2AXJ4L510Tapo Smart Wi-Fi Light Bulb, Dimmable

User Guide Tapo Smart Wi-Fi Light Bulb Tapo L510/L530 Series © 2023 TP-Link 1910013377 REV1.4.0 Contents About This Guide ····················································1 Introduction ·······························································2 Set Up Your Smart Bulb ·······································4 Basic Device Control ············································5 Configure Your Smart Bulb ································6 Group ·············································································9 Smart Actions ·························································11 Share Your Smart Bulb ·······································14 Reset Your Smart Bulb ·······································15 Authentication ························································16 1 About This Guide This guide provides a brief introduction to the Tapo Smart Wi-Fi Light Bulb and the Tapo app, as well as regulatory information. Features available in Tapo may vary by model and software version. Tapo availability may also vary by region or ISP. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Tapo experience. Conventions In this guide, the following convention is used: Convention Description Blue Key information appears in teal, including management page text such as menus, items, buttons and so on. Underline Hyperlinks are in teal and underlined. You can click to redirect to a website. Note: Ignoring this type of note might result in a malfunction or damage to the device. More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. • A Technical Community is provided for you to discuss our products at https://community.tp-link.com. • Setup Video can be found at https://www.tp-link.com/support/setup-video/. 2 Introduction The Tapo smart Wi-Fi light bulb is part of the Tapo smart home family of products, including plugs, switches, cameras and more. Smart Bulb lets you easily control your lights via the Tapo app, no matter where you find yourself. You can adjust brightness, set schedules and timers, and set an alarm that wakes you naturally by simulating the sunrise. Group lights together to control your smart bulbs more easily. Tapo L510 Series (Dimmable)Tapo L530 Series (Multicolor) A dimming range from 1%-100%, lighting for any occasion Multicolor and easy dimming for perfect ambiance *Images may differ from actual products due to different regional specifications. L510E L530E L510B L530B 3 Features • No Hub Required - Connect to your existing Wi-Fi router. • Remote Control - Instantly turn the light on/off wherever you are through the Tapo app. • Timer - Set a countdown timer to automatically turn the light on or off after a certain amount of time. • Schedule - Use Schedules to set your light to automatically turn on and off. • Preset for Convenience - Save and preset your favorite lightings for multiple scenarios. • Away Mode - Set a period of time during which the light will be randomly turned on and off to make it look like you’re home. • Sunrise and Sunset Mode - Automatically activate your bulb according to your time zone. • Energy Saving - Reduce energy use up to 85% without losing brightness or quality. • Restore Last Light State - The bulb automatically returns to its previous power-off state. • Device Sharing - Invite your family members to manage the bulb together. • Voice Control - Use Amazon Alexa or Google Assistant to control your bulb with voice commands. 4 Set Up Your Smart Bulb Follow the steps below to get started with your new smart bulb. Step 1. Download Tapo App Get the Tapo app from the App Store or Google Play, or by scanning the QR code below. Step 2. Log In Open the app, and log in with your TP-Link ID. If you don't have an account, create one first. Step 3. Add Your Smart Bulb Tap the button in the app and select your model. Follow app instructions to set up your smart bulb, and add it to your home network. 5 Basic Device Control After successfully setting up your smart bulb, you will see the home page of the Tapo app. Here you can view the status of all devices that you've added and manage them. You can tap on the device to control and manage. *Only multi-color bulbs support color-related and Auto White features. Here we take the Tapo L530E as an example. Home Page You can turn on or off the bulb any time anywhere and tap the bulb card to enter the status page. Device Status Page You can adjust colors and temperature, set a schedule, enable away mode, or set a timer to automatically control your device, and view its runtime & energy usage. Device Settings Page You can edit the basic information, set Last On State, enable gentle on/off, add a group, update firmware and more. 6 Configure Your Smart Bulb You can confiure your smart bulb by adjust lighting settings and setting Presets, Auto White, Schedule, Timer, Away Mode and more. *Only multi-color bulbs support color-related and Auto White features. Here we take the Tapo L530E as an example. Device Status Page You can adjust colors and temperature, set a schedule, enable away mode, or set a timer to automatically control your device, and view its runtime & energy usage. Set Presets With Presets, you can quickly apply your favourite preset at one tap. To edit preset, just select one and tap edit. Enable Auto White Tap Auto to select a lighting option (Auto Compensate or Auto Match) for your bulb. And the bulb will follow the color and brightness of the sun throughout the day. 7 Set Schedule Tap to add a schedule for your bulb to automatically turn on/off and adjust the lighting settings to simplify your daily routine. Set Away Mode Tap to preset the Away Mode, set the start and end time, then your bulb will be randomly turned on/off during this period. Set Timer Tap to set the timer and lighting settings, then your bulb will …

Text truncated - open the document above for the full version.

TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong 012423-17 rev2 Certification Application Attestation Statements Date: March 7, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) _____TP-Link Corporation Limited______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ____ TP-Link Corporation Limited_______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is /- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ____Sarah Wang__ (Signature 2 ) (Print name) Title: Compliance manager Company: TP-Link Corporation Limited_____ Telephone: +86 755 21534921 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

Attestation Letter Federal Communications Commission Authorization and Evaluation Division We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that the device does not support channel 12 ~ 13 in 2.4GHz band any non-US channels in all the operational mode(s) for the following product. Product: Tapo Smart Wi-Fi Light Bulb, Dimmable FCC ID: 2AXJ4L510 Model: Tapo L510E Brand: tp-link Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 07/17/2023

TP-LinkCorporationLimited 050222-17 AuthoritytoActasAgent Date:April24,2023 AmericanCertificationBody,Inc. 313ParkAvenue Suite300 FallsChurch,VA22046 ToWhomItMayConcern: ULVerificationServices(Guangzhou)Co.,Ltd,SongShanLakeBranch__isauthorizedtoactonour behalf,untilotherwisenotified,forapplicationstoAmericanCertificationBody,Inc.(ACB). Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludesFCCbenefits,pursuantto Section5301oftheAnti-DrugAbuseActof1988,21U.S.C.862.Further,noparty,asdefinedin47 CFR1.2002(b),totheapplicationissubjecttodenialoffederalbenefits,thatincludesFCCbenefits. WealsodeclarethattheinformationprovidedtotheFCCistrueandcorrecttothebestofour knowledge(47CFR2.911(d))andwehavebeeninformedofthegranteeresponsibilities(47CFR 2.909)withregardtocertifiedequipment. Thankyou, AgencyAgreementExpirationDate:____4 /24/2024 By:_____________________________________SarahWang_____________ (Signature 1 )(Printname) Title:__________LeadofProductCertificationTeam________________ Onbehalfof:_________TP-LinkCorporationLimited._________________________________ (CompanyName) Telephone:_______________+8675526615494___________________ 1 -MustbesignedbyapplicantcontactgivenforapplicantontheFCCsite,orbytheauthorizedagentifanappropriateauthorizedagent letterhasbeenprovided.Lettersshouldbeplacedonappropriateletterhead.

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: 2AXJ4L510 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 2023-07-17

Declaration of Conformity We Name: TP-Link Corporation Limited Address: Room 901, 9/F., New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hongkong Declare that: Product: Tapo Smart Wi-Fi Light Bulb, Dimmable FCC ID: 2AXJ4L510 Model: Tapo L510E Brand: tp-link Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, Name: Sarah Wang Position: Regulatory Compliance Manager Date: 07/17/2023

External Photographs Page 2 of 3 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . View of EUT-1 View of EUT-2 Page 3 of 3 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . View of EUT-3 View of EUT-4

14.41x9.41mm PANTONE COOL GRAY 3C 26.87±0.8mm （） * 1. LOGO 2. TP-Link Akitv 1.53±0.3mm （） 67.5x30.62mm PANTONE COOL GRAY 3C TP-Link Akitv Date Code: YYMM 深圳市联洲国际技术有限公司 Model (Modèle): Tapo L510E Tapo Smart Wi-Fi Light Bulb, Dimmable A19 E26 800 lumens 120V~60Hz 0.1A 2500K~6500K 8.8W CAUTION - NOT FOR USE IN TOTALLY ENCLOSED LUMINAIRES. SUITABLE FOR DAMP LOCATIONS. DO NOT USE WITH STANDARD DIMMERS, SEE INSTRUCTIONS. ATTENTION - CONVIENT AUX EMPLACEMENTS HUMIDES. NE PAS UTILISER AVEC DES GRADATEURS STANDARD. SE REPORTER AUX INSTRUCTIONS. NE CONVIENT PAS À DES LUMINAIRES TOTALEMENT FERMÉS YYMM Conforms to ANSI/UL Std.1993 Cert. to CAN/CSA Std. C22.2 No. 1993 FCC ID: 2AXJ4L510 5.5±0.3mm （） 1.76±0.3mm （）

Internal Photographs Page 2 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-1 Internal View of EUT-2 Page 3 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-3 Internal View of EUT-4 Page 4 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-5 Internal View of EUT-6 Page 5 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-7 Internal View of EUT-8 Antenna Page 6 of 6 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. . Internal View of EUT-9 Internal View of EUT-10

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT For Tapo Smart Wi-Fi Light Bulb, Dimmable MODEL NUMBER: Tapo L510E REPORT NUMBER: 4790874478-1-RF-2 ISSUE DATE: July 14, 2023 FCC ID: 2AXJ4L510 Prepared for TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4790874478-1-RF-2 Page 2 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 07/14/2023 Initial Issue REPORT NO.: 4790874478-1-RF-2 Page 3 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS .................................................................................... 4 2. TEST METHODOLOGY ........................................................................................................ 5 3. FACILITIES AND ACCREDITATION .................................................................................... 5 4. REQUIREMENT .................................................................................................................... 6 REPORT NO.: 4790874478-1-RF-2 Page 4 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Manufacturer Information Company Name: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong EUT Information EUT Name: Tapo Smart Wi-Fi Light Bulb, Dimmable Model: Tapo L510E Brand: tp-link Sample Received Date: June 6, 2023 Sample Status: Normal Sample ID: 6155166 Date of Tested: June 16, 2023 to July 14, 2023 APPLICABLE STANDARDS STANDARD TEST RESULTS 447498 D01 General RF Exposure Guidance v06 PASS FCC 47CFR§2.1091 PASS Prepared By: Checked By: Fanny Huang Denny Huang Engineer Project Associate Senior Project Engineer Approved By: Stephen Guo Operations Manager REPORT NO.: 4790874478-1-RF-2 Page 5 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Delcaration of Conformity (DoC) and Certification rules ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with ISED. The Company Number is 21320 and the test lab Conformity Assessment Body Identifier (CABID) is CN0046. VCCI (Registration No.: G-20019, R-20004, C-20012 and T-20011) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber D, the VCCI registration No. is G-20019 and R-20004 Shielding Room B , the VCCI registration No. is C-20012 and T-20011 Note: All tests measurement facilities use to collect the measurement data are located at Building 10, Innovation Technology Park, Song Shan Lake Hi tech Development Zone, Dongguan, 523808, China. REPORT NO.: 4790874478-1-RF-2 Page 6 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 4. REQUIREMENT LIMIT AND CALCULATION METHOD Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. Limits for General Population/Uncontrolled Exposure RF EXPOSURE LIMIT Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) A…

Text truncated - open the document above for the full version.

V1.4 Product Model： Tapo L510E(US) 3.0 Version： 1.0 Date： 2023/05/24 Checked By： Manufacturer: TP-Link Corporation Limited Address: Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong V1.4 Index I. Antenna Distribution ........................................................................................ 3 II. Electrical Characteristics ................................................................................ 3 III. Antenna Peak Gain .......................................................................................... 4 IV. Antenna Radiation Pattern .............................................................................. 4 V1.4 Page 3 Version:1.0 Issue Date: I. Antenna Distribution Tapo L510E(US) 3.0 II. Electrical Characteristics Ant1 Frequency 2400~2500MHz Impedance 50 Ohm V1.4 Page 4 Version:1.0 Issue Date: Antenna Type Monopole Antenna Gain -1.56 dBi Radiation pattern Omni-Directional III. Antenna Peak Gain Ant1 Frequency(MHz) 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 Gain(dBi) -1.56 -1.73 -1.88 -1.89 -1.77 -1.75 -1.72 -1.72 -1.76 -1.75 -1.76 IV. Antenna Radiation Pattern Ant1 2450MHz

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. CFR 47 FCC PART 15 SUBPART C TEST REPORT For Tapo Smart Wi-Fi Light Bulb, Dimmable MODEL NUMBER: Tapo L510E REPORT NUMBER: 4790874478-1-RF-1 ISSUE DATE: July 14, 2023 FCC ID: 2AXJ4L510 Prepared for TP-Link Corporation Limited Room 901, 9/F. , New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui, Kowloon, Hong Kong Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4790874478-1-RF-1 Page 2 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 July 14, 2023 Initial Issue REPORT NO.: 4790874478-1-RF-1 Page 3 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2013, Clause 6.2 FCC Part 15.207 Pass Conducted Output Power ANSI C63.10-2013, Clause 11.9.1.3 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2013, Clause 11.8.1 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2013, Clause 11.10.2 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2013, Clause 11.11 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2013, Clause 11.12 & Clause 11.13 FCC Part 15.247 (d) FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2013, Clause 11.6 None; for reporting purposes only. Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C> when <Accuracy Method> decision rule is applied. REPORT NO.: 4790874478-1-RF-1 Page 4 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. CONTENTS 1. ATTESTATION OF TEST RESULTS ...................................................................................... 6 2. TEST METHODOLOGY .......................................................................................................... 7 3. FACILITIES AND ACCREDITATION ...................................................................................... 7 4. CALIBRATION AND UNCERTAINTY ..................................................................................... 8 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................ 8 4.2. MEASUREMENT UNCERTAINTY ............................................................................. 8 5. EQUIPMENT UNDER TEST .................................................................................................... 9 5.1. DESCRIPTION OF EUT ............................................................................................. 9 5.2. CHANNEL LIST .......................................................................................................... 9 5.3. MAXIMUM EIRP ......................................................................................................... 9 5.4. TEST CHANNEL CONFIGURATION ......................................................................... 9 5.5. THE WORSE CASE POWER SETTING PARAMETER .......................................... 10 5.6. WORST-CASE CONFIGURATIONS ........................................................................ 11 5.7. DESCRIPTION OF AVAILABLE ANTENNAS .......................................................... 12 5.8. SUPPORT UNITS FOR SYSTEM TEST .................................................................. 13 6. MEASURING EQUIPMENT AND SOFTWARE USED ......................................................... 14 7. ANTENNA PORT TEST RESULTS ...................................................................................... 17 7.1. CONDUCTED OUTPUT POWER ............................................................................ 17 7.2. 6DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ........................................ 18 7.3. POWER SPECTRAL DENSITY ............................................................................... 20 7.4. CONDUCTED BAND EDGE AND SPURIOUS EMISSION...................................... 22 7.5. DUTY CYCLE ........................................................................................................... 24 8. RADIATED TEST RESULTS ................................................................................................ 25 8.1. RESTRICTED BANDEDGE ..................................................................................... 33 8.2. SPURIOUS EMISSIONS(1 GHZ~3 GHZ) ................................................................ 52 8.3. SPURIOUS EMISSIONS(3 GHZ~18 GHZ) .............................................................. 58 8.4. SPURIOUS EMISSIONS(9 KHZ~30 MHZ) ..............................................…

Text truncated - open the document above for the full version.

REPORT NO.: 4790874478-1-RF-1 Page 107 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 11N20SISO_Ant1_2437 11N20SISO_Ant1_2457 11N20SISO_Ant1_2462 REPORT NO.: 4790874478-1-RF-1 Page 108 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 11.3. APPENDIX C: MAXIMUM CONDUCTED OUTPUT POWER 11.3.1. Test Result Test Mode Antenna Frequency[MHz] Result[dBm] Limit[dBm] Verdict 11B Ant1 2412 19.95 ≤30.00 PASS 2417 22.29 ≤30.00 PASS 2437 22.24 ≤30.00 PASS 2457 22.47 ≤30.00 PASS 2462 22.21 ≤30.00 PASS 11G Ant1 2412 17.75 ≤30.00 PASS 2417 19.10 ≤30.00 PASS 2437 21.80 ≤30.00 PASS 2457 19.33 ≤30.00 PASS 2462 17.79 ≤30.00 PASS 11N20SISO Ant1 2412 17.61 ≤30.00 PASS 2417 19.32 ≤30.00 PASS 2437 20.65 ≤30.00 PASS 2457 20.88 ≤30.00 PASS 2462 16.95 ≤30.00 PASS Note: 1. Conducted Power=Meas. Level+ Correction Factor 2. The Duty Cycle Factor (refer to section 7.5) had already compensated to the test data. REPORT NO.: 4790874478-1-RF-1 Page 109 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 11.4. APPENDIX D: MAXIMUM POWER SPECTRAL DENSITY 11.4.1. Test Result Test Mode Antenna Frequency[MHz] Result[dBm/3kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -1.71 ≤8.00 PASS 2417 -1.83 ≤8.00 PASS 2437 -2.12 ≤8.00 PASS 2457 -1.94 ≤8.00 PASS 2462 -2.24 ≤8.00 PASS 11G Ant1 2412 -5.87 ≤8.00 PASS 2417 -5.83 ≤8.00 PASS 2437 -4.62 ≤8.00 PASS 2457 -4.4 ≤8.00 PASS 2462 -4.69 ≤8.00 PASS 11N20SISO Ant1 2412 -5.92 ≤8.00 PASS 2417 -6.12 ≤8.00 PASS 2437 -4.82 ≤8.00 PASS 2457 -4.53 ≤8.00 PASS 2462 -4.83 ≤8.00 PASS Note: 1. The Duty Cycle Factor (refer to section 7.5) had already compensated to the test data. REPORT NO.: 4790874478-1-RF-1 Page 110 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 11.4.2. Test Graphs 11B_Ant1_2412 11B_Ant1_2417 11B_Ant1_2437 REPORT NO.: 4790874478-1-RF-1 Page 111 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 11B_Ant1_2457 11B_Ant1_2462 11G_Ant1_2412 REPORT NO.: 4790874478-1-RF-1 Page 112 of 137 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0035 This report shall no…
