2AXJ4KS230V2Smart Wi-Fi Dimmer Switch

Label the Traveler wires in the two wallboxes. 3 Disconnect all wires from the two dumb switches, and then connect them to the Smart 3-Way Dimmer as below. No need to distinguish between the two traveler wires. 7 *You can find step-by-step instructions in the Kasa Smart app. Wire Your 3-Way Dimmer Turn off the circuit breaker. Then remove the two wallplates. Your dumb switches might look like this. 1 Line (Live/Hot): Usually black. One end is connected to the circuit breaker, the other to your FIRST 3-Way switch. Load: Usually black. One end is connected to the light fixture, the other to your SECOND 3-Way switch. Travelers: Usually one is black and the other is red. Neutral: Usually a bundle of white wires, not connected to the dumb switch. They may be folded up in the very back. Ground: Usually green or copper. Get to know the wires. 2 Two Traveler wires (Opposite each other with the same color screws. ) Line/Load wire (Black. Line and Load wires are in different boxes. ) 3) Label the other wire in the other wallbox as Load wire. This is the wallbox for the satellite dimmer. Identify Line and Load wires in the two wallboxes. 5 1)Turn on the circuit breaker. Use a voltage detector to identify the energized wire (Line wire). 2)Turn off the circuit breaker and label the Line wire. This is the wallbox for the main dimmer. Take care to avoid electric shocks. Load wireLine wire Label the Neutral wire in the wallbox for the main dimmer, and the Ground wires in both wallboxes. 6 Only disconnect the Line/Load wires from the two dumb switches, then cover them with provided wire nuts for safety. 4 Smart Wi-Fi Dimmer Switch KS230 KIT Quick Start Guide 7106509733 REV2.0.0*Images may differ from actual products. This quick start guide only applies to version 2.0. Wiring guide: Scan QR code or visit https://www.tp-link.com/support/faq/3400/ Set Up Your 3-Way Dimmer S T E P 2 SET UP Tap the button in the app. Select Smart Switches then Smart 3-Way Dimmer. Then follow the app instructions to set up your smart dimmer. Get the Kasa Smart app from the App Store or Google Play. DOWNLOAD APP S T EP 1 OR Satellite Dimmer Main Dimmer Power SourceTo Light Bulbs Electrical Cable (Usually inside wall) ▲ The wire colors used in this guide are recommended by National Electric Codes (NEC). They may differ from your actual wire colors. Check the main dimmer LED to see if the wires are connected correctly. Blinking red quickly: The wires are wrongly connected. Please check the wiring. It’s recommended to consult an electrician. 1. The main and satellite dimmers cannot work separately or with traditional 3-way switches. 2. You can find the detailed wiring instructions in the Kasa Smart app. 1. Method of mounting: Independently mounted (Vertically position only); 2. High Voltage - Disconnect power supply before servicing. CAUTION: Note: Need some help? ? Visit www.tp-link.com/support for technical support, user guides, FAQs, warranty & more Brightness Indicators Main Dimmer Button & LEDSatellite Dimmer Button & LED Buttons Buttons Starting up.Solid amber Blinking amber Blinking green Solid red Stay green for 30s Blinking amber & green Connecting to Wi-Fi. Ready for setup. The dimmer is being reset to factory default settings. Solid white The dimmer is off. LED is on to indicate the dimmer location in the dark. Disconnected from Wi-Fi. Connected to Wi-Fi. Position Indicator Specifications Safety Notice Before installing, servicing or removing the switch, read and follow all safety precautions including the following: • CAUTION – Risk of Electric Shock – More than one disconnect switch may be required to de-energize the equipment before servicing. A circuit breaker which disconnects the Line and Neutral conductor simultaneously is suitable. Ensure power is off at the circuit breaker before removing or installing any switch. Use a non-contact voltage tester to ensure the power is off. • The Smart Switch must be installed and used in accordance with the National Electric Code (NEC) or your local electrical code. If you are unfamiliar with these codes and requirements, or are uncomfortable performing the installation, consult a qualified electrician. • Do not install the Smart Switch with wet hands or when standing on wet or damp surfaces. • Install only in a suitable UL Listed outlet box (suitable dimensions: H > 2.95 in./75 mm, W > 1.81 in./46 mm, D > 2 in./51 mm). • Tighten terminal screws to 13 lbf-in for the main dimmer switch, and 11 lbf-in for the satellite switch. • Keep the device away from water, fire, humidity or hot environments. • Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. • Do not use the device where wireless devices are not allowed. Rating: 120 V~ 60 Hz Load: 300 W Incandescent 150 W LED (MLV) Operation temperature: 0~40°C Dimming Type*: Leading Edge Dimming / TRIAC Phase Cut Operating control, Type 1 action Pollution Degree 2 Rated Impulse Voltage 2500 V Software Class A *It’s also suggested to contact your bulb’s Support to check the supported dimming type of the bulb. ©2022 TP-Link Press to turn on / off your dimmer. Restart Reset On/Off Button Press and hold for about 5s to reset Wi-Fi while keeping previous settings. Press to restart your dimmer. Decrease or increase the brightness. Press and hold for about 10s to restore your dimmer to factory default settings. / Brightness Indicators Indicate the brightness of the light. More indicators means highers brightness. Press to turn on / off your dimmer. On/Off Button Decrease or increase the brightness. / Indicator LED The dimmer is off. LED is on to indicate the dimmer location in the dark. Position Indicator Appearance This 3-Way Dimmer Kit has a main dimmer and a satellite dimmer. They cannot work separately or with traditional 3-way switches. Main DimmerSatellite Dimmer Brightness Indicators Dimmer Buttons On/Off Button Position Indicator Reset Restart FCC Statement This equipment has been tested…

Text truncated - open the document above for the full version.

TP-Link Corporation Limited 030122-15 Authority to Act as Agent Date: August 12, 2022 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: BTL Inc./Rose Liu is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 2023-08-12 By: __________________________ Sarah Wang (Signature 1 ) (Print name) Title: Regulatory Compliance Manager On behalf of: TP-Link Corporation Limited (Company Name) Telephone: 00852-37585503 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

TP-Link Corporation Limited 030122-15 Request for Confidentiality Date: August 12, 2022 Subject: Confidentiality Request for: 2AXJ4KS230V2 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual TP-Link Corporation Limited has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: Regulatory Compliance Manager Sarah Wang (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Declaration of Conformity We Name: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Declare that: Product: Smart Wi-Fi Dimmer Switch FCC ID: 2AXJ4KS230V2 Model: KS230 KIT Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2022-08-12

TP-Link Corporation Limited Wi-Fi Channel 12 and 13 Declaration Letter Date: 2022-08-12 We, the undersigned company Company Name: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon,Hong Kong Declare that: Product description: Smart Wi-Fi Dimmer Switch Type designation: KS230 KIT Brand: tp-link FCC ID: 2AXJ4KS230V2 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Sarah Wang Tel: 00852-37585503 Email: [email protected]

Project No.: 2207C049 Page 1 of 12 ATTACHMENT PHOTOGRAPHS OF EUT Project No.: 2207C049 Page 2 of 12 Project No.: 2207C049 Page 3 of 12

Project No.: 2207C049 Page 5 of 12 KS230 KIT (Main)

Project No.: 2207C049 Page 10 of 12 KS230 KIT (Satellite)

KS230Kit(US)2.0(Main)_产品规格标贴 2022-06-22 陈博博 KS230Kit(US)2.0(Main) 白盾-128 50#网纹胶亮白PET+可打印雾膜 A1 注：序列号由工厂直接打印在产品规格标贴上（以上条码仅为示意） 标贴粘贴效果示意图 CERTIFIED TO CSA STD E60730-1 CONFORMS TO UL STD.60730-1 Smart Wi-Fi Dimmer Switch Model: KS230 KIT(US) Ver:2.0 S/N: XXXXXXXXXXXXX Rating: 120VAC 60Hz 300W Incandescent 150W LED Model: KS230 KIT FCC ID: 2AXJ4KS230V2 Main IC: 26583-KS230V2 HVIN: KS230V2 Traveler Traveler Line Traveler GroundNeutral 7202508192 Use 14 AWG or larger wires rated at least 75°C

KS230Kit(US)2.0(Satellite)_产品规格标贴 2022-06-22 陈博博 KS230Kit(US)2.0(Satellite) 白盾-128 50#网纹胶亮白PET+雾膜 A1 标贴尺寸：29.5*54.5mm ±0.2,C2,R3.5 实际粘贴效果图 29.5 C2 54.5 R3.5 注：MIC由工厂直接打印在产品规格标贴上（以上条码仅为示意） 7202508193 Smart Wi-Fi Dimmer Switch Rating: 120VAC 60Hz 300W Incandescent 150W LED Model: KS230 KIT M I C : X X-X X-X X-X X-X X-X X U S / 2 . 0 Satellite CAN ICES-3 (B)/NMB-3(B) CERTIFIED TO CSA STD E60730-1 CONFORMS TO UL STD.60730-1 Traveler Traveler Load Ground

Project No.: 2207C049 Page 4 of 12

Project No.: 2207C049 Page 6 of 12 Project No.: 2207C049 Page 7 of 12 Project No.: 2207C049 Page 8 of 12 Antenna Project No.: 2207C049 Page 9 of 12

Project No.: 2207C049 Page 11 of 12 Project No.: 2207C049 Page 12 of 12

Report No.: BTL-ISEDR-1-2207C049 Page 1 of 91 ISED Radio Test Report IC : 26583-KS230V2 This report concerns: Original Grant Project No. : 2207C049 Equipment : Smart Wi-Fi Dimmer Switch Brand Name : tp-link Test Model : KS230 KIT Series Model : N/A Applicant : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Manufacturer : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Date of Receipt : Jul. 11, 2022 Date of Test : Jul. 12, 2022 ~ Aug. 05, 2022 Issued Date : Aug. 29, 2022 Report Version : R01 Test Sample : Engineering Sample No.: DG20220711102 for conducted, DG20220711103 for others. Standard(s) : RSS-247,Issue 2, Feb. 2017 RSS-Gen,Issue 5, Amendment 2, Feb. 2021 ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Sheldon Ou Approved by : Chay Cai BTL Inc. No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People’s Republic of China. Te l : +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-ISEDR-1-2207C049 Page 2 of 91 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-ISEDR-1-2207C049 Page 3 of 91 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 12 2.4 DUTY CYCLE 13 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 15 2.6 SUPPORT UNITS 15 3 . AC POWER LINE CONDUCTED EMISSIONS 16 3.1 LIMIT 16 3.2 TEST PROCEDURE 16 3.3 DEVIATION FROM TEST STANDARD 16 3.4 TEST SETUP 17 3.5 EUT OPERATION CONDITIONS 17 3.6 TEST RESULTS 17 4 . RADIATED EMISSIONS 18 4.1 LIMIT 18 4.2 TEST PROCEDURE 19 4.3 DEVIATION FROM TEST STANDARD 20 4.4 TEST SETUP 20 4.5 EUT OPERATION CONDITIONS 21 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 21 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 21 4.8 TEST RESULTS - ABOVE 1000 MHZ 21 5 . BANDWIDTH 22 5.1 LIMIT 22 5.2 TEST PROCEDURE 22 5.3 DEVIATION FROM STANDARD 22 5.4 TEST SETUP 22 Report No.: BTL-ISEDR-1-2207C049 Page 4 of 91 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 22 5.6 TEST RESULTS 22 6 . MAXIMUM AVERAGE OUTPUT POWER & E.I.R.P. 23 6.1 LIMIT 23 6.2 TEST PROCEDURE 23 6.3 DEVIATION FROM STANDARD 23 6.4 TEST SETUP 23 6.5 EUT OPERATION CONDITIONS 23 6.6 TEST RESULTS 23 7 . CONDUCTED SPURIOUS EMISSIONS 24 7.1 LIMIT 24 7.2 TEST PROCEDURE 24 7.3 DEVIATION FROM STANDARD 24 7.4 TEST SETUP 24 7.5 EUT OPERATION CONDITIONS 24 7.6 TEST RESULTS 24 8 . POWER SPECTRAL DENSITY 25 8.1 LIMIT 25 8.2 TEST PROCEDURE 25 8.3 DEVIATION FROM STANDARD 25 8.4 TEST SETUP 25 8.5 EUT OPERATION CONDITIONS 25 8.6 TEST RESULTS 25 9 . MEASUREMENT INSTRUMENTS LIST 26 10 . EUT TEST PHOTO 28 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 33 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 36 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 41 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 44 APPENDIX E - BANDWIDTH 75 APPENDIX F - MAXIMUM AVERAGE OUTPUT POWER & 79 E.I.R.P. 79 Report No.: BTL-ISEDR-1-2207C049 Page 5 of 91 Table of Contents Page APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 82 APPENDIX H - POWER SPECTRAL DENSITY 89 Report No.: BTL-ISEDR-1-2207C049 Page 6 of 91 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-ISEDR-1-2207C049 R00 Original Report. Aug. 12, 2022 Invalid BTL-ISEDR-1-2207C049 R01 Added FVIN. Aug. 29, 2022 Valid Report No.: BTL-ISEDR-1-2207C049 Page 7 of 91 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): RSS-247,Issue 2, Feb. 2017 RSS-Gen,Issue 5, Amendment 2, Feb. 2021 Standard(s) Section Test Item Test Result Judgment Remark RSS-Gen 8.8 AC Power Line Conducted Emissions APPENDIX A PASS ------ RSS-247 5.5 RSS-Gen 8.9 RSS-Gen 8.10 Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ RSS-…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-2207C049 Page 1 of 3 FCC RF EXPOSURE REPORT FCC ID: 2AXJ4KS230V2 Project No. : 2207C049 Equipment : Smart Wi-Fi Dimmer Switch Brand Name : tp-link Test Model : KS230 KIT Series Model : N/A Applicant : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Manufacturer : TP-Link Corporation Limited Address : Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Date of Receipt : Jul. 11, 2022 Date of Test : Jul. 12, 2022 ~ Aug. 05, 2022 Issued Date : Aug. 12, 2022 Report Version : R00 Test Sample : Engineering Sample No.: DG20220711102 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Sheldon Ou Approved by : Chay Cai BTL Inc. No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People’s Republic of China. Te l : +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-2-2207C049 Page 2 of 3 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-2-2207C049 R00 Original Report Aug. 12, 2022 Valid Report No.: BTL-FCCP-2-2207C049 Page 3 of 3 1. TEST FACILITY The test facilities used to collect the test data in this report is at the location of No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People’s Republic of China. BTL's Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Antenna Specification: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 tp -link N/A PIFA N/A 2.80 Note: The antenna gain is provided by the manufacturer. 3. TEST RESULTS Antenna Gain (dBi) Antenna Gain (numeric) Max. Average Output Power (dBm) Max. Average Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.80 1.9055 21.86 153.4617 0.05820 1 Complies Note: The calculated distance is 20 cm. Output power including tune up tolerance. End of Test Report

Product Number: Product Name: Product Number: Product Name: COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2011 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. http://www.tp-link.com Product Number: Product Name: Specification For Approval Date: File No. : Version: 1.0 Customer: / Customer P/N : / TP-LINK P/N: Description: 金属插件天线 TP-LINK Checked By: Customer Approved By: TP-LINK TECHNOLOGIES CO., LTD. South Buiding, No.5 Keyuan Road, Central Zone, Science&Technology Park, Nanshan, Shenzhen, P.R.China TEL: + 86 755 26612350 + 86 755 26504400 http:// www.tp-link.com Product Number: Product Name: Page 1 Version:1.0 Issue Date: Index Specification ............................................................................................................. 2 I. Characteristics and Reliability Test ................................................................ 3 II. Antenna – S Parameter Test Data ................................................................... 4 III. Antenna – Radiation Pattern Test Data .......................................................... 5 Packing Drawing ...................................................................................................... 6 Product Number: Product Name: Page 2 Version:1.0 Issue Date: Specification Sample Photo A. Electrical Characteristics Frequency 2400 ~ 2500 MHz Impedance 50 Ohm S.W.R. <= 2.0 Antenna Gain 2.93dBi@2400~2500MHz Max Input Power <= 2 W Polarization Linear Radiation pattern Omni-Directional B. Material & Mechanical Characteristics Material of Radiator Cu Material of Plastic / Cable Type / Connector Type / Connector Pull Test / C. Environmental Operation Temperature In accordance with PCB Storage Temperature In accordance with PCB Product Number: Product Name: Page 3 Version:1.0 Issue Date: I. Characteristics and Reliability Test Test Items Test Condition and Procedure Requirements C1 S.W.R. Set DUT on Network Analyzer; make individual calibration to test Directive DUT specification C2 Antenna Gain Set DUT on Antenna Chamber; make individual calibration to test Directive DUT specification M1 Vibration MIL-STD-202G, 201 A Amplitude: 0.03 inch (0.76mm); Freq: 10 to 55 Hz 3 directions; 2 hours for each direction 1. No Visual Damage 2.FrequencyTol.<=5% M2 Random Drop Height: 1.5 Meter; 3 directions; 1 time for each direction 1. No parts separated 2. Frequency Tol.<=5% M3 Drop Test Combine DUT with router； Height: 0.6 Meter; 1 direction; 3 times for the direction 1. No parts separated 2. Frequency Tol.<=5% M4 Terminal- Pull Test MIL-STD-202G, 211A, cond. A Holding with individual specification; force applied to axis of terminal 1. Directive DUT specification 2. Frequency Tol.<=5% M5 Dimension Inspection of dimension, color, material, package, surface process Directive DUT specification E1 Salt Spray SE-GS-90T Temp: 35°C; RH: 93%±3%; NaCl solution proportion: 1.026～ 1.041; Time:12 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<=5% E2 Thermal Shock 1Cycle: -20°C (30 minutes) to +70°C (30 minutes) Cycles: 24 After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<=5% E3 Life (HighTemp.) MIL-STD-202G,108A, cond. A Temp: 70°C; Time: 8 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<=5% Product Number: Product Name: Page 4 Version:1.0 Issue Date: II. Antenna – S Parameter Test Data Product Number: Product Name: Page 5 Version:1.0 Issue Date: III. Antenna – Radiation Pattern Test Data Testing Equipment Specification Microwave Chamber ETS AMS-8923 Testing Equipment Agilent E5071C Ant 1 Freq. (MHz) 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 Gain (dBi) 2.43 2.38 2.37 2.34 2.43 2.47 2.58 2.68 2.80 2.86 2.93 Effi. (%) 52.11 52.15 51.84 51.43 52.27 52.80 53.78 53.85 54.42 54.57 55.31 Theta=90 Product Number: Product Name: Page 6 Version:1.0 Issue Date: Packing Drawing

Report No.: BTL-FCCP-1-2207C049 Page 28 of 90 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-2207C049 Page 29 of 90 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-1-2207C049 Page 30 of 90 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-1-2207C049 Page 31 of 90 Radiated Emissions Test Photos Above 1 GHz Report No.: BTL-FCCP-1-2207C049 Page 32 of 90 Conducted Test Photos
