2AXJ4P306Smart Wi-Fi Outlet Extender

Appearance Quick Start Guide Smart Wi-Fi Outlet Extender Set Up Your Outlet Extender Smart 1 2 3 Always On Images may differ from actual product. ©2023 TP-Link 7106510051 REV1.0.0 Each outlet can be independently controlled from your phone. Allows you to set conditions for turning on/off the integrated night light on the Tapo app. System LED Smart Outlet LED (1-3) Smart Outlets (Left 1-3) Common Outlets (Right 1-3) Ambient Light Sensor Buttons (1-3) 8 USB-A Ports 9 USB LED 7 USB Type-C Port Download Tapo App Get the Tapo app from the App Store or Google Play. OR Power Up & Set Up Plug in your outlet extender. Tap the button in the app and select your model. Follow the app instructions to complete setup. Integrate Third-Party Services To control your smart plug by voice, go to Me > Third-Party Services in the Tapo app and integrate Alexa, Google Assistant and other third-party services. 1 2 3 Press one of them once to turn on/off the corresponding outlet. Press and hold one of them for 5s to reset Wi-Fi while keeping other settings. Press and hold for 10s one of them to restore to factory default settings. Button Explanations 4 5 3 2 1 9 8 7 6 Solid white Starting up; Connected to Cloud. System LED Status Blinking white and orange slowly Ready for setup; Reset Wi-Fi. Blinking white and orange quickly Restore to factory default settings. Blinking orange slowly Disconnected from Wi-Fi. Solid orange Connected to Wi-Fi. LED Status Event Firmware updating.Blinking white slowly Buttons (1-3) WiFi智慧擴充插座 More Stable Installation You can install the outlet extender onto a duplex outlet by using the provided screw and/or the stabilizing post for reinforcement. Option 2: Via Stabilizing Post 1 Measure the distance between the two outlets of the duplex outlet. Option 1: Via Mounting Screw 1. Plug your Tapo device into a duplex outlet. 2 Insert the provided screw into the mounting hole and tighten the screw to secure the outlet extender. For stabilizing post. Notch 2 For mounting screw. Mounting Hole 1 35 40 45 0 35 40 45 0 35 40 45 2 4 3 2 Insert the stabilizing post into the notch of your outlet extender. Rotate clockwise until it is semi-tightened. 3 Slide the post to the measured distance so that the post can plug into the other outlet. Rotate clock wise to tighten the post. 4 Plug your outlet extender into the duplex outlet. 1 1 1 2 2 3 4 Note: The removable stabilizing post makes the device fit any type of wall socket, such as a duplex outlet, decorator outlet, USB receptacle, or GFCI outlet. Need some help? Visit https://www.tapo.com/support/ for technical support, user guides, FAQs, warranty & more ? Safety Notice • Do not ingest the stabilizing post. • Plug the product into the wall outlets with earthing connection through the plug. • Do not use the stabilizing post as a common tool. • Risk of Electric Shock. Do not allow to be used as a toy. Close attention is necessary when used by or near children to reduce the risk of ingestion of the removed stabilizing post. • If the stabilizing post is not installed into the outlet extender or removed from the outlet extender, do not place it in reach of children. CAUTION • Contains Always On Receptacles. To Reduce the Risk of Electric Shock – Disconnect the equipment from this device before servicing. • To reduce the risk of fire or electric shock, do not use this device with a receptacle in which the slot openings do not align with the blades. • To reduce the risk of fire or electric shock, use this device to outlets with a pitch of 38.8 mm ~ 43.8 mm . Specifications Input: 125V~ 60Hz 15A 1875W MAX Output: Receptacle Outlet: 15A MAX USB Single Port: 5V 3A / 9V 2A / 12V 1.5A USB Multiple Ports: 5V 3A (Total) CAUTION: Risk of electric shock. Do not insert your measurement tool into the outlets. An all-pole mains switch in accordance with IEC 62368-1 Annex L shall be incorporated in the electrical installation of the building. And the contact separation of the switch shall not less than 1.5 mm. FCC compliance information statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1 )This device may not cause harmful interference. 2 )This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.…

Text truncated - open the document above for the full version.

TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong 012423-17 rev2 Certification Application Attestation Statements Date: March 7, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) _____TP-Link Corporation Limited______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ____ TP-Link Corporation Limited_______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is /- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ____Sarah Wang__ (Signature 2 ) (Print name) Title: Compliance manager Company: TP-Link Corporation Limited_____ Telephone: +86 755 21534921 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. Product: Smart Wi-Fi Outlet Extender FCC ID: 2AXJ4P306 Model: Tapo P306 Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-11-21

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2AXJ4P306 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-11-21

Declaration of Authorization We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Smart Wi-Fi Outlet Extender FCC ID: 2AXJ4P306 Model: Tapo P306 Brand: tp-link Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-11-21

Declaration of Conformity We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Product: Smart Wi-Fi Outlet Extender FCC ID: 2AXJ4P306 Model: Tapo P306 Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-11-21

Report No.: 2306TW0102-UE Product: Smart Wi-Fi Outlet Extender Brand Name: tp-link Model Number: Tapo P306 1 of 3 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2306TW0102-UE 2 of 3 (3) EUT Photo (4) EUT Photo Report No.: 2306TW0102-UE 3 of 3 (5) EUT Photo (6) EUT Photo

Label Label Location

MRT Technology (Taiwan) Co., Ltd Report No.: 2306TW0102-U4 Phone: +886-3-3288388 Report Version 1.0 Web: www.mrt-cert.com Issue Date: 2023-11-29 Page Number: 1 of 11 RF Exposure Evaluation Declaration FCC ID : 2AXJ4P306 Applicant : TP-Link Corporation Limited Application Type : Certification Product : Smart Wi-Fi Outlet Extender Model No. : Tapo P306 Brand Name : tp-link Trademark : FCC Classification : Digital Transmission System (DTS) Received Date : June 2, 2023 Test By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2306TW0102-U4 Page Number: 2 of 11 Revision History Report No. Version Description Issue Date Note 2306TW0102-U4 1.0 Original Report 2023-11-29 Valid Report No.: 2306TW0102-U4 Page Number: 3 of 11 CONTENTS Description Page 1. INTRODUCTION .................................................................................................................... 5 1.1. Scope .......................................................................................................................... 5 1.2. MRT Test Location ....................................................................................................... 5 2. PRODUCT INFORMATION .................................................................................................... 6 2.1. Feature of Equipment under Test ................................................................................. 6 2.2. Description of Available Antennas ................................................................................ 6 2.3. Device Classification .................................................................................................... 6 2.4. Applied Standards ........................................................................................................ 6 3. RF Exposure Evaluation ...................................................................................................... 7 3.1. Limits ........................................................................................................................... 7 3.2. MPE Exemptions ......................................................................................................... 8 3.3. Test Result of RF Exposure Evaluation ....................................................................... 11 Report No.: 2306TW0102-U4 Page Number: 4 of 11 General Information Applicant TP-Link Corporation Limited Applicant Address Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Manufacturer TP-Link Corporation Limited Manufacturer Address Room901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, HongKong Test Site MRT Technology (Taiwan) Co., Ltd Test Site Address No. 38, Fuxing Second Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C) MRT FCC Registration No. 291082 Test Device Serial No. N/A Production Pre-Production Engineering Test Facility / Accreditations 1. MRT facility is a FCC registered (Reg. No. 291082) test facility with the site description report on file and is designated by the FCC as an Accredited Test Firm. 2. MRT facility is an IC registered (MRT Reg. No. 21723) test laboratory with the site description on file at Industry Canada. 3. MRT Lab is accredited to ISO 17025 by the Taiwan Accreditation Foundation (TAF Cert. No. 3261) in EMC, Telecommunications and Radio testing for FCC (Designation Number: TW3261), Industry Canada, EU and TELEC Rules. Report No.: 2306TW0102-U4 Page Number: 5 of 11 1. INTRODUCTION 1.1. Scope Measurement and determination of electromagnetic emissions (EMC) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission and the Innovation, Science and Economic Development Canada and Certification and Engineering Bureau. 1.2. MRT Test Location The map below shows the location of the MRT LABORATORY, its proximity to the Taoyuan City. These measurement tests were conducted at the MRT Technology (Taiwan) Co., Ltd. Facility located at No.38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 33377, Taiwan (R.O.C). Report No.: 2306TW0102-U4 Page Number: 6 of 11 2. PRODUCT INFORMATION 2.1. Feature of Equipment under Test Product Name: Smart Wi-Fi Outlet Extender Model No.: Tapo P306 Brand Name: tp-link Specification 802.11b/g/n Bluetooth Mode: V4.2 2.2. Description of Available Antennas Antenna Type Frequency Band (MHz) Antenna Gain (dBi) Ant 0 Ant 1 Monopole 2400 ~ 2483.5 2.08 2.37 Notes: 1. The EUT supports SISO only, and which are switched by the Switch IC. 2. All information of antenna were from the AUT report. 2.3. Device Classification According to the user manual, the antenna of this device is at least 20cm away from the body of the user, this device is classified as a Mobile Device. So, the RF exposure evaluation requirements of § 2.1091 for mobile device exposure conditions subject to MPE limits. 2.4. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⚫ FCC Part 2.1091 & KDB 447498 D04 Interim General RF Exposure Guidance v01 Report No.: 2306TW0102-U4 Page Number: 7 of 11 3. RF Exposure Evaluation 3.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) …

Text truncated - open the document above for the full version.

MRT Technology (Taiwan) Co., Ltd Report No.: 2306TW0102-U2 Phone: +886-3-3288388 Report Version: 1.0 Fax: +886-3-3288918 Issue Date: 2023-11-29 Web: www.mrt-cert.com Page Number: 1 of 66 FCC ID : 2AXJ4P306 APPLICANT : TP-Link Corporation Limited Application Type : Certification Product : Smart Wi-Fi Outlet Extender Model No. : Tapo P306 Brand Name : tp-link Trademark : FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : Part 15.247 Test Procedure(s) : ANSI C63.10-2013 Received Date : June 2, 2023 Test Date : June 12, 2023~ August 31, 2023 RF MEASUREMENT REPORT Tested By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) The test results only relate to the tested sample. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2306TW0102-U2 Page Number: 2 of 66 Revision History Report No. Version Description Issue Date Note 2306TW0102-U2 1.0 Original Report 2023-11-29 Valid Report No.: 2306TW0102-U2 Page Number: 3 of 66 CONTENTS Description Page §2.1033 General Information ......................................................................................................... 5 1. INTRODUCTION ..................................................................................................................... 6 1.1. Scope .................................................................................................................................... 6 1.2. MRT Test Location ................................................................................................................ 6 2. PRODUCT INFORMATION ..................................................................................................... 7 2.1. Equipment Description .......................................................................................................... 7 2.2. Product Specification Subjective to this Standard .................................................................. 7 2.3. Test Mode ............................................................................................................................. 7 2.4. Operation Frequency / Channel List ...................................................................................... 8 2.5. Description of Available Antennas ......................................................................................... 8 2.6. Test Configuration ................................................................................................................. 9 2.7. Test System Details ............................................................................................................ 10 2.8. Test Software ...................................................................................................................... 10 2.9. Applied Standards ............................................................................................................... 10 2.10. EMI Suppression Device(s)/Modifications ........................................................................... 10 2.11. Labeling Requirements ....................................................................................................... 10 3. DESCRIPTION of TEST ......................................................................................................... 11 3.1. Evaluation Procedure .......................................................................................................... 11 3.2. AC Line Conducted Emissions ............................................................................................ 11 3.3. Radiated Emissions ............................................................................................................ 12 4. ANTENNA REQUIREMENTS ................................................................................................ 13 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................ 14 6. MEASUREMENT UNCERTAINTY ......................................................................................... 15 7. TEST RESULT ...................................................................................................................... 16 7.1. Summary ............................................................................................................................. 16 7.2. 6dB Bandwidth Measurement ............................................................................................. 17 7.2.1. Test Limit ......................................................................................................................... 17 7.2.2. Test Procedure used ....................................................................................................... 17 7.2.3. Test Setting ..................................................................................................................... 17 7.2.4. Test Setup ....................................................................................................................... 17 7.2.5. Test Result ...................................................................................................................... 18 7.3. Output Power Measurement ................................................................................................ 19 7.3.1. Test Limit ......................................................................................................................... 19 7.3.2. Test Procedure Used ....................................................................................................... 19 7.3.3. Test Setting ..............................................…

Text truncated - open the document above for the full version.

MRT Technology (Taiwan) Co., Ltd Report No.: 2306TW0102-U3 Phone: +886-3-3288388 Report Version: 1.0 Web: www.mrt-cert.com Issue Date: 2023-11-29 Page Number: 1 of 181 FCC ID : 2AXJ4P306 Applicant : TP-Link Corporation Limited Application Type : Certification Product : Smart Wi-Fi Outlet Extender Model No. : Tapo P306 Brand Name : tp-link Trademark : FCC Classification : Digital Transmission System (DTS) FCC Rule Part(s) : Part15 Subpart C (Section 15.247) Received Date : June 2, 2023 Test Date : June 8, 2023~ August 31, 2023 RF MEASUREMENT REPORT The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Tested By : ( Owen Tsai ) Reviewed By : ( Paddy Chen ) Approved By : ( Chenz Ker) Report No.: 2306TW0102-U3 Page Number: 2 of 181 Revision History Report No. Version Description Issue Date Note 2306TW0102-U3 1.0 Original Report 2023-11-29 Valid Report No.: 2306TW0102-U3 Page Number: 3 of 181 CONTENTS Description Page 1. INTRODUCTION ...................................................................................................................... 6 1.1. Scope ........................................................................................................................... 6 1.2. MRT Test Location ....................................................................................................... 6 2. PRODUCT INFORMATION ...................................................................................................... 7 2.1. Feature of Equipment under Test ................................................................................. 7 2.2. Product Specification Subjective to this Report ............................................................ 7 2.3. Working Frequencies for this report .............................................................................. 8 2.4. Description of Available Antennas ................................................................................. 8 2.5. Test Mode .................................................................................................................... 8 2.6. Configuration of Test System ....................................................................................... 9 2.7. Test System Details ................................................................................................... 10 2.8. Description of Test Software ....................................................................................... 10 2.9. Applied Standards ...................................................................................................... 10 2.10. Duty Cycle ................................................................................................................... 11 2.11. Test Configuration ...................................................................................................... 12 2.12. EMI Suppression Device(s)/Modifications ................................................................... 12 2.13. Labeling Requirements ............................................................................................... 12 3. DESCRIPTION of TEST ......................................................................................................... 13 3.1. Evaluation Procedure ................................................................................................. 13 3.2. AC Line Conducted Emissions ................................................................................... 13 3.3. Radiated Emissions .................................................................................................... 14 4. ANTENNA REQUIREMENTS................................................................................................. 15 5. TEST EQUIPMENT CALIBRATION DATE ............................................................................. 16 6. MEASUREMENT UNCERTAINTY ......................................................................................... 18 7. TEST RESULT ....................................................................................................................... 19 7.1. Summary .................................................................................................................... 19 7.2. 6dB Bandwidth Measurement ..................................................................................... 20 7.2.1. Test Limit .................................................................................................................... 20 7.2.2. Test Procedure used .................................................................................................. 20 7.2.3. Test Setting ................................................................................................................ 20 7.2.4. Test Setup .................................................................................................................. 20 7.2.5. Test Result ................................................................................................................. 21 7.3. Output Power Measurement ....................................................................................... 24 Report No.: 2306TW0102-U3 Page Number: 4 of 181 7.3.1. Test Limit .................................................................................................................... 24 7.3.2. Test Procedure Used .................................................................................................. 24 7.3.3. Test Setting ............................................................................................................…

Text truncated - open the document above for the full version.

Product Model： Tapo P306 Manufacturer： BIG FIELD GLOBAL PTE. LTD Test Date： 2023.05.09 Tested By： Tan Yiyi BIG FIELD GLOBAL PTE. LTD. 7 Temasek Boulevard #29-03 Suntec Tower One, Singapore 038987, Index 1. Antenna Distribution ........................................................................................ 3 2. Electrical Characteristics ................................................................................ 3 3. Gain and Radiation Pattern ............................................................................. 4 3.1 Measurement Procedure ......................................................................................... 4 3.2 Test Setup ............................................................................................................... 5 3.3 S Parameter Test Data ............................................................................................ 6 3.4 Antenna Peak Gain ................................................................................................. 6 3.5 Antenna Radiation Pattern ....................................................................................... 7 Page 3 1. Antenna Distribution Tapo P306 2. Electrical Characteristics Ant1 Frequency 2400~25…
