Yes, elects to be an SDR. No, Not an SDR No Conclusion: According to the above questions reply, we can confirm this device (FCC ID: 2AXJ4EAP770) must be a Non-SDR device. Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-8-16

External Photographs Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-1 View of EUT-2 Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-3 View of EUT-4 Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-5 View of EUT-6

External Photographs Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-1 View of EUT-2 Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-3 View of EUT-4 Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-5

C B A 12 C 345678 B E D D A 9 料号：7202508759 12345 E 6789 EAP770(US) 1.0_产品规格标贴 A1 80#加强胶珠光合成纸+雾膜 EAP770(US) 1.0 庄剧慈 2023-03-06 白色 TP底壳灰 白色 白色 注：S/N码由工厂打印至27*5mm空白标贴(7210500214) 空白标贴后黏贴至指定条码框上，MAC码、SSID由工厂直接打印在标贴上。 MAC条码由“XXXXXXXXXXXX”生成， 文本打印为“XX-XX-XX-XX-XX-XX”。 SSID以软件生成工具为准 文字转曲（供应商来料效果）54.5*29.5±0.2mm，3.5R，2C 深圳市联洲国际技术有限公司 3mm3mm 3mm 卷装供货： 边距&跳距=3mm 文字方向 文字方向 BE11000 Ceiling Mount Wi-Fi 7 Access Point Model: EAP770 Power: 12V 2.5A PoE: 42.5-57V 1.2A 802.3bt Default Access: http://tplinkeap.net Username: admin Password: admin Model:EAP770(US)Ver:1.0 S/N:XXXXXXXXXXXXX MAC:XX-XX-XX-XX-XX-XX SSID: TP-Link_2.4GHz_XXXXXX SSID: TP-Link_5GHz_XXXXXX SSID: TP-Link_6GHz_XXXXXX Indoor use only MADE IN CHINA FCC ID: 2AXJ4EAP770 IC: 26583-EAP770

C B A 12 C 345678 B E D D A 9 料号： 12345 E 6789 EAP773(US) 1.0_产品规格标贴 A1 80#加强胶珠光合成纸+雾膜 白色 TP底壳灰 白色 白色 文字转曲（供应商来料效果）54.5*29.5±0.2mm，3.5R，2C 深圳市联洲国际技术有限公司 3mm3mm 3mm 卷装供货： 边距&跳距=3mm 文字方向 文字方向 庄剧慈 2023-06-28 注： 工厂自行打印S/N码、MAC、SSID、二维码、设备ID。 MAC条形码由“xxxxxxxxxxxx”生成，文本按“xx-xx-xx-xx-xx-xx”格式打印 设备ID由“XXXXXXXXXXXXXXXXXXXX”生成，文本按 “XXXX-XXXX-XXXX-XXXX-XXXX”格式打印。 SN、MAC、SSID、二维码、设备ID 仅为示意，具体以机型实际/软件生成工具为准 二维码： 尺寸：10*10mm, 码制QR Code； 扫描显示内容（二维码内容为设备ID）：XXXXXXXXXXXXXXXXXXXX 扫描显示内容示例：XXXXXXXXXXXXXXXXXXXX 字体为TP-Link Aktiv，一维码码制使用Code 128，可按实际打印效果调整 BE11000 Ceiling Mount Wi-Fi 7 Access Point Model: EAP773 Power: 12V 2.5A PoE: 42.5-57V 1.2A 802.3bt Default Access: http://tplinkeap.net Username: admin Password: admin Model:EAP773(US) Ver:1.0 S/N:XXXXXXXXXXXXX M AC : X X-X X-X X-X X-X X-X X SSID: TP-Link_2.4GHz_XXXXXX SSID: TP-Link_5GHz_XXXXXX SSID: TP-Link_6GHz_XXXXXX FCC ID: 2AXJ4EAP770 IC: 26583-EAP770 HVIN: EAP770 Indoor use only MADE IN CHINA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Device Key: XXXX-XXXX -XXXX-XXXX-XXXX

Internal Photographs Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-1 Internal View of EUT-2 ANT3: BT ANT2: WIFI 2.4G&5G ANT5: WIFI 6G ANT1: WIFI 2.4G&5G ANT4: WIFI 6G Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-3 Internal View of EUT-4 Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-5

Internal Photographs Page 2 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-1 Internal View of EUT-2 ANT3: BT ANT2: WIFI 2.4G&5G ANT5: WIFI 6G ANT1: WIFI 2.4G&5G ANT4: WIFI 6G Page 3 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-3 Internal View of EUT-4 Page 4 of 4 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-5

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT For BE11000 Ceiling Mount Wi-Fi 7 Access Point MODEL NUMBER: EAP770, EAP773 REPORT NUMBER: 4790851973-1-RF-6 ISSUE DATE: August 29, 2023 FCC ID:2AXJ4EAP770 Prepared for TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4790851973-1-RF-6 Page 2 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 August 29, 2023 Initial Issue REPORT NO.: 4790851973-1-RF-6 Page 3 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. DESCRIPTION OF EUT ..................................................................................................... 6 5. REQUIREMENT ................................................................................................................. 7 REPORT NO.: 4790851973-1-RF-6 Page 4 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Manufacturer Information Company Name: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong EUT Information EUT Name: BE11000 Ceiling Mount Wi-Fi 7 Access Point Model: EAP770 Series Model: EAP773 Model Deference: Please refer to Model Difference Statement Brand: tp-link Sample Received Date: May 12, 2023 Sample Status: Normal Sample ID: 6072980 Date of Tested: June 2, 2023 to August 29, 2023 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR§2.1091 PASS KDB-447498 D01 V06 PASS Prepared By: Checked By: Fanny Huang Denny Huang Engineer Project Associate Senior Project Engineer Approved By: Stephen Guo Operations Manager REPORT NO.: 4790851973-1-RF-6 Page 5 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 and KDB 447498 D01 General RF Exposure Guidance v06. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Delcaration of Conformity (DoC) and Certification rules ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with ISED. The Company Number is 21320 and the test lab Conformity Assessment Body Identifier (CABID) is CN0046. VCCI (Registration No.: G-20019, R-20004, C-20012 and T-20011) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber D, the VCCI registration No. is G-20019 and R-20004 Shielding Room B , the VCCI registration No. is C-20012 and T-20011 Note 1: All tests measurement facilities use to collect the measurement data are located at Building 10, Innovation Technology Park, Song Shan Lake Hi tech Development Zone, Dongguan, 523808, China Note 2: The test anechoic chamber in UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch had been calibrated and compared to the open field sites and the test anechoic chamber is shown to be equivalent to or worst case from the open field site. Note 3: For below 30MHz, lab had performed measurements at test anechoic chamber and comparing to measurements obtained on an open field site. And these measurements below 30MHz had been correlated to measurements performed on an OFS. REPORT NO.: 4790851973-1-RF-6 Page 6 of 8 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Servic…

Text truncated - open the document above for the full version.

Product Model： EAP770 Manufacturer： tp-link Test Date： 2023.8.25 Tested By： Fang Chao TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Konga TEL: 00852-37585503 http://www.tp-link.com/en Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. Gain and Radiation Pattern ............................................................................. 5 3.1 Measurement Procedure ......................................................................................... 5 3.2 Test Setup ............................................................................................................... 6 3.3 S Parameter Test Data ............................................................................................ 7 3.4 Antenna Peak Gain ................................................................................................. 9 3.5 Antenna Radiation Pattern ....................................................................................... 9 Page 3 1. Antenna Distribution EAP770 2. Electrical Characteristics Ant1 Frequency 2400 ~ 2500 &5150~5850MHz Impedance 50Ohm Antenna Type IFA Antenna Gain 3.00dBi@2400~2500MHz 3.00dBi@5150~5850MHz Radiation pattern Omni-Directional Page 4 tp-link P/N 6035500202 Ant2 Frequency 2400 ~ 2500 &5150~5850MHz Impedance 50Ohm Antenna Type IFA Antenna Gain 3.00dBi@2400~2500MHz 3.00dBi@5150~5850MHz Radiation pattern Omni-Directional tp-link P/N 6035500202 Ant3 Frequency 2400 ~ 2500MHz Impedance 50Ohm Antenna Type IFA Antenna Gain 3.00d…

Text truncated - open the document above for the full version.
